Diameter (1): 304.8 mm (12 in). Length (overall): 3,658 mm (144 in). Pressure: 3.4 bar (50 psi). Temperature: 232.2 °C (450 °F). Packing Type: Structured.
0.125" thick shell and heads Diameter (1): 203.2 mm (8 in). Length (overall): 4,572 mm (180 in). Pressure: 2.4 bar (35 psi).
packed column design pressure 2.5/3.5 barg full vacuum @ 170/260 degrees C 316 stainless steel packing rings (1) distributor plate, (1) support plate, (1) feed pipe 2-316 stainless steel bonnet heads Diameter (1): 400 mm (15.7 in). Length (overall): 3,350 mm (131.9 in). Pressure: 3.5 bar (50.8 psi). Vacuum: Yes. Temperature: 260 °C (500 °F).
packed wash column design pressure -1/ 4 bar @ 100 degrees C (995 liter) TUV bolt bonnet bottom 508mm diameter x 2520mm high packed section, 316Ti stainless steel (1.4571) Sulzer Mellapak 250Y structured packing, top head with an internal demister, feed pipe with Sulzer 316Ti stainless steel (1.4571) liquid distributor, Product Flow Rate: 1,200 m3/h (5,283 GPM). Diameter (1): 508 mm (20 in). Length (overall): 5,664 mm (223 in). Pressure: 4 bar (58 psi). Vacuum: Yes. Temperature: 100 °C (212 °F). Packing Type: Structured. Packing Material: Structured.
packing height 2.7m 316 stainless steel pall rings de-mister in top Diameter (1): 600 mm (23.6 in). Pressure: 1.1 bar (16 psi). Vacuum: Yes. Temperature: 340 °C (644 °F).
QVF/Schott clear glass packed column 25mm diameter x 25mm high clear plastic tube packing, column made up of 3 x 1m high sections, 1 x 500mm high section and 1 x dished head, column with only one head as it sat directly onto a graphite heat exchanger Diameter (1): 600 mm (23.6 in). Length (overall): 3,500 mm (137.8 in). Pressure: 0.7 bar (10.2 psi). Temperature: 120 °C (248 °F). Packing Type: Random. Packing Material: Other.
rectification column, TUV allowable working pressure -1/2 bar @ 220 degrees C (1395 liter) Diameter (1): 800 mm (31.5 in). Pressure: 2 bar (29 psi). Vacuum: Yes. Temperature: 220 °C (428 °F).
Multistage Koch 304LSS modular batch distillation system designed for distillation of specialty chemical products Currently set up as (2) theoretical stages, but expandable up to (15) theoretical stages. System includes: 304L stainless steel (SS) packed bed distillation column, 30" x 15' (2) theoretical stages, manufactured by Dusenbury Engineering
Batch tank:
Vent condenser:
Knockback condenser: - Material: - Tubes and shell: 304LSS - Head: CS
CS skirt. Rated for 15/FV Liquid outlet is 2", sides of column have seven one inch NPT nipples. Diameter (1): 457.2 mm (18 in). Length (overall): 9,144 mm (360 in). Pressure: 1.03 bar (15 psi). Vacuum: Yes. Temperature: 148.9 °C (300 °F).
Chromatography Column Home Made, not code. Diameter (1): 609.6 mm (24 in). Length (overall): 2,159 mm (85 in). Packing Type: Random. Packing Material: Other.
internal pressure -1/3 barg @ 300 degrees C (9730 liter) Diameter (1): 1,400 mm (55.1 in). Length (overall): 6,420 mm (252.8 in). Pressure: 3 bar (43.5 psi). Vacuum: Yes. Temperature: 300 °C (572 °F).
12" diameter column system , engineered by Distillation Engineering Co. Designed to bolt onto the top of a reactor with a 750-1000 gallon capacity. (depending on the chemical service) The system consists of the following parts. First a 12" x 80" SS packed column, second a top mounted re-boiler, and third a reflux tank. The column section is 12" diameter x 80" overall length. 316 SS, NB # 205, rated for FV/125 psi at 500 degrees F. Manufactured by Roben. With a packing support 10" from the bottom of the column. Estimated packed capacity is 5 ft.3. The U-Tube condenser is top mounted to the column. It is 163 ft.2, The shell is 316 SS, the tubes are 316 SS, the tube sheets are 316 SS, the heads are CS. NB # 4892. The shell is rated for FV/150 psi at 450 degrees F. The tubes are rated for 100 psi at 450 degrees F. It is manufactured by Roben, serial # 81034. It is 18" diameter x 107" overall length. Four pass shell side and Two pass tube side. 104 "U" tubes, 3/4" diameter x 16 gauge. With a 12" shell nozzle, and 3" tube nozzles. The reflux/receiver tank has a 90 Gallon capacity and is manufactured from 316 SS material. It is orientated vertically. The NB # is 275, it is rated for FV/35 psi at 650 degrees F. Manufactured by Cream City Boiler, serial # D-72-54G. The dimensions of the vessel are 24" diameter x43" straight side, Diameter (1): 304.8 mm (12 in). Pressure: 8.6 bar (125 psi).
packed distillation column Product Flow Rate: 2.3 m3/h (10 GPM). Diameter (1): 406.4 mm (16 in). Length (overall): 10,668 mm (420 in). Pressure: 10.3 bar (150 psi). Vacuum: Yes. Temperature: 148.9 °C (300 °F).
