Type: Column
Subtype: Tray
Manufacturer: Wyatt
Condition: Used
Material: Stainless Steel 316
Diameter (1): 1,350 mm (54 in)
Length (overall): 14,250 mm (561 in)
Pressure: 2.1 bar (30 psi). Vacuum: Yes. Temperature: 232.2 °C (450 °F). Number Of Trays: 38.
Type: Column
Subtype: Packed
Manufacturer: Pfaudler
Condition: Used
Material: Glasslined
Diameter (1): 304.8 mm (12 in)
Length (overall): 3,450 mm (135 in)
Glass #9115 PTFE packing support. Equipment # tag 679711.
Pressure: 10.3 bar (150 psi). Vacuum: Yes. Temperature: 232.2 °C (450 °F). Glasslined: Yes.
Type: Column
Subtype: Packed
Condition: Used
Material: Stainless Steel Other
Diameter (1): 304.8 mm (12 in)
Pressure: 8.6 bar (125 psi)
12" diameter column system , engineered by Distillation Engineering Co. Designed to bolt onto the top of a reactor with a 750-1000 gallon capacity. (depending on the chemical service) The system consists of the following parts. First a 12" x 80" SS packed column, second a top mounted re-boiler, and third a reflux tank. The column section is 12" diameter x 80" overall length. 316 SS, NB # 205, rated for FV/125 psi at 500 degrees F. Manufactured by Roben. With a packing support 10" from the bottom of the column. Estimated packed capacity is 5 ft.3. The U-Tube condenser is top mounted to the column. It is 163 ft.2, The shell is 316 SS, the tubes are 316 SS, the tube sheets are 316 SS, the heads are CS. NB # 4892. The shell is rated for FV/150 psi at 450 degrees F. The tubes are rated for 100 psi at 450 degrees F. It is manufactured by Roben, serial # 81034. It is 18" diameter x 107" overall length. Four pass shell side and Two pass tube side. 104 "U" tubes, 3/4" diameter x 16 gauge. With a 12" shell nozzle, and 3" tube nozzles. The reflux/receiver tank has a 90 Gallon capacity and is manufactured from 316 SS material. It is orientated vertically. The NB # is 275, it is rated for FV/35 psi at 650 degrees F. Manufactured by Cream City Boiler, serial # D-72-54G. The dimensions of the vessel are 24" diameter x43" straight side,
Type: Column
Subtype: Packed
Manufacturer: Estrella AG
Condition: Used
Material: Glasslined
Diameter (1): 600 mm (23.6 in)
Length (overall): 4,350 mm (172.2 in)
Column has (2) clamped straight sections 2 x 1.500mm long and 2 x 600mm diameter outside, volume of both sections 803 liter, clamped dished top section, 500mm long x 600 outside diameter, volume 97 liter and bottom section, 730mm long x 600 outside diameter, volume 137 liter. Total weight of the column is 930kg
Pressure: 2 bar (29 psi). Glasslined: Yes.
