Hastelloy - C276 Cogeim FPP 600 FF-S Agitated Jacketed Pressure Nutsche Filter - IPP# 242518

Type: Filter

Subtype: Nutsche

Manufacturer: Cogeim

Model: FFP 600 FF-S

Condition: Used

Material: Hastelloy - C276

Filtration Area: 6 m² (64.6 ft²)

Diameter: 2,800 mm (110.2 in)

• design pressure internal 4 bar + full vacuum @ -29/185 degrees C (9100 liter),
• jacket 10 bar + full vacuum @ -29/185 degrees C (165 liter),
• fixed bed design,
• 6.5-13 rpm shaft speed,
• driven by 10/6.6kw 3/50/415 volt, 1500/750 rpm EExd IIB T4 motor via a reduction gearbox,
• reversing agitator for discharging,
• packed gland,
• shaft with Hydraulic raise/lower mechanism, driven by a hydraulic power pack with a 4kw, 3/50/415 volt 1500 rpm EExd IIB T4 motor,
• side discharge with hydraulic valve,
• 304L stainless steel half pipe coil jacket on straight side,
• carbon steel half pipe coil jacket on filter base,
• slurry outlet with a 100/80mm SCHUF valve,
• weld dished top, weld flat bottom,
• 2.8m diameter x 1050mm straight side,
• internal wash ring/spray bar,
• side inspection manway with cover and davit,
• mounted on feet with load cells,
• design code: ASME VIII DIV I ED 89 + ADD 90,

system includes

• (1) 340 Nm3/hr 316L stainless steel Apovac PMZK 3817 D3x6 vacuum pump skid, manufactured by Sulzer, skid includes (1) 340 Nm3/hr 316L stainless steel PMZK 3817 D3x6 vacuum pump, manufactured by Sulzer Burkhardt, serial #52771, (1) 6.7 square meter 316L stainless steel tube and shell heat exchanger (liquid ring cooler), manufactured by Kasag, pressure tube side -1/4 barg @ -29/185 degrees C, shell -1/10 barg @ -29/185 degrees C, (1) 10 square meter 316L stainless steel tube and shell heat exchanger (exhaust gas cooler), manufactured by Kasag, pressure tube side -1/4 barg @ -29/185 degrees C, shell -1/10 barg @ -29/185 degrees C, (1) 5 square meter 316L stainless steel heat exchanger (N2 Heater), manufactured by Kasag, pressure tube side -1/4 barg @ -29/185 degrees C, shell -1/10 barg @ -29/185 degrees C, (1) 190 liter 316L stainless steel pressure tank (condensate receiver), manufactured by Kasag, pressure -1/4 barg @ 50 degrees C,
• (1) 60m3/hr @ 13.6m head 316 stainless steel centrifugal pump (P1), manufactured by Girdlestone, type 12CSD2G, serial #53451, size 80-50-175, driven by 7.5kW, 3/50/415 volt, 2890 rpm EEx de IIB T4 motor, sealless type, mounted on a baseplate,
• (1) 10m3/hr @ 26m head PFA lined centrifugal pump (P2), manufactured by Richter, type PCK/F 32-160, serial #917493/3/3, 2900 rpm, 147mm diameter impellor, driven by 5.5kW, 3/50/415 volt, 2900 rpm EEx de IIB T4 motor, mechanical seal, mounted on a baseplate

Orientation: Vertical. Pressure: 4 bar (58 psi). Temperature: 185 °C (365 °F). Vacuum: Yes. Jacket: Yes. Jacket Pressure: 10 bar (145 psi). Jacket Type: Half Pipe/Limpet. Jacket MOC: Stainless Steel 304L. Jacket Temperature: 185 °C (365 °F).

Type: Filter

Subtype: Nutsche

Manufacturer: Cogeim

Model: FFP 400 FMS

Condition: Used

Material: Hastelloy - C276

Filtration Area: 4 m² (43.1 ft²)

Diameter: 2,300 mm (90.6 in)

• design pressure internal 4 bar + full vacuum @ -29/185 degrees C (5400 liter),
• jacket 10 bar + full vacuum @ -29/185 degrees C (120 liter),
• 304L stainless steel coil jacket on straight side and bottom filter base,
• 7.3-14.6 rpm shaft speed,
• driven by 10/6.6kw 3/50/415 volt, 1500/750 rpm EExd IIB T4 motor via a reduction gearbox,
• reversing agitator for discharging,
• packed gland,
• shaft with Hydraulic raise/lower mechanism, bottom filter bed with raise/lower mechanism, both driven by a hydraulic power pack, powerpack driven by 4kw, 3/50/415 volt 1430 rpm EExd IIB T4 motor,
• side discharge with hydraulic valve,
• slurry outlet with a 80/80mm SCHUF valve,
• filter bed on wheels for cleaning,
• side inspection manway with cover and davit,
• design code: ASME VIII DIV 1 ED. 89 + A.90,

