AL-6XN MOC internal min temp -115 degrees F Shared condenser with GL 54 Capacity Design: 189.3 L (50 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 5.2 bar (75 psi). Jacket Temperature: 148.9 °C (300 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes.

clamp Top Reactor with pneumatic lightining drive 0570" thick bottom hea, 0.340 " thick top head Agitator Power: Approx 1/4 HP Agitator Seal: Mechanical seal on shaft Weight with accessories 1475 lbs. Capacity Design: 189.3 L (50 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 248.9 °C (480 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Legs.

high pressure reactor Agitator: top mounted Pro-Quip agitator drive with a flange mounted approx 3 HP motor and mechanical seal on shaft Capacity Design: 189.3 L (50 gallons). Internal Pressure: 17.2 bar (250 psi). Internal Full Vacuum: Yes. Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 180 °C (356 °F). Agitation: Yes. Support Type: Legs.

driven by 1 HP, 3/60/230/460 volt UL label Capacity Design: 378.5 L (100 gallons). Internal Pressure: 5.2 bar (75 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

clamp top reactor 75 PSI with internal vacuum. Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Body Only: Yes. Agitation: Yes. Support Type: Lugs.

Shell Rated 150/FV @ 450 degrees F., conventional jacket rated 150/FV @400 degrees F with welded 2:1 elliptical heads Shell=1.25, Heads= 1.313", jacket=0.75" Two alloy spray balls for CIP. PTFE Dip tube. 24" man way with sight glass assembly and man way assist. With Pro ring. Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Glasslined. Orientation: Vertical. Agitation: Yes. CIP: Yes. Support Type: Lugs.

Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes.

Capacity Design: 189.3 L (50 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 8.6 bar (125 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes.

Capacity Design: 378.5 L (100 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 148.9 °C (300 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes.

Capacity Design: 1,893 L (500 gallons). Body Only: Yes. Orientation: Vertical.

Built 1952 Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Temperature: 260 °C (500 °F). Jacket Pressure: 5.2 bar (75 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes. Orientation: Vertical.

Capacity Design: 757.1 L (200 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

** Customer Owned ****

Base Reactor Body, Rated for FV/25 psi at 350 degrees F. Jacket rated for 120 psi at 350 degrees F Capacity Design: 37.9 L (10 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 176.7 °C (350 °F). Body Only: Yes. Support Type: Legs.

MFR # 12269 Model SA-3000 Special three top lifting lugs, six leg couplings, four side wall lugs Shell=1 & 1/64", heads=1 & 1/64", jacket =5/8" PTE size 10 drive with an EX proof 20 HP motor and a dry seal. 36" main cover. 18" man way with pro ring and sight glass assembly with man way assist. Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F). Orientation: Vertical. Agitation: Yes.

There are no man way covers for this vessel. Instead, this process required a ring and a single use rupture disk. Capacity Design: 34,069 L (9,000 gallons). Internal Pressure: 1.03 bar (15 psi). Internal Full Vacuum: Yes. Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 3.4 bar (50 psi). Jacket Temperature: 148.9 °C (300 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Skirt.

There are no man way covers for this vessel. Instead, this process required a ring and a single use rupture disk. Capacity Design: 34,069 L (9,000 gallons). Internal Pressure: 1.03 bar (15 psi). Internal Full Vacuum: Yes. Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 3.4 bar (50 psi). Jacket Temperature: 148.9 °C (300 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Skirt.

CS jacket on 2350mm of straight side and bottom head Total weight 29200 kg Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Jacket built to ASME code Capacity Design: 39,747 L (10,500 gallons). Internal Pressure: 1.03 bar (15 psi). Internal Temperature: 121.1 °C (250 °F). Jacket Pressure: 2.8 bar (40 psi). Jacket Temperature: 121.1 °C (250 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Shell Rated 150/FV @ 450 degrees F., conventional jacket rated 150/FV @450 degrees F with welded 2:1 elliptical heads Heads= 1.313" jacket=0.75" Two alloy spray balls for CIP Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Glasslined. Orientation: Vertical. Agitation: Yes. CIP: Yes. Support Type: Lugs.

carpenter 20 welded 2:1 elliptical heads Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 5.9 bar (85 psi). Internal Full Vacuum: Yes. Internal Temperature: 100 °C (212 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Jacketed Pressure/Vacuum Reactor with Mixer Jacket rated MAWP for 100 psi @ 338 degrees F., MDMT for -20 degrees F @ 100 psi Vessel has two zone half pipe coil jacket Mixer was a double-motion agitator with scraper blades, but has been converted to a single motion agitator with scrapers Capacity Design: 5,678 L (1,500 gallons). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 170 °C (338 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Jacketed on bottom 1/3 of tank. 78" diameter x 6' tangent to tangent, 3/8" side wal. Capacity Design: 5,678 L (1,500 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 93.3 °C (200 °F). Jacket Pressure: 2.8 bar (40 psi). Jacket Temperature: 93.3 °C (200 °F). Agitation: Yes. Support Type: Legs.

• Wall thickness: 3/16"
• Head thickness: 5/16" Capacity Design: 8,328 L (2,200 gallons). Internal Pressure: 4.1 bar (60 psi). Internal Temperature: 182.2 °C (360 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 182.2 °C (360 °F). Jacket Material of Construction: Inconel. Body Only: Yes.

UNUSED Internal finish 240 grit buff polished-Bright polished, external buff polish to a matte finish. ASME NB rated and "U" stamped. welded dish heads (2:1) 10mm thick. Coil: 114 mm OD x 4 mm thick, Limpet covers bottom dish and 2028 mm of straight-side (pitch 150mm), Span 1000mm. Coil heating surface area. With Insulation rings and upper drip ring. Two top lifting lugs and one tailing lug 18" Manhole with Cover and davit arm assist, One 6" sight glass Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Conventional jacket with welded 2:1 elliptical heads heads= 1.313", jacket = 0.75" Glass lined thermowell PTFE dip tube with calibration lines on body and mixer Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Glasslined. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

-dual rated 150 psi and full vacuum at +450 f/ 71 psi and full vacuum at -50 F internal, dual rated jacketed for150 psi and full vacuum at 450 f/ 70 psi and full vacuum at -50 -9119 glass Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Support Type: Lugs.

biological reactor bioreactor for biopharmaceutical with conventional double jacket TUV Stamped Vessel rated for -1/to +3 bar at 150 degrees C Jacket rated for -1/to +3 bar at 150 degrees C Top side flange mount vertical mixer, driving a single propeller mixer with three blades Nord type SK901/4.TF Motor CE certified Capacity Design: 1,700 L (449.1 gallons). Internal Pressure: 3 bar (43.5 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 316. Orientation: Vertical. Agitation: Yes. CIP: Yes. Support Type: Legs.

• Shell OD: 81"
• Jacket OD: 84" Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 41.4 bar (600 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

0.5 gallon Hastelloy C-276 Lab size pressure reactor Stand mounted with electric drive Moline Ill. Size ML 600 Rated for 3000 psig at 350 degrees C. Electric rating 115v, 60 Hz, 8.1 amps. With three Carbon steel bodies 3" ID x 18", 3" ID x 8", 3" ID x 10".and two 316 SS bodies 3" ID x 32". Capacity Design: 3.8 L (1 gallons). Internal Pressure: 206.8 bar (3,000 psi). Internal Temperature: 176.7 °C (350 °F). Body Only: Yes. Orientation: Vertical. Support Type: Frame Mounted with Feet.

Capacity Design: 7,160 L (1,891 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 100 °C (212 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Body Only: Yes. Support Type: Lugs.

With SS dip tube Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 4.1 bar (60 psi). Internal Full Vacuum: Yes. Internal Temperature: 287.8 °C (550 °F). Jacket Pressure: 6.9 bar (100 psi). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes.

