115 to 125 max. psi Rotary Screw Air Compressor Oil Free, packaged design, with microprocessor controls, cooler and lubricator Compressor Type: Rotary. Discharge Pressure: 8.6 bar (125 psi). Flow Rate: 186.9 m3/h (110 CFM). Oil Free: Yes.
180 acfm nitrogen compressor Rotary screw design, with inlet strainer with soundproof enclosure N2 outlet connection 2" NPT, Inlet strainer connection 2" NPT, drain, 3/4" NPT. Compressor Type: Rotary. Inlet Pressure: 1.1 bar (16 psi). Discharge Pressure: 8.6 bar (125 psi). Flow Rate: 305.8 m3/h (180 CFM). Inlet Diameter: 50.8 mm (2 in).
rotary screw air compressor 90 degree inlet temperature Analog control panel. 5' long x 41" deep x 4' high. Analog control panel. 480 VAC. Compressor Type: Rotary. Discharge Pressure: 6.9 bar (100 psi). Flow Rate: 314.3 m3/h (185 CFM).
rotary screw air compressor IR Intellisys controls 44' wide x 50" deep x 56" high. Compressor Type: Rotary. Discharge Pressure: 6.9 bar (100 psi). Flow Rate: 266.7 m3/h (157 CFM).
lubricated rotary screw Electronic controls. Air cooled. With disconnect and IR Variable speed drive, Compressor Type: Rotary. Discharge Pressure: 6.2 bar (90 psi). Flow Rate: 212.4 m3/h (125 CFM). Speed (RPM): 4,545.
lubricated rotary screw Electronic controls. Air cooled With disconnect and IR Variable speed drive Compressor Type: Rotary. Discharge Pressure: 6.2 bar (90 psi). Flow Rate: 212.4 m3/h (125 CFM). Speed (RPM): 4,545.
rotary screw single stage air compressor With a 120 gallon receiver. with air cooling The compressor is belt driven The skid has analog controls. Compressor Type: Rotary. Discharge Pressure: 8.6 bar (125 psi). Flow Rate: 192 m3/h (113 CFM).
oil free air Compressor packaged design Compressor Type: Rotary. Discharge Pressure: 8.3 bar (120 psi). Flow Rate: 611.6 m3/h (360 CFM). Speed (RPM): 3,000. Oil Free: Yes.
Digital control system mounted on cabinet. Compressor Type: Rotary. Discharge Pressure: 8.8 bar (128 psi). Flow Rate: 329.6 m3/h (194 CFM).
125 psi Takes 310 lbs. of R-22. Fan driven by a 0.1 HP motor. UL listed. Compressor Type: Rotary. Inlet Pressure: 17.2 bar (250 psi). Flow Rate: 424.8 m3/h (250 CFM).
Two stage, oil flooded, rotary, air compressor Single stage screw compressor, with all accessories piped, wired and base plate mounted in a packaged design with sound proof housing. Equipped with IR "Intellisys" digital controls, for operation of the entire system and allowing for modification of 12 variables in the controller logic. 3 inch NPT air discharge line, 2" NPT cooling water inlet and outlet ports, 0.5" NPT condensate drain line. Total package amps 310 Compressor Type: Rotary. Discharge Pressure: 9.9 bar (143 psi). Flow Rate: 1,966 m3/h (1,157 CFM). Inlet Diameter: 50.8 mm (2 in).
air compressor Single stage screw compressor, with all accessories piped, wired and base plate mounted in a packaged design with sound proof housing. Equipped with IR "Intellisys" digital controls, for operation of the entire system and allowing for modification of 12 variables in the controller logic. 3 inch NPT air discharge line, 2" NPT cooling water inlet and outlet ports, 0.5" NPT condensate drain line. Total package amps 310 Compressor Type: Rotary. Discharge Pressure: 9.9 bar (143 psi). Flow Rate: 1,966 m3/h (1,157 CFM). Inlet Diameter: 50.8 mm (2 in).
rotary screw compressor Has 60 gal tank 3/60/230/460 volt Complete w/gauges and controls Compressor Type: Rotary. Flow Rate: 339.8 m3/h (200 CFM).
air cooled oil free rotary screw compressor This is a twin shaft screw compressor, positive displacement type 55 psia @ 60 degrees F outlet pressure The compressor is a type WQ 40-12/55, 1.2 kg/cu M, 20 degrees C, 75 cuM/minute 321 amps General Electric Energy Saver AC motor The intake flange is 8" and discharge flange is 6" and both are mounted at the top of the machine, and the instrumentation for monitoring the unit are mounted on the side as a panel. This unit is mounted in complete sound proof enclosure. Compressor Type: Rotary. Inlet Pressure: 1.01 bar (14.7 psi). Discharge Pressure: 3.8 bar (55 psi). Flow Rate: 2,744 m3/h (1,615 CFM). Inlet Diameter: 203.2 mm (8 in). Speed (RPM): 3,550. Oil Free: Yes.
air cooled rotary screw compressor oil free This is a twin shaft screw compressor This is a twin shaft 55 psia @ 60 degrees F outlet pressure The compressor is a type WQ 40-12/55, 1.2 kg/cu M, 20 degrees C, 75 cuM/minute General Electric Extra Severe Duty AC motor The intake flange is 8" and discharge flange is 6" and both are mounted at the top of the machine, and the instrumentation for monitoring the unit are mounted on the side as a panel. This unit is mounted in complete sound proof enclosure. Compressor Type: Rotary. Inlet Pressure: 1.01 bar (14.7 psi). Discharge Pressure: 3.8 bar (55 psi). Flow Rate: 1,359 m3/h (800 CFM). Inlet Diameter: 203.2 mm (8 in). Speed (RPM): 3,550. Oil Free: Yes.
