18.5 kW (24.8 HP) Stainless Steel 316 Centrifuge-Disc Bowl

Type: Centrifuge-Disc Bowl

Manufacturer: Alfa Laval

Model: BRPX 213S-34

Condition: Used

Material: Stainless Steel 316

Motor Horsepower: 18.5 kW (24.8 HP)

With tools

Unused Stainless Steel 316 Alfa Laval CHPX 510 SGD-35CGRX Centrifuge-Disc Bowl

Type: Centrifuge-Disc Bowl

Manufacturer: Alfa Laval

Model: CHPX 510 SGD-35CGRX

Condition: Used

Material: Stainless Steel 316

Motor Horsepower: 22 kW (29.5 HP)

Bowl Diameter: 405 mm (15.9 in)

seperator (clarifier) centrifuge Product # 88185-01-01 max. density of feed 1100 kg/m3 Max. density of sediment, 1238 kg.m3 Max density of operating liquid, 1000 kg/m3 Max operating temp. 100 degrees C Intermittent discharge of sediment Bowl size 10 Complete with motor, inlet & outlet housing, centrifugal pump/pairing disk, water harness, Manuals, inlet/outlet flowmeters and controls

Inlet Diameter: 35.5 mm (1.4 in). Bowl Volume: 16 L (4.2 gallons). Controls: Yes. RPM Maximum: 6,236.

29.8 kW (40 HP) Stainless Steel 316 Centrifuge-Disc Bowl

Type: Centrifuge-Disc Bowl

Manufacturer: Westfalia

Model: TA 140-02-576

Condition: Used

Material: Stainless Steel 316

Motor Horsepower: 29.8 kW (40 HP)

Inlet Diameter: 50.8 mm (2 in)

316SS bowl and cover 21" OD disk stack Sediment Holding: 4.6 gallons, Rated capacity: 7,926 Gallons per Hour Motor: Driven by a Louis Allis 230/460 volt Explosion proof enclosure

Bowl Volume: 70 L (18.5 gallons). Number of Phases: 2. RPM Maximum: 5,000.
