Overview
Mill
Colloid
Stalwart International
Multi-Mill
New
Stainless Steel 316
Dimensions
330 mm (13 in)
Drive
2.2 kW (3 HP)
Other Specifications
Electric
Base Plate w/ Casters
Skid
Direct Coupled
Motor
Hindustan
2.2 kW (3 HP)
220
60
3

316SS (product contact), sifter, polished with mirror finish, Multi Mill ,with Bead impact knife blade. Sanitary and cGMP construction. 1400 mm height, 330mm diameter, 316 SS perforated screen .5 mm thick, 316SS shaft 38mm diameter x 410mm long, 316 SS knife (20 mm x 55 mm x 6 mm thick) frame 304 cladded, (2) 316 ss blade scrapers (20 mm x 20 mm x 50 mm), mechanical seal, w/ charging hopper. Hindustan Motor: 2.2KW 3/60/220 w/ VFD Bolted to base plate with caster wheels (4)