Pulsair screw compressor system HPC Pulsair single rotary screw compressor air outlet temperature 9 degrees C, useable heat 77,378 Bthu/hr, expelled air temperature 23 degrees C, (1) 875 liter carbon steel air receiver, manufactured by Cool Technology ltd, design pressure 11 barg @ 100 degrees C, weld dished heads, (1) Ultrapac air dryer, type ALDO-0191, serial # 9288, 50/60 hz, 230 volt, working pressure 4 bar @ 4 degrees C (min), 16 bar @ 35 degrees C (max), ambient temperature 4 degrees C (min), 40 degrees C (max), pre-filter element MF-07/30, after filter element PE-07/30 Compressor Type: Rotary. Flow Rate: 209 m3/h (123 CFM).
(1) 915 liter carbon steel air receiver, manufactured by Cool Technology ltd, design pressure 11 barg @ 100 degrees C, weld dished heads, (1) Ultrapac air dryer, type ALDO-0191, serial # 4479, 50/60 hz, 220 volt, working pressure 4 bar @ 4 degrees C (min), 16 bar @ 35 degrees C (max), ambient temperature 4 degrees C (min), 40 degrees C (max), pre-filter element MF-07/30, after filter element PE-07/30 Compressor Type: Rotary. Flow Rate: 208.2 m3/h (122.5 CFM).
(1) 915 ltr c/steel air receiver, manufactured by Cool Technology ltd, design pressure 11 barg @ 100 deg C, weld dished heads, (1) Ultrapac air dryer, type ALDO-0191, serial # 9288, 50/60 hz, 220 volt, working pressure 4 bar @ 4 deg C (min), 16 bar @ 35 deg C (max), ambient temperature 4 deg C (min), 40 deg C (max), pre-filter element MF-07/30, after filter element PE-07/30 Compressor Type: Rotary. Flow Rate: 208.2 m3/h (122.5 CFM).
17.25 kw, 3/60/440/760 volt, 3500 rpm water cooled enclosed in soundproof cabinet, with air dryer and air reciever Compressor Type: Rotary. Flow Rate: 142.7 m3/h (84 CFM).
rotary screw compressor 3/50/380/415 volt Built in control panel contained in soundproof cabinet Compressor Type: Rotary. Flow Rate: 552.2 m3/h (325 CFM).
vert air compressor. 87500 cfh W/General Electric 350 HP motor, SN 7532. Running hrs 14009, loaded 5721 hrs Compressor Type: Rotary. Inlet Pressure: 44.3 bar (643 psi). Discharge Pressure: 209.5 bar (3,039 psi). Flow Rate: 2,481 m3/h (1,460 CFM).
rotary screw compressor. Unit is water cooled. 3/60/230/460 volt Compressor Type: Rotary. Flow Rate: 594.7 m3/h (350 CFM).
low pressure,Oil free air compressor, total running hrs 8133. power 20 KW 30/33,5 kW,3/50/60Hz/380V/2900/2950/3000/3540rpm Compressor Type: Rotary. Discharge Pressure: 2.5 bar (36.3 psi). Flow Rate: 511.2 m3/h (300.9 CFM). Speed (RPM): 3,540. Oil Free: Yes.
Ammonia Compressor C/T 20571. Inlet Casing Design Pressure 2500 PSIG, Outlet Casing Design Pressure 2500 PSIG; Outlet casing Design Temperature 450 Degrees F 1sr Critical speed 5300 RPM, Maximum Operating Temperature 380 Degrees F; Test Inlet Pressure 3750 PSIG; Test Discharge Pressure 3750 PSIG. NOTE: Used in train with turbines #206300 & 206301, and Compressor # 206303 Compressor Type: Centrifugal. Inlet Pressure: 172.4 bar (2,500 psi). Discharge Pressure: 172.4 bar (2,500 psi). Flow Rate: 1,927 m3/h (1,134 CFM). Speed (RPM): 10,850.
