Top Head. 12" x 16" hinged manway opening Diameter: 1,016 mm (40 in). Vessel Size: 757.1 L (200 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 176.7 °C (350 °F).
EM Series glass lined Top Head rated 25 psi/full vac @ 450 deg F internal. Diameter: 1,016 mm (40 in). Vessel Size: 567.8 L (150 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 232.2 °C (450 °F).
Top head (main cover) VR 100 Diameter: 762 mm (30 in). Vessel Size: 378.5 L (100 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 176.7 °C (350 °F).
32" ID ES Series W/hinges ASME Code #1740 Diameter: 812.8 mm (32 in). Vessel Size: 378.5 L (100 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 176.7 °C (350 °F).
Reactor Top Head Diameter: 1,016 mm (40 in). Vessel Size: 757.1 L (200 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 176.7 °C (350 °F).
Top Head, 150 or 200 Gallon 12" x 16" manway, Diameter: 1,016 mm (40 in). Vessel Size: 757.1 L (200 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 176.7 °C (350 °F).
Diameter: 762 mm (30 in).
Top Head with 3 boss's for mounting drive. Diameter: 609.6 mm (24 in).
Diameter: 609.6 mm (24 in).
Receiver cover Diameter: 609.6 mm (24 in).
P Series Diameter: 609.6 mm (24 in).
EL Series reactor cover Openings: 12" x 16" manway opening w/hinges 3-4" nozzles, 1-8" nozzle, 1-4 3/8" center nozzle 15" bolt circle. Diameter: 1,219 mm (48 in).
receiver cover Diameter: 762 mm (30 in). Vessel Size: 378.5 L (100 gallons). Pressure: 1.72 bar (25 psi). Temperature: 343.3 °C (650 °F).
Vessel Size: 757.1 L (200 gallons). Pressure: 6.2 bar (90 psi). Temperature: 260 °C (500 °F).
Diameter: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Pressure: 6.9 bar (100 psi). Temperature: 204.4 °C (400 °F).
top head 14"ID Diameter: 355.6 mm (14 in). Vessel Size: 37.9 L (10 gallons). Reglassed: Yes.
48" ID EL Series reactor cover Fits 200/500 gal EL/ELL Series reactor. Diameter: 1,219 mm (48 in). Vessel Size: 1,893 L (500 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 176.7 °C (350 °F).
Top Head 100/FV Diameter: 1,219 mm (48 in). Vessel Size: 1,136 L (300 gallons). Pressure: 6.9 bar (100 psi). Temperature: 232.2 °C (450 °F).
white glass great cover For a E-2000 or E-3000 series reactor For a VS10 agit drive and mech seal Diameter: 889 mm (35 in).
great cover Diameter: 812.8 mm (32 in).
receiver cover Diameter: 914.4 mm (36 in). Vessel Size: 757.1 L (200 gallons). Reglassed: Yes.
Diameter: 812.8 mm (32 in). Vessel Size: 189.3 L (50 gallons). Reglassed: Yes.
top cover Diameter: 1,016 mm (40 in). Vessel Size: 757.1 L (200 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 176.7 °C (350 °F).
Diameter: 812.8 mm (32 in). Vessel Size: 378.5 L (100 gallons). Reglassed: Yes.
reactor cover EL 200-EL 500 Diameter: 1,219 mm (48 in). Vessel Size: 757.1 L (200 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 176.7 °C (350 °F).
Diameter: 762 mm (30 in). Reglassed: Yes.
(1) 14 x 18 manway opening with Pfaudler single hole hinge Diameter: 762 mm (30 in). Reglassed: Yes.
20 Gallon "P" series Reactor Cover, 20" rated for Full Vacuum 25 psi. Diameter: 508 mm (20 in). Vessel Size: 75.7 L (20 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 343.3 °C (650 °F).
Diameter: 762 mm (30 in).
ES Series reactor. 12" x 16" manway. Fits 100 gal ES Series reactor. Diameter: 812.8 mm (32 in). Vessel Size: 378.5 L (100 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 232.2 °C (450 °F).
reactor cover Diameter: 914.4 mm (36 in).
clamp top receiver cover. Diameter: 762 mm (30 in).
clamp top cover Diameter: 762 mm (30 in).
Top head. Openings: 12" x 16" manway Fits a 150/200 gallon reactor Diameter: 1,118 mm (44 in). Vessel Size: 757.1 L (200 gallons).
