Carbon Steel Whessoe Ltd Tank - IPP# 802154

Type: Tank

Manufacturer: Whessoe Ltd

Condition: Used

Material: Carbon Steel

Capacity (Design): 300,000 L (79,250 gallons)

Orientation: Vertical

• Built to design code BS.1500.1958
• Internal design pressure 40 psig at the top

Diameter: 4,900 mm (192 in). Straight-side Length: 16,650 mm (656 in). Internal Pressure: 4.8 bar (70 psi). Internal Temperature: 35 °C (95 °F). Support: Skirt.

Type: Tank

Manufacturer: Whessoe Ltd

Condition: Used

Material: Carbon Steel

Capacity (Design): 300,000 L (79,250 gallons)

Orientation: Vertical

• Built to design code BS.1500.1958
• Internal design pressure 40 psig at top.

Diameter: 4,900 mm (192 in). Straight-side Length: 16,650 mm (656 in). Internal Pressure: 4.8 bar (70 psi). Internal Temperature: 35 °C (95 °F). Support: Skirt.

Type: Tank

Manufacturer: Struthers Wells Inc.

Condition: Used

Material: Carbon Steel

Capacity (Design): 72,450 L (19,150 gallons)

Orientation: Horizontal

• Function: Ammonia converter
• Head thickness: 3.125 inches
• Additional feature: Haldor Topsoe Basket
• Built to ASME code, but not stamped. State Special.

Diameter: 2,150 mm (84 in). Straight-side Length: 22,850 mm (900 in). Internal Pressure: 179.3 bar (2,600 psi). Internal Temperature: 246.1 °C (475 °F). Support: Lugs.

Type: Tank

Manufacturer: Delta Southwestern

Condition: Used

Material: Carbon Steel

Capacity (Design): 34,050 L (9,000 gallons)

Orientation: Vertical

• Built to ASME code , not stamped, State Special

Diameter: 3,950 mm (156 in). Straight-side Length: 1,500 mm (60 in). Internal Pressure: 27.9 bar (405 psi). Internal Temperature: 468.3 °C (875 °F). Support: Lugs.