Manufactured by Estrella AG in Ettingen, Germany Packed column consisting of (3) Clamped mid sections, each 2.000 mm long x 788 mm inside diameter, openings each section: (1) NW 150, (1) NW 50; (1) clamped dished top, 1.120 mm long x 788 mm inside diameter Diameter (1): 800 mm (31.5 in). Length (overall): 8,200 mm (322.8 in). Pressure: 2 bar (29 psi). Temperature: 200 °C (392 °F). Glasslined: Yes. Packing Type: Random. Packing Material: Ceramic Rasching Rings.
body is made up of (1) 1470mm long section and (1) 1265mm long section which bolt together, (2) bonnet heads, (2) packing plates TUV certified Diameter (1): 500 mm (19.7 in). Length (overall): 2,735 mm (107.7 in). Pressure: 6 bar (87 psi). Vacuum: Yes. Temperature: 200 °C (392 °F). Glasslined: Yes.
manufactured by Julius Montz Gmbh internal pressure -1/20 bar @ 300 degrees C column made up of 2-bolted sections, 1-3320mm long section with Muntz packing and 1-3486 long section with Muntz packing, 2-bonnet heads removeable mounting ring, TUV certified Diameter (1): 323 mm (12.7 in). Length (overall): 9,900 mm (389.8 in). Pressure: 20 bar (290.1 psi). Vacuum: Yes. Temperature: 300 °C (572 °F).
vertical packed column pressure rated -1/6 bar @ 200 degrees C 3796mm straight side with 2926mm packing section Julius Montz type B1-250 packing, internal distribution plate, (2) 316 stainless steel bonnet heads TUV certified Diameter (1): 600 mm (23.6 in). Length (overall): 5,300 mm (208.7 in). Pressure: 6 bar (87 psi). Vacuum: Yes. Temperature: 200 °C (392 °F).
operating pressure 1.8 bar 138 degrees C bottom section 650mm diameter x 6.8m straight side 600mm straight side bolted reduction head top section 350mm diameter x 3.5m straight side with bolt dished head (2) 3m high packing sections with 25mm diameter 316L stainless steel pall rings built to TUV certification Diameter (1): 650 mm (25.6 in). Length (overall): 14,965 mm (589.2 in). Pressure: 6 bar (87 psi). Vacuum: Yes. Temperature: 200 °C (392 °F).
Rectification Column Unit bolted in 4 sections: Top section is 600 mm x 1130 mm, with a 3 SqM internal spiral condensing coil; Mid-section has (2) bolted sections that expand to 600 mm diam x 2040 mm long each, with a 1020 mm thick packed beds with 316LSS Sulzer packing in each section. Bottom section has a 3 SqM Falling film evaporator section with 316LSS vertical tubes in this section Diameter (1): 600 mm (23.6 in). Length (overall): 8,372 mm (329.6 in). Pressure: 3.2 bar (46.4 psi). Vacuum: Yes. Temperature: 300 °C (572 °F).
900mm/1200mm (~35 - 47") x 8372 (~27') mm OAH Packed Rectification Column Unit bolted in 4 sections: Top section is 900 mm x 1540 mm, with a 5 SqM internal spiral condensing coil; Mid-section has (2) bolted sections that expand to 1200 mm diam x 2040 mm long each, with a 1020 mm thick packed beds with 316LSS Sulzer packing in each section. Bottom section has a 5 SqM Falling film evaporator section with 316LSS vertical tubes in this section Diameter (1): 1,200 mm (47.2 in). Pressure: 3.2 bar (46.4 psi). Vacuum: Yes. Temperature: 300 °C (572 °F).
total height 36530mm, column made up of (7) clamped sections; section 1 = weld dished top head, 1099mm straight side, 1.6m total height, section 2 = 4265mm straight side, section 3 = 4265mm straight side, section 4 = 1070mm straight side, section 5 = 3600mm straight side, section 6 = 3600mm straight side, section 7 = bottom head, with 4000mm straight side, 4475mm total height., TUV certified Diameter (1): 1,000 mm (39.4 in). Length (overall): 556,235 mm (21,899 in). Pressure: 3 bar (43.5 psi). Vacuum: Yes. Temperature: 150 °C (302 °F). Glasslined: Yes.
