asset #10006370 design pressure -0.25/0.5 barg @ -26/50 degrees C (1) 15m3/hr @ 20m head 316 stainless steel centrifugal pump, manufactured by CP Pumpen Ag, type MKP 50-32-160, serial #06-01031/51781, 2930 rpm, NPSH 0.9m, suction pressure 0.2 bar, differential pressure 1.7 bar, temperature -30/160 degrees C, driven by 5.5kw, 3/50/400 volt 2930 rpm EEx de II BT4 IP65 ATEX motor, magnetic drive, 50mm suction, 32mm discharge, mounted on a baseplate
Type: Tank
Manufacturer: DCI
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 757 L (200 gallons)
Orientation: Vertical
Diameter: 914 mm (36 in). Straight-side Length: 1,200 mm (47 in). Internal Pressure: 1.03 bar (15 psi). Internal Temperature: 100 °C (212 °F). Vacuum: Yes. Sanitary Contruction: Yes. Support: Legs.
Type: Tank
Manufacturer: Perry Products Co.
Model: HDDX-185
Condition: Unused
Material: Stainless Steel 316
Capacity (Design): 700 L (185 gallons)
Orientation: Vertical
Diameter: 813 mm (32 in). Straight-side Length: 1,500 mm (60 in). Internal Pressure: 3.4 bar (50 psi). Internal Temperature: 162.8 °C (325 °F). Vacuum: Yes. Support: Legs.
Type: Tank
Manufacturer: Deco
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 1,150 L (300 gallons)
Orientation: Vertical
Diameter: 914 mm (36 in). Straight-side Length: 1,700 mm (66 in). Internal Pressure: 5.2 bar (75 psi). Internal Temperature: 176.7 °C (350 °F). Vacuum: Yes.
Type: Tank
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 11,350 L (3,000 gallons)
Orientation: Vertical
Diameter: 2,750 mm (108 in). Straight-side Length: 1,700 mm (66 in). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 93.3 °C (200 °F). Does it have Agitation ?: Yes. Vacuum: Yes. Support: Legs.
