Motor is inverter duty.

top load, bottom discharge, 12mm thick basket, 3.15 square meter filter area, 1100 rpm permissible speed single motion plow driven by a hydraulic powerpack, powerpack driven by approx 0.75kw EX motor, mounted on a steel baseplate,

spare top and bottom section bottom discharge basket centrifuge bottom discharge design

halar lined basket

clarifier basket centrifuge bottom discharge (2) horizontal baffles basket capacity 7.6 cu ft. 316SS basket, curb and plow Top driven by hydraulic powerpak Hinged access port 1" rotary pneumatic skimmer

basket only 1/4 " drainage holes Eight 7/8" bolt hole pattern

with single action pneumatic operated plow cylinder.(no Plow) Cover has an inspection door with a 9" sight glass Cover has the following openings for piping connections One, 6" weld neck flange, One 2" opening for feed pipe, Three, 1" opening for accessories.

Hydraulic Drive HE-53-HYDR-131

Mirror Polished finish designed for GMP & Sanitary use. 316 SS perforated Basket 22KW Crompton Breaves drive w/ dynamic braking Hydraulic power pack Flame proof control panel Overall dimensions 2000mm L x 1500 mm W.

316 S lid, 316 SS basket and 316 SS cone, automatic bottom discharge, The model DSZ utilizes a pull action filter for gentle handling of material. It allows the centrifuge to function with out a scraper knife, making it ideal for sensitive products. The pneumatic pull mechanism allows for no heel to be left over after discharge. This design works excellent in the fine chemicals, pharmaceutical, and the food industries. Manufactured to GMP standards with FDA approved parts. 39 a The basket aperture is 34.5", The cover is hinged, with hydraulic power pack for lid lifting (opening). The maximum height (for lid to open) is 121.5", the maximum width is 94.5 X maximum depth of 86.6". nitrogen purged The housing is Gas tight with spray nozzles This machine does not have a electrically driven feed disk.

Hydraulic Drive HE-53-HYDR-133

Ferrum basket centrifuge with Titus cyclone cake discharge system Complete centrifuge and discharge system is gas-tight design. deep perforated basket pressure rated 1.96 Sqm, 0 to 950 upm 480 kg, 316L s/steel housing and cover pressure rated 1.6 bar @ 120 degrees C Top cover has 100mm sightglass with light 225mm sightglass 75mm wash pipe 75mm feed pipe 45mm, 80mm, and a 1/2 hinged cover 150mm filtrate outlet Unit has top entering feed and wash pipes and has a hydraulic knife for cake removal from basket walls Cake is pneumatically removed from the centrifuge though a Krauss Maffei, Titan cyclone dryer, which pulls the cake out through the top of the centrifuge Complete system includes a 630 liter SS horizontal mother liquor tank manufactured by Edak, Serial number 965/1, rated 1.6 bar, Krauss Maffei solvent condensor manufactured by J Engelsman, Serial Number 15641/2, miscellanous centrifugal pumps,
K-M Titus cylone discharge system with 2,880 CuM/Hr, SS suction fan driven by a 30 KW, 3 phase 50 cycle EExeII motor, 385 liter 1.4571 SS cake cyclone, 692 mm diameter x 450 mm ss with 1100 mm cone, discharging the cake into a 500 liter 1.4435 SS jacketed product receiver, manufactured by Hanag, rated -1/2 bar @ -30 to 200 degrees C internal; 6 bar @ -30 to 200 degrees C in the 1/2 pipe coil jacket, with bolted dished top, cone bottom, 1/2 pipe coil jacket on cone bottom, 1000mm diameter x 342 mm straight side with 682 mm deep cone bottom.
Entire system is sealed and designed for use in Solvent processes.
Previous use allowed solvent ladened product cake to be dried using ambient temperature in the cyclone air flow before being collected in the product bin

perforated basket centrifuge 316SS TI (1.4571) Half top hydraulically operated liftable cover Basket thickness 10mm Hydraulic operated knife. W/hydraulic powerpak, mfd by Hydramatic. Hydraulic driver Type A2P W/250mm sight glass