This was currently set up as a distillation system, and can be sold as such, would include column and heat exchanger at additional charge. Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 189.3 L (50 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 7.9 bar (115 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

250 liter type ODE-250-P internal design pressure 6 bar @ 200 degrees C (340 liter) jacket 6 bar @ 200 degrees C (37 liter) jacket on straight side and bottom dish Motor: 3 phase 220/380 volt 316Ti stainless steel anchor agitator packed gland Capacity Design: 250 L (66 gallons). Internal Pressure: 6 bar (87 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

With 2.5DTW drive, belt driven by a 3 HP, 3/60/230/460 volt motor, Capacity Design: 189.3 L (50 gallons). Internal Pressure: 5.5 bar (80 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 148.9 °C (300 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

biological reactor bioreactor for biopharmaceutical with conventional double jacket TUV Stamped Vessel rated for -1/to +3 bar at 150 degrees C Jacket rated for -1/to +3 bar at 150 degrees C Jacket capacity is 150 liters Top side flange mount vertical mixer, driving a single propeller mixer with three blades Nord type SK901/4.TF Motor CE certified Six bottom side nozzles for pH, DO, PO probes etc. With spray ball(S) for CIP Capacity Design: 2,100 L (554.8 gallons). Internal Pressure: 3 bar (43.5 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 316. Orientation: Vertical. Agitation: Yes. CIP: Yes. Support Type: Legs.

Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 5,678 L (1,500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Agitation: Yes.

conventional jacket 2:1 elliptical heads Shell=1 & 1/8", Heads=1.125", jacket=0.75". 24" man way with pro ring and man way assist. With sight glass assembly. Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Capacity Design: 378.5 L (100 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 7.9 bar (115 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

conventional jacket with welded2: 1 elliptical heads Two zone jacket with shell zone surface area of 36 Sq.Ft, and a head surface area of 19.4 Sq.Ft head thickness is =0.813" jacket thickness is=0.5" Capacity Design: 1,136 L (300 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Glasslined. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 8.6 bar (125 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Stainless Steel Other. Orientation: Vertical. Support Type: Ring.

Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes. Support Type: Legs.

No mixer but has drive bosses on top head Capacity Design: 1,893 L (500 gallons). Internal Pressure: 3.8 bar (55 psi). Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 2.8 bar (40 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Base reactor Capacity Design: 757.1 L (200 gallons). Internal Pressure: 5.2 bar (75 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Capacity Design: 757.1 L (200 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Hastelloy C-2000 Certified by Offenhauser Company. 4 turns half pipe on bottom head. 19 turns half pipe on side walls. Capacity Design: 3,218 L (850 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Support Type: Lugs.

(Baffle from 246687) Capacity Design: 37.9 L (10 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 8.6 bar (125 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

agitated, jacketed, reactor. rated atmos internal; SS dimple Jacket covers bottom half of tank and bottom head. Top mounted right angle down agitator drive, direct coupled to a 7.5 HP motor. Reinforcing ring around middle of tank with (4) lugs and legs attached ot the mounting ring. Capacity Design: 9,464 L (2,500 gallons). Internal Pressure: 1.01 bar (14.7 psi). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Stainless Steel Other. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 0.69 bar (10 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 4.1 bar (60 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 4.1 bar (60 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 378.5 L (100 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 7.9 bar (115 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Coil jacketed reactor Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 31 bar (450 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes. Orientation: Vertical.

NEW/UNUSED Internal finish 240 grit buff polished-Bright polished, external buff polish to a matte finish "U" stamped 10 mm thick welded dish heads (2:1) 12 mm thick Coil: 114 mm OD x 4 mm thick Limpet covers bottom dish and 2615 mm of straight side (pitch 150mm) Coil heating surface area With Insulation rings and upper drip ring. Two top lifting lugs and one tailing lug motor UL listed All nozzles have 304 SS flanges Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

UNUSED

Internal finish 240 grit buff polished-Bright polished, external buff polish to a matte finish. ASME NB rated, and "U" stamped.

welded dish heads (2:1) 12 mm thick

Coil: 114 mm OD x 4 mm thick,

Limpet covers bottom dish and 2615 mm of straight side (pitch 150mm). Coil heating surface area.

With Insulation rings and upper drip ring. Two top lifting lugs and one tailing lug.

20" Manhole with Cover and davit arm assist, one 6" sight glass, Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

heads are 7/8" jacket is 7/16" Capacity Design: 22,712 L (6,000 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 4.1 bar (60 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

Reglassed KC series reactor body Manufacturers number 4364421 With (4) side support lugs or (8) leg couplings for mounting/installation. Capacity Design: 18,927 L (5,000 gallons). Internal Pressure: 6.2 bar (90 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 8.6 bar (125 psi). Jacket Temperature: 204.4 °C (400 °F). Body Only: Yes. Support Type: Legs.

Capacity Design: 5,678 L (1,500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Agitation: Yes. Support Type: Legs.

Reglassed KC Series Capacity Design: 18,927 L (5,000 gallons). Internal Pressure: 6.2 bar (90 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 8.6 bar (125 psi). Jacket Temperature: 204.4 °C (400 °F). Body Only: Yes. Support Type: Lugs.

Cryo-Lock with curved blade turbine hub 36" great cover Manway: 18" with pro ring Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

R-0205 Built 2017 Motor EX proof & VFD compatible Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

100/90# DTW Drive Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

RA series reactor assembly Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Jacket rated; 90psi @ 350 degrees F or 80psi @ 400 degrees F. Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.2 bar (90 psi). Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical. Support Type: Legs.

Reactor Bottom bottom only Capacity Design: 1,893 L (500 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

NEW/UNUSED 240 grit buff polished -Bright polished , external buff polish to matte finish. Capacity Design: 22,712 L (6,000 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Body Only: Yes. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Capacity Design: 75.7 L (20 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

• Internal Finish 240 Grit Buff Polished
• With drip ring and Insulation support
• Two lifting lugs, two tailing lugs. Capacity Design: 22,712 L (6,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 111.7 °C (233 °F). Sanitary Construction: Yes. Jacket Pressure: 0.69 bar (10 psi). Jacket Temperature: 111.7 °C (233 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Glasslined. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Conventional jacket head thickness15/16" jacket thickness=35/64" Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Shell rated 150/FV @ 450 degrees F., conventional jacket 150/FV @450 degrees F 2:1 elliptical heads. Shell=1 & 1/8", Heads=1.125", jacket=0.75". PTFE dip tube. 24" man way with pro ring and man way assist. With sight glass assembly. Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

ES series Capacity Design: 189.3 L (50 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

48" ID diameter x 5' 1" tangent to tangent Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Support Type: Legs.

Base reactor Bottom: MFG# J034083 Clamped top: MFG# J034083A Both top and bottom built 2000 Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 5.9 bar (85 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

#5015 Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

3" half pipe, 14 Ga, 6 turns on a 45 degree pitch Capacity Design: 908.5 L (240 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

2000 gallon DeDietrich SA glass line Reactor including body with covers, RW drive with mechanical seal housing bolted in place, mechanical seals, motor, Cry-o-Lock shaft and blades , CBT Hub/Turbine, Baffle, J Bolts. Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 315.6 °C (600 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Reglassed in Year 2000 Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 5.5 bar (80 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Flange mounted Pfaudler 4TW agit drive, Mdl FDWV-50410-7B, SN 82004466-001, rated 7.5 HP, 10:1 ratio, belt driven by 7 1/2 HP, 3/60/230/460 volt, 1750 rpm motor, UL label. Capacity Design: 2,839 L (750 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Inconel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

reactor assembly Vessel rated 150 psi /FV @ 500 degrees F. Conventional jacket rated for FV/150 psi @ 500 degrees F Conventional jacket head thickness15/16" jacket thickness=35/64" Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

reactor assembly. Vessel rated 100/FV @ 500 degrees F head thickness15/16", jacket thickness=35/64".
PTE 08 Drive with estimated 15 HP EXP motor, and stuffing box for seal 30" main cover with 14" x 18" man way, and pro ring and spring assist.. Man way has one 4" nozzle. Sight glass assembly Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Mirror polished Bio Reactor with conventional jacket vessel rated for -1 to +3 bar at 150 degrees C Jacket rated for -1 to +3 bar at 150 degrees C TUV stamped Motor CE certified Jacket volume is 10 liter.
With six bottom side nozzles for electrodes. Equipped with Spray ball(s) for Clean in Place (CIP). Capacity Design: 76 L (20.1 gallons). Internal Pressure: 3 bar (43.5 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 150 °C (302 °F). Orientation: Vertical. Agitation: Yes. CIP: Yes. Support Type: Legs.

