0.54 m² (5.8 ft²) Stainless Steel 316 Rotary Vacuum Filter For Sale IPP# 704670

IPP# 704670, 0.54 m² (5.8 ft²) Stainless Steel 316 Rotary Vacuum Filter For Sale

Condition:

Used

Material:

Stainless Steel 316

Manufacturer:

BHS Werk

Filtration Area:

0.54 m² (5.8 ft²)

Diameter:

700 mm (27.6 in)

Pressure:

3 bar (43.5 psi)

Temperature:

80 °C (176 °F)

Overall Width:

300 mm (11.8 in)

Gear Box Details:

PIV reduction gearbox

Height:

300 mm (11.8 in)

Motor Hertz:

Motor Power:

5.5 kW (7.4 HP)

Motor Speed (RPM):

1,440

Motor Voltage:

415

Nozzle Schedule:

Openings: vacuum inlets 4-37mm; feed 4-37mm; discharge 355mm x 228mm.

Support Details:

Base mtd

Additional Info:

fully enclosed rotary fest filter Design code: K3-190. Packed glands on shaft flameproof motor via 900-150 rpm PIV reduction gearbox then via 1.2-7.25 rpm PIV reduction gearbox Unit with hydraulic lubricating system driven by 0.18 KW, 1330 rpm, Type FC2 Lewa pump
