Airoil-Flaregas F.C.10 flare tip, Pilots Derrick supported Flare stack, Customer ref #62/3336085/2H1/ON, The FC.10 flare tip inclusive of the Flarex molecular seal, Derrick supported flare stack and Knock out drum, stack is 44m high with supporting steel work, access ladder and working platform, it has been designed to safely dispose of the specified gas streams by flaring, The tip is provided with 3 x pilots which are ignited from a manual electric ignition system (this system is unavailable), Detection of the individual pilot flames is by Thermocouple, The smokeless operation of the flare is enhanced by utilization of a central steam injection nozzle Process conditions: Flared gas stream: Operating temperature:180 deg C, Maximum flow rate: 5850 kg/hr, Molecular weight:15.36 Utilities: Permanent Purge gas flow: 1.2 nm3/hr, Pilot & ignition gas flow: 7.7 kg/hr, Pilot & ignition gas pressure: 440 kpa, Pilot & ignition gas molecular weight: 17, Ignition air flow (intermittent): 40 nm3/hr, Ignition air pressure: 600 kpa, Steam supplies: Maximum flow to tip nozzle: 250 kg/hr, Steam pressure: 380 kpa, Electricity supply to ignition pulse generator:240 volt, Electricity to pilot flame indication trip amplifiers: 24 volt