Mirror polished Bio Reactor with conventional jacket vessel rated for -1-3 bar at 150 degrees C. Jacket rated for -1-3 bar at 150 degrees C TUV stamped Vertical top mount agitator with double stack up mechanical seal with 2 seal pots Driven agitator is a high polish helical screw drive motor is a Lonne, 50 Hz, 0.6 kW, 1350 rpm, 220/240vac. Motor CE certified Jacket volume is 10 liter With six bottom side nozzles for electrodes Equipped with Spray ball(s) for Clean in Place (CIP) Capacity Design: 75.7 L (20 gallons). Internal Pressure: 3 bar (43.5 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 150 °C (302 °F). Orientation: Vertical. Agitation: Yes. CIP: Yes. Support Type: Legs.

2500 liter driven by a SEW-Eurodrive 4.4kw 3/50/380 volt, 1430 rpm Ex eG3 motor 2.2kw exciter motor, (2) sets of intermig blades on shaft internal pressure 3.2 bar @ -196/+ 00 degrees C (2880 liter) jacket 6 bar @ -196/+100 degrees C (45 liter) mechanical seal with lubricator 2-internal baffles plates on sidewall 304 stainless steel (1.4301) half pipe coil jacket on straight side and bottom dish Capacity Design: 2,880 L (760.8 gallons). Internal Pressure: 3.2 bar (46.4 psi). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Stainless Steel 304. Agitation: Yes. Support Type: Lugs.

2000 liter TUV internal pressure vacuum @ 150 degrees C (2640 liter), jacket 12 bar @ 220 degrees C (85 liter) Ekato agitator drive Capacity Design: 2,640 L (697.4 gallons). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Jacket Pressure: 12 bar (174 psi). Jacket Temperature: 220 °C (428 °F). Agitation: Yes. Support Type: Lugs.

TUV certified and stamped Internal pressure -1/6 bar @ 200 degrees C (2434 liter), jacket -1/20 bar @ 200 degrees C (62 liter) Valves, filters, pipework, etc. may be available. Capacity Design: 2,434 L (643 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 20 bar (290.1 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes.

Internal pressure -1/6 bar @ 200 degrees C (2434 liter) jacket -1/20 bar @ 200 degrees C (62 liter) TUV certified and stamped Valves, filters, pipework, etc. may be available. Capacity Design: 2,434 L (643 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 20 bar (290.1 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes.

TUV Certified internal pressure -1/6 bar @ 200 degrees C (1666 liter) jacket -1/20 bar @ 200 degrees C (60 liter) straight side and bottom dish ancillaries such as valves, filters, pipework etc may be available Capacity Design: 1,666 L (440.1 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 20 bar (290.1 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes. Support Type: Legs.

316Ti (1.4571) stainless steel jacket on lower half of the straight side and bottom dish internal pressure -1/6 bar @ 200 degrees C (1600 liter), jacket 6 bar @ 200 degrees C (170 liter) TUV certified Capacity Design: 1,600 L (422.7 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes. Support Type: Legs.

finished to a mirror buff polish cGMP rated and sanitary construction Rated 3/FV kg/cm2 @ 150 degrees C. Jacket Rated: 3 kg/cm2 @ 150 with welded dished heads (2:1) Motor: .75KW 3/60/220 V Capacity Design: 400 L (105.7 gallons). Internal Pressure: 2.9 bar (42.7 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 2.9 bar (42.7 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

#9115 glass lined diptube Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 5.9 bar (85 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

#5015 Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 5.9 bar (85 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

#5015 Stainless steel diptube Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

• Coils: 6 turns of 3" schedule 10 coil on the side, 2 turns of 3" schedule 10 coil on the bottom Capacity Design: 1,136 L (300 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Bare Reactor Capacity Design: 189.3 L (50 gallons). Internal Pressure: 20.7 bar (300 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

77 psi and full vacuum at -50 F internal. 72 psi and full vacuum at -50 F 9119 glass, Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Support Type: Lugs.

Jacket rated 65 psi with out Full vacuum at 400 degrees F or 50 psi/FV @ 400 degrees F Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 4.5 bar (65 psi). Jacket Temperature: 204.4 °C (400 °F). Body Only: Yes.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 5.2 bar (75 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Support Type: Legs.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

belt driven Capacity Design: 4,500 L (1,189 gallons). Internal Pressure: 2.8 bar (40 psi). Internal Full Vacuum: Yes. Internal Temperature: 203 °C (397.4 °F). Jacket Pressure: 1.72 bar (25 psi). Jacket Temperature: 203 °C (397.4 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes.

belt driven Capacity Design: 4,500 L (1,189 gallons). Internal Pressure: 2.8 bar (40 psi). Internal Full Vacuum: Yes. Internal Temperature: 203 °C (397.4 °F). Jacket Pressure: 1.72 bar (25 psi). Jacket Temperature: 203 °C (397.4 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes.

belt driven Capacity Design: 4,500 L (1,189 gallons). Internal Pressure: 2.8 bar (40 psi). Internal Full Vacuum: Yes. Internal Temperature: 203 °C (397.4 °F). Jacket Pressure: 1.72 bar (25 psi). Jacket Temperature: 203 °C (397.4 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes.

MFR # 0054002044 Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 242.2 °C (468 °F). Body Only: Yes. Support Type: Lugs.

conventional jacket with welded 2:1 elliptical heads Heads= 1.313", jacket=0.75" Jacket heating surface area shell is 117 Sq.Ft., jacket heating surface area bottom head is 75.4 Sq.Ft Two alloy spray balls for CIP PTFE Dip tube Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Glasslined. Orientation: Vertical. Agitation: Yes. CIP: Yes. Support Type: Lugs.

TUV CE0408 Pressure internal 6 bar + vacuum @ 180 degrees C (6990 liter), Jacket 6 bar + vacuum @ 180 degrees C (140 liter) 904L stainless steel body and agitator shaft mechanical seal with lubricator jacket on straight side and bottom dish Capacity Design: 6,990 L (1,847 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 180 °C (356 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 180 °C (356 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes. Support Type: Lugs.

R-0203 Built 2017 Motor EX proof & VFD compatible Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

#5015 MFR# R190-0043 Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

Purchase reactor Assembly Capacity Design: 1,893 L (500 gallons). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Capacity Design: 189.3 L (50 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 378.5 L (100 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 113.6 L (30 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 7.9 bar (115 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Capacity Design: 1,136 L (300 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Base reactor Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical.

clamp top reactor Vessel rated 150 psi at 350 degrees F. Jacket rated FV/120 psi at 350 degrees F Capacity Design: 37.9 L (10 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Shell rated 100/FV @ 450 degrees F, head thickness is=3/8" top & 5/16" bottom. Jacket thickness is 1/4". Capacity Design: 378.5 L (100 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

30" great cover Capacity Design: 7,571 L (2,000 gallons). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

NEW/UNUSED Internal finish 240 grit buff polished-Bright polished external buff polish to a matte finish 10 mm thick welded dish heads (2:1) 10mm thick Coil: 114 mm OD x 4 mm thick, Limpet covers bottom dish and 2028 mm of straight-side (pitch 150mm), Span 1000mm Coil heating surface area With Insulation rings and upper drip ring. Two top lifting lugs and one tailing lug motor UL listed All nozzles have 304 SS flanges Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Sanitary Construction: Yes. Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Agitator drive by Lightnin, with a Louis Allis Pacemaker Motor. Two speed Pacemaker motor, 3.3 -20 HP, 250-1760 RPM, 3 Phase 60 Hz, 460 Volts. Bottom: Center bottom outlet Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 9.1 bar (132 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes. Support Type: Lugs.