(1) 60m3/hr @ 13.6m head 316L stainless steel centrifugal pump, manufactured by Girdlestone, type 12CSD2G, serial #53453, driven by 7.5kW, 3/50/415 volt, 2890 rpm EEx de IIB T4 motor, mechanical seal, mounted on a baseplate,

(1) centrifugal pump, manufactured by Chemquip Fluid Engineers, type PCK/F32-160, serial #546336/8/2, 2900 rpm, 147mm diameter impellor, driven by 5.5kW, 3/50/415 volt, 2900 rpm EEx de IIB T4 motor, mechanical seal, mounted on a baseplate

Orientation: Vertical. Pressure: 4 bar (58 psi). Temperature: 185 °C (365 °F). Vacuum: Yes. Jacket: Yes. Jacket Pressure: 10 bar (145 psi). Jacket Type: Half Pipe/Limpet. Jacket MOC: Stainless Steel 304L. Jacket Temperature: 185 °C (365 °F).

Type: Filter

Subtype: Nutsche

Manufacturer: Cogeim

Model: Filtro FPP-800-FF

Condition: Used

Material: Stainless Steel 316

Filtration Area: 8 m² (86.1 ft²)

Diameter: 3,200 mm (126 in)

• design pressure internal 4 bar + full vacuum @ -29/185 degrees C (12800 liter),
• jacket 10 bar + full vacuum @ -29/185 degrees C (150 liter),
• classification: ATEX Ex II 2GD II B c Tx, II 2G IIB c Tx, CE 13700575,
• fixed bed design,
• shaft with bellows,
• shaft speed 3.5-7.1 rpm,
• driven by 27/16kw, 3/50/400 volt ATEX II 2G/D EEx de IIB T4 motor,
• Flowserve gas type mechanical seal,
• shaft with Hydraulic raise/lower mechanism, driven by a hydraulic power pack,
• side discharge with hydraulic valve,
• internal spray bar with nozzles,
• side inspection manway with cover and davit,
• slurry discharge with SCHUF pneumatic double acting actuated valve,
• design code: ASME VIII DIV 1 97/23/CE,

(1) 15 m3/hr @ 8.4m head 316 stainless steel centrifugal pump, manufactured by CP Pumpen Ag, serial #07-00784/55975, type MKP 65-40-160, pressure 16 bar @ -40/205 degrees C, differential pressure 0.6 bar, NPSH 1.1m, driven by 1.5kW, 3/50/400 volt 1450 rpm IP55 EEx de II BT4 ATEX motor, magnetic drive, openings suction 62mm, discharge 32mm, mounted on a baseplate

Orientation: Vertical. Pressure: 4 bar (58 psi). Temperature: 185 °C (365 °F). Vacuum: Yes. Jacket: Yes. Jacket Pressure: 10 bar (145 psi). Jacket Type: Half Pipe/Limpet. Jacket MOC: Stainless Steel 304. Jacket Temperature: 185 °C (365 °F).

Type: Filter

Subtype: Nutsche

Manufacturer: Cogeim

Model: FPP 800 FF

Condition: Used

Material: Stainless Steel 316L

Filtration Area: 8 m² (86.1 ft²)

Diameter: 3,200 mm (126 in)

• design pressure internal 4 bar + full vacuum @ -28.8/185 degrees C (12800 liter),
• jacket 10 bar + full vacuum @ -28.8/185 degrees C (140 liter),
• internals mirror polished to 0.4um Ra,
• fixed bed design,
• 3.2m diameter x 1.2m straight side,
• bottom discharges,
• shaft with internal bellows,
• shaft driven by 30kw 3/50/400 volt IP55 EExd IIB T4 motor via a 210:1 ratio reduction gearbox,
• shaft speed 1.43-10.7 rpm,
• mechanical seal with lubricator,
• shaft with Hydraulic raise/lower mechanism, driven by a hydraulic power pack with a 7.5kw 3/50/400 volt IP55 EExd IIB T4 motor,
• jacket on straight side and bottom filter bed,
• internal wash ring/spray bar,
• side inspection manway with cover and davit,
• design code: 97/23/CE (supported by ASME VIII DIV 1 Ed 2000),

(1) centrifugal pump, driven by 11/12.5kW 3/50-60/690-400/660-380/415-440 volt, 2936/2929/2942/3526 rpm EEx de IIB T4 B3 ATEX motor,

Orientation: Vertical. Pressure: 4 bar (58 psi). Temperature: 185 °C (365 °F). Vacuum: Yes. Jacket: Yes. Jacket Pressure: 10 bar (145 psi). Jacket Type: Half Pipe/Limpet. Jacket MOC: Stainless Steel 316. Jacket Temperature: 185 °C (365 °F).
