ELL reactor Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

RCI agitator. Counter clockwise rotation With a 3TW drive end Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

with a RW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,277 mm (129 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Drive Model: RW.

Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

RCI Agitator Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

For a 5 RW Drive Fits an RA gallon reactor Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

5TW drive end Fits a 1000 Gallon reactor. Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

Diameter: 76.2 mm (3 in). Length: 2,724 mm (107.3 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

4RW drive end RA reactor Diameter: 88.9 mm (3.5 in). Length: 2,724 mm (107.3 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

a 5RW Drive end. Counterclockwise rotation. Fits a RA750 gallon. Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

2-tier agitator with 4 blades 12" span on bottom tier 2.5 DTW drive end 16" span on top tier Diameter: 38.1 mm (1.5 in). Length: 1,378 mm (54.3 in). Span: 368.3 mm (14.5 in). Vessel Size: 378.5 L (100 gallons). Dual Tier: Yes. Reglassed: Yes. Glass Agitator Drive Model: TW.

Dual Flight Press Lock Agitator Shaft. dual tier 5" upper tier , 4 5/16" lower tier Diameter: 127 mm (5 in). Length: 4,826 mm (190 in). Dual Tier: Yes.

2.5 DTW end. Fits a "P" series. Diameter: 38.1 mm (1.5 in). Length: 1,226 mm (48.3 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

counter clockwise rotation With a 2.5 DTW drive end Fits a P 30 reactor. Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise.

counter clockwise rotation 2.5 DTW drive end Fits a 30 Gallon "P" series reactor. Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise.

2.5 DTW drive end Diameter: 38.1 mm (1.5 in). Length: 1,435 mm (56.5 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

2.5 DTW drive end. Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

TW drive end, mechanical seal. For a 200 gal EM series reactor. Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

One set of two PBT agitator blades CCW rotation Diameter: 114.3 mm (4.5 in). Span: 1,219 mm (48 in). Glass Agitator Type: Pitch Turbine. Reglassed: Yes. Rotation: Counterclockwise.

• Fits RA Series reactor Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

with a DTW drive end Diameter: 139.7 mm (5.5 in). Length: 4,623 mm (182 in). Span: 1,372 mm (54 in). Vessel Size: 15,142 L (4,000 gallons).

6 RW end Diameter: 114.3 mm (4.5 in). Length: 4,147 mm (163.3 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Fits 5 TW or DTW drive . Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

5 RW drive end Reglassed by UGE 2007. Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Cryo-lock shaft upper tier 5" lower tier 4 1/2" fits a 3V Tech 5000 gallon. Diameter: 127 mm (5 in). Length: 5,258 mm (207 in). Vessel Size: 18,927 L (5,000 gallons). Dual Tier: Yes. Glass Agitator Type: Cryo-Lock.

Cryo-lock shaft upper tier 5" lower tier 4 1/2" fits a 3V tech 5000 gallon. Diameter: 127 mm (5 in). Length: 5,258 mm (207 in). Vessel Size: 18,927 L (5,000 gallons). Dual Tier: Yes. Glass Agitator Type: Cryo-Lock.

Counter clockwise rotation. Diameter: 114.3 mm (4.5 in). Span: 1,219 mm (48 in). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Rotation: Counterclockwise.

with a 3/4" DTW drive end. Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

3DTW drive end Diameter: 76.2 mm (3 in). Length: 1,562 mm (61.5 in). Span: 762 mm (30 in). Vessel Size: 567.8 L (150 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

RCI Agitator fits a P30 Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

5RW drive end Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Glass Agitator Drive Model: RW.

For 5DTW drive Compatibility: Fits 750 gal RA Series reactor Diameter: 88.9 mm (3.5 in). Length: 2,591 mm (102 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

• With 3 1/2" diameter seal area, plated, for a mechanical seal
• For 5RW drive
• RA/SA Series reactor Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Drive end for a 4RW Diameter: 76.2 mm (3 in). Length: 2,089 mm (82.3 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

With stainless steel sleeve 5RW drive end Fits a RA 750 reactor Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

6RW end. Designed for counter clockwise rotation. Diameter: 114.3 mm (4.5 in). Length: 4,147 mm (163.3 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Diameter: 38.1 mm (1.5 in). Length: 1,435 mm (56.5 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

2.5 DTW drive end Diameter: 38.1 mm (1.5 in). Length: 1,267 mm (49.9 in). Span: 609.6 mm (24 in). Vessel Size: 283.9 L (75 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

RCI Agitator Diameter: 38.1 mm (1.5 in). Length: 1,245 mm (49 in). Span: 609.6 mm (24 in). Vessel Size: 283.9 L (75 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

6 RW drive end. Diameter: 114.3 mm (4.5 in). Length: 4,147 mm (163.3 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

6RW drive end Counterclockwise rotation. Diameter: 114.3 mm (4.5 in). Length: 4,147 mm (163.3 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Counter clock wise rotation Diameter: 88.9 mm (3.5 in). Length: 3,632 mm (143 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

with a DTW drive end. Diameter: 139.7 mm (5.5 in). Length: 4,623 mm (182 in). Span: 1,372 mm (54 in). Vessel Size: 15,142 L (4,000 gallons). Reglassed: Yes.

For a RA/SA series reactor Drive end for a 5TW drive end Fits a 1000 gallon reactor. Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

Glass lined CBT Hub with a 29" span and 2.5" bore

500 gallon glass lined cryo-lock shaft. With 3525 SRW drive end and 2.5" diameter shaft end.

CBT Hub counter clockwise rotation. Span: 838.2 mm (33 in). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

RCI Agitator for 5RW Fits 100/1500 gallon Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

DTW drive end. Diameter: 114.3 mm (4.5 in). Length: 4,147 mm (163.3 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

4 RW drive end. Diameter: 76.2 mm (3 in). Length: 2,572 mm (101.3 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Agitator Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Reglassed: Yes. Rotation: Counterclockwise.

Has 8RW drive end Seal area plated with SS Counter clockwise rotation Fits a RA reactor Diameter: 139.7 mm (5.5 in). Length: 5,321 mm (209.5 in). Span: 1,626 mm (64 in). Vessel Size: 22,712 L (6,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Fits a 200 Gallon EM series Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

nucerite 3-blade agit. W/TW end EL Series reactor Diameter: 88.9 mm (3.5 in). Length: 1,829 mm (72 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons).

3 blade retreat curve agitator 44 1/2" overall length, x 1 1/2" diameter with a 20" spam with a2.5 DTW drive end Diameter: 38.1 mm (1.5 in). Length: 1,118 mm (44 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons).

2.5 DTW drive end Diameter: 38.1 mm (1.5 in). Length: 1,124 mm (44.3 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Vessel Size: 7,571 L (2,000 gallons).

Cryo-Lock shaft for RW Drive. Diameter: 88.9 mm (3.5 in). Length: 3,708 mm (146 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

5RW drive end Diameter: 88.9 mm (3.5 in). Length: 3,727 mm (146.8 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock.

3/4" DTW drive end. Diameter: 76.2 mm (3 in). Length: 2,540 mm (100 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Cryo-Lock CBT hub Counter clockwise rotation Diameter: 88.9 mm (3.5 in). Span: 838.2 mm (33 in). Glass Agitator Type: Cryo-Lock.

2.5 DTW end Diameter: 38.1 mm (1.5 in). Length: 857.3 mm (33.8 in). Span: 406.4 mm (16 in). Vessel Size: 75.7 L (20 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

VBT hub Lower Set ,Fits a 5000/6000 gallon reactor . Diameter: 127 mm (5 in). Span: 1,092 mm (43 in). Vessel Size: 22,712 L (6,000 gallons).

Diameter: 76.2 mm (3 in). Length: 1,562 mm (61.5 in). Span: 762 mm (30 in). Vessel Size: 567.8 L (150 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

with a DTW drive end Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Drive Model: DTW.

with a DTW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Drive Model: DTW.

Cryo-lock shaft with 7-8RW drive end Diameter: 139.7 mm (5.5 in). Length: 5,156 mm (203 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

6RW drive end Diameter: 114.3 mm (4.5 in). Length: 4,147 mm (163.3 in). Span: 1,372 mm (54 in). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Diameter: 114.3 mm (4.5 in). Length: 4,147 mm (163.3 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Fits a 500 gallon Diameter: 76.2 mm (3 in). Length: 1,956 mm (77 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

RCI Agitator drive end Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Diameter: 76.2 mm (3 in). Length: 1,562 mm (61.5 in). Span: 762 mm (30 in). Vessel Size: 567.8 L (150 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Diameter: 139.7 mm (5.5 in). Length: 5,445 mm (214.4 in). Span: 1,372 mm (54 in). Vessel Size: 18,927 L (5,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Diameter: 88.9 mm (3.5 in). Length: 2,724 mm (107.3 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Diameter: 88.9 mm (3.5 in). Length: 3,632 mm (143 in). Span: 1,118 mm (44 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Diameter: 76.2 mm (3 in). Length: 1,346 mm (53 in). Span: 609.6 mm (24 in). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 38.1 mm (1.5 in). Length: 1,245 mm (49 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Length: 1,270 mm (50 in). Span: 609.6 mm (24 in). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 38.1 mm (1.5 in). Length: 1,397 mm (55 in). Span: 609.6 mm (24 in). Vessel Size: 567.8 L (150 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: Philadelphia.

Diameter: 76.2 mm (3 in). Length: 2,096 mm (82.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: RW.

With DTW drive end. Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,118 mm (44 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,118 mm (44 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Diameter: 76.2 mm (3 in). Length: 1,803 mm (71 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Diameter: 76.2 mm (3 in). Length: 3,239 mm (127.5 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Has a 4.5" machined surface for cryo-lock blades(Blades not included) Diameter: 139.7 mm (5.5 in). Length: 4,893 mm (192.6 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

RW drive end Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

• glass lined Cryro-Lock shaft
• with an 5 RW end
• Fits a 1000 or 1500 gallon vessel Diameter: 88.9 mm (3.5 in). Length: 3,048 mm (120 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: Cryo-Lock. Glass Agitator Drive Model: RW.

RCI agitator Fits a 5 DTW drive end . Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons).

Dual Flight Agitator 4RW drive end Fits 500 gallon cone bottom reactor. Diameter: 76.2 mm (3 in). Length: 2,311 mm (91 in). Span: 457.2 mm (18 in). Vessel Size: 1,893 L (500 gallons).

RCI Agitator with a 5DTW drive fits a 2000 gallon Diameter: 88.9 mm (3.5 in). Length: 3,658 mm (144 in). Span: 1,118 mm (44 in).

RCI Agitator, with a 2.5DTW drive end. Diameter: 38.1 mm (1.5 in). Length: 1,435 mm (56.5 in). Span: 508 mm (20 in).

CBT Glass lined with 3.5" bore. Diameter: 88.9 mm (3.5 in). Span: 838.2 mm (33 in). Glass Agitator Type: CBT. Reglassed: Yes.

with a PTE -06 drive end. Diameter: 69.9 mm (2.8 in). Length: 3,277 mm (129 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons).

CBT with a 4.5" diameter hub Fits a 3000-4000 Gallon Reactor. Diameter: 114.3 mm (4.5 in). Span: 1,040 mm (40.9 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: CBT.