1.4529 SS (AL-6XN super-Austenitic SS) fermenter/ reactor with internal cooling coil and sparge ring for gas addition Polished stainless steel interior motor : 3/50/380 volt Bergmann double mechanical seal on shaft

• TUV standard
• Jacket volume: 440 liter Vertical Internal cooling coils rated 13 liter rated -1/6bar@200 degrees C
• Sparge ring in bottom of tank for adding gas into the fermentation process
• Empty weight: 2450 Kg
• Shipping dimensions: Length= 4100 mm; Width= 1800 mm; Height= 1800 mm; Weight= 2450 kg Capacity Design: 3,600 L (951 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes. Support Type: Lugs.

Conventional jacket, welded 2:1 elliptical heads. Shell=0.75", heads= 1.313", jacket = 0.75" Pfaudler 7055 SRW with a 20 HP motor and a 18:1 ratio, with a dry seal. Cryo-Lock mixer 41" CBT hub CW with calibration lines. Two PTFE dip tube, with calibration lines on body and mixer. 24" manway with pro ring, and sight glass assembly and man way assist Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Support Type: Lugs.

Reconditioned Vessel rated for 600 psi at 600 degrees F. jacket good for FV/90 psi at 400 psi Assembled with a reconditioned 4 RDTW drive mechanical seal with new bearings and seals and motor Capacity Design: 1,325 L (350 gallons). Internal Pressure: 41.4 bar (600 psi). Internal Full Vacuum: Yes. Internal Temperature: 315.6 °C (600 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

• Turbines: (1) 4 blade pitched paddle turbine, (1) 4 blade flat disk turbine Capacity Design: 2,271 L (600 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Capacity Design: 757.1 L (200 gallons). Body Only: Yes.

Capacity Design: 113.6 L (30 gallons). Internal Pressure: 9.3 bar (135 psi). Internal Temperature: 315.6 °C (600 °F). Jacket Pressure: 9.3 bar (135 psi). Jacket Temperature: 315.6 °C (600 °F). Jacket Material of Construction: Carbon Steel. Support Type: Legs.

RW drive, mechanical seal and lubricator, 10 HP 3/60/230/460V 1750 RPM motor Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Internal finish: #4 polish-203-30 RA 10 turns 3" half pipe coil on side (0.109" wall) with jumper to 4 turns on bottom Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Sanitary Construction: Yes. Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Stainless Steel 316L. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

• Bottom outlets, 1.5" center bottom, two 0.5" and one 1" Capacity Design: 1,041 L (275 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Jacket Pressure: 3.4 bar (50 psi). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

agitated jacketed reactor. contract number 400978. With glass 3008. Designed Code CODAP 85. 1400 mm diameter x 1611 mm from top flange to bottom discharge nozzle, mechanical seal on shaft with AAA lubricator type YPE A0168. Driven by 4.0 kW 3/50/220/ 380V, 1420 RPM motor. Capacity Design: 2,040 L (538.9 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

Capacity Design: 22,712 L (6,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes.

Capacity Design: 1,136 L (300 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Glasslined. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

90 psi w/full vac int. (4) lugs and (4) sockets for pipe legs. Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Body Only: Yes. Support Type: Legs.

reactor bottom Jacket rated 80 psi @ 350 degrees F, 65 psi w/internal vacuum; internal rated 25 psi/full vac @ 600 degrees F Capacity Design: 1,893 L (500 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 315.6 °C (600 °F). Jacket Pressure: 5.5 bar (80 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical. Support Type: Legs.

60" diameter x 52" to bottom outlet, (4) couplings for pipe legs. Capacity Design: 1,893 L (500 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 5.5 bar (80 psi). Jacket Temperature: 176.7 °C (350 °F). Support Type: Legs.

clamp top reactor body Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

reactor bottom Capacity Design: 1,893 L (500 gallons). Internal Pressure: 1.03 bar (15 psi). Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 4.8 bar (70 psi). Jacket Temperature: 176.7 °C (350 °F). Support Type: Lugs.

reactor bottom 65 psi/full vacuum with full vacuum internal. Capacity Design: 1,893 L (500 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 5.5 bar (80 psi). Jacket Temperature: 176.7 °C (350 °F). Support Type: Legs.

90 psi w/internal vacuum internal rated FV/75 psi @ 500 degrees F Capacity Design: 1,893 L (500 gallons). Internal Pressure: 5.2 bar (75 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Support Type: Legs.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 5.9 bar (85 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Support Type: Legs.

Capacity Design: 113.6 L (30 gallons). Internal Pressure: 4.1 bar (60 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 5.9 bar (85 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Support Type: Legs.

with Pfaudler 2.5 TW drive. 1/4" sid wall and bottom head, CS 2 zone straight jacket. Top Mounted 2.5 TW drive belt driven by approx 1 hp motor. Capacity Design: 113.6 L (30 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Temperature: 260 °C (500 °F). Jacket Pressure: 3.1 bar (45 psi). Jacket Temperature: 260 °C (500 °F). Agitation: Yes. Support Type: Legs.

Capacity Design: 378.5 L (100 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 12.4 bar (180 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Inconel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Internal Coils: Yes, (8) turns 2.5" schedule 160 internal pipe coil Right angle Lightnin Model #86-S-75 agitor drive, SN 92A7774201 Capacity Design: 4,164 L (1,100 gallons). Internal Pressure: 137.9 bar (2,000 psi). Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

no motor Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 3.4 bar (50 psi). Jacket Temperature: 148.9 °C (300 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

carpenter 20
Half pipe coil jackets Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 5.9 bar (85 psi). Internal Full Vacuum: Yes. Internal Temperature: 100 °C (212 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

With a Lightnin Right angle mixer , model 34-C-15, serial # 968835904301 Ratio 25.7,Out put rpm 68, 15 HP recommended. See sales comments regarding Jacket Driven by an AC motor Capacity Design: 12,590 L (3,326 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 121.1 °C (250 °F). Jacket Pressure: 2.8 bar (40 psi). Jacket Temperature: 121.1 °C (250 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Glass lined reactor assembly Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Sanitary Construction: Yes. Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Purchase reactor Assembly Capacity Design: 15,142 L (4,000 gallons). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

base reactor with main cover, agitator shaft and baffle MFRG # 30266 Capacity Design: 22,712 L (6,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F). Agitation: Yes. Support Type: Lugs.

Capacity Design: 22,712 L (6,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Support Type: Legs.

Unit has pedestal for drive mount (no drive). Capacity Design: 492.1 L (130 gallons). Internal Pressure: 68.9 bar (1,000 psi). Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 12.1 bar (175 psi). Jacket Temperature: 343.3 °C (650 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

jkt open top reactor btm Capacity Design: 56.8 L (15 gallons). Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Capacity Design: 1,136 L (300 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical. Agitation: Yes.

