Glasslined Pfaudler P 30 Tank - IPP# 87736

Type: Tank

Manufacturer: Pfaudler

Model: P 30

Condition: Re-glassed

Material: Glasslined

Capacity (Design): 113.6 L (30 gallons)

Orientation: Vertical

• Constructed of ASTM A285 Grade B and lined with C 2317 glass.

Diameter: 508 mm (20 in). Straight-side Length: 508 mm (20 in). Internal Pressure: 2.1 bar (30 psi). Internal Temperature: 232.2 °C (450 °F). Support: Lugs.

Type: Tank

Manufacturer: Pfaudler

Condition: Used

Material: Glasslined

Capacity (Design): 9,450 L (2,500 gallons)

Orientation: Horizontal

Diameter: 2,150 mm (85 in). Straight-side Length: 2,150 mm (84 in). Support: Legs.

Type: Tank

Manufacturer: Pfaudler

Condition: Used

Material: Glasslined

Capacity (Design): 1,900 L (500 gallons)

Orientation: Vertical

Diameter: 1,400 mm (56 in). Straight-side Length: 1,150 mm (46 in). Internal Pressure: 5.2 bar (75 psi). Internal Temperature: 176.7 °C (350 °F). Support: Legs.

Type: Tank

Manufacturer: Pfaudler

Condition: Used

Material: Glasslined

Capacity (Design): 378.5 L (100 gallons)

Orientation: Horizontal

Internal Pressure: 5.2 bar (75 psi). Internal Temperature: 343.3 °C (650 °F). Support: Legs.