Cryo-Lock blade CBT with a 4.5" diameter hub clockwise rotation Fits a 3000-4000 Gallon Reactor. Diameter: 1,041 mm (41 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: Cryo-Lock.

Series: RA with 6RW end. Diameter: 114.3 mm (4.5 in). Length: 3,991 mm (157.1 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: Cryo-Lock.

500 gallon glass lined RCI agitator.

Span: 838.2 mm (33 in). Vessel Size: 5,678 L (1,500 gallons). Hub size: 3.5. Glass Agitator Type: CBT. Reglassed: Yes. Rotation: Counterclockwise.

Diameter: 38.1 mm (1.5 in). Length: 781.1 mm (30.8 in). Span: 304.8 mm (12 in). Vessel Size: 37.9 L (10 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Diameter: 88.9 mm (3.5 in). Span: 838.2 mm (33 in). Glass Agitator Type: CBT.

Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Diameter: 114.3 mm (4.5 in). Length: 3,556 mm (140 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Diameter: 55.6 mm (2.2 in). Length: 2,711 mm (106.8 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: Philadelphia.

3 blade retreat curve agitator. OAL - 106.75, drive end diameter - 2.1875, span - 44”. PTE-6 drive end

Length: 2,572 mm (101.3 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

3 blade retreat curve agitator. OAL - 105 3/4”, drive end diameter 2.1875”. Span - 36”. PTE-6 drive end.

for 7 RW or 8 RW Diameter: 139.7 mm (5.5 in). Length: 4,877 mm (192 in). Vessel Size: 15,142 L (4,000 gallons). Hub size: 4.5. Glass Agitator Type: Cryo-Lock. Glass Agitator Drive Model: RW.

For a 7 and 8 RW Diameter: 139.7 mm (5.5 in). Length: 4,877 mm (192 in). Vessel Size: 15,142 L (4,000 gallons). Hub size: 4.5. Glass Agitator Type: Cryo-Lock. Glass Agitator Drive Model: RW.

Diameter: 139.7 mm (5.5 in). Length: 4,877 mm (192 in). Vessel Size: 15,142 L (4,000 gallons). Hub size: 4.5". Glass Agitator Type: Cryo-Lock. Glass Agitator Drive Model: RW.

with a DTW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Drive Model: DTW.

Diameter: 88.9 mm (3.5 in). Length: 3,073 mm (121 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

• Cryo-Lock turbine set
• Complete set of (2) Cryo-Lock agitator blades.
• Turbine PBT.
• Each pieces has a (2) blade pitched paddle
• with 2.5" ID center shaft opening Diameter: 63.5 mm (2.5 in). Span: 558.8 mm (22 in). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

Cryo-Lock shaft for RW With 5.5" hub. Has stainless steel inlay for mechanical seal. Diameter: 139.7 mm (5.5 in). Length: 4,585 mm (180.5 in). Vessel Size: 18,927 L (5,000 gallons). Glass Agitator Type: Cryo-Lock.

Drive compatibility: 5TW Fits 2,000 gal RA Series reactor. Diameter: 88.9 mm (3.5 in). Length: 3,632 mm (143 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 76.2 mm (3 in). Length: 3,251 mm (128 in). Glass Agitator Type: 3 Blade Retreat Curve.

Glass Agitator Type: 3 Blade Retreat Curve.

White Glass. Diameter: 76.2 mm (3 in). Length: 1,753 mm (69 in). Span: 609.6 mm (24 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Dark blue Glass. Diameter: 76.2 mm (3 in). Length: 1,753 mm (69 in). Span: 609.6 mm (24 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: RW.

Diameter: 38.1 mm (1.5 in). Length: 1,435 mm (56.5 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

• With a diameter 3" DTW drive end
• Fits an EM Gallon Reactor Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

agitator with 5 RW end Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

Reactor, dimensions: 30" deep x 78" wide Shaft: None Vessel Size: 2,000 L (528.4 gallons). Glass Agitator Type: Anchor.

E3000 Series white glass 3-blade agit W/3" (76mm) dia seal area for mech seal. For VS10 drive. Diameter: 88.9 mm (3.5 in). Length: 2,896 mm (114 in). Span: 1,041 mm (41 in).

counter clockwise rotation With a 5RW drive end Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

1000 gallon Cryo-lock shaft only with 3.5" hub and 4DTW drive end.

Diameter: 38.1 mm (1.5 in). Length: 1,064 mm (41.9 in). Span: 609.6 mm (24 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

1 Set PBT Blades Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Vessel Size: 11,356 L (3,000 gallons). Hub size: 4.5. Glass Agitator Type: Cryo-Lock. Rotation: Clockwise.

1 Set PBT Blades Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Vessel Size: 11,356 L (3,000 gallons). Hub size: 4.5. Glass Agitator Type: Cryo-Lock. Rotation: Clockwise.

1 Set PBT Blades Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Vessel Size: 11,356 L (3,000 gallons). Hub size: 4.5. Glass Agitator Type: Cryo-Lock. Rotation: Counterclockwise.

w/63q12 lightnin drive end single tier . Length: 3,632 mm (143 in). Vessel Size: 11,356 L (3,000 gallons). Dual Tier: Yes. Glass Agitator Type: Glass-Loc. Glass Agitator Drive Model: Lightnin.

Single Tier Length: 3,632 mm (143 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: Glass-Loc. Glass Agitator Drive Model: Lightnin.

Diameter: 88.9 mm (3.5 in). Length: 3,207 mm (126.3 in). Vessel Size: 3,785 L (1,000 gallons). Hub size: 3.5. Glass Agitator Type: Cryo-Lock. Glass Agitator Drive Model: SRW.

RCI Agitator of an ES 75 Diameter: 38.1 mm (1.5 in). Length: 1,267 mm (49.9 in). Span: 609.6 mm (24 in). Vessel Size: 26.5 L (7 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

2.5 DTW drive Diameter: 38.1 mm (1.5 in). Length: 1,372 mm (54 in). Span: 362 mm (14.3 in). Vessel Size: 378.5 L (100 gallons). Dual Tier: Yes. Glass Agitator Type: Pitch Turbine. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

5RW drive end with a seal area plated with Stainless Steel. Diameter: 88.9 mm (3.5 in). Length: 2,692 mm (106 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

• Measures 126 1/4" OAL x 3.5" diameter for hub and for mechanical seal
• 5RW end
• Fits an RA 1000/RA 1500 gallon reactor Diameter: 88.9 mm (3.5 in). Length: 3,207 mm (126.3 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

• 4 blade cryolock hub
• counter clockwise rotation Diameter: 63.5 mm (2.5 in). Span: 736.6 mm (29 in). Glass Agitator Type: Cryo-Lock.

Light blue glass Diameter: 88.9 mm (3.5 in). Length: 3,556 mm (140 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock.

Glass lined PBT Fits 3000 & 4000 gallon reactors Diameter: 114.3 mm (4.5 in). Span: 1,041 mm (41 in). Vessel Size: 15,142 L (4,000 gallons).

One set of 35" span glass lined Cryo-lock PBT Blades counter clock wise rotation has 3 1/2" bore. Diameter: 88.9 mm (3.5 in). Span: 889 mm (35 in). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

5RW drive end Fits a 2000 gallon. Diameter: 88.9 mm (3.5 in). Length: 3,721 mm (146.5 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

with a 5 DTW drive end Diameter: 88.9 mm (3.5 in). Length: 3,632 mm (143 in). Span: 1,118 mm (44 in). Reglassed: Yes.

with a 5RW drive end . Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Reglassed: Yes.

with a 5DTW drive end . Diameter: 88.9 mm (3.5 in). Length: 3,632 mm (143 in). Span: 1,118 mm (44 in). Reglassed: Yes.

with a 4RW drive end Diameter: 76.2 mm (3 in). Length: 2,718 mm (107 in). Span: 914.4 mm (36 in). Reglassed: Yes.

with 4DTW drive end Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 914.4 mm (36 in).

with a 5DTW drive end Diameter: 88.9 mm (3.5 in). Length: 3,620 mm (142.5 in). Span: 1,118 mm (44 in). Reglassed: Yes.

Fits a 500 gallon Diameter: 76.2 mm (3 in). Length: 2,718 mm (107 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons).

CBT blades. 114.25 mm (3.5" ) hub size Fits a 1500-2000 Gallon reactor. Diameter: 114.3 mm (4.5 in). Span: 1,040 mm (40.9 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock.

Cryo-lock shaft. With 4.5" bore. Diameter: 114.3 mm (4.5 in). Length: 3,988 mm (157 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

PBT blades Diameter: 88.9 mm (3.5 in). Span: 838.2 mm (33 in). Glass Agitator Type: Cryo-Lock.

Has a 4 RW drive end. Diameter: 76.2 mm (3 in). Length: 2,731 mm (107.5 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons).

RCI Agitator Drive end off Diameter: 139.7 mm (5.5 in). Length: 4,204 mm (165.5 in). Span: 1,524 mm (60 in).

RCI Agitator Diameter: 139.7 mm (5.5 in). Length: 4,204 mm (165.5 in). Span: 1,524 mm (60 in).

RCI Agitator Drive end off Diameter: 139.7 mm (5.5 in). Length: 4,204 mm (165.5 in). Span: 1,524 mm (60 in).

CBT hub Clock wise rotation 3.5" bore. Span: 736.6 mm (29 in).

RCI Agitator drive end cut off. Diameter: 139.7 mm (5.5 in). Length: 4,121 mm (162.3 in). Span: 1,524 mm (60 in). Reglassed: Yes.

RCI Agitator drive end cut off. Diameter: 139.7 mm (5.5 in). Length: 4,204 mm (165.5 in). Span: 1,524 mm (60 in). Reglassed: Yes.

Diameter: 6 inches (seal area for DTW drive), 3 1/2 inches (hub diameter) Hub diameter: 4 1/2 inches Diameter: 88.9 mm (3.5 in). Length: 4,597 mm (181 in). Glass Agitator Type: Cryo-Lock.

Dual flight Seal area: 5 inches diameter for PTE drive Upper machined area: 4 ½ inches Lower machined area: 3 ½ inches Diameter: 127 mm (5 in). Length: 5,131 mm (202 in). Vessel Size: 22,712 L (6,000 gallons). Glass Agitator Type: Cryo-Lock.

Diameter - 4 ½” for seal area for PTE drive and 4 ½” for machined area for Diameter: 114.3 mm (4.5 in). Length: 4,591 mm (180.8 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: Cryo-Lock.

(seal area for PTE drive), 5 ½ inches (machined area Fits 6000 gallon Reactor Diameter: 127 mm (5 in). Length: 4,801 mm (189 in). Vessel Size: 22,712 L (6,000 gallons). Glass Agitator Type: Cryo-Lock.

PBT blade Diameter: 139.7 mm (5.5 in). Span: 1,372 mm (54 in).

Drive end: 2.5 DTW Diameter: 38.1 mm (1.5 in). Length: 1,124 mm (44.3 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Glass Agitator Drive Model: DTW.

Series: P series Drive end: 2.5 DTW Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

5RW drive end Fits a 1000-1500 gallon reactor Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

CBT hub ,counter clockwise rotation. Span: 1,041 mm (41 in).

