21" cone Filter vessel volume 496 liter Each plate 760mm diameter Cake is discharged by means of oscillation Filter has (8) horizontal leaves Filtration Area: 3.3 m² (35.5 ft²). Diameter: 914.4 mm (36 in). Orientation: Horizontal. Pressure: 8 bar (116 psi). Temperature: 80 °C (176 °F).
Filter body manufactured by R Stihler, serial #9018 Filter tank capacity 593 liter. with (2) vibratory motors Motor: 3 phase non-flameproof motors and bottom cone Filtration Area: 4.6 m² (49.5 ft²). Diameter: 900 mm (35.4 in). Pressure: 6 bar (87 psi). Temperature: 100 °C (212 °F). Jacket: Yes. Jacket MOC: Carbon Steel.
1090 liter - volume measurement in liters jacketed - type of equipment centrifugal discharge pressure leaf filter - type of filter Rated 72 PSI @ 302 degrees F internal; 72 psi, 90 liter @ 302 degrees F in the jacket (15) plates - number of plates in the filter on 80 mm spacing - distance between plates 55mm cake thickness Vessle is 1000 mm diameter. 0.42KW drive for centrifugal cake discharge Filtration Area: 6.3 m² (67.8 ft²). Diameter: 760 mm (29.9 in). Pressure: 5 bar (72 psi). Temperature: 150 °C (302 °F). Jacket: Yes. Jacket Pressure: 5 bar (72 psi). Jacket Temperature: 150 °C (302 °F).
Sanitary pressure filter system Product #: 4534000 Components: (4) filter chambers, pneumatically operated control manifold, 300 gal poly tank, and misc piping Each filter chamber 12" dia x 37" str side and holds (12) 2 5/8" dia x 30" long cartridges. All filter piping is polished sanitary fittings. (4) filter chambers are mtd on base Control manifold 44" wide x 38" long x 87" high. Manifold includes piping for in place steam cleaning of filter chambers. Filtration Area: 0.42 m² (4.5 ft²). Pressure: 8.3 bar (120 psi).
Internal pressure rating: 60psi @ -20 to 350 degree F Jacket pressure rating: 14.5psi @ -20 to 350 degree F (12) 18" Deep plates. 70 Gallon volume, Vessel dimensions: 2' diameter x 3' straight side Filtration Area: 2 m² (22 ft²). Diameter: 457.2 mm (18 in). Orientation: Vertical. Pressure: 4.1 bar (60 psi). Temperature: 176.7 °C (350 °F). Jacket: Yes. Jacket Type: Standard. Jacket MOC: Carbon Steel. Jacket Pressure: 1 bar (14.5 psi). Jacket Temperature: 176.7 °C (350 °F). Vessel Capacity: 265 L (70 gallons).
Manufactured by Durco Enzinger Vertical tank horizontal Plate design, with wet cake discharge, with Slucing bar SS bolt on plate coil jacket on bottom head with bolted dished bottom with swing bolts Mounted on top is a faractioanl HP drive that turns the slucing bar that rund down the middel of the plate stack 6" diameter bottom cake discharge Filtration Area: 7.2 m² (77 ft²). Diameter: 914.4 mm (36 in). Orientation: Vertical. Pressure: 5.2 bar (75 psi). Temperature: 148.9 °C (300 °F). Jacket MOC: Carbon Steel. Jacket Pressure: 1.03 bar (15 psi). Jacket Temperature: 121.1 °C (250 °F).
CS jkt (18) vert filter plates Swing bolt dish top 141" thick. 1-6" center btm outlet Filtration Area: 7 m² (75 ft²). Diameter: 1,067 mm (42 in). Orientation: Vertical. Pressure: 5.2 bar (75 psi). Temperature: 93.3 °C (200 °F). Jacket: Yes. Jacket Pressure: 5.2 bar (75 psi). Jacket Temperature: 93.3 °C (200 °F).
Horizontal plate design Centrifugal discharge driven by 40 HP, 3/60/230/460 volt, 1775 rpm motor thru Falk gearbox input 1750, ratio 6.246:1, output 290 Filtration Area: 28.8 m² (310 ft²). Diameter: 1,372 mm (54 in). Orientation: Vertical. Pressure: 6.2 bar (90 psi). Temperature: 93.3 °C (200 °F).