900mm/1200mm (~35"/47") x 8372 (~27 ft) mm OAH Packed Rectification Column Unit bolted in 4 sections: Top section is 900 mm x 1540 mm, with a 5 SqM internal spiral condensing coil; Mid-section has (2) bolted sections that expand to 1200 mm diam x 2040 mm long each, with a 1020 mm thick packed beds with 316LSS Sulzer packing in each section. Bottom section has a 5 SqM Falling film evaprator section with 316LSS vertical tubes in this section Diameter (1): 1,200 mm (47.2 in). Pressure: 3.2 bar (46.4 psi). Vacuum: Yes. Temperature: 300 °C (572 °F).
Glass #9115 PTFE packing support. Equipment # tag 679711. Diameter (1): 304.8 mm (12 in). Length (overall): 3,429 mm (135 in). Pressure: 10.3 bar (150 psi). Vacuum: Yes. Temperature: 232.2 °C (450 °F). Glasslined: Yes.
glass rectification packed Column 900mm packing height Diameter (1): 300 mm (11.8 in). Length (overall): 1,800 mm (70.9 in). Glasslined: Yes.
glass rectification packed column 2m packing height Diameter (1): 300 mm (11.8 in). Length (overall): 3,100 mm (122 in). Glasslined: Yes.
Column has (2) clamped straight sections 2 x 1.500mm long and 2 x 600mm diameter outside, volume of both sections 803 liter, clamped dished top section, 500mm long x 600 outside diameter, volume 97 liter and bottom section, 730mm long x 600 outside diameter, volume 137 liter. Total weight of the column is 930kg Diameter (1): 600 mm (23.6 in). Length (overall): 4,374 mm (172.2 in). Pressure: 2 bar (29 psi). Glasslined: Yes.
Column has (2) clamped straight sections 2 x 1.500mm long and 2 x 600mm diameter outside volume of both sections 803 liter clamped dished top section 500mm long x 600 outside diameter volume 97 liter and bottom section 730mm long x 600 outside diameter, volume 137 liter. Total weight of the column is 900kg. Diameter (1): 600 mm (23.6 in). Length (overall): 4,374 mm (172.2 in). Pressure: 2 bar (29 psi). Glasslined: Yes.
600/700mm (~24"/27.5") diameter x 8700mm (~29') high Methanol Recovery column with 600mm diameter x 1850mm length (including carbon steel feet) bottom section, openings bottom: (1) DN50, (1) DN80, openings side wall: (2) DN25, (1) DN50, (1) DN65, (1) DN300, (4) DN80 sight glass, with 600mm diameter x 1850mm length middle section, openings side wall: (4) DN25, (2) DN80 sight glass, with 600/700mm diameter x 440mm length reduction section, openings (1) DN25, (1) DN50, with 700mm diameter x 2000mm length middle section, openings side wall: (4) DN25, (2) DN80 sight glass, with 700mm diameter x 2000mm length top section, openings side wall: (4) DN25, with 700mm diameter x 550mm high top cover, openings (3) DN25, (1) DN32, (1) DN250, including (1) 700mm diameter sieve ring, (1) 600mm diameter sieve ring, (2) 600mm diameter parts Diameter (1): 700 mm (27.6 in). Length (overall): 8,700 mm (342.5 in). Pressure: 2 bar (29 psi).
AG glass lined packed column pressure -1/2 bar @ 100 degrees C (1) clamped mid section Unit has (1) teflon perforated packing support plate Diameter (1): 400 mm (15.7 in). Length (overall): 2,000 mm (78.7 in). Pressure: 2 bar (29 psi). Vacuum: Yes. Temperature: 100 °C (212 °F). Glasslined: Yes.
316lss Packed Rectification Column Unit bolted in 4 sections: Top section is 400 mm x 1140 mm, with aproz 2.5 SqM internal spiral condensing coil; Mid-section has (2) bolted sections that expand to 400 mm diam x 2040 mm long each, with a packed beds with 316LSS Sulzer packing in each section. Bottom section has a Falling film evaprator section with 316LSS vertical tubes in this section Diameter (1): 400 mm (15.7 in). Pressure: 3.2 bar (46.4 psi). Vacuum: Yes. Temperature: 300 °C (572 °F).
pressure -1/6 bar @ -10/220 degrees C 969mm inside diameter Glass type 3115/blue Diameter (1): 1,000 mm (39.4 in). Length (overall): 3,000 mm (118.1 in). Pressure: 6 bar (87 psi). Vacuum: Yes. Temperature: 220 °C (428 °F). Glasslined: Yes.
520/610 mm diameter With (3) internal distribution trays, with ceramic saddle packing beds Diameter (1): 610 mm (24 in). Length (overall): 5,300 mm (208.7 in). Pressure: 2 bar (29 psi). Temperature: 170 °C (338 °F).