1000/1500 gallon Has a 5 RW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Reglassed: Yes.

Agitator with new upper end, EL series 3/4 DTW drive end. Diameter: 76.2 mm (3 in). Length: 1,854 mm (73 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Reglassed: Yes.

Fits an ELL Series Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

for a 2.5 DTW drive end Fits a 20 galon reactor Diameter: 38.1 mm (1.5 in). Length: 838.2 mm (33 in). Span: 304.8 mm (12 in). Vessel Size: 75.7 L (20 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

8/6/24 TK - Used to assemble 241071. Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

for a 5 RW Diameter: 76.2 mm (3 in). Length: 3,007 mm (118.4 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock.

CBT Hub with 3.5" bore. Clockwise rotation. Diameter: 88.9 mm (3.5 in). Span: 736.6 mm (29 in). Glass Agitator Type: CBT. Reglassed: Yes. Rotation: Clockwise.

Drive end: 5DTW Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

5DTW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Drive end: 6DTW Diameter: 114.3 mm (4.5 in). Length: 3,708 mm (146 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

SA Agitator shaft Shaft only (no blades) White glass Diameter: 88.9 mm (3.5 in). Length: 1,981 mm (78 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: Glass-Loc.

(Shaft Only-No Blades) White Glass Diameter: 88.9 mm (3.5 in). Length: 3,023 mm (119 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Glass-Loc.

Agitator shaft SA Shaft only (no blades) White glass Diameter: 88.9 mm (3.5 in). Length: 3,023 mm (119 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Glass-Loc.

White Glass. SA Type: Shaft (no blades) Diameter: 88.9 mm (3.5 in). Length: 2,159 mm (85 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: Glass-Loc.

agitator shaft White Glass. (Shaft Only-No Blades). Diameter: 88.9 mm (3.5 in). Length: 2,769 mm (109 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Glass-Loc.

White Glass SA Drive end is a 61Q06. Diameter: 88.9 mm (3.5 in). Length: 2,769 mm (109 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

White Glass Diameter: 88.9 mm (3.5 in). Length: 2,565 mm (101 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

White Glass Diameter: 76.2 mm (3 in). Length: 1,753 mm (69 in). Span: 609.6 mm (24 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 584.2 mm (23 in). Span: 584.2 mm (23 in). Vessel Size: 1,893 L (500 gallons). Hub size: 3.5. Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Rotation: Counterclockwise.

Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

RCI Agitator with 5 DTW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

Diameter: 1,118 mm (44 in). Length: 3,289 mm (129.5 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 88.9 mm (3.5 in). Span: 838.2 mm (33 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock. Rotation: Clockwise.

CBT Hub

Cryo-lock agitator shaft, for a 5 RW drive Diameter: 76.2 mm (3 in). Length: 3,210 mm (126.4 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock.

Diameter: 38.1 mm (1.5 in). Length: 857.3 mm (33.8 in). Span: 406.4 mm (16 in). Vessel Size: 75.7 L (20 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Diameter: 76.2 mm (3 in). Length: 3,454 mm (136 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Rotation: Counterclockwise. Glass Agitator Drive Model: Philadelphia.

Reserved for Siegfried reglassing a 3BRC agitator Vessel Size: 7,571 L (2,000 gallons).

with 5 TW drive end Diameter: 88.9 mm (3.5 in). Length: 3,534 mm (139.1 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: TW.

with RW drive end Diameter: 76.2 mm (3 in). Length: 2,057 mm (81 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 38.1 mm (1.5 in). Length: 781.1 mm (30.8 in). Span: 304.8 mm (12 in). Vessel Size: 37.9 L (10 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Pfaudler glass lined Cryo-lock CBT hub. 29" span with a 3.5" bore

Pfaudler glass lined cryo-lock shaft. 4 RW drive end

Seal area plated with stainless steel Drive end: 4RW Diameter: 88.9 mm (3.5 in). Length: 2,724 mm (107.3 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Customer Owned---fits a RA3000 gallon Diameter: 114.3 mm (4.5 in). Length: 3,835 mm (151 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Dual Tier: Yes. Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Vessel Size: 15,142 L (4,000 gallons).

Vessel Size: 15,142 L (4,000 gallons).

Vessel Size: 7,571 L (2,000 gallons).

Vessel Size: 3,785 L (1,000 gallons).

Vessel Size: 1,893 L (500 gallons).

Vessel Size: 1,893 L (500 gallons).

Vessel Size: 757.1 L (200 gallons).

Vessel Size: 757.1 L (200 gallons).

Vessel Size: 378.5 L (100 gallons).

Vessel Size: 378.5 L (100 gallons).

Vessel Size: 189.3 L (50 gallons).

Vessel Size: 189.3 L (50 gallons).

Vessel Size: 113.6 L (30 gallons).

Vessel Size: 113.6 L (30 gallons).

Vessel Size: 1,136 L (300 gallons).

Vessel Size: 1,136 L (300 gallons).

dual flight bottom tier diameter 3 1/2" , upper tier diameter 3/1/2" , with a 5RW drive end Diameter: 88.9 mm (3.5 in). Length: 3,721 mm (146.5 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

Cryo-Lock CBT hub clockwise rotation. Diameter: 88.9 mm (3.5 in). Span: 838.2 mm (33 in). Glass Agitator Type: Cryo-Lock.

white glass Seal size on glass: 135mm Dimensions to glass: 490mm Diameter: 170 mm (6.7 in). Length: 4,450 mm (175.2 in). Span: 1,600 mm (63 in). Vessel Size: 12,500 L (3,302 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Seal size on glass: 60mm Dimensions to glass: 310mm blue glass Diameter: 92 mm (3.6 in). Length: 1,970 mm (77.6 in). Span: 800 mm (31.5 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Seal size on glass: 60mm Dimensions to glass: 310mm blue glass Diameter: 92 mm (3.6 in). Length: 1,970 mm (77.6 in). Span: 800 mm (31.5 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Anchor height: 1350mm white glass Diameter: 143 mm (5.6 in). Length: 3,700 mm (145.7 in). Span: 1,830 mm (72 in). Vessel Size: 6,000 L (1,585 gallons).

Anchor height: 1320mm white glass Compatible vessel size: approx. 7500/8000 liters Diameter: 117 mm (4.6 in). Length: 3,620 mm (142.5 in). Span: 1,800 mm (70.9 in). Vessel Size: 8,000 L (2,113 gallons).

blue glass Stub shaft diameter: 110mm 110mm diameter x 490mm long steel stub shaft 120mm diameter seal area Diameter: 140 mm (5.5 in). Length: 4,040 mm (159.1 in). Span: 1,400 mm (55.1 in). Vessel Size: 8,000 L (2,113 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Agitator shaft color: White Sub shaft length: 1540mm fits approx. 8000 liter Diameter: 110 mm (4.3 in). Length: 4,040 mm (159.1 in). Span: 800 mm (31.5 in). Vessel Size: 8,000 L (2,113 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

550mm long carbon steel stub end, blue glass Diameter: 105 mm (4.1 in). Length: 3,225 mm (127 in). Span: 1,000 mm (39.4 in). Glass Agitator Type: 3 Blade Retreat Curve.

700mm long carbon steel stub end with a 110mm long Hastelloy sleeve Diameter: 152mm (seal) Material: Hastelloy blue glass 730mm from center of shaft to tip of finger Diameter: 160 mm (6.3 in). Length: 6,180 mm (243.3 in). Span: 1.1 mm (0.04 in). Glass Agitator Type: 3 Blade Retreat Curve.

Stub end: 380mm long carbon steel Color: Blue glass Distance from center of shaft to tip of finger: approx. 400mm 1000 liter (300 gallon) reactor Diameter: 85 mm (3.3 in). Length: 1,850 mm (72.8 in). Span: 600 mm (23.6 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

R66 series Gland: High duty packed fits a 1,000 gal R66 series reactor 560mm from center of shaft to tip of finger Diameter: 96 mm (3.8 in). Length: 2,710 mm (106.7 in). Span: 850 mm (33.5 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Stub shaft: 230mm long x 70mm diameter, carbon steel with Hastelloy sleeve and internal keyway Packed gland: high duty Distance from center of shaft to tip of finger: 560mm fits approx. 300 gallon reactor Diameter: 96 mm (3.8 in). Length: 2,100 mm (82.7 in). Span: 780 mm (30.7 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Agitator shaft length: Not specified Stub end length: 390mm blue glass fits approx. 1800 liter vessel Diameter: 90 mm (3.5 in). Length: 2,250 mm (88.6 in). Span: 700 mm (27.6 in). Vessel Size: 1,800 L (475.6 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Drive end: Houdaille Rotapower RA series Diameter: 127 mm (5 in). Length: 5,588 mm (220 in). Span: 1,524 mm (60 in). Vessel Size: 18,927 L (5,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Designed for high duty packing gland. Diameter: 50 mm (1.97 in). Length: 1,400 mm (55.1 in). Span: 460 mm (18.1 in). Glass Agitator Type: 3 Blade Retreat Curve.

Drive end: RW Diameter: 88.9 mm (3.5 in). Length: 3,277 mm (129 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

RCI Agitator Diameter: 139.7 mm (5.5 in). Length: 4,204 mm (165.5 in). Span: 1,524 mm (60 in). Vessel Size: 22,712 L (6,000 gallons).

CBT Hub Diameter: 88.9 mm (3.5 in). Span: 736.6 mm (29 in).

RCI Agitator, Diameter: 139.7 mm (5.5 in). Length: 4,204 mm (165.5 in). Span: 1,524 mm (60 in).

with a PTE drive end Capacity options: 4000 or 5000 gallons Diameter: 114.3 mm (4.5 in). Length: 4,902 mm (193 in). Span: 1,372 mm (54 in). Vessel Size: 18,927 L (5,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Designed to fit a 3/4 DTW drive. Diameter: 69.9 mm (2.8 in). Length: 2,565 mm (101 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Designed to fit a 3 DTW drive. Diameter: 69.9 mm (2.8 in). Length: 1,575 mm (62 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Three tier Cryo-lock Diameter: 155.4 mm (6.1 in). Length: 5,842 mm (230 in). Vessel Size: 30,283 L (8,000 gallons). Glass Agitator Type: Cryo-Lock.

One set of 56" span PBT Blades counter clock wise rotation has 5.5" bore. Diameter: 139.7 mm (5.5 in). Span: 1,422 mm (56 in).

CBT hub with 3.5" bore. Diameter: 584.2 mm (23 in). Glass Agitator Type: Cryo-Lock.

Fits a 1000/1500 Gallon. Diameter: 101.6 mm (4 in). Length: 3,251 mm (128 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 101.6 mm (4 in). Length: 2,108 mm (83 in). Span: 1,168 mm (46 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 76.2 mm (3 in). Length: 2,565 mm (101 in). Span: 965.2 mm (38 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Fits a 50 "P" series. Diameter: 50.8 mm (2 in). Length: 1,130 mm (44.5 in). Span: 520.7 mm (20.5 in). Glass Agitator Type: 3 Blade Retreat Curve.