Certified by Votator Corp horizontal plate design thru Falk gearbox, input 1750, ratio 6.246:1, output 290 Shell is 0.375 " thick head is 0.375" thick, head is 0.500" thick Filtration Area: 28.8 m² (310 ft²). Diameter: 1,372 mm (54 in). Orientation: Vertical. Pressure: 6.2 bar (90 psi). Temperature: 93.3 °C (200 °F).
304SS jkt on sidewalls Dry cake discharge Filter tank measures 750mm dia x 1035mm str side, bolt dish top, cone btm 440mm long w/304SS dia btm discharge opening Vert tank W/packing gland on shaft horiz leaf design Filtration Area: 5 m² (54 ft²). Pressure: 5 bar (72 psi). Temperature: 120 °C (248 °F). Jacket: Yes. Jacket MOC: Stainless Steel 316. Jacket Pressure: 2 bar (29 psi). Jacket Temperature: 120 °C (248 °F).
Cake Discharge: Dry, suitable for direct or pre-coat filtration Number of Filter Screens: 22 445 gallon 20 HP 3/60/230/460 volt Additional Features: Includes a spare filter plate pack. Filtration Area: 10 m² (107.6 ft²). Diameter: 1,118 mm (44 in). Pressure: 5.2 bar (75 psi). Temperature: 93.3 °C (200 °F).
pressure filter Filtration Area: 7.3 m² (78.2 ft²). Diameter: 838.2 mm (33 in). Orientation: Vertical. Pressure: 6.9 bar (100 psi). Temperature: 176.7 °C (350 °F). Cake Volume: 0.14 m3 (4.9 ft3).
Mfd by Enviroclear/Amstar 304SS shell Shell mfd by Nolte and Son NB #2110 hinged door w/swing bolt closure Unit has (8) 16" x 30" x 1 3/4" deep horiz filter trays Filtration Area: 2.4 m² (26 ft²). Diameter: 762 mm (30 in). Pressure: 5.2 bar (75 psi). Temperature: 160 °C (320 °F). Jacket: Yes. Jacket MOC: Stainless Steel 304.
(1) swing bolt dish head on davit Filtration Area: 4.6 m² (50 ft²). Diameter: 812.8 mm (32 in). Orientation: Horizontal. Pressure: 5.2 bar (75 psi). Temperature: 135 °C (275 °F). Jacket: Yes. Jacket MOC: Carbon Steel. Jacket Pressure: 2.1 bar (30 psi). Jacket Temperature: 135 °C (275 °F).
Vert shell, horiz plate design (5) 12" x 30" long plates. Filtration Area: 2.3 m² (25 ft²). Diameter: 457.2 mm (18 in). Orientation: Vertical. Pressure: 6.9 bar (100 psi). Temperature: 93.3 °C (200 °F). Jacket: Yes. Jacket MOC: Stainless Steel 316.
vert tank pressure filter Cake capacity: 0.445 cu ft Filtration Area: 0.33 m² (3.5 ft²). Orientation: Horizontal. Pressure: 4.1 bar (60 psi). Temperature: 343.3 °C (650 °F). Jacket: Yes. Jacket MOC: Carbon Steel. Jacket Pressure: 1 bar (14.5 psi).
Pemco Leaves: (2) 12" x 40", (2) 18" x 40", (3) 22" x 40" vertical leaves Filtration Area: 6.5 m² (70 ft²). Diameter: 609.6 mm (24 in). Orientation: Vertical.
Enviroclear/Amstar Horiz shell Horiz leaf design jkt pressure filter SN 8207 Filtration Area: 2.8 m² (30 ft²). Diameter: 508 mm (20 in). Orientation: Horizontal. Pressure: 6.2 bar (90 psi). Temperature: 160 °C (320 °F). Jacket: Yes. Jacket Pressure: 2.1 bar (30 psi). Jacket Temperature: 160 °C (320 °F).
jacketed Unit has (12) 2" deep plates Filtration Area: 1.11 m² (12 ft²). Jacket: Yes.
0.141 " tank thickness with scavenger plate 0.414 CuFt cake capacity 7 plates (number of plates included) Filtration Area: 1.05 m² (11.3 ft²). Pressure: 4.1 bar (60 psi). Temperature: 176.7 °C (350 °F).
