with out a still pot. Needs a 750-1000 gallon reactor to complete (sold separate) Designed to bolt onto the top of a reactor with a 750-1000 gallon capacity. (depending on the chemical service) The system consists of the following parts First a 12" x 80" SS packed column, second a top mounted re-boiler, and third a reflux tank. The column section is 12" diameter x 80" overall length. 316 SS, NB # 205, rated for FV/125 psi at 500 degrees F. Manufactured by Roben. With a packing support 10" from the bottom of the column. Estimated packed capacity is 5 ft.3. The U-Tube condenser is top mounted to the column. It is 150 ft.2, The shell is 316 SS. NB # 4892. The shell is rated for FV/150 psi at 450 degrees F The tubes are rated for 100 psi at 450 degrees F. It is manufactured by Roben, serial # 81034. It is 18" diameter x 107" overall length. Two pass tube side. With 2" tube nozzles. The reflux/receiver tank has a 60 Gallon capacity and is manufactured from 316 SS material. It is orientated vertically. The dimensions of the vessel are 24" diameter x30" straight side, Diameter: 304.8 mm (12 in). Length: 2 m (6.7 ft). Still Type: Column Still. Pressure: 8.6 bar (125 psi). Temperature: 260 °C (500 °F). Column: Yes. Orientation: Vertical.
Diameter: 1,800 mm (70.9 in). Length: 3 m (9.7 ft). Still Type: Pot still. Pressure: 2 bar (29 psi). Temperature: 200 °C (392 °F). Support Type: Legs. Packing/tray: Packing. Column: Yes. Orientation: Vertical.
45 liter water still system distillate outlet temperature 70 degree C (158 degree F), steam is condensed into distillate by cold cooling water, slow steam speed with special baffle produces high distillate quality even from soft water, ventilation system to remove gasses from the steam, excess salts limited by adjustable bleed valve. System consists of (1) 45 liter 316L stainless steel boiler tank, 420mm diameter x 350mm straight side, with 9.5 KW, 220/380 volt Loval immersion type heating element, element mounted on bottom of tank. (1) 75 liter 316L stainless steel condenser tank with 12mm diameter cooling spiral, internal baffle. This tank mounts on top of boiler tank. Openings: distillate 1-20mm, 1-12mm cooling water feed, 1-12mm cooling water outlet. (1) 316L stainless steel rectangular regulating tank. 625mm long x 325mm wide x 200mm deep with magnetic float/level switch, Type 862D-F40, 240/440 volt, 70 watt. (1) 480 liter 316L stainless steel vertical pressure tank. Manufactured by Olsa, Serial #1237. Rated 1 bar @ 120 degree C. 800mm diameter x 1000mm straight side, welded dished top and bottom. (4) turns on coil, (3) 75mm diameter x 700mm long stainless steel tubes for heater elements mounted on bottom of straight side (no heating elements). Openings: top 1-180mm, 3-20mm (1 with probe and sensor, 1 with pressure gauge), 1-12mm; coil 2-20mm; bottom 1-50mm. Diameter: 420 mm (16.5 in). Length: 0.35 m (1.15 ft). Still Type: Column Still. Pressure: 1.01 bar (14.7 psi). Temperature: 100 °C (212 °F). Column: Yes. Orientation: Vertical.
2,200 L/Day sanitary polished WFI still with five columns Vessel rated for -1 to 9 bar at 184 degrees C jacket rated for -1 to 10 bar at 184 degrees C Vessel volume 184 liters, jacket volume 26 liters Skid breaks down into two pieces 1.4 m l x 1.1 m d x 2.6 m h, and 750 mm l x 1.1 m d x 2.6 m high. Diameter: 1,100 mm (43.3 in). Length: 2.2 m (7.1 ft). Still Type: Column Still. Pressure: 9 bar (130.5 psi). Temperature: 184 °C (363.2 °F). Flow Rate: 92 L/h (0.41 GPM). Controls: Yes. Support Type: Skid. Column: Yes. Orientation: Horizontal.
2802 lbs./hr steam pressure of 87 psi DI Water still Finn Aqua with (4) 316SS DI columns enclosed in a 304SS housing with associated pumps, valves,collection pots Housingis 36" wide x 11' long x 11' high Pressure: 8 bar (116 psi). Temperature: 175 °C (347 °F). Controls: Yes. Support Type: Skid. Column: Yes.
