Pump-Vacuum 69.7 m3/h (41 CFM) Stainless Steel 316 For Sale - IPP# 246871

Type: Pump-Vacuum

Manufacturer: Nash

Model: CL-702

Condition: Used

Material: Stainless Steel 316

Air Flow: 1,232 m3/h (725 CFM)

Discharge Pressure: 0.61 bar (8.8 psi)

18" hg abs, liquid ring horizontal vacuum pump, with two 4" inlets and two 3" outlets. Driver # E-2613, Explosion proof drive.

Orientation: Horizontal. Inlet Diameter: 101.6 mm (4 in). Outlet Diameter: 76.2 mm (3 in). Seal Type: Liquid Ring.

Type: Pump-Vacuum

Manufacturer: Nash

Model: SH6

Condition: Used

Material: Stainless Steel 316

Air Flow: 662.6 m3/h (390 CFM)

Discharge Pressure: 0.85 bar (12.3 psi)

Vacuum level: 25"Hg

Orientation: Horizontal. Seal Type: Liquid Ring.

Type: Pump-Vacuum

Manufacturer: Nash

Model: CL

Condition: Used

Material: Carbon Steel

Air Flow: 1,699 m3/h (1,000 CFM)

Discharge Pressure: 0.81 bar (11.8 psi)

24" hg Size: 1002 Test number: 7903116 Life Line T AC motor. Model TBDP Motor style: 6808122G31 Motor rating: 72 amps

Orientation: Horizontal. Inlet Diameter: 203.2 mm (8 in). Outlet Diameter: 101.6 mm (4 in).

Type: Pump-Vacuum

Manufacturer: Nash

Model: CL-2001

Condition: Used

Air Flow: 730 m3/h (429.7 CFM)

Orientation: Horizontal

without motor material A48 CL 30 B pressure suction side 1,5 bar sealing medium water

Seal Type: Liquid Ring.
