0.25 inch, 316 SS tube, Micro motion flow meter, Model #D SO12S105. Serial #134182. Rated for -240 to 204 degrees Celsius. 0.25 inch NPT female connections. Flow rates maximum 11 lbs/min. to minimum, .55 lbs./min. Tube rated for 1700 psi, connections rated for 275 psi.
Type: Miscellaneous
Manufacturer: Micro motion
Model: T150TR641SIU
Condition: Used
383 gpm, T150 Series, Titanium flow tube, 304LSS fittings, Micro Motion Portable, cart mounted, straight tube flow meter system. Model T150TR641SIU, Serial Number 901560, rated to 1450 PSI, fits 1.5" diameter line size, rated liquid flow is 0 to 87000 Kg/Hr, 0 to 87000 Liter/Hr. Mounted on a prortable cart.
Type: Miscellaneous
Manufacturer: Webeco GmbH, Bad Schwartau, Germany
Model: ME100PH
Condition: Used
Material: Stainless Steel 316
type ME100PH 316 s/steel/glass UV reactor, manufactured by Webeco, serial #VA60474, 10 bar pressure, 5-60 deg C water temperature, 6.2 m3 volume, protection class IP54, 75mm diameter x 1m long glass tube mounted in a 316 s/steel cabinet
Type: Miscellaneous
Manufacturer: Graham
Condition: Used
Material: Stainless Steel 316
125 psi, two stage ejector and intercondesnser, designed and built by Graham for Swenson Evaporator. Includes the following equipment, 1-6" shell ejector 316 SS, 125 psi motive force x 54" long; 1-2" shell ejector 316 SS, 125 psi motive force, 24" long,: 1- 100 Sq. ft. all 316 SS, horizontal shell and tube heat exchanger, manufactured by Graham, serial # 753723, NB # 17680. Shell rated for FV/20 psi at 300 degrees F, tubes rated for 75 psi at 200 degrees F. 10" diameter x 115" overall length with 3" cooling water nozzles.
Type: Miscellaneous
Manufacturer: FMC
Condition: Used
Material: Stainless Steel 316
Rated 240 psi @ 406 deg F. 10" dia x 5'7" long shell w/int screw. 10" inlet/outlet, each w/316SS rotary airlock valve, driven by 1 HP motor. Screw driven by 1 HP, 3/60/480 volt, 1750 rpm motor. Packing gland on shaft. Shell thickness .280", head 1.38". Mtd on stand.