Continuous filter/washer Number of stationary filter plates: 11 Number of solid rotor discs with cake trimming vanes: 12 Drive: 3 HP adjustable speed drive Seal: Mechanical seal Sensor: Torque sensor Cake outlet size: 3/4" Filtrate outlet size: 2" Feed inlet size: 1/2" Mounting: On stand Control panel: Included 500 psi Pulsa diaphragm metering pump, Mdl 7120-S-E, driven by 1/2 HP motor. Filtration Area: 0.28 m² (3 ft²). Diameter: 152.4 mm (6 in). Pressure: 27.6 bar (400 psi). Temperature: 93.3 °C (200 °F).
Filtration resistance due to cake build-up on stationary filter plates is limited to specific controlled thickness by the wiping action of the blades attached to rotating discs in each stage 12-stages, 24-rotating discs thru Dodge reducer, 5.5:1 ratio. W/control panel Filtration Area: 6 m² (65 ft²). Pressure: 27.6 bar (400 psi). Temperature: 93.3 °C (200 °F).
continuous filter/washer Filtration resistance due to cake build-up on stationary filter plates is limited to specific controlled thickness by the wiping action of the blades attached to rotating discs in each stage 12-stages, 24-rotating discs thru Dodge reducer 5.5:1 ratio W/control panel Filtration Area: 6 m² (65 ft²). Pressure: 27.6 bar (400 psi). Temperature: 93.3 °C (200 °F).
Jacketed pressure leaf/plate filter Vertical vessel with horizontal plates Internal volume: 410 liters internal pressure -1/6 bar @ -25/250 degrees C (410 liter), jacket -1/6 bar @ -25/250 degrees C (65 liter) With manual screw press mechanism, davit assist for top cover Filtration Area: 6 m² (64.6 ft²). Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 250 °C (482 °F). Jacket: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 250 °C (482 °F).
Jacketed pressure leaf/plate filter Vertical vessel with horizontal filter plates Internal volume: 410 liters Internal pressure: -1/6 bar @ -25/200 degrees C (410 liter) Jacket pressure: -1/6 bar @ -25/200 degrees C (65 liter) With manual screw press mechanism, davit assist for top cover Filtration Area: 6 m² (64.6 ft²). Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 200 °C (392 °F). Jacket: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Vessel Capacity: 410 L (108.3 gallons).
Filtration resistance due to cake build-up on stationary filter plates is limited to specific controlled thickness by the wiping action of the blades attached to rotating discs in each stage 12-stages, 24-rotating discs thru Dodge reducer, 5.5:1 ratio. W/control panel. Filtration Area: 6 m² (65 ft²). Pressure: 27.6 bar (400 psi). Temperature: 93.3 °C (200 °F).
vessel 670mm diameter x 650mm straight side plate type H13, manual screw plate pressure mechanism, top cover with lift/swivel davit arm Filtration Area: 3.2 m² (34.4 ft²). Diameter: 600 mm (23.6 in). Orientation: Horizontal. Pressure: 6 bar (87 psi). Temperature: 165 °C (329 °F).
Centrifugal discharge pressure leaf filter
Centrifugal discharge pressure leaf filter Vessel volume: 5250 ltr approx 1.6m diameter x 1.6mm straight side vertical chamber associated equipment includes, 2 x diaphragm pumps, 1 x Hilge centrifugal pump, Filtration Area: 80 m² (861.1 ft²). Diameter: 1,500 mm (59.1 in). Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 20 °C (68 °F).
vessel volume 5250 liter approx 1.6m diameter x 1.6mm straight side vertical chamber, approx 300mm discharge, mounted on (3) stainless steel legs, associated equipment includes 1 x 3000 liter vertical stainless steel pressure tank, pressure 0,5 bar to 20°C, 1.4m diameter x 1.4m straight side, weld dished top, weld coned bottom, mounted on 3 legs, 1 x approx 600 liter stainless steel tank with agitator, 2 x diaphragm pumps, 1 x Hilge centrifugal pump. Filtration Area: 80 m² (861.1 ft²). Diameter: 1,500 mm (59.1 in). Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 20 °C (68 °F).
5.69 bar @ -29/+60 deg C packed gland on shaft, built to ASME V111 div 1 Filtration Area: 80 m² (861.1 ft²). Diameter: 1,400 mm (55.1 in). Pressure: 5.7 bar (82.5 psi). Temperature: 60 °C (140 °F).
design pressure 5.69 bar @ -29/+60 deg C Shaft seal: Packed gland built to ASME V111 div 1 Filtration Area: 80 m² (861.1 ft²). Diameter: 1,400 mm (55.1 in). Pressure: 5.7 bar (82.5 psi). Temperature: 60 °C (140 °F).
