column with built in condenser 1020mm packing height Sulzer Packing (NO PACKING), top of column has a built in 9 square meter 316L stainless steel tube, shell and head horizontal condenser, manufactured by Dynamit Nobel, pressure tube side 9 bar @ 200 deg C (35 liter), shell 4 bar + vacuumn @ 200 deg C (220 ltr), (120) 25mm diameter x 2mm x 950mm long tubes, (2) dished heads TUV
Type: Column
Subtype: Packed
Manufacturer: Dynamite Nobel
Condition: Used
Material: Stainless Steel 316
Diameter (1): 590 mm (23.2 in)
Length (overall): 6,400 mm (252 in)
internal pressure -1/3 bar @ 300 deg C (1530 liter) jacket 8 bar @ 300 deg C, (14 liter) (2) 590mm diameter x 2.5m long bolted sections each with packing height of 2m long (1) bonnet top head, half pipe vertical coil on straight side only, Julius Montz A2 type 304 stainless steel packing (NO PACKING) TUV
Pressure: 3 bar (43.5 psi). Vacuum: Yes. Temperature: 300 °C (572 °F).
Type: Column
Subtype: Packed
Manufacturer: Sulzer
Condition: Used
Material: Stainless Steel 316
Diameter (1): 400 mm (15.7 in)
Pressure: 3.2 bar (46.4 psi)
316lss Packed Rectification Column Unit bolted in 4 sections: Top section is 400 mm x 1140 mm, with aproz 2.5 SqM internal spiral condensing coil; Mid-section has (2) bolted sections that expand to 400 mm diam x 2040 mm long each, with a packed beds with 316LSS Sulzer packing in each section. Bottom section has a Falling film evaprator section with 316LSS vertical tubes in this section
Vacuum: Yes. Temperature: 300 °C (572 °F).
Type: Column
Subtype: Packed
Manufacturer: Sulzer
Condition: Used
Material: Stainless Steel 316
Diameter (1): 900 mm (35.4 in)
Pressure: 3 bar (43.5 psi)
800/900 mm x 8520 mm (~31-35" x 28') /OAH Packed Rectification Column Design operating conditons: 1.2 Torr, @ 245 Degrees C, 225 to 380 kg/h gass flow; 315 to 470 kg/h liter. Unit bolted in 4 sections: Top section is 800 mm x 1700 mm, with a 8 SqM internal spiral condensing coil; Mid-section has (2) bolted sections that expand to 900 mm diam x 4400 mm long total, 2200 mm long each, with a 1020 mm thick packed beds with 316LSS Sulzer packing in each section. Bottom section narrows to 800 mm diameter with an 8.2 SqM Falling film evaprator section with 316LSS vertical tubes in this section
Vacuum: Yes. Temperature: 300 °C (572 °F).
Type: Column
Subtype: Packed
Manufacturer: Sulzer
Condition: Used
Material: Stainless Steel 316
Diameter (1): 600 mm (23.6 in)
Length (overall): 8,372 mm (329.6 in)
Rectification Column Unit bolted in 4 sections: Top section is 600 mm x 1130 mm, with a 3 SqM internal spiral condensing coil; Mid-section has (2) bolted sections that expand to 600 mm diam x 2040 mm long each, with a 1020 mm thick packed beds with 316LSS Sulzer packing in each section. Bottom section has a 3 SqM Falling film evaporator section with 316LSS vertical tubes in this section
Pressure: 3.2 bar (46.4 psi). Vacuum: Yes. Temperature: 300 °C (572 °F).
