Angle Mount 16 degree. Diameter--Width: 254 mm (10 in). Length: 5,486 mm (216 in). Orientation: Horizontal. Power Transmission: Belt. Inlet Size: 254 mm (10 in). Outlet Discharge Size: 203.2 mm (8 in). Powered By: Electric. Screw Diameter: 228.6 mm (9 in). Screw Type: Single screw. Conveyor Rate: 1300 lbs./Hr..
Twin Screw Trough is 20" wide x 10" deep with two 8" screws, length is 8' long. Diameter--Width: 508 mm (20 in). Length: 2,438 mm (96 in). Orientation: Horizontal. Power Transmission: Direct Coupled. Powered By: Electric. Screw Diameter: 203.2 mm (8 in). Screw Type: Double screw.
Diameter--Width: 508 mm (20 in). Length: 2,438 mm (96 in). Orientation: Horizontal. Power Transmission: Direct Coupled. Powered By: Electric. Screw Diameter: 203.2 mm (8 in). Screw Type: Double screw.
Rated 2000 lbs./Hr. at 40 lbs./Cu.Ft. Two-(2) 5' 9 &3/8 cooling sections. Diameter--Width: 374.7 mm (14.8 in). Length: 6,706 mm (264 in). Orientation: Horizontal. Power Transmission: Direct Coupled. Inlet Size: 203.2 mm (8 in). Outlet Discharge Size: 203.2 mm (8 in). Powered By: Electric. Screw Diameter: 450.9 mm (17.8 in). Screw Type: Single screw. Screw Heated/Cooled: Yes. Cooling ?: Yes. Heating/Cooling Surface Area: 4.2 m² (45 ft²). Rotation: Clockwise.
Diameter--Width: 228.6 mm (9 in). Length: 5,791 mm (228 in). Orientation: Horizontal. Power Transmission: Direct Coupled. Inlet Size: 203.2 mm (8 in). Outlet Discharge Size: 254 mm (10 in). Powered By: Electric. Screw Diameter: 228.6 mm (9 in). Screw Type: Single screw.
Diameter--Width: 254 mm (10 in). Length: 5,791 mm (228 in). Orientation: Horizontal. Power Transmission: Direct Coupled. Inlet Size: 203.2 mm (8 in). Outlet Discharge Size: 254 mm (10 in). Screw Diameter: 228.6 mm (9 in). Screw Type: Single screw.
"V" trough Diameter--Width: 355.6 mm (14 in). Length: 2,438 mm (96 in). Orientation: Horizontal. Power Transmission: Gear. Inlet Size: 203.2 mm (8 in). Outlet Discharge Size: 203.2 mm (8 in). Screw Diameter: 177.8 mm (7 in). Screw Type: Single screw.
screw conveyor.
12" x 16" charge port, 12" x 16" rectangular discharge port.
13" pitch on screw.
Packing gland on 304SS shaft and 304SS screw.
No drive and no covers (lids). Length: 457.2 mm (18 in). Orientation: Horizontal. Inlet Size: 304.8 mm (12 in). Outlet Discharge Size: 304.8 mm (12 in). Screw Diameter: 762 mm (30 in). Screw Type: Single screw.
screw pitch 9". Trough inside 13'4" x 10" Has packing glands. W/outboard bearings. Openings: top 10" x 10"; discharge btm 1-8". Length: 338.6 mm (13.3 in). Orientation: Horizontal. Power Transmission: Belt. Inlet Size: 254 mm (10 in). Outlet Discharge Size: 203.2 mm (8 in). Screw Diameter: 228.6 mm (9 in). Screw Type: Single screw.
super screw Conveyor Type #2 3/16" wall 3.5" diameter shaft Capacity is 18 M Dry Size is 9" x 2" x 13' 4" Diameter--Width: 228.6 mm (9 in). Length: 338.6 mm (13.3 in). Orientation: Vertical. Power Transmission: Belt. Powered By: Electric. Screw Type: Single screw.
Inclined cooling screw conveyor Diameter--Width: 533.4 mm (21 in). Length: 482.6 mm (19 in). Orientation: Inclined.
recycle conveyor for a porcupine dryer 12' long x 24" high x 40" wide. Diameter--Width: 152.4 mm (6 in). Length: 304.8 mm (12 in). Orientation: Inclined. Power Transmission: Direct Coupled.
900mm wide x 6.6m long x 640mm deep, 'u' trough design, wtih 300mm pitch 321 s/steel screw, direct driven by SEW Eurodrive, type K97DV-160M4, mounted on carbon steel legs. Diameter--Width: 900 mm (35.4 in). Length: 6.6 mm (0.26 in). Orientation: Inclined. Power Transmission: Direct Coupled. Powered By: Electric. Screw Diameter: 610 mm (24 in). Screw Type: Single screw.
paddle type screw conveyor, s/steel trough 12" wide x 12" deep x 13'10" long, s/steel screw driven by an electric motor via a gearbox, no top cover on trough, 12" x 12" discharge Diameter--Width: 254 mm (10 in). Length: 349.3 mm (13.8 in).