5.69 bar @ -29/+60 deg C packed gland on shaft built to ASME V111 div 1 Filtration Area: 80 m² (861.1 ft²). Diameter: 1,400 mm (55.1 in). Pressure: 5.7 bar (82.5 psi). Temperature: 60 °C (140 °F).
Funda filter Chemap WA number: 6470 3/50/220/380 volt Filtration Area: 1 m² (10.8 ft²). Orientation: Vertical. Pressure: 14.7 bar (213.2 psi). Temperature: 170 °C (338 °F). Jacket: Yes. Jacket MOC: Carbon Steel. Jacket Pressure: 0.48 bar (7 psi). Jacket Temperature: 76.7 °C (170 °F).
Filter type: Ecofilter -10 to 50 deg C Vertical tank, horizontal leaf design with centrifugal cake discharge. Includes feed pump. built on control panel Filtration Area: 15 m² (161.5 ft²). Orientation: Vertical. Pressure: 8 bar (116 psi). Temperature: 50 °C (122 °F).
Internal (390 liter) Jacket (50 liter) (21) stainless steel plates 600mm Diameter, 750mm diameter x 1000mm straight side, Cake volume: 105 liter Filtration Area: 5.3 m² (56.5 ft²). Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 133 °C (271.4 °F). Jacket: Yes. Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 133 °C (271.4 °F).
Vessel Number: 5055GW Capacity: 955 liters Centrifugal wet cake discharge Elements: (32) 805mm diameter elements, (2) 805mm diameter scavenger elements Seal: Mechanical seal under driven Filtration Area: 15 m² (161.5 ft²). Diameter: 805 mm (31.7 in). Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 100 °C (212 °F).
Vessel Number 5056GW Capacity: 955 liters Centrifugal wet cake discharge (32) 805mm diameter elements, (2) 805mm diameter scavenger elements mechanical seal Filtration Area: 15 m² (161.5 ft²). Diameter: 805 mm (31.7 in). Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 100 °C (212 °F).
vessel # 5293GW rated inside -1/6bar volume 1.000 liter rated jacket -1/6bar volume 110 liter, vertical jacketed centrifugal discharge. Cake capacity 0.45 cubic feet. Filtration Area: 15 m² (161.9 ft²). Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 200 °C (392 °F). Jacket: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F).
1 sqm rest filtration area Vessel volume: 500 ltr Jacket volume: 46 ltr Internal pressure: vac/6 bar @ -10/200 degrees C Number of filter elements: 13 Number of rest filter elements: 2 Distance between filter elements: 30mm filter cake volume 150 ltr Filtration Area: 6.5 m² (70 ft²). Diameter: 80 mm (3.1 in). Pressure: 6 bar (87 psi). Temperature: 200 °C (392 °F). Jacket: Yes. Jacket MOC: Stainless Steel 304.
Vessel #: 5292GW rated inside -1/6bar volume 1.000 liter rated jacket -1/6bar volume 110 liter centrifugal discharge. Cake capacity 0.45 cubic feet Filtration Area: 15 m² (161.9 ft²). Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 200 °C (392 °F). Jacket: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F).
Stawag Funda pressure leaf filter 55°C to 65°C internal 1.5 m³ volume Voltage: 3~380A/660V Current: 11.4A/6.6A Number of plates: 18 Filtration Area: 7 m² (75.3 ft²). Diameter: 900 mm (35.4 in). Pressure: 6.5 bar (94.3 psi). Temperature: 65 °C (149 °F).
Test pressure: 11.9 bar centrifugal discharge Total capacity 539 gals (448 Imperial gals) Unit has (20) 39" diameter discs Type A for wet cake discharge. Filtration Area: 15 m² (161.5 ft²). Diameter: 1,100 mm (43.3 in). Pressure: 6.9 bar (100.1 psi). Jacket: Yes. Jacket MOC: Carbon Steel.