One set of two PBT agitator blades 4.5 bore with clock wise rotation. Diameter: 114.3 mm (4.5 in). Span: 1,219 mm (48 in). Glass Agitator Type: Pitch Turbine. Rotation: Clockwise.

CBT hub Diameter: 101.6 mm (4 in). Span: 863.6 mm (34 in). Glass Agitator Type: Cryo-Lock.

CBT hub Diameter: 101.6 mm (4 in). Span: 812.8 mm (32 in). Glass Agitator Type: Cryo-Lock.

CBT hub. Diameter: 88.9 mm (3.5 in). Span: 584.2 mm (23 in). Glass Agitator Type: Cryo-Lock.

Fits a 1000/1500 Gallon. Drive end for a DTW. Diameter: 82.6 mm (3.3 in). Length: 3,099 mm (122 in). Span: 1,168 mm (46 in). Vessel Size: 5,678 L (1,500 gallons).

Drive end for a DTW. Diameter: 82.6 mm (3.3 in). Length: 2,591 mm (102 in). Span: 1,219 mm (48 in). Vessel Size: 1,893 L (500 gallons).

With DTW drive end, tapered to 2.5". Diameter: 69.9 mm (2.8 in). Length: 1,524 mm (60 in). Span: 863.6 mm (34 in). Vessel Size: 757.1 L (200 gallons).

Diameter: 76.2 mm (3 in). Length: 2,096 mm (82.5 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons).

Fits 1000/1500 gallon. With 5RW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,073 mm (121 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons).

With 5RW drive end Diameter: 88.9 mm (3.5 in). Length: 2,769 mm (109 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons).

With DTW drive end, tapered to 2 1/2". Diameter: 50.8 mm (2 in). Length: 1,435 mm (56.5 in). Span: 558.8 mm (22 in). Vessel Size: 378.5 L (100 gallons).

Diameter: 85.6 mm (3.4 in). Length: 3,073 mm (121 in).

DTW Agitator Diameter: 66.5 mm (2.6 in). Length: 1,930 mm (76 in). Vessel Size: 1,136 L (300 gallons).

Diameter: 71.4 mm (2.8 in). Length: 3,874 mm (152.5 in). Vessel Size: 7,571 L (2,000 gallons).

agitator shaft 3 1/2" diameter hub. Diameter: 88.9 mm (3.5 in). Length: 3,061 mm (120.5 in). Vessel Size: 7,571 L (2,000 gallons).

Fits a SA 1500 Gallon . Diameter: 68.1 mm (2.7 in). Length: 3,349 mm (131.9 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons).

Fits 1000/1500 gallon. With DTWa 5 drive end Diameter: 79.2 mm (3.1 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Reglassed: Yes.

Designed to fit a PTE drive. Diameter: 76.2 mm (3 in). Length: 3,864 mm (152.1 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

CBT hub counter clockwise rotation. Span: 584.2 mm (23 in).

CBT hub ,counter clockwise rotation. Span: 584.2 mm (23 in).

CBT hub ,counter clockwise rotation. Span: 736.6 mm (29 in).

CBT hub ,counter clockwise rotation. Span: 736.6 mm (29 in).

CBT hub ,counter clockwise rotation. Span: 838.2 mm (33 in).

CBT hub ,counter clockwise rotation. Span: 838.2 mm (33 in).

CBT hub ,counter clockwise rotation. Span: 838.2 mm (33 in).

CBT hub ,counter clockwise rotation. Span: 838.2 mm (33 in).

CBT hub ,counter clockwise rotation. Span: 1,041 mm (41 in).

207mm long carbon steel end with keyway 170mm long x 50mm wide glass seal area white glass 300mm from center of shaft to tip of finger fits approx. 800 liter reactor Diameter: 62 mm (2.4 in). Length: 1,315 mm (51.8 in). Span: 560 mm (22 in). Vessel Size: 800 L (211.3 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

207mm long carbon steel end with keyway 170mm long x 50mm wide glass seal area white glass 300mm from center of shaft to tip of finger fits approx. 800 liter reactor Diameter: 62 mm (2.4 in). Length: 1,315 mm (51.8 in). Span: 560 mm (22 in). Vessel Size: 800 L (211.3 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

for 5RW drive, RCI Agitator.
Fits a 1000/1500 gallon. Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 914.4 mm (36 in). Vessel Size: 5,678 L (1,500 gallons).

With a 3.5" keyway and tapered drive end. Diameter: 114.3 mm (4.5 in). Length: 3,531 mm (139 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: Glass-Loc.

RCI agitator Drive end fits a Q12 Lightnin drive. Diameter: 101.6 mm (4 in). Length: 4,902 mm (193 in). Span: 1,372 mm (54 in). Glass Agitator Type: 3 Blade Retreat Curve.

Lightnin drive end. Diameter: 114.3 mm (4.5 in). Length: 4,877 mm (192 in). Span: 1,219 mm (48 in). Glass Agitator Type: 3 Blade Retreat Curve.

With a 3.5" keyway and tapered drive end. Diameter: 114.3 mm (4.5 in). Length: 3,531 mm (139 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: Glass-Loc.

Diameter: 76.2 mm (3 in). Length: 1,676 mm (66 in). Span: 914.4 mm (36 in). Vessel Size: 757.1 L (200 gallons).

Cryo-Lock shaft for RW With 5.5" hub. Diameter: 139.7 mm (5.5 in). Length: 4,585 mm (180.5 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: Cryo-Lock.

Diameter: 88.9 mm (3.5 in). Length: 2,870 mm (113 in). Span: 1,295 mm (51 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: Anchor.

DTW drive end. Diameter: 54 mm (2.1 in). Length: 1,257 mm (49.5 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons).

22" long tapered hub Stepped glass from 4.5" to 5.5". Diameter: 88.9 mm (3.5 in). Length: 3,531 mm (139 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: Glass-Loc.

2.5 DTW drive end Diameter: 34.9 mm (1.38 in). Length: 1,010 mm (39.8 in). Span: 508 mm (20 in). Vessel Size: 113.6 L (30 gallons).

2.5 DTW drive end. Diameter: 38.1 mm (1.5 in). Length: 1,257 mm (49.5 in). Span: 508 mm (20 in). Vessel Size: 378.5 L (100 gallons).

Agitator drive end cut off Diameter: 63.5 mm (2.5 in). Length: 2,388 mm (94 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons).

with a 3/4" DTW drive end. Diameter: 76.2 mm (3 in). Length: 2,572 mm (101.3 in). Span: 914.4 mm (36 in). Vessel Size: 2,839 L (750 gallons).

Diameter: 88.9 mm (3.5 in). Length: 2,388 mm (94 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons).

Diameter: 38.1 mm (1.5 in). Length: 857.3 mm (33.8 in). Span: 254 mm (10 in). Vessel Size: 75.7 L (20 gallons).

Diameter: 88.9 mm (3.5 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock.

plated with stainless steel, and a 4.5" diameter machined area for cryolock blades. No blades included. Drive end is for 6 RW. Diameter: 114.3 mm (4.5 in). Length: 3,991 mm (157.1 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: Cryo-Lock.

DTW drive end. Diameter: 69.9 mm (2.8 in). Length: 1,759 mm (69.3 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 57.2 mm (2.3 in). Length: 2,616 mm (103 in). Span: 1,016 mm (40 in). Vessel Size: 1,893 L (500 gallons).

Currently has Nucerite Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 114.3 mm (4.5 in). Length: 1,219 mm (48 in).

Turbine blade hub Diameter: 114.3 mm (4.5 in). Length: 1,219 mm (48 in). Span: 152.4 mm (6 in).

Diameter: 76.2 mm (3 in). Length: 1,981 mm (78 in). Span: 1,168 mm (46 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 76.2 mm (3 in). Length: 1,524 mm (60 in). Span: 812.8 mm (32 in). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 76.2 mm (3 in). Length: 1,524 mm (60 in). Span: 812.8 mm (32 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 101.6 mm (4 in). Length: 2,591 mm (102 in). Span: 1,168 mm (46 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Fits 4 RW gearbox Fits a 1000 Gallon reactor. Diameter: 76.2 mm (3 in). Length: 3,251 mm (128 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Press Lock Agitator Shaft 5" upper tier , 4 1/4" lower tier . Length: 4,851 mm (191 in). Vessel Size: 18,927 L (5,000 gallons). Dual Tier: Yes.

VBT hub with 4.5” bore Fits 4000/5000 gallon reactors Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Vessel Size: 18,927 L (5,000 gallons).

23" span CBT hub Span: 584.2 mm (23 in).

seal size on glass=100mm fits 7500/8000 liter vessel dimensions to glass=420mm, white glass Diameter: 117 mm (4.6 in). Length: 3,600 mm (141.7 in). Span: 1,100 mm (43.3 in). Vessel Size: 8,000 L (2,113 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

3-blade steel shaft 70mm diameter x 360mm 60mm diameter holes for blades no blades Diameter: 104 mm (4.1 in). Length: 2,530 mm (99.6 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: Cryo-Lock.

3" seal A 3 or 4 DTW drive Diameter: 101.6 mm (4 in). Length: 2,642 mm (104 in). Span: 508 mm (20 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

3 1/2" seal area Diameter: 108 mm (4.3 in). Length: 3,886 mm (153 in). Vessel Size: 7,571 L (2,000 gallons). Dual Tier: Yes. Glass Agitator Type: Glass-Loc.

4 blade PBT downward counter clockwise rotation with a 33 degrees blade pitch One complete set with four blades Diameter: 88.9 mm (3.5 in). Span: 965.2 mm (38 in). Glass Agitator Type: Cryo-Lock.

One set of three (3) Glass Lok paddles 3.5" hub size Diameter: 279.4 mm (11 in). Length: 584.2 mm (23 in). Glass Agitator Type: Glass-Loc.