Top head, Openings: 14" x 18" manway Diameter: 1,372 mm (54 in). Vessel Size: 1,893 L (500 gallons).
top head Diameter: 1,524 mm (60 in).
Bottom size: 20-30 Gallon One 4" nozzle, one 2.25" drive nozzle, Three 2" nozzles. Diameter: 508 mm (20 in). Vessel Size: 113.6 L (30 gallons).
Diameter: 1,219 mm (48 in). Vessel Size: 1,893 L (500 gallons).
EM Series reactor top head Diameter: 1,016 mm (40 in). Reglassed: Yes.
OD: 27" ID: 24" reactor cover Diameter: 685.8 mm (27 in).
Inner diameter: 52 inches Clamp top head full vacuum Diameter: 1,321 mm (52 in). Vessel Size: 1,893 L (500 gallons). Pressure: 6.9 bar (100 psi). Temperature: 343.3 °C (650 °F).
reactor cover. Fits 250 gal DG Series reactor Diameter: 762 mm (30 in). Vessel Size: 946.4 L (250 gallons).
reactor top head MFG #E99267, with 12" x 16" manway opening Diameter: 1,524 mm (60 in). Vessel Size: 1,893 L (500 gallons). Pressure: 1.72 bar (25 psi). Temperature: 176.7 °C (350 °F).
reactor cover. Fits 150/200 gal EM Series reactor. Diameter: 1,016 mm (40 in). Vessel Size: 757.1 L (200 gallons).
clamp top receiver cover. Diameter: 609.6 mm (24 in). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 232.2 °C (450 °F).
top head Head arrangement: (3) 4" , (1) 4" center drive nozzle, (1) 6" , (1) 12x16 manway opening. One year UGE warranty Diameter: 1,016 mm (40 in). Pressure: 1.72 bar (25 psi). Temperature: 260 °C (500 °F).
with Davit hinge in center of cover. No sight glass. Diameter: 457.2 mm (18 in). Reglassed: Yes.
P Series Diameter: 762 mm (30 in). Vessel Size: 378.5 L (100 gallons).
Top Head. Cover Pressure rating: 150 psi/FV Diameter: 812.8 mm (32 in). Vessel Size: 378.5 L (100 gallons). Pressure: 10.3 bar (150 psi). Reglassed: Yes. Temperature: 232.2 °C (450 °F).
Glass type: 2009 With gearbox pedestal attached. Diameter: 609.6 mm (24 in). Pressure: 10.3 bar (150 psi). Temperature: 260 °C (500 °F).
top head Fits a P100 series reactor. Diameter: 762 mm (30 in). Reglassed: Yes.
60" I.D. ELL series. Diameter: 1,524 mm (60 in). Vessel Size: 1,893 L (500 gallons). Reglassed: Yes.
reactor cover Diameter: 508 mm (20 in). Vessel Size: 113.6 L (30 gallons). Pressure: 2.1 bar (30 psi). Reglassed: Yes.
great cover 1-18" manway opening With a davit support boss Fits 500 gallon ELL Series reactor. Diameter: 1,524 mm (60 in). Vessel Size: 1,893 L (500 gallons). Pressure: 5.2 bar (75 psi). Reglassed: Yes. Temperature: 260 °C (500 °F).
great cover Diameter: 762 mm (30 in). Reglassed: Yes.
top head cover Diameter: 355.6 mm (14 in). Vessel Size: 37.9 L (10 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 343.3 °C (650 °F).
20" ID dish top head Diameter: 508 mm (20 in). Vessel Size: 113.6 L (30 gallons). Reglassed: Yes.
ELL Top Head Diameter: 1,626 mm (64 in). Vessel Size: 1,893 L (500 gallons). Pressure: 6.9 bar (100 psi). Temperature: 176.7 °C (350 °F).
reactor cover. w/(4) 5/8" bosses and bolt circle of 15" Fits 300 gal EL Series reactor. Diameter: 1,219 mm (48 in). Vessel Size: 1,136 L (300 gallons). Reglassed: Yes.
EL Series reactor cover Openings: 1-4" center nozzle, 3-4" nozzles, 1-8" nozzle, 12" x 16" manway opening. Fits 300 gal EL Series reactor. Diameter: 1,321 mm (52 in). Vessel Size: 1,136 L (300 gallons).
reactor cover Reglassed by UGE 2005. Diameter: 508 mm (20 in). Vessel Size: 113.6 L (30 gallons). Pressure: 10.3 bar (150 psi). Reglassed: Yes.
