New Stainless Steel 304 Shandong HG Machinery Co., LTD. Fermenter - IPP# 245650

Type: Fermenter

Manufacturer: Four Corp

Condition: Used

Material: Stainless Steel 304

Capacity: 132,475 L (35,000 gal)

Agitation: Yes

• Do not have motors/drive systems, No manway cover .

Diameter: 3,658 mm (144 in). Length: 14,935 mm (588 in). Jacket: Half Pipe/Limpet. Orientation: Vertical. Pressure: 3.4 bar (50 psi). Temperature: 148.9 °C (300 °F). Jacket MOC: Stainless Steel 304. Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 148.9 °C (300 °F).

Type: Fermenter

Manufacturer: ThermoFisher

Model: HyPerforma SUF0030.2238

Condition: Used

Material: Stainless Steel 304

Capacity: 30 L (7.9 gal)

Agitation: Yes

• See Legacy Description
• Agitator drive Brother 3 phase induction motor, CE certified. F3S3055-WF4AENX Rated for ambient to 40 degrees C. o.5 HP, 5:1 Ratio 208V 60 Hz,1.80 a, 1700 rpm. MFR # 72D96232002.

Diameter: 266.7 mm (10.5 in). Length: 787.4 mm (31 in). Jacket: Dimple. Orientation: Vertical. Pressure: 0.03 bar (0.5 psi). Temperature: 4.4 °C (40 °F). Jacket MOC: Stainless Steel 304. Number of Jacket Zones: 1. Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 65.6 °C (150 °F). Internal Finish: Buff Polish. External Finish: Buff Polish.

Type: Fermenter

Manufacturer: ThermoFisher

Model: HyPerforma SUF0300.4075

Condition: Used

Material: Stainless Steel 304

Capacity: 300 L (79.3 gal)

Agitation: Yes

• See Legacy description
• 5:1 Turndown Ratio, 3:1 Height to Diameter ratio.
• Jacket area 7.77 Sq. Ft., Jacket volume 10.85 liters
• 4 Tank Baffles, Internal impeller 2 HP drive motor with 5:1 Gear reduction
• Max rotation speed 375 RPMs.

Diameter: 577.9 mm (22.8 in). Length: 1,689 mm (66.5 in). Jacket: Dimple. Orientation: Vertical. Pressure: 0.03 bar (0.5 psi). Temperature: 40 °C (104 °F). Jacket MOC: Stainless Steel 304. Number of Jacket Zones: 1. Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 65.6 °C (150 °F). Internal Finish: Buff Polish. External Finish: Buff Polish.

Type: Fermenter

Manufacturer: ThermoFisher

Model: HyPerforma SUF0300.4075

Condition: Used

Material: Stainless Steel 304

Capacity: 300 L (79.3 gal)

Agitation: Yes

• See legacy description
• 5:1 Turndown Ratio, 3:1 Height to Diameter ratio.
• Jacket area 7.77 Sq. Ft., Jacket volume 10.85 liters
• 4 Tank Baffles, Internal impeller 2 HP drive motor with 5:1 Gear reduction
• Max rotation speed 375 RPMs.

Diameter: 577.9 mm (22.8 in). Length: 1,689 mm (66.5 in). Jacket: Dimple. Orientation: Vertical. Pressure: 0.03 bar (0.5 psi). Temperature: 40 °C (104 °F). Jacket MOC: Stainless Steel 304. Number of Jacket Zones: 1. Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 65.6 °C (150 °F). Internal Finish: Buff Polish. External Finish: Buff Polish.