TW drive end Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

DTW drive end calibration lines on the glass Diameter: 50.8 mm (2 in). Length: 1,118 mm (44 in). Span: 431.8 mm (17 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

2.5 DTW or TW drive end Diameter: 50.8 mm (2 in). Length: 1,321 mm (52 in). Span: 457.2 mm (18 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

DTW/TW drive end P series reactor Diameter: 38.1 mm (1.5 in). Length: 1,118 mm (44 in). Span: 508 mm (20 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

3 blade pitch style PTE - 10 end Length: 3,759 mm (148 in). Span: 914.4 mm (36 in). Glass Agitator Type: Glass-Loc.

glasslock shaft tapered end Diameter: 88.9 mm (3.5 in). Length: 3,467 mm (136.5 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Glass-Loc.

white glass lined 3-finger impellor agitator shaft for a impellor agitator shaft CE6300 liter reactor, DIN 28157 used with a mechanical seal Diameter: 114.3 mm (4.5 in). Length: 3,600 mm (141.7 in). Span: 1,100 mm (43.3 in).

white glass lined 3-finger impellor agitator shaft for a CE2500 liter reactor DIN 28157 used with a mechanical seal Diameter: 101.6 mm (4 in). Length: 3,540 mm (139.4 in). Span: 960 mm (37.8 in).

white glass, fits a DeDietrich model 125-140mm drive, 143mm diameter shaft, 125mm diameter x 75mm wide seal area, 120mm diameter x 500mm long, stub shaft with keyway Diameter: 143 mm (5.6 in). Length: 4,950 mm (194.9 in). Span: 1,200 mm (47.2 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

With 3 1/2" dia seal area for a mech seal For 6TW drive Fits 3,000 gal RA96 Series reactor. Diameter: 88.9 mm (3.5 in). Length: 3,835 mm (151 in). Span: 1,422 mm (56 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

white glass 1100mm diameter span steel shaft 114mm diameter x 625mm length Diameter: 142 mm (5.6 in). Length: 3,655 mm (143.9 in). Span: 1,100 mm (43.3 in). Vessel Size: 7,500 L (1,981 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 114.3 mm (4.5 in). Length: 3,810 mm (150 in). Span: 1,219 mm (48 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,829 mm (72 in). Glass Agitator Type: 3 Blade Retreat Curve.

seal size on glass=135mm dimensions to glass=490mm white glass Diameter: 170 mm (6.7 in). Length: 5,250 mm (206.7 in). Span: 1,600 mm (63 in). Vessel Size: 20,000 L (5,283 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 76.2 mm (3 in). Length: 1,753 mm (69 in). Span: 762 mm (30 in). Glass Agitator Type: 3 Blade Retreat Curve.

single flight with 5.5" mechanical surface Diameter: 139.7 mm (5.5 in). Length: 5,353 mm (210.8 in). Vessel Size: 30,283 L (8,000 gallons). Glass Agitator Type: Cryo-Lock.

impellor agitator for reactor Vessel Size: 4,000 L (1,057 gallons).

Vessel Size: 567.8 L (150 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 101.6 mm (4 in). Length: 2,870 mm (113 in). Span: 1,168 mm (46 in). Glass Agitator Type: 3 Blade Retreat Curve.

6DTW drive end Diameter: 120.7 mm (4.8 in). Length: 3,835 mm (151 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

white glass End shape: Tapered 100mm seal area Fits 3800 liter reactor. Diameter: 101.6 mm (4 in). Length: 2,946 mm (116 in). Span: 1,080 mm (42.5 in). Vessel Size: 3,800 L (1,004 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

nucerite 3-blade retreat curve agit W/2" dia seal area for a mech seal. For 1.5TW drive. Diameter: 50.8 mm (2 in). Length: 1,168 mm (46 in). Span: 558.8 mm (22 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 38.1 mm (1.5 in). Length: 857.3 mm (33.8 in). Span: 406.4 mm (16 in). Vessel Size: 75.7 L (20 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Flared end. Fits 1900-2800 liter reactor. Diameter: 139.7 mm (5.5 in). Length: 2,692 mm (106 in). Span: 1,200 mm (47.2 in). Vessel Size: 2,800 L (739.7 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

DTW drive end Fits a 200 gallon reactor Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

61 1/2" long 3/4" DTW drive end Fits a 200 EM series reactor Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Glass Agitator Type: 3 Blade Retreat Curve.

3/4" DTW drive end Fits a 200 EM series reactor Diameter: 76.2 mm (3 in). Length: 1,537 mm (60.5 in). Span: 762 mm (30 in). Glass Agitator Type: 3 Blade Retreat Curve.

3/4" DTW drive end Fits a 500 R-60 series reactor Diameter: 76.2 mm (3 in). Length: 1,937 mm (76.3 in). Span: 762 mm (30 in). Glass Agitator Type: 3 Blade Retreat Curve.

4" DTW drive end Fits a 500 RA series reactor Diameter: 76.2 mm (3 in). Length: 2,210 mm (87 in). Span: 914.4 mm (36 in). Glass Agitator Type: 3 Blade Retreat Curve.

101 1/4" long 3/4" DTW drive end Diameter: 76.2 mm (3 in). Length: 2,648 mm (104.3 in). Span: 914.4 mm (36 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

5" DTW drive end Fits a 1000/1500 gallon reactor Diameter: 88.9 mm (3.5 in). Length: 2,692 mm (106 in). Span: 914.4 mm (36 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

RCI agitator with a 5 RW drive end Fits 1000/1500 gallon Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons).

RCI agitator with a 5 RW drive end Fits 750 gallon Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons).

with a 5 RW drive end Fits 1000/1500 gallon Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons).

SHAFT Glass Agitator Type: 3 Blade Retreat Curve.

RCI agitator

with a 4 DTW drive end Fits a 500-750 gallon reactor Diameter: 63.5 mm (2.5 in). Length: 2,565 mm (101 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: Cryo-Lock.

RCI agitator Designed to fit a 100 gallon EM series reactor Diameter: 69.9 mm (2.8 in). Length: 1,343 mm (52.9 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons).

RCI agitator 3/4 " DTW drive end Designed to fit a 100 gallon ES series reactor Diameter: 88.9 mm (3.5 in). Length: 1,562 mm (61.5 in). Span: 762 mm (30 in). Vessel Size: 378.5 L (100 gallons).

3/4" DTW drive end Diameter: 88.9 mm (3.5 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

PTE drive end Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Glass Agitator Type: 3 Blade Retreat Curve.

CBT hub Fits 300/500 gallon Diameter: 114.3 mm (4.5 in). Span: 584.2 mm (23 in). Vessel Size: 1,893 L (500 gallons).

Ceramic Coating With 3 1/2" dia seal area for a mech seal Ceramic Coating drive Diameter: 88.9 mm (3.5 in). Length: 3,150 mm (124 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

W/3" x 10" Hastelloy sleeve. Packing gland. For PTE drive. RA Series reactor. Diameter: 88.9 mm (3.5 in). Length: 3,150 mm (124 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

135mm seal size on glass dimensions to glass=1670mm blue glass Diameter: 124 mm (4.9 in). Length: 5,100 mm (200.8 in). Span: 1,240 mm (48.8 in). Vessel Size: 8,000 L (2,113 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

nucerite anchor agit. W/3" dia seal area, for a mech seal. For 4TW drive. Fits 300 gal EL Series reactor. Diameter: 76.2 mm (3 in). Length: 1,854 mm (73 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: Anchor.

Cryo-Lock shaft Glass Agitator Type: Cryo-Lock.

with 2.5DTW drive. Diameter: 38.1 mm (1.5 in). Length: 1,118 mm (44 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

3DTW drive end Designed to fit a 200 gallon EM series reactor. Diameter: 76.2 mm (3 in). Length: 1,562 mm (61.5 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons).

PBT hub with a 5.5" diametre hub. Clockwise rotation Diameter: 1,092 mm (43 in). Glass Agitator Type: Cryo-Lock.

Cryo-Lock blade CBT with a 3.5" diameter hub clockwise rotation. Diameter: 838.2 mm (33 in). Glass Agitator Type: Cryo-Lock.

PBT hub,with a 3.5" diameter bore. Clockwise rotation Diameter: 1,092 mm (43 in).

with 2.5DTW drive Diameter: 38.1 mm (1.5 in). Length: 1,207 mm (47.5 in). Span: 508 mm (20 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

PBT hub,with a 3.5" diameter hub. Clockwise rotation. Diameter: 1,092 mm (43 in).

with a DTW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,835 mm (151 in). Span: 1,118 mm (44 in).

CBT hub 34" span with a 3" bore. Diameter: 76.2 mm (3 in). Span: 838.2 mm (33 in).

Cryo-lock agitator shaft, for a 4 DTW drive Diameter: 76.2 mm (3 in). Length: 3,016 mm (118.8 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock.

CBT Hub

Cryo-lock agitator shaft, for a 5 RW drive Diameter: 76.2 mm (3 in). Length: 3,210 mm (126.4 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock.

Diameter: 88.9 mm (3.5 in). Length: 3,073 mm (121 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons).

with a PTE drive end Length: 3,835 mm (151 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons).

with a 5 RW drive end Diameter: 76.2 mm (3 in). Length: 3,200 mm (126 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons).

blue glass With 2 3/4" (70mm) dia seal area for a mech seal. For VS10 drive. E2000 Series reactor. Diameter: 88.9 mm (3.5 in). Length: 2,642 mm (104 in). Span: 939.8 mm (37 in). Vessel Size: 1,987 L (525 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

white glass W/3" dia seal area, for a mech seal W/special drive end, for non-metallic seal For PTE-08 Phila drive Fits 1,000 gal SA Series reactor. Diameter: 88.9 mm (3.5 in). Length: 3,302 mm (130 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

With 2 3/4" dia seal area for a mech seal. For TW drive. Fits 300 gal EL Series reactor Diameter: 76.2 mm (3 in). Length: 1,829 mm (72 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Has threaded end. 100mm seal area. Fits 1900 liter reactor. Diameter: 101.6 mm (4 in). Length: 2,642 mm (104 in). Span: 1,000 mm (39.4 in). Vessel Size: 1,900 L (501.9 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

nucerite With 3 1/2" dia seal area for a mech seal. For 5TW drive. Fits 750 gal RA Series reactor. Diameter: 88.9 mm (3.5 in). Length: 2,591 mm (102 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

2.5 DTW drive end. Diameter: 63.5 mm (2.5 in). Length: 1,003 mm (39.5 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

CBT hub clockwise rotation with 3 1/2" bore Span: 838.2 mm (33 in). Vessel Size: 7,571 L (2,000 gallons).

PTE-10 drive end. Diameter: 76.2 mm (3 in). Length: 3,861 mm (152 in). Span: 1,118 mm (44 in). Vessel Size: 2,000 L (528.3 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Cryo-Lock shaft. Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock.

with a PTE -08 drive end. Diameter: 76.2 mm (3 in). Length: 3,277 mm (129 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons).

with a PTE-6 drive end Diameter: 63.5 mm (2.5 in). Length: 2,667 mm (105 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons).

5 RW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,708 mm (146 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock.

CBT hub Diameter: 76.2 mm (3 in).

2.5 DTW drive end. Diameter: 38.1 mm (1.5 in). Length: 1,524 mm (60 in). Span: 609.6 mm (24 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Fits 1,500 gal reactor. Diameter: 88.9 mm (3.5 in). Length: 3,048 mm (120 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Cryo-Lock shaft, Measures 146 1/2" OAL x 3.5" diameter. Diameter: 88.9 mm (3.5 in). Length: 3,721 mm (146.5 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock.

Diameter: 88.9 mm (3.5 in). Length: 3,721 mm (146.5 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock.

CBT Hub clockwise rotataion with 3 1/2" bore. Diameter: 88.9 mm (3.5 in). Span: 838.2 mm (33 in).

CBT hub with a 3.5" bore. Diameter: 838.2 mm (33 in). Glass Agitator Type: Cryo-Lock.

2.5 DTW drive end Reglassed by UGE 2007. Diameter: 38.1 mm (1.5 in). Length: 1,124 mm (44.3 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Diameter: 38.1 mm (1.5 in). Length: 1,124 mm (44.3 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Fits 7-8 RW drive end Reglassed: Yes.

For Pfaudler E4000 reactor w/VS10 drive end. Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

5RW drive end Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Drive end: 2.5 DTW Reglassed by UGE 2006 Diameter: 76.2 mm (3 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

Four blade retreat curve Rotation: Clockwise for clamp top reactor Diameter: 38.1 mm (1.5 in). Length: 1,530 mm (60.3 in). Span: 368.3 mm (14.5 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: CBT. Rotation: Clockwise.

