Searching for reliable flaker drums and belts? With over 47 years of experience, 20 complete process plant sites, and 15,000+ pieces of process equipment ready to ship, IPP delivers cost-effective solutions that help manufacturers meet demanding production timelines and budgets.
Flaker drums and belts are essential drying and solidification tools used across industries including chemicals, food processing, pharmaceuticals, and specialty materials. These systems are ideal for converting wet feedstocks into dry, uniform flakes ready for further processing or packaging.
Flaker drums apply a thin film of liquid product onto a heated rotating drum, where moisture evaporates, and the dried product is scraped off into consistent flakes. Flaker belts operate similarly, using a heated conveyor belt to achieve uniform drying and flaking for products that require a gentler process.
Browse the IMS inventory or contact IPP for expert advice and pricing to secure your flaker drum or belt today. With immediate availability, you can avoid costly production delays.
Type: Dryer-Flaker Drum and Belt
Manufacturer: Steel Belt Systems
Condition: Used
Material: Stainless Steel 304
Flaker Width: 1,500 mm (59.1 in)
For Belt: Length of Flaker: 18,000 mm (708.7 in)
approx 28.8 square meter 301 (NICRO 12.1)/304 stainless steel enclosed horizontal belt flaker with Pastillator 1.5m wide x 18000mm cooling length 301 (NICRO 12.1) stainless steel belt 19250mm belt length between center of rolls 38500mm total length of belt 1mm belt thickness, (3) cooling zones, zone 1 = 5.5m long (3 bar @ 5-9 degrees C), zone 2 = 6m long (3 bar @ 5-9 degrees C), zone 3 = 6.5m long (3 bar @ 5-9 degrees C), (179) plastic cooling nozzles, (2) 800mm wide 304 stainless steel drums belt enclosed in a 304 stainless steel housing, pneumatic operated belt tensioner, belt with bakelized fiber scraper blades (1) 120mm diameter x 1.4m wide 304 stainless steel RollDrop pastillator for distributing the liquid drops onto the cooling belt, 8mm toothed rotor pitch, type 3 x 1mm, comb material TEKAPEEK, 105 degrees C Pastillator with pneumatic operated raise/lower mechanism, belt with pneumatic operated knife discharge with a brass blade, 304 stainless steel water trays, built on controls, Thermo Scientific model MINI-11-101F weight integrator, emergency stop button and pull cord, all mounted on a Galvanised carbon steel frame, approx 20600mm total length of flaker, (1) discharge belt conveyor, Pastillator description: The product is fed at controlled temperature onto a roller rotor, whose rim is designed with teeth having regular shape and pitch. The liquid product slips constantly between the teeth pattern; drops are gathering on the back of every tooth, thanks to the complementary comb in touch with the toothed rotor. The formed drops are then deposited on the cooled steel belt, thanks to the centrifugal and gravitational force, generating simultaneously pastilles form.
Area of Flaker: 28.8 m² (310 ft²). Orientation: Horizontal. Single Belt or Double Belt ?: Single. Flaker Feed Type: Standard Drop Pastillator. Number of Cooling Zones for Belt: 3. Nozzles per Cooling Zone: 60. Scraper: Yes. Scraper Details: bakelized fiber.
Type: Dryer-Flaker Drum and Belt
Manufacturer: Berndorf belt systems
Model: 924MDT
Condition: Used
Material: Stainless Steel Other
Flaker Width: 1,524 mm (60 in)
For Belt: Length of Flaker: 20,117 mm (792 in)
belt flaker, with Accu-Drop Pastillator and Variable Speed Drive Belt system is 60" wide x 75 feet long. With six (138" x 59" x 5'5") water collectors 190 Gallons rated for 55 degrees F. Six water spray systems, 116" x 2" OD. Hot melt is feed through a rotoform, with steam to keep hot melt in a liquid state. Shell side (Product side) rated for 400 degrees F, tube side, (steam) rated for 300-350 degrees F. Rotoform is 59" long x 3.25" diameter Main Belt is driven by a Euro drive variable-speed, with a helical reducer 3 HP gear ratio 34.26:1 Overall belt speed is from 25 FPM up to 125 FPM. (This can also be adjusted with different sprockets.) 1750 rpm. 2.77 HP, service factor 1 with output torque 892. The rated temperature range is 51-110 degrees F. Driven by a 1 hp AC motor, continuous duty TEFC. Model # DF26DT1001.54, serial # 88075 1570.07.
Area of Flaker: 30.7 m² (330 ft²). Orientation: Horizontal. Single Belt or Double Belt ?: Single. Flaker Feed Type: Heated Refeed Pastillator.
Type: Dryer-Flaker Drum and Belt
Manufacturer: Berndorf belt systems
Model: 924MDT
Condition: Used
Material: Stainless Steel Other
Flaker Width: 1,524 mm (60 in)
For Belt: Length of Flaker: 20,117 mm (792 in)
belt flaker, with Accu-Drop Pastillator and Variable Speed Drive Belt system is 60" wide x 75 feet long. With six (138" x 59" x 5'5") water collectors 190 Gallon rated for 55 degrees F Six water spray systems, 116" x 2" OD. Hot melt is feed through a rotoform with steam to keep wax in a liquid state. Shell side(product side) rated for 400 degrees F, tube side, (steam) rated for 300-350 degrees F. Rotoform is 59" long x 3.25" diameter Main Belt is driven by a Euro drive variable-speed with a helical reducer 3 HP gear ratio 34.26:1 Overall belt speed is from 25 FPM up to 125 FPM. (This can also be adjusted with different sprockets.) Overall shipping dimensions are 75" wide x 66" tall (to top of mounted pastillator) x 75' long. Belt thickness is 0.040", belt height is 48".
Area of Flaker: 30.7 m² (330 ft²). Orientation: Horizontal. Single Belt or Double Belt ?: Single. Flaker Feed Type: Heated Refeed Pastillator.
Type: Dryer-Flaker Drum and Belt
Manufacturer: Sandvik
Condition: Used
Material: Stainless Steel Other
Flaker Width: 1,500 mm (59.1 in)
For Belt: Length of Flaker: 24,850 mm (978.3 in)
1.5m wide x 24.85m long rotoform cooling conveyor/belt Drawing Number 6530. 5m long hot water section 17.5m cooling water section Cooling water capacity: 185 GPM @ 30 psi, Hot water zone has 16 sprays x 4 runs x 0.71 gpm (45.4 gpm), Cold water zone has 49 sprays x 4 runs x 0.71 gpm (139.1 gpm), 900mm diameter tension drum, 900mm diameter drive drum andvik Dropformer feed unit with hot oil heated weir, chain driven by 0.75 KW, 3/50/415 volt motor via varispeed gearbox. brass knife discharge, carbon steel support frame with sump tanks mounted under the belt, Flaker includes a discharge vibratory shaker for size classifacation, (3) Sihi Centrifugal cooling water pumps, Russel Finex inline water filter,
Area of Flaker: 37 m² (398.3 ft²). Orientation: Horizontal. Single Belt or Double Belt ?: Single. Flaker Feed Type: Standard Drop Pastillator. Number of Cooling Zones for Belt: 4. Nozzles per Cooling Zone: 49. Scraper: Yes. Scraper Details: Discharge scraper - Brass MOC.