Ref works order #005342/A Cake space 7.69 cubic feet (0.218 cubic meter) horizontal plate design Manual plate tensioning mechanism on top cover. Filtration Area: 7.3 m² (78.6 ft²). Diameter: 950 mm (37.4 in). Orientation: Vertical. Pressure: 3 bar (43.5 psi). Temperature: 145 °C (293 °F).
Pressure leaf/plate filter Internal volume: 640 liters Internal pressure: -1/6 bar approx (20) 800mm diameter stainless steel internal horizontal filter plates manual screw press mechanism, davit assist for top cover Filtration Area: 9.5 m² (102.3 ft²). Diameter: 950 mm (37.4 in). Pressure: 6 bar (87 psi). Temperature: 200 °C (392 °F).
Pressure leaf/plate filter Internal volume: 640 liters pressure -1/6 bar manual screw press mechanism, davit assist for top cover Filtration Area: 9.5 m² (102.3 ft²). Diameter: 950 mm (37.4 in). Pressure: 6 bar (87 psi). Temperature: 200 °C (392 °F).
Plate pack for a pressure filter Plates stamped # 2229. Seven plates plus a scavenger. With holders and rods. Diameter: 457.2 mm (18 in).
Plate pack for a pressure filter. 3 plates, no scavenger. With holders and rods. Diameter: 457.2 mm (18 in).
Fundabac filter Volume: 165 liters Pressure rating: -1/10 bar @ 0/200 degrees C with 3 filter candles, Filtration Area: 1.3 m² (14 ft²). Diameter: 320 mm (12.6 in). Pressure: 10 bar (145 psi). Temperature: 200 °C (392 °F).
filter body Cake capacity: 1.552 Cu.Ft. No plates or internals. Filtration Area: 1.2 m² (12.9 ft²). Diameter: 50.8 mm (2 in). Pressure: 4.1 bar (60 psi). Temperature: 176.7 °C (350 °F). Jacket: Yes. Jacket MOC: Carbon Steel. Jacket Pressure: 3.4 bar (50 psi). Jacket Temperature: 176.7 °C (350 °F).
pressure leaf filter body Discharge type: centrifugal Tank capacity: 350 litres Serial number: KH839 Int rated 6 bar/full vac @ 200 deg C Unit will take (10) leaves Vessel is 900mm (36"). No leaves w/unit. Filtration Area: 5 m² (53.8 ft²). Diameter: 812.8 mm (32 in). Pressure: 6 bar (87 psi). Temperature: 200 °C (392 °F).
Cake capacity: 0.229 cubic feet Has scavenger plate Filtration Area: 0.58 m² (6.2 ft²). Diameter: 406.4 mm (16 in). Orientation: Vertical.
Has (7) 18" dia shallow plates. Has .414 cu ft cake capacity. Has 2" btm outlet w/scavenger plate. Filtration Area: 1.05 m² (11.3 ft²). Diameter: 508 mm (20 in). Orientation: Vertical. Pressure: 4.1 bar (60 psi).
horizontal leaf, vertical tank pressure filter Mech seals on shaft top and btm No drive. Filtration Area: 18.6 m² (200 ft²). Diameter: 1,067 mm (42 in). Orientation: Horizontal.
vertical leaf pressure filter Pressure rating: 4 ATU Filter housing retracts on an overhead rail for cleaning the filter. Filter tank 1200mm diameter x 2100mm straight side, (1) welded dished head, (1) clamped head with ratchet closure (30) leaves. Filter housing has cake level detector and wash nozzles for the leaves mounted under the leaves fixture. Equipped with (3) 1.4571 cake bins, 800mm wide x 1700mm long with casters. Designed to German TUV standards. Filtration Area: 39.6 m² (426.3 ft²). Diameter: 1,200 mm (47.2 in). Orientation: Vertical. Pressure: 3.9 bar (56.9 psi). Temperature: 120 °C (248 °F).
swing bolt top Filtration Area: 1.02 m² (11 ft²). Diameter: 508 mm (20 in). Orientation: Vertical. Pressure: 4.1 bar (60 psi). Temperature: 21.1 °C (70 °F).
Capacity: 760 liter Temperature Range: -25/200 deg C driven by hydraulic Filtration Area: 10 m² (107.6 ft²). Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 200 °C (392 °F). Jacket: Yes.
Pressure leaf filter Cake capacity: 27 cu ft Vert tank, vert leaf design Filtration Area: 24.1 m² (259 ft²). Diameter: 1,067 mm (42 in). Orientation: Vertical. Pressure: 5.2 bar (75 psi). Temperature: 93.3 °C (200 °F).