• Glass type 3009LB
• Light blue glass -design pressure internal -1/6 bar @ -25/150 degrees C (100 liter) jacket -1/6 bar @ -25/150 degrees C (36 liter)
• Open topped
• CE marked
• Stainless steel cladding/insulation on the straight side Capacity Design: 100 L (26.4 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Jacket Pressure: 16 bar (232.1 psi). Jacket Temperature: 150 °C (302 °F). Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

Drive Motor is CE certified Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 0.69 bar (10 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 4.1 bar (60 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

• Top heads: Schott glass
• Top openings: several, one with a flow valve for regulating feed into the reactor
• Bottom outlet: center with a valve Motor 3 phase, 230/460 volt
• Mounting: designed to mount in a frame. wtih a 3 blade agitator shaft and tantalum diptube/ baffle. Capacity Design: 18.9 L (5 gallons). Internal Pressure: 1.03 bar (15 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 7.6 bar (110 psi). Jacket Temperature: 204.4 °C (400 °F). Orientation: Vertical. Agitation: Yes.

No drive with unit, only drive base with 4 blade Cryolock impellor. Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Support Type: Legs.

No Nameplate Capacity Design: 1,893 L (500 gallons). Orientation: Vertical.

Built 1950 Capacity Design: 3,785 L (1,000 gallons). Orientation: Vertical.

Built Capacity Design: 113.6 L (30 gallons). Orientation: Vertical.

Built 1960 Capacity Design: 189.3 L (50 gallons). Orientation: Vertical.

40 Gallon Jacketed flask Capacity Design: 151.4 L (40 gallons). Orientation: Vertical.

100/90# Capacity Design: 3,785 L (1,000 gallons). Orientation: Vertical.

#5015 Pipe coil jacket MFR # R190-0035 3” center bottom drain Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Support Type: Lugs.

#5015 MFR# R190-0038 Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Support Type: Lugs.

MFR # R185-0129 Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Support Type: Lugs.

60” diameter x 76” deep Capacity Design: 2,839 L (750 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 5.9 bar (85 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical. Agitation: Yes.

Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 5.5 bar (80 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical.

RS series Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 8.6 bar (125 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Order 60670

• Pressure ratings:
• Internal: -1/6 Bar @ -25/+200°C
• Jacket: -1/6 Bar @ -25/+200°C
• Lining material: glass WWG9115
• With a top mounted drive,
• Pfaudler mechanical seal DIN28138-125,
• with thermosyphon vessel Burgmann TS 2000
• Bottom pneumatic outlet valve: APA-BT 150/100 Capacity Design: 11,768 L (3,109 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

6,300 liter order number 60669 Pressure ratings: Internal -1/6 Bar @ -25/+200°C total volume 8,190 liters; Jacket rated -1/6 Bar @ -25/+200°C total volume 795 liters. Lined with glass WWG9115 With a top mounted drive with Burgmann mechanical seal type M462L-D20 and Burgmann Thermosyphon TS 2000 pneumatic bottom outlet valve, and solids dosing device, Capacity Design: 8,190 L (2,164 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Weight empty 4300 lbs Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Orientation: Vertical.

Weight empty 4300 lbs Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Orientation: Vertical.

Jacket type: Coil jacketed Motor is rated 10HP,190/380V, 50HZ @1470 RPM or 15HP, 208-230/460V, 60HZ @1770 RPM. Type: TGS UL class: 1,2 Group: CD,FG Capacity Design: 7,571 L (2,000 gallons). Orientation: Vertical. Agitation: Yes.

Tycon glass lined dual zone coil jacketed reactor Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Agitation: Yes.

Capacity Design: 1,893 L (500 gallons). Orientation: Vertical.

RA series Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical. Support Type: Legs.

Two fin baffles and two dip tubes. Capacity Design: 30,283 L (8,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes. Orientation: Vertical. Agitation: Yes.

Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Agitation: Yes.

Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Agitation: Yes.

glass lined reactor assembly Equipped with 2.5 TW drive with belt driven motor. Capacity Design: 189.3 L (50 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical.

base reactor Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical.

vessel # V2110 built to design code BS5500 CAT2 Capacity Design: 2,270 L (599.7 gallons). Internal Pressure: 5 bar (72.5 psi). Jacket Pressure: 11.3 bar (163.9 psi). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

6300 liter internally rated -1/+6 bar@ -25/+200 deg C Capacity Design: 7,585 L (2,004 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Body Only: Yes. Orientation: Vertical.

6300 liter internally rated -1/+6 bar@ -25/+200 deg C Capacity Design: 7,585 L (2,004 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Body Only: Yes. Orientation: Vertical.

VS20 mechanical seal with lubricator Capacity Design: 4,545 L (1,201 gallons). Internal Pressure: 6.8 bar (99.1 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6.8 bar (99.1 psi). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

VS20 mechanical seal Capacity Design: 4,545 L (1,201 gallons). Internal Pressure: 6.8 bar (99.1 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6.8 bar (99.1 psi). Orientation: Vertical. Support Type: Lugs.

3200 liter internal pressure 6 bar + vacuum @ 200 degrees C (3420 liter), jacket 6 bar @ 200 degrees C (320 liter), motor : 3/50/220/380 Capacity Design: 3,420 L (903.5 gallons). Internal Pressure: 6 bar (87 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Email type: 3008 (blue) driven by 3 kw, 3/50/60/220-480 volt, 1465-1760 rpm motor Capacity Design: 6,850 L (1,810 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes.

auftr number: 61505/R96, Glass type: WWG-9115, Pfaudler VS0-20G agitator drive, belt driven by 22kw, 3/50/290/500 volt, 1455 rpm motor, TUV certified. Capacity Design: 3,110 L (821.6 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Capacity Design: 2,000 L (528.3 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical.

driven by 4/4,5 kW internal pressure -1/6 bar @ 200 Degrees C, jacket 6 bar @ 200 Degrees C, Capacity Design: 1,200 L (317 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

DIN number: 28136 Glass type: 8000 (white) Thermowell: (1) quatro pipe thermowell 2m diameter x 2416mm tan to bottom outlet, belt driven by 15kw, 3/50/290/500 volt, 1460 rpm EExd e11CT motor, VS0 16/100 mechanical seal with lubricator, shaft speed 125 rpm, (1) beavertail baffle, (1) thermowell (quatro pipe), Capacity Design: 7,595 L (2,006 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes.

auftr #53250-R91, Glass type: WWG TUV certified Capacity Design: 2,167 L (572.5 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

Jacket volume: 319 liters, Glass type: WWG-9115, 1.4m diameter x 1684mm top opening to bottom outlet, VS10 agitator drive, belt driven by 4/6 kw, 3/50/500 volt, 722/1450 rpm EExell Atex 1098/34 motor, shaft speed 60-120 rpm, mechanical seal with lubricator, (1) beavertail baffle, TUV and CE certified Capacity Design: 2,115 L (558.7 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Code number 418010, internal pressure -1/6 bar @ -25/200 degrees C jacket -1/6 bar @ -25/200 degrees C (792 liters) glass type 3009/blue, CRANE-MCR 90 double mechanical seal, model 100 drive driven by 10.8 kw, 3/50/220/380 volt, 1430 rpm motor, built to CODAP 85 by DeDietrich & Cie, Zinswiller Capacity Design: 6,000 L (1,585 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes.

Code number: 400930 (2) flat baffles, agitator drive MDL125-140 with 30kW 3/50hz/220/380V/1460rpm E-motor. belt driven. bottom glass lined valve available, built to CODAP 85, Capacity Design: 14,335 L (3,787 gallons). Internal Pressure: 4 bar (58 psi). Internal Full Vacuum: Yes. Internal Temperature: 180 °C (356 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 180 °C (356 °F). Orientation: Vertical. Agitation: Yes.