800/900 mm x 8520 mm (~31-35" x 28') /OAH Packed Rectification Column Design operating conditons: 1.2 Torr, @ 245 Degrees C, 225 to 380 kg/h gass flow; 315 to 470 kg/h liter. Unit bolted in 4 sections: Top section is 800 mm x 1700 mm, with a 8 SqM internal spiral condensing coil; Mid-section has (2) bolted sections that expand to 900 mm diam x 4400 mm long total, 2200 mm long each, with a 1020 mm thick packed beds with 316LSS Sulzer packing in each section. Bottom section narrows to 800 mm diameter with an 8.2 SqM Falling film evaprator section with 316LSS vertical tubes in this section Diameter (1): 900 mm (35.4 in). Pressure: 3 bar (43.5 psi). Vacuum: Yes. Temperature: 300 °C (572 °F).
Welded dish heads packed bed column ( with two repair tags, 2005, by CDI) Top packing bed is 5' from top under distribution tray, 9' bed of Koch-Glitsch Fleximax 200 in 316 SS Bottom bed 26'6" bed of Koch-Glitsch Fleximax 200 in 316 SS Column operates at 60 psi with a delta pressure of 40"wc across column. Diameter (1): 1,524 mm (60 in). Length (overall): 17,678 mm (696 in). Pressure: 12.4 bar (180 psi). Vacuum: Yes. Temperature: 204.4 °C (400 °F).
column with 1 head 2 pipes + 1 head Diameter (1): 220 mm (8.7 in). Length (overall): 2,500 mm (98.4 in). Glasslined: Yes.
packed column
Packed with Koch-Glitsch Fleximax
400 rasching rings in 304 SS
17' 6" total packed area on
gas injection packing support Diameter (1): 609.6 mm (24 in). Length (overall): 7,315 mm (288 in). Pressure: 7.9 bar (115 psi). Temperature: 148.9 °C (300 °F).
PTFE Lined (80 mil) With replacement sections by Edlon Bolted together by flanges in sections Packed with 60 cu ft Koch 2" flexsaddle random packing Specs from process for this scrubber: Volume of gas cleaned; 2205 cfm, Temp. of gas; 105 degrees F, Liquid flow rated; 53 gpm, Inlet velocity to scrubber; 5.3 fps. Nominal pressure drop across column; 25 " h2O Diameter (1): 1,143 mm (45 in). Length (overall): 6,706 mm (264 in). Pressure: 1.01 bar (14.7 psi). Temperature: 71.1 °C (160 °F).
PTFE Lined Bolted together by flanges in sections, with bolted top and bottom heads Diameter (1): 1,219 mm (48 in). Length (overall): 5,486 mm (216 in).
vertical packed column ref # F11563-1 working pressure 0.5 barg + FV @ 180 degrees C 6.35mm shell thickness VKR distributor range 0.07-0.25 m3/hr packing height 2100mm 10-layers of Sulzer M2YW 316L stainless steel packing top head with spray nozzle 2-316L stainless steel bonnet heads Product Flow Rate: 0.25 m3/h (1.1 GPM). Diameter (1): 600 mm (23.6 in). Length (overall): 2,750 mm (108.3 in). Pressure: 5.7 bar (82.7 psi). Vacuum: Yes. Temperature: 180 °C (356 °F).
blue (3009) internal pressure rated -1/6 bar @ -25/200 degrees C (volume 147liter) Diameter (1): 400 mm (15.7 in). Length (overall): 1,060 mm (41.7 in). Pressure: 6 bar (87 psi). Temperature: 200 °C (392 °F). Glasslined: Yes.
internal pressure -1/3 bar @ 300 deg C (1530 liter) jacket 8 bar @ 300 deg C, (14 liter) (2) 590mm diameter x 2.5m long bolted sections each with packing height of 2m long (1) bonnet top head, half pipe vertical coil on straight side only, Julius Montz A2 type 304 stainless steel packing (NO PACKING) TUV Diameter (1): 590 mm (23.2 in). Length (overall): 6,400 mm (252 in). Pressure: 3 bar (43.5 psi). Vacuum: Yes. Temperature: 300 °C (572 °F).
column with built in condenser 1020mm packing height Sulzer Packing (NO PACKING), top of column has a built in 9 square meter 316L stainless steel tube, shell and head horizontal condenser, manufactured by Dynamit Nobel, pressure tube side 9 bar @ 200 deg C (35 liter), shell 4 bar + vacuumn @ 200 deg C (220 ltr), (120) 25mm diameter x 2mm x 950mm long tubes, (2) dished heads TUV Diameter (1): 500 mm (19.7 in). Length (overall): 3,016 mm (118.7 in). Pressure: 4 bar (58 psi). Vacuum: Yes. Temperature: 200 °C (392 °F).
Heads are 0.180" thick Diameter (1): 558.8 mm (22 in). Length (overall): 7,620 mm (300 in). Pressure: 3.4 bar (50 psi). Temperature: 148.9 °C (300 °F).
