with chrome screw and chrome lined barrel. Jacketed barrel for cooling, hinged longitudinally for cleaning and maintenance.
Type: Extruder
Manufacturer: SMS Buss
Model: TCS-100-16D Kneader
Condition: Used
Material: Carbon Steel
Diameter: 99.8 mm (3.9 in)
Number of Heating Zones: 5
single screw Ko-Kneader system, processing length 16 L/D, carbon steel heated screw, 15mm screw oscillating stroke, screw root diameter 65mm, Theo. pitch in kneading zone (2-spirals) 60mm, pitch in infeed zone (1-spiral) 55mm, free volume (5 barrel section) 5.35 dm3, screw driven by a 2-speed motor, 90kw, 3/50/380/400/415/660/690 volt, 1481/1483/1485 rpm or 105kw, 3/60/440 volt, 1780 rpm, cast chrome steel barrel, barrel with special high nickel content carbon steel liner and kneading pins, barrels steam/water heated, (4) Regloplas type P160 water/steam heater temperature controllers for barrel heating, 6.5 liter volume, rated 6 bar @ 160 deg C, (1) 1m wide x 4m cooling length carbon steel chilled conveyor, manufactured by Bergerbachmann, belt driven by approx 1.1kw motor, 200mm diameter squeezing roll, 400mm diameter cooling roll, conveyor with Netzsch Condux carbon steel Granulator, type CS-300-800-11, serial # 6889, rotor speed 600 rpm, (2) Mixaco SM-600-D stainless steel high intensity mixers, 600ltr capacity, driven by 45kw, 3/50/400/690 volt 740 rpm motor, air pressure 6 bar, total volume 750 liter, 1180mm diameter x 690mm deep, 350mm feed, 300mm discharge with valve, each mixer with it own bag charging station
Screw Length: 1,900 mm (74.8 in). Barrel MOC: Stainless Steel Other. Heating type: Steam. L/D Ratio: 16:1. Number of Cooling Zones: 1.
