Wet Gas Compressor Radial Split case two stage compressor motor through a Lufin gear reducer
The Datum compressor is an 18 frame size(inside case diameter) with a radial split case, six impellers and a back to back rotor design. The machine features a lube skid that supports the compressor, motor and gear, a gas skid for the double Dry Gas seals, and instrumentation for vibration and temperature detection.
MMSCFD Dry: 49.73; Lbs/Hr Wet: 224,820;
Inlet PSIA: 20.9; Inlet Temp: 106 Degree F; Inlet ACFM Wet: 24,183
Designed for Outdoor Use, Under roof.
All Electricals are Class 1, Group CD, Division 2.
Speeds: Maximum Continuous 5,653 RPM,
Trip Speed 5,719,
CCW rotation from drive end. With one piece shaft.
Motor, Gear reducer, and Compressor skid mounted.
Lufkin Gear reducer, 3.178:1 ratio, rated 10,300 HP.
The Oil control system is by Cobey, and skid mounted.
The Seal gas system and skid are by Flowserve.