Glass type: 3125, shaft driven by1.3 kW 3/ 50Hz/400/690V/1415rpm exp motor, Capacity Design: 860 L (227.2 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

500 liter 120 liter (jacket), agitator driven by SEW Eurodrive (CE) max 181 rpm. Email type WWG/blue, three blade impeller agitator with normal baffle. 1000 mm Inside diameter x 1190 mm height from bottom outlet to agitator flange, Motor data: ATEX (CE), 230-400 V/6.8 kW/50 Hz/1435 rpm, ex proof (T4) Capacity Design: 654 L (172.8 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Internal Temperature: -200 °C (-328 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: -200 °C (-328 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

500 liter total volume 654 liter; Jacket volume: 120 liters agitator driven by SEW Eurodrive (CE) max 181 rpm, Email type 61/blue, three blade impeller agitator with one finger up baffle with tantal tip. 1000 mm Inside diameter x 1190 mm height from bottom outlet to agitator flange, Motor data: ATEX (CE), 230-400 V/6.8 kW/50 Hz/1435 rpm, ex proof (T4) Capacity Design: 654 L (172.8 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Internal Temperature: -200 °C (-328 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: -200 °C (-328 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

agitated jacketed reactor, Order number: 50970 Volume of pressure jacket: 331 liter Belt driven by a 5,5kW electrical motor, Motor type 3KT132SA-2, 3~/50Hz/380-660V/2.870rpm, ExdeIIBT4 Capacity Design: 2,157 L (569.8 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

dual rated 150 psi and full vacuum at +450 F/ 77 psi and full vacuum at -50 F internal, dual rated jacketed for 150 psi and full vacuum at 400 F/ 72 psi and full vacuum at -50 F 9119 glass Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes.

Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Agitation: Yes.

Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

dual rated 150 psi and full vacuum at +450 f/ 72psi and full vacuum at -50 F internal, dual rated jacketed for150 psi and full vacuum at 450 f/ 72 psi and full vacuum at -50F -9119 glass Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

R-0210 Built 2017 Motor EX proof & VFD compatible Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Sanitary Construction: Yes. Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

NB# 45442, SN# 189-0501. Openings include: agitator (1) 1" nozzle, Baffle (1) " nozzle, inlet (3) 2 " nozzle, outlet (1)2" nozzle, jacket connection (1) 1 1/2 nozzles, previous stock # 225483.

belt drive with adjustable sheeve varidrive 20 HP 3/60/460V motor 100 rpm output, 14.8 to 1 ratio Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Support Type: Legs.

R-0208 Built 2017 Motor EX proof & VFD compatible Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Sanitary Construction: Yes. Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

3200 liter TUV internal pressure -1/2 bar @ 110 degrees C (3630 liter), jacket 8 bar @ 220 degrees C (140 liter) Motor: 3 phase interrupted ribbon type agitator mechanical seal with lubricator pot 316Ti stainless steel (1.4571) half pipe coil jacket on straight side, 316Ti stainless steel (1.4571) standard jacket on bottom dish Capacity Design: 3,630 L (958.9 gallons). Internal Pressure: 2 bar (29 psi). Internal Temperature: 110 °C (230 °F). Jacket Pressure: 8 bar (116 psi). Jacket Temperature: 220 °C (428 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes. Support Type: Lugs.

jacketed agitated reactor Direct coupled to approx. 3 hp, 3/60/230/460V, Capacity Design: 378.5 L (100 gallons). Internal Pressure: 4.1 bar (60 psi). Internal Full Vacuum: Yes. Internal Temperature: 60 °C (140 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 121.1 °C (250 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes.

Conventional jacket Shell rated 150/FV @ 450 degrees F. Conventional jacket 140/FV @450 degrees F. Jacket is a three zone design head zone surface area is 75 Sq.Ft Shell=1.25" Heads= 1.313" Jacket= 0.75" With PFTE dip tube Graduation lines on vessel and mixer Capacity Design: 18,927 L (5,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 9.7 bar (140 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Drive Serial Number 5-01440P Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

H baffle with integral tip Capacity Design: 7,571 L (2,000 gallons). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

with leg brackets. split pipe coil Jacket Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 31 bar (450 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Support Type: Lugs.

Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Support Type: Legs.

Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Orientation: Vertical. Support Type: Legs.

double jacketed reactor CE confirm, pharma grade sanitary internal pressure rated by -1/+3.8 bar @ 0/+126 degrees C (volume 418 liter), jacket pressure rated by 3 bar @ -5/+95 degrees C (volume 9 liter), with stainless steel top mounted off set agitator type RF47DT90S2/VS 3~/50Hz/230-400V/1,410rpm with control panel.. Capacity Design: 418 L (110.4 gallons). Internal Pressure: 3.8 bar (55.1 psi). Internal Full Vacuum: Yes. Internal Temperature: 126 °C (258.8 °F). Jacket Pressure: 3 bar (43.5 psi). Jacket Temperature: 95 °C (203 °F). Agitation: Yes.

Series: GL Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 9 bar (130 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Capacity Design: 37.9 L (10 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Support Type: Legs.

Capacity Design: 12,113 L (3,200 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 4.1 bar (60 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Support Type: Lugs.

RA series Capacity Design: 1,136 L (300 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

direct coupled Body with electrical heated jacket and full insulation with stainless steel clad jacket motor : 3/210 volt Capacity Design: 2 L (0.53 gallons). Internal Pressure: 358.7 bar (5,202 psi). Internal Temperature: 300 °C (572 °F). Jacket Material of Construction: Stainless Steel Other. Agitation: Yes.

EM series. Disassembled Capacity Design: 757.1 L (200 gallons). Agitation: Yes. Support Type: Legs.

Previously stock number 86077 that never went to IMS, so it was issued a new number. Capacity Design: 567.8 L (150 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Glasslined. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

reactor bottom Capacity Design: 94.6 L (25 gallons). Internal Pressure: 0.83 bar (12 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 7.9 bar (115 psi). Jacket Temperature: 232.2 °C (450 °F). Support Type: Lugs.

apparatus #59-2135-54 internal design pressure 20 bar @ 115 degrees C jacket 5 bar @ 152 degrees C (17 liter) straight side and bottom dish insulated and cladd with stainless steel Capacity Design: 3,010 L (795.2 gallons). Internal Pressure: 20 bar (290.1 psi). Internal Temperature: 115 °C (239 °F). Jacket Pressure: 5 bar (72.5 psi). Jacket Temperature: 152 °C (305.6 °F). Jacket Material of Construction: Stainless Steel 304. Agitation: Yes. Support Type: Legs.

Base reactor with 30" main cover and 14" x 18" man way with a 4" sight glass. Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Motor was for testing only, will need to be purchased when it is sold. Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

• Base reactor Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

reactor body only Capacity Design: 5,678 L (1,500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes.

reactor body Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical.

Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Special, no Bottom outlet, can not take a cover, use as an open top only. (AS) Capacity Design: 757.1 L (200 gallons). Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Sockets for pipe legs.

non-jacketed base reactor Additional feature: SS ring for adding an insulation shroud around top seam of tank (tank is not insulated) Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Support Type: Lugs.

RA Series 90 psi with/full vacuum internal Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Support Type: Legs.

Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes. Support Type: Legs.

Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes. Support Type: Legs.

RA series glass lined reactor body Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Support Type: Legs.

Base Reactor, Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F).

• Reglassed in Mexico by Pfaudler.
• 75 psi w/full vac int Capacity Design: 2,839 L (750 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes. Support Type: Legs.

reactor bottom 65 psi w/full vac internal Capacity Design: 1,893 L (500 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 5.5 bar (80 psi). Jacket Temperature: 176.7 °C (350 °F). Support Type: Legs.

body (bare). 75 psi w/full vacuum internal Capacity Design: 1,893 L (500 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Body Only: Yes. Support Type: Lugs.