Heads are 0.180" thick Diameter (1): 558.8 mm (22 in). Length (overall): 7,620 mm (300 in). Pressure: 4.8 bar (70 psi). Temperature: 148.9 °C (300 °F).
Heads are 0.180" thick Diameter (1): 558.8 mm (22 in). Length (overall): 7,620 mm (300 in). Pressure: 3.4 bar (50 psi).
Heads are 0.180" thick Diameter (1): 558.8 mm (22 in). Length (overall): 4,572 mm (180 in). Pressure: 3.4 bar (50 psi). Temperature: 148.9 °C (300 °F).
Heads are 0.180" thick Diameter (1): 558.8 mm (22 in). Length (overall): 7,620 mm (300 in). Pressure: 3.4 bar (50 psi). Temperature: 148.9 °C (300 °F).
Zirconium/Alloy 59 packed column design pressure 5 bar + FV @ -20/205 deg C, 14580mm straight side, top section is 1350mm diameter x 7089mm straight side thickness is 6mm to 7.9mm, 4549mm high packing section, bottom section is 1.7m diameter x 7.9m straight side thickness 6mm, 4.4m high packing section, packing is glass filled polypropylene, also includes c/steel top platform and ladders Diameter (1): 1,700 mm (66.9 in). Pressure: 5 bar (72.5 psi). Vacuum: Yes. Temperature: 205 °C (401 °F).
(2) parallel jacketed designed by general electric serial #5027 jacket 12.8 bar + FV @ 200 degrees C (2) 350mm diameter x 4988mm straight side 4.7m high packing section per column, cascade mini ring packing column connected to the same top and bottom head Diameter (1): 350 mm (13.8 in). Pressure: 7 bar (101.5 psi). Vacuum: Yes. Temperature: 200 °C (392 °F).
(1) 3050mm high packed section and (1) 1520mm packed section, 37mm diameter Pall ring packing, (2) distribution plates, (1) demister, (2) packing support plates bolt dished top, weld dished bottom Diameter (1): 1,000 mm (39.4 in). Length (overall): 8,300 mm (326.8 in). Pressure: 2.7 bar (39.2 psi). Vacuum: Yes. Temperature: 186 °C (366.8 °F).
304 stainless steel internal wire mesh packing (9) sections of packing 380mm (1) pre-distribution plate, (1) distirbution plate, coned top head Diameter (1): 800 mm (31.5 in). Length (overall): 3,970 mm (156.3 in). Pressure: 1.1 bar (16 psi). Vacuum: Yes. Temperature: 315 °C (599 °F).
jacketed de-mister tank jacket 6.4 bar @ 343 degrees C (3) 304 stainless steel jackets on straight side and (1) on bottom dish Diameter (1): 2,300 mm (90.6 in). Length (overall): 3,800 mm (149.6 in). Pressure: 1.1 bar (16 psi). Temperature: 343 °C (649.4 °F).
Polypropylene packing Diameter (1): 800 mm (31.5 in). Pressure: 1.1 bar (16 psi). Vacuum: Yes. Temperature: 150 °C (302 °F).
(1) 5.2m high and (1) 3.7m high, stainless steel pall rings, Diameter (1): 355 mm (14 in). Pressure: 1 bar (14.5 psi). Vacuum: Yes. Temperature: 180 °C (356 °F).
rectification/distillation column Diameter (1): 800 mm (31.5 in).
Zirconium Packed with rasching rings. Diameter (1): 609.6 mm (24 in). Length (overall): 10,566 mm (416 in).
(2) 3.6m high packing sections, type of packing was Raschig rings (not available) 8mm thick carbon steel shell and flat heads with 0.76mm thick Tantalum lining, (2) 2mm thick Tantalum distribution plates, (2) 2mm thick Tantalum support plates Diameter (1): 578 mm (22.8 in). Length (overall): 9,878 mm (388.9 in). Pressure: 5.3 bar (76.9 psi). Vacuum: Yes. Temperature: 200 °C (392 °F).
25mm diameter Polyprop pall rings Diameter (1): 310 mm (12.2 in). Pressure: 1.8 bar (26.1 psi). Temperature: 165 °C (329 °F).
No mane plate Teflon lined internals Appears to have structured packing. Diameter (1): 304.8 mm (12 in). Length (overall): 7,620 mm (300 in).
vertical packed stripper column NB # 360 (total skirt length 22'.4' attached to column with the remaining 18' section available) 264" of packing with supports and distributors Diameter (1): 762 mm (30 in). Length (overall): 14,630 mm (576 in). Pressure: 6.9 bar (100 psi). Vacuum: Yes. Temperature: 176.7 °C (350 °F).
vertical packed column. Rated atmospheric. Pad mounted with a flat welled top. Diameter (1): 609.6 mm (24 in). Length (overall): 4,267 mm (168 in).
vertical packed column. 39' 7" straight side. Packed with three sections of Norton N1, Polypropylene 1" super intalox saddles. One packed section 168", Two packed sections each 96" , with 68 cu. Ft. of packing. One Norton model 845 distributor, Hastelloy C-276 rated for min./Max flow of 4.31-7.4 GPM. Two, Norton model 1007 redistributors, Hastelloy-C276, rated for Min./Max. flow of 9.11-15.61 GPM. Packing supported by Norton Model 818 support plate fabricated from Hastelloy C-276, (three required). max design load each 1106 lbs./Sq.Ft. Diameter (1): 457.2 mm (18 in). Pressure: 1.38 bar (20 psi). Vacuum: Yes. Temperature: 204.4 °C (400 °F).