500 Gallon Manufactured by Alloy Fab for Dartco Shell is .250" thick Top head is .312" thick Cone is .312/.437" thick jacket is .109" thick 6.5 turns half pipe on top head 18 turns half pipe on straight side 5 turns half pipe bottom head All half pipe jacket is 2" Diameter: 1,067 mm (42 in). Pressure: 9.4 bar (136 psi). Temperature: 315.6 °C (600 °F). Jacket: Yes. Jacket Type: Half Pipe/Limpet. Jacket MOC: Stainless Steel 304. Jacket Pressure: 17.2 bar (250 psi). Jacket Temperature: 315.6 °C (600 °F).
jacket 1,9 bar at 150°C (10) 316Ti stainless steel filter leaves Mechanical seal on shaft, carbon steel half pipe coil on bottom head Filter volume 670 liter Filtration Area: 4.7 m² (50.6 ft²). Diameter: 805 mm (31.7 in). Pressure: 6 bar (87 psi). Temperature: 150 °C (302 °F). Jacket: Yes. Jacket Type: Half Pipe/Limpet. Jacket MOC: Carbon Steel. Jacket Pressure: 9 bar (130.5 psi). Jacket Temperature: 150 °C (302 °F).
70 ltr pressure filter Centrifugal discharge packing gland on shaft Motor: 220/480 V Diameter: 800 mm (31.5 in). Jacket: Yes. Jacket MOC: Stainless Steel 304.
jaceketed pressure leaf filter with centrifugal discharge Shell made of 316 stainless steel (1.4439) jacket made of 1.4571 Internal pressure 6 bar & full vacuum ; jacket 6 bar @ -10/+200 degrees C with control panel Filter volume 670 liter, jacket volume 45 liter Filtration Area: 5.7 m² (61.4 ft²). Diameter: 900 mm (35.4 in). Pressure: 6 bar (87 psi). Jacket: Yes. Jacket MOC: Stainless Steel 321. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F).
Internal pressure 90 psi (6.2 ATU and full vacuum) @ 200 degrees C; jacket 90 psi @ 200 degrees C (16) horizontal leaves Centrifugal discharge driven by 4 PS, 3/50/500 volt, 462 rpm XP motor Filtration Area: 2.5 m² (26.9 ft²). Orientation: Vertical. Pressure: 6.2 bar (90 psi). Temperature: 200 °C (392 °F). Jacket: Yes. Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 93.3 °C (200 °F).
Fundabac Filter 970 liter capacity, jacket is 170 liters Filtration Area: 4.6 m² (50 ft²). Pressure: 6 bar (87 psi). Temperature: 150 °C (302 °F). Jacket: Yes. Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 150 °C (302 °F).
21" cone Filter vessel volume 496 liter Each plate 760mm diameter Cake is discharged by means of oscillation with 3.5 KW, 3/50/380 volt motor Filter has (8) horizontal leaves Filtration Area: 3.3 m² (35.5 ft²). Diameter: 914.4 mm (36 in). Pressure: 8 bar (116 psi). Temperature: 80 °C (176 °F).
Head .187" thick, shell .140" thick Horiz tank, horiz plate design. 30" dia x 60" str side. Plates: (2) 16" wide x 60" long; (2) 24" wide x 60" long; (4) 28" wide x 60" long. Dish heads on davits. 2-2" inlets on top head, Filtration Area: 7 m² (75 ft²). Pressure: 5.2 bar (75 psi). Temperature: 343.3 °C (650 °F).
Niagara 316 stainless steel horizontal tank vertical leaf pressure filter Rated 4.5 Kg/cm @ 120 degrees C Volume 2.555 cubic meter Chamber 1650mm long x 1150mm diameter Manual opening mechanism Pull plates out Filtration Area: 18.5 m² (199.1 ft²). Orientation: Vertical. Temperature: 120 °C (248 °F).
ASME #19142 250" thick heads 187" shell Tank has 1100 gal capacity (1) dish head is hinged and has swing bolts Horiz tank, horiz plate design (12) plates, 34.5 cu ft cake capacity Dry cake discharge w/hydraulic cylinder to rotate plates to vert for cake discharge Unit has (12) 1" openings with manifold for filtrate discharge Filtration Area: 19.2 m² (206.9 ft²). Diameter: 1,219 mm (48 in). Pressure: 4.1 bar (60 psi). Temperature: 204.4 °C (400 °F).