• Coil Pipe Rating: 150 psi at 350 degrees F Two wraps with 12 turns 2" coils inside wrap, 12 turns 2" coil outside wrap. Estimated surface are of internal coils is 238 Sq. Ft. Estimated surface area of outer half pipe jacket is 125 sq. ft.
  Heads Thickness: 0.25"
• Half Pipe Coil Jacket Thickness: 11 Gauge. Capacity Design: 4,921 L (1,300 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

630 liter

• CE number: 401381
• Glass type: 3009 -internal design pressure -1/6 bar @ -25/200 degrees C (847 liter) jacket -1/6 bar @ -25/200 degrees C (152 liter)
• 3-finger retreat curved agitator (white glass)
• vari-speed drive
• Motor: 3 phase
• 260/460 volt -- shaft speed 29/166 rpm
• mechanical seal with lubricator
• Body and top cover: Blue glass 1-50mm (jacket)
• Certification: CE certified Capacity Design: 847 L (223.8 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Support Type: Lugs.

100 liter

• CE number: 401379
• Glass type: 3009 internal design pressure -1/6 bar @ -25/200 degrees C (127 liter) jacket -1/6 bar @ -25/200 degrees C (38 liter)
• 3-finger retreat curved agitator (white glass)
• Motor: 3 phase
• vari-speed drive
• 260/460 volt
• Body and top cover: Blue glass
• Certification: CE certified Capacity Design: 127 L (33.5 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

driven by 10 HP, 3/60/460V, Capacity Design: 9,464 L (2,500 gallons). Agitation: Yes. Support Type: Legs.

Biostat STR-1000 DW, disposable bioreactor Skid mounted system with controls 1225 mm w x 1664 mm d x 2692 mm h Footprint = 2.04 m2. Double wall, electro polished, double front door, one viewing window. Two hinges allow the doore to open in the middle for bag replacement. Removable/Replacement bags have built in magnetic agitators internal to the bags.
Two ports for sensors, top mounted drive, magntic (agitator is inside the bag). Control tower 304 SS with a 22" touch screen. Power supply 400 vac/50 Hz/18A. With 90 rpm agitation module, and heating/cooling module. Rated for 8 degrees C above cooling water up to 40 degrees C, with over temperature protection, and 6 bar cooling water connection. Complete with Mass flow controllers, pumps, and measurement sensors. Weight 875 kg. With a Watson Marlow 520 Du digital control variable speed peristaltic pump. Serial # 160321-053702.
With Snyder Electric UPS system APC 750. Capacity Design: 999.3 L (264 gallons). Orientation: Vertical. Agitation: Yes. Support Type: Skid.

• BE-12500 liter TUV Internal pressure -1/6 bar @ -30/200 degrees C (14355 liter) jacket -1/30 bar @ -20/200 degrees C (1370 liter) Glass type: 809 2.4m diameter x 3538mm tan line to tan line R&M Italia AR5-125/2 agitator drive 21 - 103 rpm (120 rpm max) agitator speed Motor phase : 3 (3) sets of 4-blade cryolock agitator mechanical seal with lubricator possibly with (2) beavertail thermowells carbon steel half pipe coil jacket Capacity Design: 14,355 L (3,792 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 30 bar (435.1 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes.

BE-12500 liter TUV -internal pressure -1/6 bar @ -30/200 degrees C (14355 liter) jacket -1/30 bar @ -20/200 degrees C (1370 liter) Glass type: 809 2.4m diameter x 3538mm tan line to tan line 21 - 103 rpm (120 rpm max) agitator speed Motor: 3 phase (3) sets of 4-blade cryolock impellors Capacity Design: 14,355 L (3,792 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 30 bar (435.1 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes.

• Fabrication location: Dow Shop
• Jacket connections: 1.5"
• ac motor
• Single phase Center bottom opening is 2" jacket connections are 1.5" Capacity Design: 1,136 L (300 gallons). Internal Pressure: 5.5 bar (80 psi). Internal Temperature: 121.1 °C (250 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Conventional jacket with welded 2:1 elliptical heads. Shell=1", heads =1", jacket =5/8". . Mixing by a Cryo-Lock 29" CW CBT hub, with calibration lines. PTFE Dip tube, Alloy dip pipe and CIP spray balls. 18" manway with sight glass assembly, pro ring and man way assist. Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. CIP: Yes. Support Type: Legs.

Hyclone Bioreactor (S.U.B.). Single use bioreactor for Animal and insect cell culture with Topside agitation. Requires Bio-Process Container (BPC): disposable liner, supplied sterilized (NOT INCLUDED) . Water jacketed.
Polyethylene impeller with bearing /seal assembly linked to external mixer drive. Mixer: 120VAC, 1-Ph, 60Hz. Equipped with motor assisted cover and electrical control panel Capacity Design: 250 L (66 gallons). Agitation: Yes. Support Type: Skid.

CE VSO 100 quick change mechanical seal

• Jacket: Converted to standard DIN configuration during reglassing Design code ASME VIII Div
• Reglassed by UGE in 2010. Capacity Design: 6,300 L (1,664 gallons). Internal Pressure: 6.6 bar (95.7 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6.6 bar (95.7 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

driven by 25 kW,3/50/220/380 volt, 1450 RPM motor Capacity Design: 8,000 L (2,113 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Body Only: Yes. Agitation: Yes. Support Type: Lugs.

low temperature reactor assembly Rated 100/FV PSI @-101 to 450 degrees F internal or 40/FV PSI @ -250 to 101 Degrees F; Jacket rated 180 PSI @ -100 to 350 degrees F or 72 PSI @ -250 to -101 degrees F. Needs to be reglassed, or converted only s/s reactor Capacity Design: 757.1 L (200 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 12.4 bar (180 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Stainless Steel 316. Agitation: Yes.

5RW drive - Flange mounted Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Support Type: Legs.

With a 5RW drive, 15 to ratio, belt driven by a mechanical Vari-Speed with an adjustable sheeve, 10 HP motor. Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes. Support Type: Legs.

TW drive Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes. Support Type: Legs.

Capacity Design: 7,590 L (2,005 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

jacketed reactor Capacity Design: 1,136 L (300 gallons).

Shell rated 150 psi/FV @ 450 degrees F. Conventional jacket rated 150 psi/FV @ 450 degrees F with welded 2:1 elliptical heads Capacity Design: 1,136 L (300 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Glass Type C2317 MDMT -20 deg. F Capacity Design: 37.9 L (10 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Support Type: Legs.

Capacity Design: 113.6 L (30 gallons). Internal Pressure: 2.1 bar (30 psi). Internal Temperature: 343.3 °C (650 °F). Orientation: Vertical.

reactor assembly mechanical seal with lubricator Reglassed by UGE in 2010. Capacity Design: 4,545 L (1,201 gallons). Internal Pressure: 6.8 bar (99.1 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6.8 bar (99.1 psi). Body Only: Yes. Agitation: Yes. Support Type: Lugs.

repair tag by Superior Welding, serial # 05-89-2004-01 with welded 2:1 elliptical heads Internal coil, of 321 SS seamless pipe, is 2 & 3/8" diameter x 0.218 wall thickness. It has 13 turns with a 36" mean diameter on a 4" pitch. Mixing is by a 16" diameter radial type impeller rotating at 258 rpm This drive arrangement features Contamination free mixing, and zero atmospheric leakage Capacity Design: 1,893 L (500 gallons). Internal Pressure: 86.2 bar (1,250 psi). Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 20.7 bar (300 psi). Jacket Temperature: 398.9 °C (750 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

12500 liter internal pressure -1/6 bar @ -20/220 degrees C (15150 liter) jacket -1/6 bar @ -20/220 degrees C (440 liter), Capacity Design: 15,150 L (4,002 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes. Support Type: Lugs.

with welded 2:1 elliptical heads Internal coil, of 321 SS seamless pipe, is 2 & 3/8" diameter x 0.218 wall thickness. It has 13 turns with a 36" mean diameter on a 4" pitch. Mixing is by a 16" diameter radial type impeller rotating at 258 rpm Driven by a 5 HP motor, 440 v 60 Hz, 3 ph, and has a belt driven MagneDrive II series seal less magnetic drive, manufactured by Parker/Autoclave Engineers. This drive arrangement features Contamination free mixing, and zero atmospheric leakage Capacity Design: 1,893 L (500 gallons). Internal Pressure: 86.2 bar (1,250 psi). Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 20.7 bar (300 psi). Jacket Temperature: 398.9 °C (750 °F). Jacket Material of Construction: Stainless Steel 321. Orientation: Vertical. Support Type: Legs.