Schott glass distillation packed column system each 1m high with glass rasching ring packing material 2m total packing height, system includes (3) 2.5 square meter glass condenser, (1) glass receiver and (1) empty column section. Diameter (1): 300 mm (11.8 in).
built to TUV Diameter (1): 1,000 mm (39.4 in). Length (overall): 9,500 mm (374 in). Pressure: 6 bar (87 psi). Vacuum: Yes. Temperature: 200 °C (392 °F).
top section 710mm diameter x 12m straight side, bottom section 610mm diameter x 8840mm straight side top part of column with (2) packed sections: 1-1820mm high and 1-5980mm high, bottom section with (2) packed part of column with (2) packed sections both 3120mm high, type 6M packing Diameter (1): 710 mm (28 in). Length (overall): 25,052 mm (986.3 in). Pressure: 2 bar (29 psi). Vacuum: Yes. Temperature: 200 °C (392 °F).
2 x packed seactions, top section 1.3m diameter x 2340mm high, bottom section 1.3m diameter x 4160mm high, 12m straight side built to TUV Diameter (1): 1,300 mm (51.2 in). Length (overall): 16,000 mm (629.9 in). Pressure: 1 bar (14.5 psi). Vacuum: Yes. Temperature: 200 °C (392 °F).
horizontal packed column Built for Koch, Inc., Otto K York. serial # 40527 with one welded dish head and one bolted flange head. 47" internal packed with SS Mesh packing Diameter (1): 101.6 mm (4 in). Pressure: 10.3 bar (150 psi). Temperature: 200 °C (392 °F).
with 304SS structured packing from tangent to tangent. Designed to hang from ceiling. Diameter (1): 711.2 mm (28 in). Length (overall): 1,524 mm (60 in). Pressure: 2.1 bar (30 psi). Temperature: 204.4 °C (400 °F). Packing Type: Structured.
exhaust gas scrubber packed column TUV certified, (2) packed sections each 355mm diameter x 2850mm high, Sulzer packing, (2) 316 stainless steel (1.4571) bonnet heads. Diameter (1): 355 mm (14 in). Length (overall): 6,900 mm (271.7 in). Pressure: 3.2 bar (46.4 psi). Vacuum: Yes. Temperature: 100 °C (212 °F).
exhaust gas scrubber packed column fabrik #7/995.357 TUV certified 1- 508mm diameter x 4531mm high packed section, (23) Montz Pak type B1-400 316 stainless steel (1.4404) structured packing, 316 stainless steel distribution plate with 22 holes, column made up of 2-bolted sections (1 section = 508mm dimeter x 2445mm high,1 section = 508mm diameter x 2800mm high), (2) 316 stainless steel bonnet heads Diameter (1): 508 mm (20 in). Diameter (2): 12,903 mm (508 in). Length (overall): 6,834 mm (269.1 in). Pressure: 3.2 bar (46.4 psi). Vacuum: Yes. Temperature: 50 °C (122 °F). Packing Type: Structured.
300 kg/Hr, recovered VCM stripping system, designed to stripping unreacted VCM from PVC slurry process reducing vent gas to less than 1 ppm VCM. This system is EVC Technology, and can be used to strip volatiles from a variety of liquid processes like waste water. Used in a 15 ton/Hour maximum dry PVC production line. VCM stripper system includes: 1355 mm diameter x 15780 mm high, SAF 2507 VCM stripping column system with support equipment. Column manufactured by Mechannica Sarda, Rated 1.2 bar/FV @ 110 degrees C. 23,500 liters. Weight 5000 Kg. System includes: (1) 76 square meter 316L stainless steel tube, 304 stainless steel shell and carbon steel head vertical heat exchanger. Manufactured by Ravagnan SpA. fabrik #5085, design pressure tube side 7.84 + vacuum @ 150 degrees C (534 liter), shell 6 bar @ 100 degrees C (370 liter), (305) 20mm diameter x 1.6mm x 4050mm long 316L stainless steel tubes. Shell is 6mm thick. (2) carbon steel bonnet head, 489mm diameter shell, 5635mm overall height, mounted on lugs, Approx. 93 Square meter stainless steel process side spiral condenser, (1) 2700 liter 316 stainless steel vertical separator vessel, manufactured by O.C.S, pressure rated 3 bar + vacuum @ 149 degrees C, 1.4m diameter x 1.3m straight side, weld dished top and bottom, mounted on legs, miscellaneous stainless steel receivers and centrifugal circulating pumps.
