304SS rotor/ CS housing Mikro-atomizer 304SS single screw feed Type 6MA Single row swing stirrup design. 3/230/460 volt UL label. Feeder belt driven by 1/2 HP, 3/60/230/460 volt, 1750 rpm motor, UL label. Stellite tipped on 304SS blades.
Type: Pulverizer
Subtype: Jet
Manufacturer: Nederman MikroPul
Model: 6MA
Condition: Used
Motor Power (Design): 14.9 kW (20 HP)
Orientation: Horizontal
Ni-resist micro-atomizer Exhaust manifold y-connection to baghouse. Separating wheels stellite, SS hammers. 3/60/230/460 volt Feeder belt driven.
Type: Pulverizer
Subtype: Jet
Manufacturer: Nederman MikroPul
Model: 5MA
Condition: Used
Material: Stainless Steel 304
Motor Power (Design): 3.7 kW (5 HP)
Orientation: Horizontal
baghouse discharge. (1) row swing hammer design. 3/60/230/460 volt UL label. Single screw feeder belt driven by 1/4 HP, 1/60/115/230 volt, 1725 rpm variable speed X-proof motor. Feeder driven thru Boston gear reducer Mdl UF113A20, rated for 1/3 HP, 20:1 ratio. Unit complete w/discharge chute, feed hopper
Type: Pulverizer
Subtype: Jet
Manufacturer: Nederman MikroPul
Model: 5MA
Condition: Used
Material: Stainless Steel 304
Motor Power (Design): 3.7 kW (5 HP)
Orientation: Horizontal
atomizer baghouse discharge. (1) row swing hammer design. 3/60/230/460 volt UL label Single screw feeder belt driven by 1/4 HP, 1/60/115/230 volt, 1725 rpm variable speed X-proof motor. Feeder driven thru Boston gear reducer Mdl UF113A20, rated for 1/3 HP, 20:1 ratio.
Type: Pulverizer
Subtype: Jet
Manufacturer: Mikro
Model: 6MA
Condition: Used
Material: Stainless Steel Other
Outlet Discharge Diameter: 76.2 mm (3 in)
Inlet Diameter: 139.7 mm (5.5 in)
Mikro Atomizer Rated for 6,000 rpm. Capable of handling capacities from 100 to 1000 lbs/hr dependent on the material, this machine handles 3 functions in one machine. Pulverizes, air classifies and conveys the material.
Motor Power (Design): 22.4 kW (30 HP). Speed (RPM): 6,000. Orientation: Horizontal.