176 lbs./hr.of pure steam generated at 58 psi Clean Steam Generator Finn Aqua with (1) 316SS DI columns enclosed in a 304SS housing with associated pumps, valves, condensors, collection pots Housingis 36" wide x 51" long x 11' high Diameter: 250 mm (9.8 in). Length: 3.1 m (10 ft). Still Type: Column Still. Pressure: 8 bar (116 psi). Temperature: 175 °C (347 °F). Controls: Yes. Support Type: Skid. Orientation: Vertical.
1339 lbs/hr based on 58 psi steam capacity DI Water still with (5) 316SS DI columns Finn Aqua enclosed in a 304SS housing with associated pumps, valves, condensors, collection pots Housingis 36" wide x 7' long x 11' high Pressure: 8 bar (116 psi). Temperature: 175 °C (347 °F). Flow Rate: 1,136 L/h (5 GPM). Controls: Yes. Support Type: Skid. Column: Yes. Orientation: Vertical.
4700 lbs/hr
Pure Steam Generator
Falling film design to remove pyrogenic material
Steam heated.
Electricals rated 3.0 kW, 480 volt, 60 cyc, 5.2 amp with 0.5 kW 120 volt 4.2 amp, 60 cyc controls.
All product surfaces are sanitary 316SS construction. Skid
with process controls in a SS control cabinet
Sesigned to consistenly generat Pure Steam for usin in Pharma and biotec industries. Controls: Yes. Support Type: Skid. Orientation: Vertical.
1,200 lbs./hr PyroPure Clean steam generator Produces pyrogen free pure steam that meets USP requirements With external shell and tube evaporator, double tube sheet 316LSS contact surfaces, polished to 20 ra max. blowdown cooler which serves as a pre-heater for water entering the evaporator steam seperator and feedwater pump Evaporater NB # 32477 serial #4767410-1 Shell rated for 150/FV psi at 366 degrees F tubes rated for 150/FV psi at 366 degrees F Cooler NB #32664 Serial # 4864670-1 shell rated for FV/150 psi at 336 degrees F tubes rated for FV/150 psi at 336 degrees F Feed water pump, 316SS manufactured by Fristam Pump direct driven by a 3 hp 3500 rpm AC motor All parts mounted on a skid with the following controls AB PLC control with Panel View Plus operator interface I/O cabinet and Motor staring cabinet complete with breaker Feedwater inlet is 1" TC sanitary Steam inlet is 1.5" flange(150 psi max) Pure steam outlet is 2" TC sanitary Condensate outlet is 1" FNPT drain is 1" TC, and instrument air is 1/4" FNPT Dimensions are 48" wide x 46.5" deep x 107" high. Shipping weight is 2,150 lbs. Diameter: 1,219 mm (48 in). Length: 2.7 m (8.9 ft). Pressure: 10.3 bar (150 psi). Temperature: 168.9 °C (336 °F). Controls: Yes. Support Type: Skid. Orientation: Vertical.
100 gal 304SS still system. Consisting of (1) 100 gal horiz tank w/12" dia tube bundle thru (1) head. (1) 12" dia x 27' long SS column (1) 10" dia x 10' long condense Diameter: 304.8 mm (12 in). Length: 8.2 m (27 ft). Pressure: 1.72 bar (25 psi). Temperature: 204.4 °C (400 °F). Support Type: Saddle. Column: Yes. Orientation: Horizontal.