E Series reactor cover Openings: Man way is 9" x 12" no code stamp Diameter: 812.8 mm (32 in). Pressure: 1.72 bar (25 psi). Reglassed: Yes.
top head Reglassed by UGE 2006. Diameter: 508 mm (20 in). Vessel Size: 113.6 L (30 gallons). Reglassed: Yes.
reactor cover, Diameter: 812.8 mm (32 in). Vessel Size: 378.5 L (100 gallons). Pressure: 1.72 bar (25 psi). Reglassed: Yes. Temperature: 232.2 °C (450 °F).
REACTOR COVER w/4" sight glass. Fits 500 gal CTJ Series reactor. Diameter: 1,372 mm (54 in). Vessel Size: 1,893 L (500 gallons).
Diameter: 508 mm (20 in).
EM series Top Head with 12" x 16" manway opening Diameter: 1,016 mm (40 in). Vessel Size: 757.1 L (200 gallons).
XL Series Manufacturer #E680-8129 Diameter: 1,626 mm (64 in). Vessel Size: 3,785 L (1,000 gallons). Pressure: 6.9 bar (100 psi). Temperature: 232.2 °C (450 °F).
Diameter: 1,524 mm (60 in). Vessel Size: 1,893 L (500 gallons).
EM series two finger down baffle, 4DTW drive system, 15:1 overall ratio RCI agitator Diameter: 1,016 mm (40 in). Vessel Size: 757.1 L (200 gallons).
with 18"x 14" manway Diameter: 762 mm (30 in).
Top Head with 5" x 8" hand hole and cover (1) 2 1/2" drive nozzle with (4) bosses (3) 2" nozzles. Diameter: 127 mm (5 in). Vessel Size: 30.3 L (8 gallons).
reactor cover W/tripod for agit. Diameter: 1,575 mm (62 in). Reglassed: Yes.
reactor cover w/tripod agit drive, Pfaudler type SWV280 w/Kissling variable speed gear reducer, 4 PS, 1410 rpm. Diameter: 1,575 mm (62 in). Vessel Size: 2,500 L (660.4 gallons). Reglassed: Yes.
Diameter: 812.8 mm (32 in).
Diameter: 609.6 mm (24 in).
Diameter: 609.6 mm (24 in). Pressure: 1.72 bar (25 psi). Temperature: 343.3 °C (650 °F).
Top Head. Openings: 12" x 16" manway Diameter: 1,524 mm (60 in). Vessel Size: 1,893 L (500 gallons).
Top Head. Openings: 12" x 16" manway Diameter: 1,524 mm (60 in). Vessel Size: 1,893 L (500 gallons).
reglassed cover - low psi Diameter: 1,118 mm (44 in). Reglassed: Yes.
Reglassed Dished Top Head Pressure rating: 150/FV psi Temperature rating: 650 degrees Fahrenheit Diameter: 609.6 mm (24 in). Pressure: 10.3 bar (150 psi). Reglassed: Yes. Temperature: 343.3 °C (650 °F).
reactor Top Head (1) 12" x 16" manway opening Diameter: 1,524 mm (60 in). Pressure: 1.72 bar (25 psi). Temperature: 343.3 °C (650 °F).
reactor cover Diameter: 762 mm (30 in). Reglassed: Yes.
Good Used ES Series reactor cover. with Non-Standard Hinges Openings: 9" x 12" manway opening w/non standard hinges 9" Bolt Circle Fits: 50-75-100gal ES Series Diameter: 812.8 mm (32 in). Vessel Size: 378.5 L (100 gallons).
reactor cover Bolt holes - (3) 1/2" bolt holes Bolt circle - 9" Fits 100 gal P Series reactor. Diameter: 762 mm (30 in). Vessel Size: 378.5 L (100 gallons). Reglassed: Yes.
Ipp stocks over 2,000 glass lined and reglassed parts for various types of process equipment, many from well known manufacturers like Pfaudler and De Dietrich. You'll also find some surplus, unused spare parts as well. Many of the reglassed parts were reglassed in Romania by IPP's affiliate company, UGE.
Choose from 9 categories to find the part you need. Browse over 600 types of mixing paddles, agitators and impellers, over 400 types of baffles and over 500 covers and manways.
Don't See What You Need?
Give us a call or use the form on this page to send us a note describing what you need. Our buyers are constantly evaluating and making new purchases so what you need might be in our purchasing pipeline. If not, our seasoned sales team may be able to help you locate the part somewhere else through one of their contacts.
