Unused Carbon Steel Praj Industries Tank - IPP# 235447

Type: Tank

Manufacturer: Praj Industries

Condition: Unused

Material: Stainless Steel 304L

Capacity (Design): 5,250 L (1,400 gallons)

Orientation: Vertical

Two top lifting trunnions.

Diameter: 1,350 mm (53 in). Straight-side Length: 3,650 mm (144 in). Internal Pressure: 1.72 bar (25 psi). Internal Temperature: 110 °C (230 °F). Vacuum: Yes. Support: Lugs.

Type: Tank

Manufacturer: Praj Industries

Condition: Unused

Material: Stainless Steel 304L

Capacity (Design): 999 L (264 gallons)

Orientation: Vertical

Two top lifting trunnions.

Diameter: 1,100 mm (43 in). Straight-side Length: 965 mm (38 in). Internal Pressure: 2.2 bar (32 psi). Internal Temperature: 160 °C (320 °F). Support: Legs.

Type: Tank

Manufacturer: Struthers Wells Inc.

Condition: Used

Material: Carbon Steel

Capacity (Design): 72,450 L (19,150 gallons)

Orientation: Horizontal

• Function: Ammonia converter
• Head thickness: 3.125 inches
• Additional feature: Haldor Topsoe Basket
• Built to ASME code, but not stamped. State Special.

Diameter: 2,150 mm (84 in). Straight-side Length: 22,850 mm (900 in). Internal Pressure: 179.3 bar (2,600 psi). Internal Temperature: 246.1 °C (475 °F). Support: Lugs.

Type: Tank

Manufacturer: Delta Southwestern

Condition: Used

Material: Carbon Steel

Capacity (Design): 34,050 L (9,000 gallons)

Orientation: Vertical

• Built to ASME code , not stamped, State Special

Diameter: 3,950 mm (156 in). Straight-side Length: 1,500 mm (60 in). Internal Pressure: 27.9 bar (405 psi). Internal Temperature: 468.3 °C (875 °F). Support: Lugs.