Drive end: 2.5 DTW Reglassed by: UGE Year of reglassing: 2006 Diameter: 38.1 mm (1.5 in). Length: 857.3 mm (33.8 in). Span: 406.4 mm (16 in). Vessel Size: 75.7 L (20 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

2.5DTW drive end P series Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

43" diameter PBT hub 8.5" wide with a 4.5" hub Clockwise rotation Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: Pitch Turbine. Reglassed: Yes. Rotation: Clockwise.

PBT Blades Counter clockwise rotation Diameter: 139.7 mm (5.5 in). Span: 1,422 mm (56 in). Vessel Size: 30,283 L (8,000 gallons). Glass Agitator Type: Pitch Turbine. Reglassed: Yes. Rotation: Counterclockwise.

CBT clockwise rotation. 2000/1000 gallon reactor. Diameter: 114.3 mm (4.5 in). Span: 838.2 mm (33 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: CBT. Reglassed: Yes. Rotation: Clockwise.

CBT clockwise rotation. 2000/1000 gallon reactor. Diameter: 114.3 mm (4.5 in). Span: 838.2 mm (33 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: CBT. Reglassed: Yes. Rotation: Clockwise.

REGLASSED Fits a 200 Gallon reactor. Diameter: 76.2 mm (3 in). Length: 1,562 mm (61.5 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

VBT hub 5000/6000 gallon reactor Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Vessel Size: 22,712 L (6,000 gallons).

1.5/16" diameter 2.5 DTW drive end. Fits a P20 Gallon reactor Diameter: 38.1 mm (1.5 in). Length: 857.3 mm (33.8 in). Span: 406.4 mm (16 in). Vessel Size: 75.7 L (20 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

114.25 mm (4.5")diameter hub Designed for clockwise rotation Fits a 1500/2000 Gallon reactor. Diameter: 812.8 mm (32 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: CBT. Reglassed: Yes.

129.6 mm (5.1") diameter Designed for clockwise rotation Fits a 3000/4000 Gallon reactor. Diameter: 1,041 mm (41 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: CBT. Reglassed: Yes.

114.25 mm(4.5") hub. Designed for counter clockwise rotation. Fits a 750/1000 Gallon reactor Diameter: 685.8 mm (27 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

114.25 mm(4.5") hub. Designed for counter clockwise rotation. Fits a 750/1000 Gallon reactor. Diameter: 685.8 mm (27 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

• 139.5 mm (5.5") hub
• Designed for counter clockwise rotation
• Fits a 5000 gallon reactor. Diameter: 1,092 mm (43 in). Vessel Size: 18,927 L (5,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

114.25 mm (5.5") hub Rotation direction: Counter clockwise Compatibility: Fits a 5000 gallon reactor Diameter: 1,092 mm (43 in). Vessel Size: 18,927 L (5,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

Designed to operate counterclockwise. Fits an RA 4000 gallon reactor. Diameter: 139.7 mm (5.5 in). Length: 4,648 mm (183 in). Span: 1,372 mm (54 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

For a ELL reactor with a 4TW end Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

Designed to rotate counter clockwise 1500-2000 gallon reactor Diameter: 88.9 mm (3.5 in). Span: 889 mm (35 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Rotation: Counterclockwise.

Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

43" PBT clock wise rotation 1 glass line Cryolock blade set Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Glass Agitator Type: Pitch Turbine. Rotation: Clockwise.

6-1/8” diameter seal area Upper hub measures 5.5” center hub is 4.5” lower hub is 3.5" Diameter: 158.8 mm (6.3 in). Length: 5,851 mm (230.4 in). Vessel Size: 30,283 L (8,000 gallons). Glass Agitator Type: Cryo-Lock.

PBT Blade Diameter: 114.3 mm (4.5 in). Span: 1,219 mm (48 in). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Rotation: Counterclockwise.

Counter clockwise rotation Diameter: 114.3 mm (4.5 in). Span: 1,219 mm (48 in). Glass Agitator Type: Pitch Turbine. Reglassed: Yes. Rotation: Counterclockwise.

5RW drive end Seal area plated with stainless steel Counter clockwise rotation RA reactor Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Fabricated CW CBT 41" /4.5" -Rough Diameter: 114.3 mm (4.5 in). Span: 1,041 mm (41 in). Glass Agitator Type: CBT. Rotation: Clockwise.

Fabricated CW CBT 33"/ 3.5" -Rough Diameter: 88.9 mm (3.5 in). Span: 838.2 mm (33 in). Glass Agitator Type: CBT. Rotation: Clockwise.

new fabricated Cryo-Lock CCW CBT 41"/4.5" diameter shaft size. Counterclockwise rotation Fits a 3,000-4,000 Gallon. Diameter: 114.3 mm (4.5 in). Span: 1,041 mm (41 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: CBT. Rotation: Counterclockwise.

Special RA1500 Gallon with a 63Q10 end. Diameter: 92.1 mm (3.6 in). Length: 3,473 mm (136.8 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise.

Fabricated Cryo-Lock CCW CBT 33"/3.5-Rough Diameter: 88.9 mm (3.5 in). Span: 838.2 mm (33 in). Glass Agitator Type: CBT. Rotation: Counterclockwise.

4RW drive end Diameter: 76.2 mm (3 in). Length: 2,089 mm (82.3 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

impellor agitator 5DTW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

with 5RW drive end Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

impellor agitator 5DTW drive end Reglassed by UGE 2007. Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

Diameter: 38.1 mm (1.5 in). Length: 857.3 mm (33.8 in). Span: 406.4 mm (16 in). Vessel Size: 75.7 L (20 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

5RW drive end Fits a 1000 or 1500 Gallon reactor Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Reglassed by UGE 2006. Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

DTW drive end Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Fits an RA-2000 reactor Diameter: 88.9 mm (3.5 in). Length: 3,534 mm (139.1 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock. Glass Agitator Drive Model: TW.

5RW drive end. Plated seal. Diameter: 88.9 mm (3.5 in). Length: 3,207 mm (126.3 in). Span: 838.2 mm (33 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

RA 750 gallon 5 DTW drive end. Diameter: 88.9 mm (3.5 in). Length: 2,591 mm (102 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

5RW drive end Reglassed by UGE 2008 Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Diameter: 76.2 mm (3 in). Length: 1,562 mm (61.5 in). Span: 762 mm (30 in). Vessel Size: 567.8 L (150 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

CBT hub Designed for clockwise rotation Diameter: 114.3 mm (4.5 in). Span: 1,041 mm (41 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: CBT. Reglassed: Yes. Rotation: Clockwise.

PBT hub, wide with a 4.5" hub Clockwise rotation. Diameter: 76.2 mm (3 in). Length: 1,854 mm (73 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: Cryo-Lock. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

counterclockwise rotation 3DTW drive end Designed to fit a EL 300 series reactor. Diameter: 76.2 mm (3 in). Length: 1,854 mm (73 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Counterclockwise rotation Drive end fits a 2.5 DTW Fits a P & ES 100 Gallon reactor Diameter: 38.1 mm (1.5 in). Length: 1,435 mm (56.5 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Counterclockwise rotation 3-4 DTW drive end Fits an EL500 Gallon reactor Diameter: 76.2 mm (3 in). Length: 2,572 mm (101.3 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

nucerite 3-blade retreat curve agit With 3 1/2" dia seal area for a mech seal. For 5DTW drive. Fits 1,1000 gal RA Series reactor. Diameter: 88.9 mm (3.5 in). Length: 3,124 mm (123 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

Good agitator light blue nucerite. W/3" dia seal area for a mech seal For 3/4 RW drive ELL Series reactor Diameter: 88.9 mm (3.5 in). Length: 2,096 mm (82.5 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons).

with 5RW drive end. Fits a 750 gallon reactor. Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

nucerite Fits a 3 or 4DTW drive Fits 500 gal ELL Series reactor. Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

One set of 44" span glass lined RCI impeller blades Diameter: 88.9 mm (3.5 in). Span: 1,118 mm (44 in). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

nucerite cryolock agit shaft. W/3" dia seal for a mech seal. W/RW end. For RW drive. Fits 1000/1500 gal reactor. Diameter: 88.9 mm (3.5 in). Length: 2,997 mm (118 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

Fits ELL 500 gallon reactor Diameter: 76.2 mm (3 in). Length: 2,096 mm (82.5 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

H Baffle. With 1 1/8" RTD hole. Diameter: 76.2 mm (3 in). Length: 1,308 mm (51.5 in). Vessel Size: 757.1 L (200 gallons).

Capacity: 6000/8000 gallons 4-1/2" dia for blades with RW drive end. Diameter: 152.4 mm (6 in). Length: 5,220 mm (205.5 in). Vessel Size: 30,283 L (8,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

Press Lock WB T blades Top set only Diameter: 127 mm (5 in). Span: 1,194 mm (47 in).

Press Lock WB T blades Top set only Diameter: 127 mm (5 in). Span: 1,194 mm (47 in).

Press Lock RCI blades bottom set only Diameter: 69.9 mm (2.8 in). Span: 838.2 mm (33 in).

Press Lock RCI Blades bottom set only Diameter: 109.5 mm (4.3 in). Span: 838.2 mm (33 in).

Press Lock RCI bottom blade set For a 5000 gallon reactor Diameter: 117.3 mm (4.6 in). Span: 1,092 mm (43 in). Vessel Size: 18,927 L (5,000 gallons).

VBT hub Set Fits a 5000/6000 gallon reactor . Diameter: 127 mm (5 in). Span: 1,092 mm (43 in). Vessel Size: 22,712 L (6,000 gallons).

VBT hub Lower Set Fits a 5000/6000 gallon reactor . Diameter: 127 mm (5 in). Span: 1,092 mm (43 in). Vessel Size: 22,712 L (6,000 gallons).

VBT hub , with a 5” bore. Fits a 5000/6000 gallon reactor . Diameter: 127 mm (5 in). Span: 1,092 mm (43 in). Vessel Size: 22,712 L (6,000 gallons).

VBT hub with 4.5” bore Fits 4000/5000 gallon reactors Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Vessel Size: 18,927 L (5,000 gallons).

VBT hub with 4.5” bore Fits 4000/5000 gallon reactors Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Vessel Size: 18,927 L (5,000 gallons).

Cryo-Lock CBT hub clockwise rotation Diameter: 88.9 mm (3.5 in). Span: 838.2 mm (33 in). Glass Agitator Type: Cryo-Lock.

VBT hub Fits a 5000/6000 gallon reactor Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Vessel Size: 22,712 L (6,000 gallons).

5000/6000 gallon reactor Diameter: 114.3 mm (4.5 in). Span: 1,092 mm (43 in). Vessel Size: 22,712 L (6,000 gallons).

Press-lock agitator shaft Diameter: 88.9 mm (3.5 in). Length: 3,620 mm (142.5 in).

Cryo-Lock shaft for 7/8 RW drive. 5.5" diameter hub, Has stainless steel inlay for mechanical seal. Diameter: 139.7 mm (5.5 in). Length: 4,572 mm (180 in). Vessel Size: 18,927 L (5,000 gallons). Glass Agitator Type: Cryo-Lock.