vertical decanter centrifuge with motorized liquid skimmer Rated 150/180 l/mn flow rate manufactured by Rousselet Robatel Rated 150/180 l/mn flow rate 5-60 degrees C 100 liter solids capacity Solid bowl is 1000mm diameter x 500 mm deep bowl 1.4539 Stainless top cover mounted on a hinge with an electric motor for opening the cover liquid skimmers and solid discharge skimmer Liquid skimmer is driven by a 0,15/0,22kW, 3 ph/50 cyc/ 400 volt electrical motor, manufactured by CEO, type 63-2/4, serial number 00017320102, 2 speed 1400/2760 rpm Includes (1) control panel; with (1) control cabinet with hydraulic power pack with aa 0,55-0,66kW electrical motor, manufactured by Leroy Somer, type LS80LT, serial number 660550RM001, 3ph/50-60Hz/230-460V/ 1.385-1.700rpm; Centrifuge and powerpack is mounted on stainless steel frame. System is CE rated

perforated basket centrifuge EX motor with air cooling fan mounted on top driven by 0.12 KW 3/50/380 volt motor.

Heine 316SS (V4AE) Basket thickness 6mm Pneumatic operated liftable half top cover. W/1-200mm sight glass, 1-100mm sight glass, 2-25mm, 1-50mm, 1-75mm; 1-100mm discharge W/hydraulic motor and W/hydraulic powerpak

top load, bottom discharge wall thickness of the basket 12mm lid with assist mechanism basket with electric motor

top load/unload pressure 1.8 bar @ 150 deg C via a hydraulic Rexroth type 380/660 volt 1480/1475 rpm motor Thermosyphon which is hydraulic driven by the same powerpack, 2-internal spray nozzles, 1-150mm filtrate outlet half of the top cover is hinged and has a open/close assist mechanism, hydraulic panel,

Housing coated with Eldon, lid coated with Edlon, and basket coated with Edlon cone is C-22,
Ref. No. 10889. The model DSZ utilizes a pull action filter for gentle handling of material. It allows the centrifuge to function with out a scraper knife, making it ideal for sensitive products The pneumatic pull mechanism allows for no heel to be left over after discharge. This design works excellent in the fine chemicals, pharmaceutical, and the food industries. Manufactured to GMP standards with FDA approved parts. Reliance Duty Master serial #02MAZ24644 G002 ZZ, 5 HP, 1750 rpm, 460v., 3 ph., 60 Hz. Frame L184 TD, TEFC Enclosure 140 Lbs.. Rated for 950 rpm, maximum charge is 500 kg. The basket aperture is 34.5", The maximum height (for lid to open) is 121.5", the maximum width is 94.5 X maximum depth of 86.6". The housing is Gas tight nitrogen purged.

brushed finish internal, and sanitary lid is 316 SS basket is 316 SS and cone is 316 SS. pull action filter for gentle handling of material. It allows the centrifuge to function with out a scraper knife, making it ideal for sensitive products. The pneumatic pull mechanism allows for no heel to be left over after discharge. This design works excellent in the fine chemicals, pharmaceutical, and the food industries. Manufactured to GMP standards with FDA approved parts. The basket aperture is 34.5", The Feed disk drive is driven by a Reliance Duty Master serial # 01MAP61661G001CE,3 HP, 1770 RPM, 230/460v,60 Hz Inverter ready, The cover is hinged, with hydraulic power pack for lid lifting (opening). The maximum height (for lid to open) is 121.5", the maximum width is 94.5" X maximum depth of 86.6" nitrogen purged. No CIP spray balls.

perforated basket centrifuge. Hastelloy basket, halar lined curb, 2.4610 basket, cover 1.4571 material Gas tight Cover 1/2 leftable hydraulically. Control panel. Perforation 8mm dia W/0.75 KW, Motor: 3 phase Hydraulic pump: 0.75 KW, 3/50/380 volt, 1450 rpm

1.4581 perforated basket centrifuge. Half top hydraulically operated liftable cover. Basket thickness 10mm Hydraulic operated knife. mfd by Hydramatic, hydraulic driver Type A2P. W/250mm sight glass

manual discharge top wall thickness of the basket 6mm

perforated basket centrifuge Half top cover liftable Basket thickness 8mm Temp sensor 500mm dia feed pipe No drive

316 SS curb, 316 SS lid Job 362370 Auto Bottom discharge Oil Gear hydraulic drive Top hinged access/inspection door spray wash bar & pneumatic plow Has SS discharge chute With control panel for main power.