Rotary screw compressor system oil flodded, variable speed drive, contained in soundproof cabinet, conpressor with: (1) ingersoll rand "thermal mass" TMS250 cycling refrigerated air dryer, SN: TMS250-0503/3863, max allowable pressure 16 bar, refigerant 5.8kg of R134A, electric's 3/50/380-420 volt, min ambient temperature 0-43 degrees c, max inlet temperature 55 degrees c, (2) ingersoll rand IRGP/IRHE 706 high efficiency pre-filters, (1) domnick hunter CP375 activated carbon tower filter (oil vapor removal > 0.003ppm) Compressor Type: Rotary. Flow Rate: 1,200 m3/h (706 CFM).
rotary screw compressor system oil flooded, fixed speed design contained in soundproof cabinet, compressor with (1) ingersoll rand "thermal mass" TMS250 cycling refrigerated air dryer, SR # TMS250-503/3862, max allowable pressure 16 bar, refrigerant 5.8kg of R134A electric's 3/50/380-420 volt, min ambient temp 0/143 degrees c, max inlet temp 55 degrees c, (2) ingersoll rand IGRP/IRHE 706 high efficiency pre-filters, (1) domnick hunter CP375 activated carbon tower filter (oil vapor removal > 0.003ppm), Compressor Type: Rotary. Flow Rate: 1,200 m3/h (706 CFM).
Rotary Screw Compressor Type: 6015E07AS 380-415 volt compressor with 340 ltr, Compressor Type: Rotary. Discharge Pressure: 7 bar (101.5 psi).
air-end rotary screw compressor type Cyclon 6000 max pressure 7.5 bar 3/50/380-415 volt single stage design, unit consists of: drive motor, air-end, reclaimer oil cooler, after cooler, fan, starter assembly and controller Compressor Type: Rotary. Discharge Pressure: 7 bar (101.5 psi). Flow Rate: 299 m3/h (176 CFM).
air-end rotary screw compressor type Cyclon 6000 3/50/380-415 volt unit consists of: drive motor, air-end, reclaimer oil cooler, after cooler, fan, starter assembly and controller Compressor Type: Rotary. Discharge Pressure: 7.5 bar (108.8 psi). Flow Rate: 299 m3/h (176 CFM).
air-end rotary screw compressor Cyclon 6000 3/50/380-415 volt single stage design, unit consists of: drive motor, air-end, reclaimer, oil cooler, after cooler, fan, starter assembly, and controller Compressor Type: Rotary. Discharge Pressure: 7.5 bar (108.8 psi). Flow Rate: 7.7 m3/h (4.5 CFM).
Type: Cyclon 6000 single stage design unit consists of: drive motor, air-end, reclaimer, oil cooler, after cooler, fan, starter assembly, and controller Compressor Type: Rotary. Discharge Pressure: 7.5 bar (108.8 psi). Flow Rate: 7.7 m3/h (4.5 CFM).
S20 Rotary Screw compressor max service pressure 8 bar Driven by 2-speed motor, 15 kw, 3/50/400/690 volt, 2910 rpm water cooled, enclosed in soundproof cabinet with air dryer and c/steel air reciever Compressor Type: Rotary. Flow Rate: 142.7 m3/h (84 CFM). Speed (RPM): 3,000.
oil free air Compressor packaged design. Compressor Type: Rotary. Flow Rate: 611.6 m3/h (360 CFM).
with integrated air dryer, mounted in an acoustic cabinet, Compressor Type: Rotary. Discharge Pressure: 12.5 bar (181.3 psi). Flow Rate: 1,836 m3/h (1,081 CFM). Speed (RPM): 2,255.
IP55 motor, water cooled, with integrated air dryer, mounted in an acoustic cabinet, Compressor Type: Rotary. Discharge Pressure: 10.4 bar (150.8 psi). Flow Rate: 2,130 m3/h (1,254 CFM). Speed (RPM): 3,000. Oil Free: Yes.
driven by 250kW, 3/50/690/400 volt, 1489 rpm IP55 motor, air cooled, integrated refrigerant air dryer, type ID 770W, serial #APF143965, 10.7kW, 3/50/380/415 volt, air pressure (max) 14.5 bar (e) @ 55 degrees C, refrigerant pressure 29/26 bar, all inside and acoustic cabinet, built on controls, Compressor Type: Rotary. Discharge Pressure: 9.8 bar (141.4 psi). Flow Rate: 2,500 m3/h (1,471 CFM). Speed (RPM): 1,488.
Compressors are designed to compress (over 20 psi) and move air and other gases such as hydrogen, oxygen, nitrogen, etc. IPP's Compressors for sale are listed by the Cubic Feet per Minute or CFM rating and pressure.
Centrifugal compressors use centrifugal forces to pump air or gas to develop pressure. They typically operate at speeds of 3500 rpm or higher. Multiple stages are used to produce the required pressure rise. This type of compressor is driven by an electric motor, steam turbine, or gas turbine, with or without speed increasing gears.
Rotary compressors, blowers, and vacuum pumps are positive displacement type machines. This type of machine incorporates rotating internal lobes, screws or vanes that compress the gas or air. They are constant volume machines with variable discharge pressure. The volume can be varied only by changing the speed or bypassing or wasting some of the capacity of the machine. The types of rotary compressors are classified by the type of rotor they use. These include: straight-lobe, sliding vane, liquid piston, screw type.
Reciprocating compressors are furnished in either single-stage or multi-stage types. The principal parts of this type of machine are the cylinders and the pistons. The different types you will see include single acting air cooled or water cooled, single stage double acting water cooled, horizontal or vertical.