300 kg/Hr, recovered VCM stripping system, designed to stripping unreacted VCM from PVC slurry process reducing vent gas to less than 1 ppm VCM. This system is EVC Technology, and can be used to strip volatiles from a variety of liquid processes like waste water. Used in a 15 ton/Hour maximum dry PVC production line. VCM stripper system includes: 1355 mm diameter x 15780 mm high, SAF 2507 VCM stripping column system with support equipment. Column manufactured by Mechannica Sarda, Rated 1.2 bar/FV @ 110 degrees C. 23,500 liters. Weight 5000 Kg. System includes: (1) 76 square meter 316L stainless steel tube, 304 stainless steel shell and carbon steel head vertical heat exchanger. Manufactured by Ravagnan SpA. fabrik #5086, design pressure tube side 7.84 + vacuum @ 150 degrees C (534 liter), shell 6 bar @ 100 degrees C (370 liter), (305) 20mm diameter x 1.6mm x 4050mm long 316L stainless steel tubes. Shell is 6mm thick. (2) carbon steel bonnet head, 489mm diameter shell, 5635mm overall height, mounted on lugs, (1) Approx. 93 Square meter stainless steel process side spiral condenser, (1) 2700 liter 316 stainless steel vertical separator vessel, manufactured by O.C.S, pressure rated 3 bar + vacuum @ 149 degrees C, 1.4m diameter x 1.3m straight side, weld dished top and bottom, mounted on legs, miscellaneous stainless steel receivers and centrifugal circulating pumps.
T/T Monel 400 The reboiler feed section is Monel 400 with (7) trays on 18" spacing; the rectifying section is 10 guage 304SS with 16' of 304SS packing, and stripping section is 10 gauge 304SS with 16' of 304SS packing. Packed with 1" 304SS pall rings, yielding (6) theoretical stages The column has (4) bolted sections - 22' base section (containing the skirt and 15' long Monel 400 reboiler feed section) 16'8" intermediate (rectifying) section 18' upper section (stripping) , and 2'6" cap Origninal design ratings are : distillate - 1093 lbs/hr of ethanol, 46 lbs.hr water 100 degrees F , 8.8 psig Diameter (1): 762 mm (30 in). Length (overall): 18,000 mm (708.7 in).
Top is 18" long clamped bonnet, bottom is 18" long clamped bonnet Glass #3315 Has bolt-on plate coil jkt, mfd by Tranter, NB #227, SN P15042. Rated 60 psi @ -22 deg F. Diameter (1): 762 mm (30 in). Length (overall): 1,321 mm (52 in). Pressure: 8.6 bar (125 psi). Vacuum: Yes. Temperature: 343.3 °C (650 °F). Glasslined: Yes.
With Gempack 2A structured 304SS packing which yields (7) theoretical plates / stages Column has 3 sections: 29'6" base section 18' intermediate section, and 2'6" cap Diameter (1): 762 mm (30 in). Length (overall): 15,240 mm (600 in).
drawing no.Q 16095 operating pressur -1/+1 bar 5 parts 2800mm packing height,part 1=1300mm long (packed) with (1)25mm opening, part 2=200mm long, part 3=1500mm long (packed) with (2) 25mm openings, part 3=400mm long with (1)200mm opening, part 4=400mm long with (1) 165mm opening Diameter (1): 200 mm (7.9 in). Length (overall): 4,400 mm (173.2 in). Pressure: 1 bar (14.5 psi). Vacuum: Yes. Temperature: 150 °C (302 °F). Glasslined: Yes.
Glass # 9115 90 psi on jacket @ 450 deg. F. Diameter (1): 304.8 mm (12 in). Length (overall): 3,810 mm (150 in). Pressure: 10.3 bar (150 psi). Vacuum: Yes. Temperature: 232.2 °C (450 °F). Glasslined: Yes.
glass lined packed column Clamp dish top, no btm No packing. Diameter (1): 762 mm (30 in). Length (overall): 2,261 mm (89 in). Pressure: 1.01 bar (14.7 psi). Temperature: 204.4 °C (400 °F). Glasslined: Yes.
