multi valve , single row, solid rotor, backpressure design. Casing is manufactured from a Chrome Molly Alloy, with a forged Shaft. "Engineering solution" Single stage. Special 13,506 rpm, rated 1150 psi steam @ 890 deg F, 550 psi exhaust. Includes spare parts.
Type: Turbine
Subtype: Steam
Manufacturer: Turbodyne
Model: U-22575
Condition: Used
Power: 8,572 kW (11,495 HP)
Speed (RPM): 12863
multi valve single row, solid rotor Casing is manufactured from a Chrome Molly Alloy, with a forged Shaft. "Engineering solution" Single stage Special 13,506 rpm, rated 1150 psi steam @ 890 deg F, 550 psi exhaust Includes spare rotor and parts
Inlet Pressure: 79.3 bar (1,150 psi). Inlet Temperature: 476.7 °C (890 °F). Outlet Pressure: 37.9 bar (550 psi). Backpressure?: Yes. Stages: 1.
Type: Turbine
Subtype: Steam
Manufacturer: Turbodyne
Model: S5
Condition: Used
Power: 3,980 kW (5,337 HP)
Speed (RPM): 5650
Order #U-19182 6435 trip speed. Frame S5, 2nd critical rpm 11,500. Includes a spare rotor. (NOTE: Used to drive a gas compressor, see IPP# 222927 for full compressor).
Inlet Pressure: 41.4 bar (600 psi). Inlet Temperature: 398.9 °C (750 °F). Outlet Pressure: 3.8 bar (55 psi). Outlet Temperature: 189.4 °C (373 °F).
