Name: Polypropylene Seitz 40/60 Filter Press
Brand: Seitz Enzinger
SKU: 219880

Overview

Type:

Filter

Subtype:

Press

Manufacturer:

Seitz Enzinger

Model:

40/60

Condition:

Used

Material:

Polypropylene

Capacity

Filtration Area:

5.2 m² (55.4 ft²)

Cake Volume:

0.002 m3 (0.07 ft3)

Other Specifications

Pressure:

6 bar (87 psi)

Frame Thickness:

12 mm (0.47 in)

Feed Type:

Top Inlet

Discharge Type:

Bottom corner

Number of Frames:

Support Type:

Legs

Dimensions

Overall Length:

2,220 mm (87.4 in)

Overall Width:

800 mm (31.5 in)

Overall Height:

950 mm (37.4 in)

Chamber Height:

750 mm (29.5 in)

Chamber Length:

750 mm (29.5 in)

Chamber Width:

12 mm (0.47 in)

Plates

Filter Press Plate Type:

Plate and Frame

Number of Plates:

Plate MOC:

Plastic

Plate Diameter or Width:

400 mm (15.7 in)

Plate Height:

400 mm (15.7 in)

Plate Thickness:

12 mm (0.47 in)

Plates Shifted By:

Manual

Additional Info:

Seitz Enzinger plate and frame filter press with (2) end plates (4) eye
Manual Screw closure openings (2) DN50

Polypropylene Seitz 40/60 Press Filter

Type: Filter

Subtype: Press

Manufacturer: Seitz Enzinger

Model: 40/60

Condition: Used

Material: Polypropylene

Filtration Area: 5.2 m² (55.4 ft²)

Pressure: 6 bar (87 psi)

Seitz Enzinger plate and frame filter press (4) eye
Manual Screw closure

Cake Volume: 0.002 m3 (0.07 ft3). Filter Press Plate Type: Plate and Frame. Number of Frames: 24. Number of Plates: 23. Plate MOC: Polypropylene. Skeleton MOC: 304 SS. Plate Diameter or Width: 400 mm (15.7 in). Plate Height: 400 mm (15.7 in). Plates Shifted By: Manual.

Polypropylene Seitz 40/60 Press Filter

Type: Filter

Subtype: Press

Manufacturer: Seitz Enzinger

Model: 40/60

Condition: Used

Material: Polypropylene

Filtration Area: 5.2 m² (55.4 ft²)

Pressure: 6 bar (87 psi)

Seitz Enzinger plate and frame filter press (2) end plates;(4) eye.
Manual Screw closure

Cake Volume: 0.002 m3 (0.07 ft3). Filter Press Plate Type: Plate and Frame. Number of Frames: 22. Number of Plates: 22. Plate MOC: Plastic. Skeleton MOC: 304 SS. Plate Diameter or Width: 400 mm (15.7 in). Plate Height: 400 mm (15.7 in). Plate Thickness: 12 mm (0.47 in). Plates Shifted By: Manual.

Polypropylene Seitz 40/60 Press Filter

Type: Filter

Subtype: Press

Manufacturer: Seitz Enzinger

Model: 40/60

Condition: Used

Material: Polypropylene

Filtration Area: 5.2 m² (55.4 ft²)

Pressure: 6 bar (87 psi)

Seitz Enzinger plate and frame filter press (4) eye
Manual Screw closure

Cake Volume: 0.002 m3 (0.07 ft3). Filter Press Plate Type: Plate and Frame. Number of Frames: 24. Number of Plates: 23. Plate MOC: Plastic. Plate Diameter or Width: 400 mm (15.7 in). Plate Height: 400 mm (15.7 in). Plate Thickness: 12 mm (0.47 in). Plates Shifted By: Manual.
