twin shell blender system maximum density of 50 lbs./cu.ft Shell diameter is 54" (est.), manway diameter is 17 3/4" with air operated butterfly valve Brake supplied with motor Electrical requirements are 230/460, 3 ph, 60 hz

V blender openings: (2) diameter 455mm and (1) diameter 165mm driven by electrical motor Motor type HD7A Motor: 380/420 volt

Octagonal blender/mixer, with a Mirror Polish internal finish. Designed with GMP and sanitary construction, 625" shell diameter 615" shell length 2.5" shell thickness 250" Cone length, 2.5" cone thickness 6" bottom butterfly valve.

with #4 finish for product contact, sanitary double cone blender, Rated for max. density 70 lbs./cu. ft., Rotation from drive side is clockwise, speed is 11.3 rpm. Agitator speed is 3300 rpm. With sanitary Gemcomatic assembly for discharge to drums. Auto loading, Chopper with out blade. 18" port. With NEMA 12 Control Panel, including circuit breaker and local controls. Agitator motor with 20 HP, 1800 rpm, 3 ph/60 Hz/ 230/460v. TEFC with a 256T frame. Drive motor is 7.5 HP,1800 RPM, 3 ph/60 Hz/ 230/460v. TEFC with a 213T frame main braking motor is 3 HP, 1800 rpm,3 ph/60 Hz/ 230/460v. TEFC with a 213T frame. Both drive and brake are tied in through a Symcyclo gear reduction drive at 17:1 ratio. Sanitary covers over drives and legs.

Maximum density of charge-65lbs.cu./ft Driven through a Patterson Helix reducer

Type: Double cone mixer Cone dimensions: 2130mm diameter x 600mm straight side, with (2) 1020mm long cone sections Openings: cones 2-300mm, 1-36mm, 1-36mm, 1-12mm; straight side 1-36mm.

double cone blender 72" dia, 1-8" top, 1-8" btm, 1-12" on str side. Shell driven by 10 HP, 3/60/440 volt 1800 rpm motor thru Falk reducer, 100 rpm output Mtd on A-frame stands.

liquid/solid twin shell blender. Maximum density 55 lbs/cubic feet. Shell 48" outer diameter Blender rotation 11 rpm, liquid/solids intensifier bar rotation 1174 rpm. Mixer gear driven by 7.5 HP, 3/60/460 volt TEFC motor, 1750 rpm output speed with belt and drive with protective guard. Intensifier bar driven by 20 HP, 3/60/230/460 volt, 100 rpm output speed TEFC gear motor. 3/4" type RSP rotary union. Mixer equipped with 3 7/16" Dodge type pillow block bearings. Mixer has (2) 18" diameter access ports with quick openings. 1-20" outer diameter discharge port with air operated valve.

twin shell blender 36" shell diameter with 18" manway diameter with air operated butterfly valve Electrical requirements are 230/460, 3 ph, 60 hz

Porta Hopper double cone Blender with intensifier bar with (2) Hopper bottoms. Intesifier bar is set up for dry mixing, has liquid capabilities 56" diameter shell gear head motor for blender drive. Blend speed 13. 4 RPM-Maximum desity of charge 125 lbs./cu.ft.

twin shell blender 90 lbs. cu.ft. maximum density shell diameter is 24", manway diameter is 17 & 3/4" with a air operated butterfly valve Electrical requirement is 208/230/460 volts, 3 ph, 60 hz. With brake

shell "V" blender with Intensifier Bar rated 75 Lbs/CuFt Designed for dry blending (2) 18" charge ports with covers, 8" discharge port with manual butterfly valve.

1m diameter x 2200mm long stainless steel rotating granulation drum mixer Della (HFH Russig) Drum is hydraulically lifted for designed angles of -2/+10 degrees. Pellets are transported upwards thus presenting the following advantages: uniformally sized granulates, increased throughput, lower energy. Spray nozzles for material granulation With removable 316 stainless steel vibratory feeder system operating on rails.

blender (2) 12" feed ports. 6" discharge with butterfly valve. General Electric gear reducer rated 13.99-1 ratio.

double cone blender with intensifier bar rated 55 lbs/CuFt Has liquid addition capabilities Internal Finish #4 polish (20-25 Micro Inch) Pneumatic valve on blender f eed opening 2 HP gear head motor for blender drive Other general notes: Vessel speed(rpm), 14.6, Positioning speed (rpm) 1.46, Agitator speed (FPM) 4900 approx., Total Volume (CF) 53.3.

Job # I 46278" diameter with a 19" band, 45" to the cone. Top 15" man ways with mechanical seals. Bottom 15" butterfly valve.(6) 1" nozzles Separate lubrication system available for bearings. Motor in place for intensifier bar, but the bar has been removed.

double cone mixer CS Jacket rated 30 psi @ 275 deg F. 72" dia. Has rotary joint Packing gland UL label Has 16" quick open manway and 10" dia swing gate valve.

twin shell "V" blender with Intensifier Bar. rated 75 Lbs/CuFt. Designed for dry blending. With 1/4 HP gear head motor for blender drive, 1.5 HP motor for intesifier bar. (2) 10" charge ports with covers, oval discharge port with cover.

motor with chain and sproket drive. Unit enclosed in a plastic housing

blender Maximum density 55 lbs/cubic feet. Shell 48" outer diameter Blender rotation 11 rpm, liquid/solids intensifier bar rotation 1174 rpm 1750 rpm output spped, with belt and drive with protective guard. Intensifier bar driven by 20 HP, 3/60/230/460 volt, 100 rpm output speed TEFC gear motor. 3/4" type RSP rotary union Mixer equipped with 3 7/16" Dodge type pillow block bearings Mixer has (2) 18" diameter access ports with quick openings. 1-20" outer diameter discharge port with air operated valve.

polished double cone jacket mixer. Internal rated full vacuum @ 200 degree F; jacket rated 15 psi @ 200 degree F. 59 lbs/cubic feet density. Full CS jkt 16" charge port, 8" discharge w/butterfly valve.