Shell manufactured by BHS, Serial 329063 Glass #8000. with 7-internal filter plate. full vacuum (810 liter) Feed has 2-50mm w/(2) vibratory feeders Top has additional 4-100mm nozzles Bottom discharge is 500mm Filtration Area: 5.5 m² (59.2 ft²). Diameter: 1,200 mm (47.2 in). Pressure: 6 bar (87 psi). Jacket: Yes. Jacket Pressure: 6 bar (87 psi).
pressure bag filter, moduline Qic-Lock maxiline, working pressure 10 bar @ 120 degrees C (185 liter) (4) 165mm diameter x 710mm long bags, Connections DN50 (2") Diameter: 165 mm (6.5 in). Orientation: Vertical. Pressure: 10 bar (145 psi). Temperature: 120 °C (248 °F).
Funda pressure leaf filter W/centrifugal dry cake discahrge Shell 508mm dia x 150mm l Filtration Area: 2 m² (21.5 ft²). Pressure: 5 bar (72.5 psi). Temperature: 130 °C (266 °F). Jacket: Yes. Jacket MOC: Stainless Steel 316. Jacket Pressure: 2.5 bar (36.3 psi). Jacket Temperature: 130 °C (266 °F).
1.4401/1.4571 (316SS/316SS/TI) horizontal tank Rated 4 ATU @ 120 degree C Filter housing retracts on an overhead rail for cleaning the filter (1) clamped head with ratchet closure Equipped with (30) leaves Filter housing has cake level detector and wash nozzles for the leaves mounted under the leaves fixture Equipped with (3) 1.4571 cake bins, 800mm wide x 1700mm long with casters Floor space requirements: 6500mm long x 1600mm wide x 2600mm high Designed to German TUV standards Filtration Area: 39.6 m² (426.3 ft²). Diameter: 1,200 mm (47.2 in). Orientation: Vertical. Temperature: 120 °C (248 °F).
Funda filter with centrifugal discharge (23) 1000mm diameter filter elements mounted @ 30mm spacing Wet cake discharge Filtration Area: 18 m² (193.8 ft²). Diameter: 1,100 mm (43.3 in). Pressure: 5 bar (72.5 psi). Temperature: 100 °C (212 °F).
Funda filter with centrifugal discharge (33) 800mm diameter filter elements @ 30mm spacing Filter volume 1380 liters Designed for wet cake discharge. Requires 30 KW motor. Filtration Area: 15 m² (161.5 ft²). Diameter: 1,080 mm (42.5 in). Pressure: 10 bar (145 psi). Temperature: 100 °C (212 °F).
15mm (0,6") thickness horizontal filter plates. 5 cubik feet cake capacity. 650mm diameter (26") x 750mm (30") straight side vertical chamber Filtration Area: 8 m² (86.1 ft²). Diameter: 600 mm (23.6 in). Orientation: Horizontal. Pressure: 5.9 bar (86 psi). Temperature: 160 °C (320 °F). Jacket: Yes. Jacket MOC: Carbon Steel. Jacket Pressure: 6.3 bar (92 psi). Jacket Temperature: 160 °C (320 °F).
vertical sparkler type filter cGMP rated and sanitary construction buff polished to a mirror finish Rated for 3.5 kg/cm2 With a cake holding capacity of 64 Liters 18" x 15. (15 plates) Main filter body bolts together (2 sections) on board centrifugal pump with 2.2 kw drive motor. Overall dimensions: 1521 mm wide x 1440 mm deep x 1771 high Filtration Area: 2.4 m² (25.8 ft²). Orientation: Vertical. Pressure: 3.4 bar (49.7 psi). Cake Volume: 64 m3 (2,260 ft3). Jacket: Yes. Jacket MOC: Stainless Steel 304.
Funda filter with centrifugal discharge Shell 900mm diameter x 960mm from flanged top to bottom discharge (22) 800mm diameter filter elements @ 30mm spacing Requires 15 PS motor Wet cake discharge Filtration Area: 10 m² (107.6 ft²). Diameter: 900 mm (35.4 in). Pressure: 5 bar (72.5 psi). Temperature: 100 °C (212 °F).
