type Variocleaner Rated internal pressure 0.005 bar @-10/50 Degrees C carbon steel, heated screws rated 3 bar @ 50 Degrees C, 75 liter each; jacket has two sections 120 liters each bolt flat end 2404mm screw length. Openings: top: 1-650mm, 1-250mm, 4-100mm side glassis, jacket: 3-40mm, bottom: 2-50mm
Type: Dryer-Holoflite & Screw
Manufacturer: Hi Line Industries
Model: 2155M25
Condition: Used
Material: Stainless Steel 316
Length: 4,115 mm (162 in)
Number of Screws: 1
12" dia x 13'6" long ferrilium/316SS conveyor dryer Rated 5 TPH Shaft 22 rpm Ferrilium housing 316SS hollow screw conveyor outboard bearings 3/60/230/460 volt,
Internal Pressure: 1.03 bar (14.9 psi). Internal Temperature: 148.9 °C (300 °F).
Type: Dryer-Holoflite & Screw
Manufacturer: Hi Line Industries
Model: 17.5-29
Condition: Used
Material: Stainless Steel 316
Length: 5,486 mm (216 in)
Number of Screws: 1
Holoflite dryer Estimated heat transfer area is 78 Sq.Ft. Agitator 16" diameter and 18' long. Material of construction 316SS on the screw and ferrilium vessel outboard bearings
Orientation: Horizontal. Heat Transfer Surface Area: 7.2 m² (78 ft²).
