Name: Carbon Steel Cartridge And Candle Filter
Brand: Breidenbach-Masch
SKU: 219091

Overview

Type:

Filter

Subtype:

Cartridge And Candle

Manufacturer:

Breidenbach-Masch

Model:

22V-4/160-5F-S

Condition:

Used

Material:

Carbon Steel

Capacity

Filtration Area:

1.6 m² (17.2 ft²)

Dimensions

Diameter:

600 mm (23.6 in)

Orientation:

Vertical

Overall Length:

1,100 mm (43.3 in)

Other Specifications

Pressure:

6 bar (87 psi)

Temperature:

350 °C (662 °F)

Cake Volume:

385 m3 (13,596 ft3)

Nozzle Schedule:

openings top: (2) DN25 straight side:(2) DN125, bottom: (1) DN50

Support Type:

Legs

Support Details:

mounted on 4-legs.

Top Head

Top Head Type:

Dish

Top Head Fastening:

Bolted

Bottom Head

Bottom Head Type:

Dish

Bottom Head Fastening:

Welded

Additional Info:

(4) stainless steel (1.4571) 175mm diameter x 700mm long filter elements

Unused Carbon Steel Cartridge And Candle Filter

Type: Filter

Subtype: Cartridge And Candle

Manufacturer: Crall Products

Model: 28-12-736-SST

Condition: Unused

Material: Carbon Steel

Filtration Area: 18.6 m² (200 ft²)

Diameter: 711.2 mm (28 in)

cartridge filter MDMT is 0 degrees F at 150 psi Inlet and outlet piping is 3" weld neck flange Filter has swing arm for removing the head. Shell thickness is .250" Head Thickness is .250" Hydro Test to 195 psi. Ext PSI 50 psi at 300 degree F

Pressure: 10.3 bar (150 psi). Temperature: 148.9 °C (300 °F).