water Sterilizer unit
Unit has (2) sterilizer heat exchanger tubes mounted in a frame
Tube A: National board number 2810, serial number 37173/1,
rated 116 psi @ 347 degrees F both sides;
Tube B: National board number 2811, serial number 37173/2,
rated 116 psi @ 347 degrees F both sides
multi-effect WFI stills system the Finn Aqua Multiple Effect Water Stills uses an enhanced falling film evaporation technology that removes impurities at high velocities, delivering the highest quality water for injection. the Multiple Effect Water Still uses a staged evaporation and condensation process to produce water for injection. Plant steam is applied only to the first column evaporator (effect) with the subsequent columns using the steam produced in the previous column as the source of energy. Similarly, cooling water is applied only at the condenser to condense pure steam into water for injection. The columns subsequent to the first column use feed water as the cooling source, which is evaporated, as the pure steam from the preceding column is condensed producing water for injection. Produced distillate and remaining pure steam is condensed in the condenser and flowing further to the plant’s water for injection tank. system consists of (5) ) 316L stainless steel (1.4404/1.4571) vertical heat exchangers, pressure 8 bar @ 175 deg C (9.7ltr), (1) 200ltr 316L stainless steel (1.4404/1.4571) tube, head and shell horizontal condenser, pressure 2 bar @ 133 deg C, driven by a 3 kW 2900 rpm motor, (5) stainless steel Pall Filters, (1) 2500 liter 316L stainless steel (1.4571 ) vertical pressure tank with half pipe coil, pressure -1/6 bar @ 200 deg C, 1.8m diameter x 1.5m straight side, Diameter: 300 mm (11.8 in). Length: 2.7 m (8.7 ft). Pressure: 8 bar (116 psi). Temperature: 175 °C (347 °F). Column: Yes. Multi Effect: Yes.
Estimated 10 CFM wet venturi scrubbing system suitable for acidic products. Skid mount system featuring on board Explosion Proof controls, and a Magnetic drive recirculation pump. Skid contains the following equipment: One-20 Gallon, glass lined, vertical, clamp top tank fitted with a venturi nozzle. Manufactured by Ceramic Coatings, serial # 6-39887, NB # 1425, rated for 150 psi at 450 degrees F. One- Iwaki mag drive pump model # MX-401, size 1.5" x 1.5", rated for 25 GPM at 50 ft./hd.,with a 3.66" diameter impeller, and direct driven by a Baldor 1 hp motor rated for 3450 rpm. Pump and vessel include all piping and valves to complete system. On board controls and instrumentation include level indication, flow and suction pressure. Controls rated for Class I, Group C & D, Class II, Groups E,F & G. Pressure: 10.3 bar (150 psi). Temperature: 232.2 °C (450 °F). Controls: Yes. Support Type: Skid. Orientation: Vertical.
WFI water distillation system 3.4 kW, 480 volt, 60 cyc, 6.2 amp with 0.5 kW 120 volt 4.2 amp, 60 cyc controls. All product surfaces are sanitary 316SS construction. Flow Rate: 2,271 L/h (10 GPM). Controls: Yes. Support Type: Skid. Orientation: Vertical. Multi Effect: Yes.
vertical pressure vessel\still with column internal pressure -1/15 bar @ 300 degrees C (13750 liter) 700mm diameter x 2850mm total height 321 stainless steel (1.4541) packed column, manufactured by Germania, fabrik #34715, internal pressure 15 barg @ 300 degrees C (1000 liter), structured packing, 1545mm packing height, bonnet top head, Diameter: 2,200 mm (86.6 in). Length: 3 m (9.9 ft). Still Type: Column Still. Pressure: 15 bar (217.6 psi). Temperature: 300 °C (572 °F). Support Type: Legs. Column: Yes. Orientation: Vertical.
clean steam generator circuit 1: design condition 12 bar @ 191.7 degrees C fluid group 2 circuit 2: 7 bar @ 170.5 degrees C fluid group 2 supply 8 abr 50 Hz, 400 volt, 1 kw, 3 phase provides sterilised grade clean steam suitably treated water using steam as the medium incorporating an integral feedwater pre-heating and degassing system preheater tank is 316L stainless steel boiler and heating coil 316L stainless steel all contained in a soudproof cabinet Pressure: 12 bar (174 psi). Temperature: 191 °C (375.8 °F).
BUTYLACETATE SYSTEM 4200/4300 SYSTEMS-CONSISTS OF MISC COLUMNS, HEAT EXCHANGERS, PUMPS, DRUMS ETC Column: Yes.
8200/7200 SYSTEM CONSISTING OF GLASS COLUMNS, HEAT EXHANGERS, SEPARATORS, PUMPS ETC Column: Yes.
5400 SYSTEM CONSISTING OF COLUMNS, HEAT EXCHANGERS, PUMPS, DRUMS ETC Column: Yes.
