With (1) 316 stainless steel centrifugal pump, manufactured by Girdlestone, type 10AS3G, serial #54100, size 50-40-175, mechanical seal, driven by 5.5kW, 3/50/415 volt, 2900 rpm EEx de IIB T4 IP55 motor, mounted on a baseplate,
Type: Tank
Manufacturer: Isaac Webster and Sons Ltd
Condition: Used
Material: Stainless Steel 316L
Orientation: Horizontal
Internal Pressure: 3.5 bar (50.8 psi)
Internal Temperature: 350 °C (662 °F). Vacuum: Yes. Support: Saddle.
Type: Tank
Manufacturer: Isaac Webster and Sons Ltd
Condition: Used
Material: Stainless Steel 316L
Capacity (Design): 6,300 L (1,650 gallons)
Orientation: Vertical
(1) 2.4 m3/hr @ 30m head 316L stainless steel centrifugal pump. manufactured by Girdlestone, type 10AS3G, NPSHa 7m, suction pressure 0,50 bar(g), max working pressure 16 bar(g), John Crane mechanical seal, driven by 7.5kw, 3/50/415 volt 2890 rpm EExd zone 1, IIA/B T4 motor, 50mm inlet, 32mm outlet, mounted on a baseplate
Diameter: 2,000 mm (78.7 in). Straight-side Length: 2,000 mm (78.7 in). Internal Pressure: 3.5 bar (50.8 psi). Internal Temperature: 170 °C (338 °F). Vacuum: Yes. Support: Legs.
Type: Tank
Manufacturer: Isaac Webster and Sons Ltd
Condition: Used
Material: Stainless Steel 316L
Capacity (Design): 1,600 L (422.7 gallons)
Orientation: Vertical
Diameter: 1,200 mm (47.2 in). Straight-side Length: 1,400 mm (55.1 in). Internal Pressure: 3.5 bar (50.8 psi). Internal Temperature: 185 °C (365 °F). Jacket Type: Half Pipe/Limpet. Jacket Material: Stainless Steel 316. Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 185 °C (365 °F). Vacuum: Yes. Support: Lugs.
Type: Tank
Manufacturer: Isaac Webster and Sons Ltd
Condition: Used
Material: Stainless Steel 316L
Capacity (Design): 755 L (199.4 gallons)
Orientation: Vertical
Diameter: 800 mm (31.5 in). Straight-side Length: 1,250 mm (50 in). Internal Pressure: 3.5 bar (50.8 psi). Internal Temperature: 170 °C (338 °F). Does it have Agitation ?: Yes. Vacuum: Yes. Support: Lugs.