600mm inside diameter x 14.200mm overall height glass packed column. Manufactured by Schott Schleiffer Chemie-Technik in Switzerland Number of main parts: 13 Number of glass middle sections: 11 Glass cover top height: 400mm Glass cover top inside diameter: 600mm Glass cover top openings: (1) NW 200, (2) NW 25 Glass cover bottom height: 300mm Glass cover bottom inside diameter: 600mm Glass cover bottom openings: (1) NW 100 First middle section height: 600mm First middle section inside diameter: 600mm First middle section opening: (1) NW 80 Second middle section height: 1.500mm Second middle section inside diameter: 600mm Second middle section openings: (2) NW 50, (2) NW 25 Third middle section height: 1.500mm Third middle section inside diameter: 600mm Third middle section openings: (3) NW 50 Fourth middle section height: 1.500mm Fourth middle section inside diameter: 600mm Fourth middle section openings: (2) NW 25, (1) Fifth middle section height: 1.500mm Fifth middle section inside diameter: 600mm Fifth middle section openings: (2) NW 25 Sixth middle section height: 600mm Sixth middle section inside diameter: 600mm Sixth middle section openings: (1) NW 80 Seventh middle section height: 1.500mm Seventh middle section inside diameter: 600mm Seventh middle section openings: (2) NW 50, (2) NW 25 Eighth middle section height: 600mm Eighth middle section inside diameter: 600mm Eighth middle section openings: (1) NW 150 Ninth middle section height: 1.500mm Ninth middle section inside diameter: 600mm Ninth middle section openings: (2) NW 50, (2) NW 25 Tenth middle section height: 1.500mm Tenth middle section inside diameter: 600mm Tenth middle section openings: (2) NW 25 Eleventh middle section height: 1.200mm Eleventh middle section inside diameter: 600mm Eleventh middle section openings: (1) NW 150, (2) NW 100, (1) NW 50, (2) NW 25 Included items: support pipe construction, flanges, connection pieces, ceramics pall ring packing material, and many glass accessories. Diameter (1): 600 mm (23.6 in). Glasslined: Yes.
with ring support Glass #9115 With PTFE packing support Diameter (1): 304.8 mm (12 in). Length (overall): 3,429 mm (135 in). Pressure: 10.3 bar (150 psi). Vacuum: Yes. Temperature: 232.2 °C (450 °F). Glasslined: Yes.
Has Aldur ceramic support system. Diameter (1): 609.6 mm (24 in). Length (overall): 6,096 mm (240 in). Pressure: 8.6 bar (125 psi). Temperature: 343.3 °C (650 °F). Glasslined: Yes.
QVF Glass Column, designed by DeDietrich, built by QVC. Each section is made of borosilicate glass ISO 3585. This column is unused and packed in crates, ready for transport. (8) grid supports for packing (no packing with column) Column sections are manufactured by QVF, are CE rated designed for FV/+0.6 barg Column consists of (15) sections 800 mm OD x 1000 mm long, (1) 800 mm OD x 800 mm long "T" section at the bottom with column inlet nozzle; (1) 800 mm OD x 800 mm long "T" section mounted at the top with column outlet nozzle; (1) 800 mm x 800mm long section; (2) dished bell section for the column top and bottom. Column includes: (23) coupling rings, (3) flange counter balance supports, (8) packing grid supports, (12) pieces of non-asbestos gaskets. Diameter (1): 800 mm (31.5 in). Length (overall): 17,400 mm (685 in). Pressure: 0.6 bar (8.7 psi). Vacuum: Yes. Temperature: 200 °C (392 °F).
No packing included Diameter (1): 609.6 mm (24 in). Length (overall): 6,839 mm (269.3 in). Pressure: 3.4 bar (50 psi). Vacuum: Yes. Temperature: 148.9 °C (300 °F).
glass rectification packed Column, no packing Column consisting of 1-300mm diameter x 1m high column section, type PS12/1000; 1-300mm diameter x 600mm high head, type SK16083, openings head (1) DN 225, (1) DN 150. Diameter (1): 300 mm (11.8 in). Length (overall): 1,600 mm (63 in).
high clear glass rectification packed Column. column consisting of 1-300mm diameter x 1.5m high column section, type CS300/1500 and 1-300mm diameter x 495mm high diffuser bend (head), type PBR300/150, opening head (1) DN 150. Diameter (1): 300 mm (11.8 in). Length (overall): 1,950 mm (76.8 in).
Fractional distillation is the most common industrial separation process. Because distillation uses significant energy for both heating and cooling, it can account for half or more of a particular plant's entire operating costs. It's important to save on the capital equipment of a new distillation plant or an expansion project. Buying previously owned, aka used or second hand, distillation columns saves capital.
Another reason to consider buying used or second hand distillation columns is that the most effective ways to reduce distillation operating costs are through process optimization and control techniques, such as measuring differential pressure, not by buying newly manufactured columns.
IPP's stock of fractionation columns were used in a wide array of applications such as solvent recovery columns in Benzene, Toulene, Styrene, VCM plants, purification columns and light alcohol distillation columns in specialty chemical plants, steam stripping columns in the agrichemical/fertilizer industry at ammonia, urea, and di-methyl amine (DMA) plants, in VOC scrubbing systems for removing unreacted olefins and hydrocarbons found at PET plants and high vacuum batch distillation processes among others.
