Carbon Steel Baker Perkins Mixer-Double Arm - IPP# 212416

Type: Mixer-Double Arm

Manufacturer: Baker Perkins

Condition: Used

Material: Carbon Steel

Capacity (Design): 1,703 L (450 gallons)

Capacity (Working): 1,136 L (300 gallons)

Sigma Blade mixer
Jacket trough,
with inside dimensions approx 56" long x 50" wide x 48" deep, bolted sides
Unit is geared one side, with chain and sprocket drive
230/460 volt
Amperage is rated for 174/87a
Vessel has a tilt discharge.
Hydraulic system is mounted to the machine base
for the tilt function.

Blade Type: Sigma Blade. Tilting: Yes. Hydraulics: Yes.

Type: Mixer-Double Arm

Manufacturer: Baker Perkins

Condition: Used

Material: Carbon Steel

Capacity (Design): 568 L (150 gallons)

Capacity (Working): 379 L (100 gallons)

Sigma Blade Mixer
jacket trough, tilt discharge.
With tangential sigma blades,
packing glands on shaft, rated atmospheric internal,
with dust cover. Geared both sides,
driven through a jack shaft,
with chain and sprocket drive on one end
Unit has a seperate power pack for tilt discharge.

Jacket Pressure: 8.62 bar (125 psi). Jacket Temperature: 204 °C (400 °F). Blade Type: tangential sigma blades. Tilting: Yes.

Type: Mixer-Double Arm

Manufacturer: Baker Perkins

Condition: Used

Material: Carbon Steel

Capacity (Design): 568 L (150 gallons)

Capacity (Working): 379 L (100 gallons)

Sigma Blade Mixer
jacket trough,
tilt discharge.
packing glands on shaft, rated atmospheric internal,
with dust cover
Geared both sides,
driven through a jack shaft,
with chain and sprocket drive on one end
Unit has a seperate power pack for tilt discharge.

Jacket Pressure: 8.62 bar (125 psi). Jacket Temperature: 204 °C (400 °F). Blade Type: tangential sigma blades. Tilting: Yes.

Type: Mixer-Double Arm

Manufacturer: Baker Perkins

Model: 20 TUEM

Condition: Used

Material: Carbon Steel

Capacity (Design): 3,312 L (875 gallons)

Capacity (Working): 1,893 L (500 gallons)

size 20 TUEM,
jacketed,
Bowl tilting time 35 seconds.
Mixing trough 58.5"
Front blade output speed 25.5 RPM.
Rear blade output speed 14.5 RPM.
V belt driven.
Base is 16'7" long x 9' 11" wide.

Jacket Pressure: 8.62 bar (125 psi). Blade Type: dual Sigma blades. Blade Speed (RPM): 25.5. Tilting: Yes. Vacuum: Yes. Hydraulics: Yes.
