With 52-V-103 discharge rotary valve, and Cincinnati Fan Blower. Discharge valve chain driven by a 0.75 HP motor, 1750 rpm, 230/460 V, 3 ph., 60 Hz. Cat # E108. Valve is Model MD40 serial # 847414-002-1--Cincinnati blower driven by a Baldor 10 HP AC motor at 3500 rpm. 215T frame 230/460 3 ph., 60 Hz.
Type: Dust Collector
Subtype: Bag House
Manufacturer: Hosokawa Alpine
Model: M6R
Condition: Used
Material: Carbon Steel
Diameter: 609.6 mm (24 in)
Flow Direction: Pulse jet
Rated -150/50 MBar. Filter area is 8 m2 with cone bottom. Bolted top manifold that is 16" straight side. with 1.5" diameter manifold feed line, (2) pulse jet feed lines. With CS fan. Rotary Airlock valve on bottom.
Pressure: 0.05 bar (0.73 psi). Filtration Area: 8 m2 (86.1 ft2).
Type: Dust Collector
Subtype: Bag House
Manufacturer: Nederman MikroPul
Condition: Used
Material: Carbon Steel
Cartridge: Yes
(1) cylindrical cartridge filter, fan manufactured by Nedermann, serial # 663, driven by 1.5 kw, 3/50/220/240/380/420 volt, 2800 rpm motor, shaker manufactured by Nedermann, serial # 529, driven by 0.25 kw, 3/50/220/240/380/415 volt, 2800 rpm motor, unit with built on timer, openings: top: 1-150mm, side: 1-150mm (fan connection), bottom: 1-250mm, unit mounted on carbon steel frame
Type: Dust Collector
Subtype: Bag House
Manufacturer: Donaldson Torit
Model: DFO-1-1-Single filter
Condition: Used
Material: Carbon Steel
Pressure: 4.1 bar (60 psi)
Air Flow Rate: 1,359 m3/h (800 CFM)
Dust collector Filtration area Dimensions: 25" wide x 52" high x 65" wide
Filtration Area: 17.7 m2 (190 ft2).
Type: Dust Collector
Subtype: Bag House
Manufacturer: UAS
Model: VP-750
Condition: Used
Material: Carbon Steel
Air Flow Rate: 1,274 m3/h (750 CFM)
Cartridge: Yes
Portable cartridge Sound level: 74 dBA Drawer capacity: 0.631 cubic feet Weight: 402 lbs 1.5/3HP easy to remove single cartridge cabinet mounted controls low-profile cabinet for easy maneuvering 5" caster wheels access handle for portability.
Filtration Area: 13.1 m2 (141 ft2).
