Stainless Steel 316 United McGill 9E-10 SP Dryer-Shelf - IPP# 245506

Type: Dryer-Shelf

Manufacturer: United McGill

Model: 9E-10SP

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 11.3 m² (122 ft²)

Vacuum Rated: Yes

Number of Shelves: 10. Shelf Pressure: 3.4 bar (50 psi). Shelf Temperature: 176.7 °C (350 °F). Chamber Height: 2,032 mm (80 in). Chamber Width: 1,118 mm (44 in). Chamber Length: 1,016 mm (40 in). Temperature: 176.7 °C (350 °F). Number of Pans: 30. Pan Capacity: 0.75 m3 (26.4 ft3).

Type: Dryer-Shelf

Manufacturer: Hering

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 10 m² (107.6 ft²)

Vacuum Rated: Yes

Vacuum Shelf Dryer, electrically heated. Shelves with 19 pans, 990mmx490mmx50mm, chamber volumn is 1,400 liters, Vacuum Shelf Dryer by 220V 3/ PE 50Hz, (1) control cabinet.

Number of Shelves: 10. Shelf Length: 1,000 mm (39.4 in). Shelf Width: 1,000 mm (39.4 in). Shelf Pressure: -0.97 bar (-14 psi). Shelf Temperature: 200 °C (392 °F). Temperature: 200 °C (392 °F). Number of Pans: 19. Pan Capacity: 0.46 m3 (16.2 ft3).

Type: Dryer-Shelf

Manufacturer: Leybold

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 9.8 m² (105 ft²)

Number of Shelves: 9

vacuum shelf dryer. shelves cored for steam heating, Distance between shelves 3". Hinged front door with swing bolt closure. Also 2-3" sight glasses. Unit full insulation. Openings: vac 1-4", 2-2"; steam 4-3/4".

Shelf Length: 1,016 mm (40 in). Shelf Width: 1,067 mm (42 in). Orientation: Vertical. Number of Pans: 0.

Type: Dryer-Shelf

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 4.5 m² (48 ft²)

Vacuum Rated: Yes

vacuum shelf dryer. shelves cored for steam heating. Distance between shelves 3". Hinged front door with swing bolt closure. Also 1-4" sight glass. Unit with full insulation. Openings: vacuum 1-2 1/2"; steam 2-1 1/4", 4-3/4".

Number of Shelves: 4. Shelf Length: 1,041 mm (41 in). Shelf Width: 1,067 mm (42 in). Chamber Height: 1,702 mm (67 in). Chamber Width: 1,524 mm (60 in). Chamber Length: 1,524 mm (60 in). Orientation: Vertical. Temperature: 100 °C (212 °F). Number of Pans: 0.
