Stainless Steel 304L Cartridge And Candle Filter 6.6 m² (71.4 ft²) For Sale

Type:

Filter

Subtype:

Cartridge And Candle

Manufacturer:

Mott Hypulse

Model:

Hypulse LSI

Condition:

Used

Material:

Stainless Steel 304L

Filtration Area:

6.6 m² (71.4 ft²)

Diameter:

508 mm (20 in)

Orientation:

Vertical

Pressure:

10.3 bar (150 psi)

Temperature:

148.9 °C (300 °F)

Outlet Discharge Width:

50.8 mm (2 in)

Overall Length:

2,489 mm (98 in)

Overall Height:

2,489 mm (98 in)

Overall Width:

609.6 mm (24 in)

Top Head Type:

Flat

Top Head MOC:

Stainless Steel 304L

Top Head Fastening:

Bolted

Bottom Head Type:

Cone

Bottom Head MOC:

Stainless Steel 304L

Bottom Head Fastening:

Welded

Candle Cartridge Diameter:

76.2 mm (3 in)

Candle Cartridge Length:

1,524 mm (60 in)

Candle Cartridge MOC:

Stainless Steel 316L

Nozzle Schedule:

One 6" back wash drain, four 2" nozzles, two 1/2" nozzles

Number Cartridge's or Candles:

Outlet Discharge Diameter:

50.8 mm (2 in)

Straight Side Length:

1,981 mm (78 in)

Support Type:

Lugs

Washing:

Yes

Additional Info:

Certified by Robert Mitchel Co. Inc. 150 psi at 300 degrees F.
DET 1 Filter element Part # B2214227-03
3/16" wall thickness

Filter - IPP# 220783