Turbine: 4 blade Rotation direction: Clockwise Reactor size: 750-1000 gallons Diameter: 63.5 mm (2.5 in). Span: 736.6 mm (29 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock.

dark blue glass. RW drive end. Can be used with IPP stock Number 206796, unjacketed special offset drive reactor. Check if it can be sold separately before selling. Diameter: 88.9 mm (3.5 in). Length: 3,454 mm (136 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock.

counter clockwise rotation For RA500 with 4RW drive end. Diameter: 76.2 mm (3 in). Length: 2,724 mm (107.3 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

with a 3 DTW drive end EM reactor Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Curved Blade Turbine Dark blue glass Clockwise rotation Fits a 300-500 Gallon reactor Diameter: 63.5 mm (2.5 in). Span: 584.2 mm (23 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: CBT. Reglassed: Yes. Rotation: Clockwise.

Unused with a 5RW drive end Diameter: 88.9 mm (3.5 in). Length: 3,727 mm (146.8 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

Good Used

• Cryo Lock blade set, CBT
• 750-1000 gal RA & RS reactor Diameter: 63.5 mm (2.5 in). Span: 736.6 mm (29 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

2.5 DTW drive end "P" series reactor Diameter: 38.1 mm (1.5 in). Length: 1,124 mm (44.3 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

with 5 DTW end Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

2 piece blades Cryo-Lock 3 blade retreat curve hub 3.5" hub Counterclockwise rotation Diameter: 88.9 mm (3.5 in). Span: 1,118 mm (44 in). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Rotation: Counterclockwise.

three tier cryolock shaft Upper tier diameter: 5.5 inches Center tier diameter: 4.5 inches Lower hub diameter: 3.5 inches Diameter: 155.4 mm (6.1 in). Length: 5,842 mm (230 in). Vessel Size: 30,283 L (8,000 gallons). Dual Tier: Yes. Glass Agitator Type: Cryo-Lock.

Counter clockwise rotation CBT hub Fits a 300-500 gallon reactor. Diameter: 88.9 mm (3.5 in). Span: 584.2 mm (23 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: CBT. Reglassed: Yes. Rotation: Counterclockwise.

Diameter: 76.2 mm (3 in). Length: 3,239 mm (127.5 in). Span: 1,118 mm (44 in).

agitator PBT Glass Agitator Type: Cryo-Lock.

Diameter: 76.2 mm (3 in). Length: 1,854 mm (73 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: Cryo-Lock.

Good Used 1000/1500 gallon Diameter: 88.9 mm (3.5 in). Length: 3,073 mm (121 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: Cryo-Lock.

retreat curve impellor agitator Diameter: 50.8 mm (2 in). Length: 933.5 mm (36.8 in). Span: 508 mm (20 in). Glass Agitator Type: 3 Blade Retreat Curve.

Seal area plated with stainless steel. 6 RW drive end Designed to operate counterclockwise. Diameter: 114.3 mm (4.5 in). Length: 4,147 mm (163.3 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

• with 4 RW end
• 3" seal area
• R 42 series reactor Length: 1,930 mm (76 in). Span: 965.2 mm (38 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

4 DTW Drive end Diameter: 82.6 mm (3.3 in). Length: 1,759 mm (69.3 in). Span: 812.8 mm (32 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

4 RW Drive end Diameter: 76.2 mm (3 in). Length: 2,083 mm (82 in). Span: 1,130 mm (44.5 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

no drive end Diameter: 50.8 mm (2 in). Length: 939.8 mm (37 in). Span: 1,130 mm (44.5 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Tw with stuffing box Diameter: 50.8 mm (2 in). Length: 1,003 mm (39.5 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

• CBT Hub
• For use with RA/RS48 300-500gal Diameter: 63.5 mm (2.5 in). Span: 584.2 mm (23 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: CBT. Reglassed: Yes. Rotation: Clockwise.

• CBT blade set
• a 3000-4000 gallon reactor Diameter: 139.7 mm (5.5 in). Span: 1,118 mm (44 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: Cryo-Lock.

• Drive end fits a 5RW gearbox
• Fits an RA gallon reactor Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Fits a RA 500-750 gallon reactor Diameter: 63.5 mm (2.5 in). Length: 2,565 mm (101 in). Span: 19,050 mm (750 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: SRW.

with 5 RW end Diameter: 88.9 mm (3.5 in). Length: 3,810 mm (150 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

1.5" seal area 2.5 DTW drive end Fits a 50 gallon "P" series reactor. Diameter: 38.1 mm (1.5 in). Length: 1,124 mm (44.3 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

1.5" seal area Designed to fit a P30 reactor DTW drive end Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 113.6 L (30 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Rotation: Counterclockwise.

with a counter clockwise rotation Seal size 3" plated with SS. 4 RW drive end Fits a RA 300 reactor Diameter: 76.2 mm (3 in). Length: 2,089 mm (82.3 in). Span: 914.4 mm (36 in). Vessel Size: 1,136 L (300 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

• Designed to fit an RA 750 reactor
• Has a 5RW end
• seal size of 3.5"
• Glass type C2312 Diameter: 88.9 mm (3.5 in). Length: 2,781 mm (109.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

5RW drive end Counter clockwise rotation Fits an RA 2000 reactor. Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Glass Agitator Drive Model: RW.

6DTW end. Diameter: 114.3 mm (4.5 in). Length: 3,677 mm (144.8 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: Cryo-Lock.

Agitator end type: RW end Diameter: 88.9 mm (3.5 in). Length: 3,277 mm (129 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

Diameter: 38.1 mm (1.5 in). Length: 781.1 mm (30.8 in). Span: 304.8 mm (12 in). Vessel Size: 37.9 L (10 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Diameter: 38.1 mm (1.5 in). Length: 781.1 mm (30.8 in). Span: 304.8 mm (12 in). Vessel Size: 37.9 L (10 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Cryolock pitch blade turbine set with 3 1/2" bore. Diameter: 88.9 mm (3.5 in). Span: 889 mm (35 in). Glass Agitator Type: Cryo-Lock.

Drive end: 3 DTW Diameter: 76.2 mm (3 in). Length: 1,562 mm (61.5 in). Span: 812.8 mm (32 in). Vessel Size: 567.8 L (150 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

EM series reactor Diameter: 38.1 mm (1.5 in). Length: 1,435 mm (56.5 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

Fits a 1,000/1,500 gallon reactor. 5RW drive end Diameter: 88.9 mm (3.5 in). Length: 3,213 mm (126.5 in). Vessel Size: 5,678 L (1,500 gallons). Dual Tier: Yes. Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

turbine Hub 3.5" center opening for shaft Designed to operate counter clockwise Diameter: 584.2 mm (23 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

RCI Agitator drive end cut off Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,118 mm (44 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

impellor agit For E2000 Series reactor Glass Agitator Type: 3 Blade Retreat Curve.

impellor agit E4000 Series reactor Glass Agitator Type: 3 Blade Retreat Curve.

nucerite 3-blade impellor agit. Seal diameter: 3" (76mm) Mechanical seal compatibility: VS10 Reactor series: CE4000 Diameter: 114.3 mm (4.5 in). Length: 2,997 mm (118 in). Span: 965.2 mm (38 in). Glass Agitator Type: 3 Blade Retreat Curve.

impellor agit. Seal dia. 4" (100mm) for VS20 seal, white glass.
For CE4000 Series reactor. Diameter: 114.3 mm (4.5 in). Length: 3,048 mm (120 in). Span: 1,118 mm (44 in). Glass Agitator Type: 3 Blade Retreat Curve.

anchor agit For 8,000 liter reactor Vessel Size: 8,000 L (2,113 gallons). Glass Agitator Type: Anchor.

anchor agit For 1600 liter reactor Vessel Size: 1,600 L (422.7 gallons). Glass Agitator Type: Anchor.

anchor agit For 4,000 liter reactor Vessel Size: 4,000 L (1,057 gallons). Glass Agitator Type: Anchor.

3-blade impellor agit. VS20 seal blue glass shaft seal dia 100mm For E4000 Series reactor Diameter: 114.3 mm (4.5 in). Length: 3,048 mm (120 in). Span: 1,118 mm (44 in).

nucerite Diameter: 101.6 mm (4 in). Length: 2,413 mm (95 in). Span: 1,016 mm (40 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Fits 3,000 gal RA/SA Series reactor Diameter: 152.4 mm (6 in). Length: 3,810 mm (150 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

EM series RCI agitator Diameter: 76.2 mm (3 in). Length: 1,562 mm (61.5 in). Span: 762 mm (30 in). Vessel Size: 567.8 L (150 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

Drive end: RW Reglassed by UGE in 2008. Diameter: 139.7 mm (5.5 in). Length: 5,105 mm (201 in). Span: 1,372 mm (54 in). Vessel Size: 18,927 L (5,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Cryolock Pitch Blade Turbine Rotation direction: Clockwise Diameter: 88.9 mm (3.5 in). Span: 1,092 mm (43 in). Glass Agitator Type: Pitch Turbine. Rotation: Clockwise.

Unused 1500/2000 gal Glaslock Turbine paddle model #850 8" x 10" paddle Diameter: 59.7 mm (2.4 in). Vessel Size: 7,571 L (2,000 gallons).

69.5" long 3DTW drive end Fits an EM200 series reactor. Diameter: 76.2 mm (3 in). Length: 1,765 mm (69.5 in). Span: 762 mm (30 in). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Flat blade turbine (VBT) with 4 1/2" bore (7" OD) (1) Upper teir turbine for dual shaft. Diameter: 114.3 mm (4.5 in). Span: 965.2 mm (38 in). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

and a counter clockwise rotation. 2.5 DTW drive end Diameter: 38.1 mm (1.5 in). Length: 1,435 mm (56.5 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Drive end: 2.5 DTW Model: P series Diameter: 38.1 mm (1.5 in). Length: 857.3 mm (33.8 in). Span: 406.4 mm (16 in). Vessel Size: 75.7 L (20 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

End for a 5 RW drive Light blue glass Fits a 1500/1000 gallon reactor. Fits a 1500/1000 gallon reactor Diameter: 88.9 mm (3.5 in). Length: 3,239 mm (127.5 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

5RW drive end Fits a 1000-1500 Gallon reactor. Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Diameter: 88.9 mm (3.5 in). Length: 2,572 mm (101.3 in). Span: 914.4 mm (36 in). Glass Agitator Type: 3 Blade Retreat Curve.

RS or K series 3.5" machined area for cryolock hub Stainless steel plated seal area Diameter: 88.9 mm (3.5 in). Length: 3,727 mm (146.8 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

PTE drive end. with a 7RW drive end. Designed to operate counter clockwise. Fits an RA 4000 Reactor. Diameter: 139.7 mm (5.5 in). Length: 5,042 mm (198.5 in). Span: 1,372 mm (54 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Beavertail baffle With integral tip Diameter: 73 mm (2.9 in). Length: 1,378 mm (54.3 in). Span: 146.1 mm (5.8 in). Vessel Size: 757.1 L (200 gallons). Reglassed: Yes.

5DTW drive end Fits a 1000-1500 Gallon reactor Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Diameter: 38.1 mm (1.5 in). Length: 1,010 mm (39.8 in). Span: 406.4 mm (16 in). Vessel Size: 37.9 L (10 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise.

• Has 5 RW Drive end
• Fits 1000-1500 gal RA reactors Diameter: 88.9 mm (3.5 in). Length: 3,207 mm (126.3 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

5RW drive end. Fits a 1000-1500 RA series reactor. Diameter: 88.9 mm (3.5 in). Length: 3,207 mm (126.3 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

• 3/4 DTW end
• Fits 500 gal ELL series
• with a 4DTW drive end. Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

• Seal size is 1.5"
• Fits a 100 gallon P and ES reactor
• With a 2.5 DTW drive end Diameter: 38.1 mm (1.5 in). Length: 1,435 mm (56.5 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

7RW drive end. Diameter: 139.7 mm (5.5 in). Length: 5,042 mm (198.5 in). Span: 1,372 mm (54 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

2.5 DTW drive end "P" series reactor Diameter: 38.1 mm (1.5 in). Length: 781.1 mm (30.8 in). Span: 304.8 mm (12 in). Vessel Size: 37.9 L (10 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

• 2 blade Cryo-Lock blades PBT
• with 3 1/2" bore. (Set of 2.) Diameter: 88.9 mm (3.5 in). Span: 685.8 mm (27 in). Glass Agitator Type: Pitch Turbine. Reglassed: Yes.

2 blade Cryo-Lock hub 1- 2 blade hub only Diameter: 88.9 mm (3.5 in). Span: 889 mm (35 in). Glass Agitator Type: Pitch Turbine. Reglassed: Yes.

38" span Turbine VBT.-2 hubs 2 blade Cryo-Lock hub with 4 1/2" bore Diameter: 114.3 mm (4.5 in). Span: 965.2 mm (38 in). Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

agitator shaft with 3525 end 2 1/2" seal area 3525 SRW drive end RA reactor Diameter: 63.5 mm (2.5 in). Length: 3,150 mm (124 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: SRW.

4 TW end Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

5 RW drive end RA 1000-1500 gallon reactor Diameter: 88.9 mm (3.5 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: RW.

Fabricated CW CBT 23"/3.5" -Rough Diameter: 88.9 mm (3.5 in). Span: 584.2 mm (23 in). Glass Agitator Type: CBT. Rotation: Clockwise.

2.5" seal diameter Diameter: 63.5 mm (2.5 in). Length: 2,057 mm (81 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: SRW.

Cryo-Lock three blade retreat curve impellor turbine with counterclock wise rotation Approximately 3 1/2" bore. (1) set, (2) pieces Diameter: 88.9 mm (3.5 in). Span: 1,118 mm (44 in). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Rotation: Counterclockwise.

shaft 143mm diameter x 4940mm over all length seal size on glass 125mm dimension to glass 490mm Diameter: 120 mm (4.7 in). Length: 4,940 mm (194.5 in). Span: 1,400 mm (55.1 in). Vessel Size: 15,142 L (4,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Rotation: Counterclockwise.

Drive end: 2.5 DTW Diameter: 38.1 mm (1.5 in). Length: 857.3 mm (33.8 in). Span: 406.4 mm (16 in). Vessel Size: 75.7 L (20 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Seal area diameter: 1.5" for a mechanical seal For 2.5 DTW drive Fits a 200 Gallon reactor. Diameter: 38.1 mm (1.5 in). Length: 1,791 mm (70.5 in). Span: 508 mm (20 in). Vessel Size: 757.1 L (200 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

Cryolock Pitched 2-Blade Turbine Two hubs Diameter: 88.9 mm (3.5 in). Span: 889 mm (35 in). Glass Agitator Type: Pitch Turbine.

2.5DTW drive end Diameter: 38.1 mm (1.5 in). Length: 1,435 mm (56.5 in). Span: 609.6 mm (24 in). Vessel Size: 378.5 L (100 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

RA series 5DTW drive end Diameter: 88.9 mm (3.5 in). Length: 3,534 mm (139.1 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: TW.

Diameter: 88.9 mm (3.5 in). Length: 3,013 mm (118.6 in). Span: 736.6 mm (29 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: TW.

counterclockwise rotation Designed to fit an ELL 500 gallon reactor 4TW drive end. Diameter: 76.2 mm (3 in). Length: 1,930 mm (76 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: TW.

Teflon lined RCI agitator 3 or 4 DTW Diameter: 76.2 mm (3 in). Length: 2,223 mm (87.5 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Reglassed: Yes.

Diameter: 76.2 mm (3 in). Length: 2,184 mm (86 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

No end Diameter: 114.3 mm (4.5 in). Length: 2,921 mm (115 in). Span: 1,245 mm (49 in). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

RCI agitator Fits 4RW drive Diameter: 76.2 mm (3 in). Length: 2,731 mm (107.5 in). Vessel Size: 1,893 L (500 gallons). Reglassed: Yes.

with a 6RW drive end Diameter: 114.3 mm (4.5 in). Length: 3,991 mm (157.1 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Glass Agitator Drive Model: RW.

for 6DTW Diameter: 114.3 mm (4.5 in). Length: 3,454 mm (136 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

For packing gland. Fits 300 gal EL Series reactor. Diameter: 88.9 mm (3.5 in). Length: 1,676 mm (66 in). Span: 1,016 mm (40 in). Glass Agitator Type: Anchor. Reglassed: Yes.

Drive end: TW/DTW Diameter: 38.1 mm (1.5 in). Length: 1,118 mm (44 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

with a 5RW drive end. Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Vessel Size: 7,571 L (2,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Glass Agitator Drive Model: RW.

With a 5RW drive end Diameter: 88.9 mm (3.5 in). Length: 3,239 mm (127.5 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Reglassed: Yes. Glass Agitator Drive Model: RW.

4 DTW drive end. Diameter: 88.9 mm (3.5 in). Length: 2,794 mm (110 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

With a 3/4 DTW drive end Diameter: 76.2 mm (3 in). Length: 1,918 mm (75.5 in). Span: 1,118 mm (44 in). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

Diameter: 76.2 mm (3 in). Length: 2,083 mm (82 in). Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: RW.

With PTE-08 drive end Diameter: 88.9 mm (3.5 in). Length: 3,023 mm (119 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Drive Model: Philadelphia.

Diameter: 38.1 mm (1.5 in). Length: 1,181 mm (46.5 in). Span: 304.8 mm (12 in). Vessel Size: 37.9 L (10 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes.

Press Lock RCI blades Bottom set only Diameter: 109.5 mm (4.3 in). Span: 1,092 mm (43 in).

with a 2.5 DTW drive end. Diameter: 38.1 mm (1.5 in). Length: 1,124 mm (44.3 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Glass Agitator Drive Model: DTW.

Good Used tapered to 2 1/2" Diameter: 57.2 mm (2.3 in). Length: 2,692 mm (106 in). Span: 914.4 mm (36 in). Vessel Size: 1,893 L (500 gallons).

with a 5RW drive end Diameter: 88.9 mm (3.5 in). Length: 3,277 mm (129 in). Span: 1,118 mm (44 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Reglassed: Yes. Glass Agitator Drive Model: RW.

RW drive end Diameter: 88.9 mm (3.5 in). Length: 3,213 mm (126.5 in). Vessel Size: 3,785 L (1,000 gallons). Glass Agitator Type: Cryo-Lock. Glass Agitator Drive Model: RW.

Diameter: 736.6 mm (29 in). Span: 736.6 mm (29 in). Vessel Size: 3,785 L (1,000 gallons). Hub size: 3.5. Reglassed: Yes.

Diameter: 76.2 mm (3 in). Length: 2,731 mm (107.5 in). Span: 1,168 mm (46 in). Vessel Size: 2,839 L (750 gallons).

Diameter: 76.2 mm (3 in). Length: 2,731 mm (107.5 in). Span: 1,118 mm (44 in). Vessel Size: 2,839 L (750 gallons).

Diameter: 101.6 mm (4 in). Length: 3,277 mm (129 in). Span: 914.4 mm (36 in). Vessel Size: 3,785 L (1,000 gallons).

Calibration lines: Yes Drive shaft end: Ligthnin 63Q12 Diameter: 88.9 mm (3.5 in). Length: 3,823 mm (150.5 in). Span: 1,372 mm (54 in). Vessel Size: 11,356 L (3,000 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

CBT hub. 750/1000 gallon reactor Diameter: 736.6 mm (29 in). Span: 736.6 mm (29 in). Vessel Size: 3,785 L (1,000 gallons). Hub size: 2.5 Inch. Glass Agitator Type: Cryo-Lock. Reglassed: Yes.

CBT hub clockwise rotation Diameter: 1,041 mm (41 in). Span: 1,041 mm (41 in). Vessel Size: 15,142 L (4,000 gallons). Hub size: 4.5. Glass Agitator Type: Cryo-Lock. Reglassed: Yes. Rotation: Clockwise.

Diameter: 38.1 mm (1.5 in). Length: 1,003 mm (39.5 in). Span: 508 mm (20 in). Vessel Size: 189.3 L (50 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Rotation: Counterclockwise.

Three blade agitator. Span: 1,118 mm (44 in). Vessel Size: 1,893 L (500 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

Diameter: 38.1 mm (1.5 in). Length: 781.1 mm (30.8 in). Span: 304.8 mm (12 in). Vessel Size: 37.9 L (10 gallons). Hub size: . Glass Agitator Type: 3 Blade Retreat Curve. Rotation: Counterclockwise. Glass Agitator Drive Model: DTW.

1000/1500 gallon Diameter: 88.9 mm (3.5 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Glass Agitator Type: 3 Blade Retreat Curve. Glass Agitator Drive Model: DTW.

74mm diameter x 790mm long carbon steel stub shaft anchor height 700mm 2.8m total length glass Blue glass Diameter: 100 mm (3.9 in). Length: 2,800 mm (110.2 in). Span: 1,200 mm (47.2 in). Vessel Size: 3,028 L (800 gallons). Glass Agitator Type: Anchor.

E10000 Series reactor. 870mm long stub end, 120mm diameter seal area white glass Diameter: 180 mm (7.1 in). Length: 4,300 mm (169.3 in). Span: 1,320 mm (52 in). Glass Agitator Type: 3 Blade Retreat Curve.

500mm long carbon steel stub end with keyway 118mm diameter glass seal area Blue glass with white level marking Approx. 660mm from center of shaft to tip of finger Diameter: 140 mm (5.5 in). Length: 4,050 mm (159.4 in). Span: 1,320 mm (52 in). Vessel Size: 10,000 L (2,642 gallons). Glass Agitator Type: 3 Blade Retreat Curve.

End Off agitator shaft Reglassed: Yes.

With a 4RW drive end. Vessel Size: 1,893 L (500 gallons). Reglassed: Yes.

PTE8 drive end Fits a 1000/1500 Gallon. Diameter: 66.5 mm (2.6 in). Length: 3,289 mm (129.5 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Reglassed: Yes.

PTE8 drive end Fits a 1000/1500 Gallon. Diameter: 85.6 mm (3.4 in). Length: 3,099 mm (122 in). Span: 1,118 mm (44 in). Vessel Size: 5,678 L (1,500 gallons). Reglassed: Yes.