Three turns schedule 10 half pipe on bottom head, Eight turns schedule 10 half pipe on side walls. Mixing by Eastern model FRG-C2M with double mechanical seal Duel sets of four blade pitch turbine mixers Capacity Design: 946.4 L (250 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 5.2 bar (75 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Support Type: Legs.

Capacity Design: 12,113 L (3,200 gallons). Internal Pressure: 4.2 bar (61 psi). Internal Temperature: 93.3 °C (200 °F). Jacket Pressure: 13 bar (188 psi). Jacket Temperature: 93.3 °C (200 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Lugs.

Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

Glass type: 3008 High fire polish with several plugs visible Capacity Design: 5,678 L (1,500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Agitation: Yes.

1200 psi jacketed autoclave reactor Model 504C15CMX , Serial Number 97G1899101. Equipped with a top mounted 3/60/230/460V U stamped W 52, Jacket is 1/2 way up on the straight side. Capacity Design: 9,842 L (2,600 gallons). Internal Pressure: 82.7 bar (1,200 psi). Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 343.3 °C (650 °F). Agitation: Yes. Support Type: Lugs.

total volume: 8900 Liter, jacket volume: 1.700 Liter, average jacket thickness 30mm. Capacity Design: 8,900 L (2,351 gallons). Internal Pressure: 84 bar (1,218 psi). Internal Full Vacuum: Yes. Internal Temperature: 250 °C (482 °F). Jacket Pressure: 25 bar (362.6 psi). Jacket Temperature: 250 °C (482 °F). Body Only: Yes. Orientation: Vertical.

Capacity Design: 8,300 L (2,193 gallons). Internal Pressure: 12.5 bar (181 psi). Internal Temperature: 70 °C (158 °F). Jacket Pressure: 4 bar (58 psi). Jacket Temperature: 0 °C (32 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Lugs.

• Additional attribute: Reactor has a 321 SS Direct coupled to a Reeves variable speed drive, 2 HP 3/60/460 Volt Reactor has a 321 SS sanitary jacket Capacity Design: 3,331 L (880 gallons). Internal Pressure: 3.8 bar (55 psi). Internal Full Vacuum: Yes. Internal Temperature: 148.9 °C (300 °F). Sanitary Construction: Yes. Jacket Pressure: 18.8 bar (272 psi). Jacket Temperature: 148.9 °C (300 °F). Jacket Material of Construction: Inconel. Agitation: Yes. Support Type: Legs.

plus 2.4m for the drive on top Capacity Design: 54,900 L (14,503 gallons). Internal Pressure: 0.5 bar (7.3 psi). Internal Full Vacuum: Yes. Internal Temperature: 132 °C (269.6 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 102 °C (215.6 °F). Agitation: Yes.

plus 2.4m for the drive on top Type HWL140E Capacity Design: 54,900 L (14,503 gallons). Internal Pressure: 0.5 bar (7.3 psi). Internal Full Vacuum: Yes. Internal Temperature: 132 °C (269.6 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 105 °C (221 °F). Agitation: Yes.

Capacity Design: 189.3 L (50 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

agitated reactor with coils, Pressure Vessel Code TKN 1987 (Swedish), Vessel is heated with (3) steam tube bundles mounted through the lower side wall, each tube bundle has 2,3 square meters of heating surface area, they are rated for 3 bar at 143 degrees C., and each has 19 tubes at 800 mm long, each have a bolted carbon steel head. Tube Material is titanium ASTM B 265 Gr.2. Top mounted agitator drive, SEW eurodrive Type RF87AM123S/M, max moment 1280 Nm, 700mm span, Capacity Design: 5,400 L (1,427 gallons). Internal Pressure: 1 bar (14.5 psi). Internal Temperature: 120 °C (248 °F). Agitation: Yes. Support Type: Lugs.

head thickness15/16"", jacket thickness=35/64"" Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

reactor assembly Vessel rated 100/FV @ 500 degrees F. Conventional jacket rated for FV/90psi @ 500 degrees F head thickness15/16" jacket thickness=35/64" PTE 08 Drive with estimated 15 HP EXP motor, and stuffing box for seal Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Support Type: Legs.

"P" 50 reactor assembly. Baffle and RCI installed. Capacity Design: 189.3 L (50 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

50 Gallon "P" Series reactor assembly Baffle and RCI installed, motor installed at time of purchase Capacity Design: 189.3 L (50 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Capacity Design: 7,571 L (2,000 gallons). Orientation: Vertical. Support Type: Legs.

Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Support Type: Legs.

straight side and bottom dish internal pressure -1/6 bar @ -10/200 degrees C (3685 liter), jacket -1/20 bar @ -10/200 degrees C (75 liter) Highly polished Finish Ancillaries: Valves, filters, pipework, etc. (may be available) Capacity Design: 3,685 L (973.5 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Sanitary Construction: Yes. Jacket Pressure: 20 bar (290.1 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes.

internal pressure -1/6 bar @ -30/150 degrees C (3643 liter), jacket -1/10 bar @ -30/150 degrees C (120 liter) straight side and bottom dish CE 0036 certified, TUV certified Mounting ring Fully insulated Capacity Design: 3,643 L (962.4 gallons). Internal Pressure: 6 bar (87 psi). Internal Temperature: 150 °C (302 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes.

internal pressure -1/6 bar @ 200 degrees C (3600 liter), jacket -1/20 bar @ 220 degress C (60 liter) TUV certified valves, filters, pipework etc may be available Motor to gear is broken Capacity Design: 3,600 L (951 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 20 bar (290.1 psi). Jacket Temperature: 220 °C (428 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes. Support Type: Legs.

Jkt rated 100 psi @ 256 deg C, 150 psi test; int rated 60 psi/full vac @ 256 deg C, 124 psi test direct driven by 5 HP, 3/50/415 volt flameproof motor Capacity Design: 3,331 L (880 gallons). Internal Pressure: 4.1 bar (60 psi). Internal Full Vacuum: Yes. Internal Temperature: 256 °C (492.8 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 256 °C (492.8 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Support Type: Lugs.

Jacketed on shell and bottom head with 49.69 sq. ft of surface area. With Top mounted Philadelphia mixer model MT-02, 14.1 ratio, coupled to a 2 hp 3/60/230/460 volt motor, Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 5.2 bar (75 psi). Jacket Temperature: 148.9 °C (300 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

• With Lightnin, 1.5 hp mixer.
• 1" jacket supply and return lines. Capacity Design: 757.1 L (200 gallons). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Support Type: Legs.

with a mill finish internal Internal Finish: Mill Special mounting bracket for cleaning (4.5-1) ratio serial 92AHF0857 Capacity Design: 37.9 L (10 gallons). Internal Pressure: 1.03 bar (15 psi). Internal Full Vacuum: Yes. Internal Temperature: 210 °C (410 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 210 °C (410 °F). Jacket Material of Construction: Stainless Steel 304. Orientation: Vertical. Agitation: Yes.

jacketed Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 15.5 bar (225 psi). Internal Full Vacuum: Yes. Internal Temperature: 37.8 °C (100 °F). Jacket Pressure: 4.5 bar (65 psi). Jacket Temperature: 37.8 °C (100 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Support Type: Legs.

Capacity Design: 2,271 L (600 gallons). Internal Pressure: 2.8 bar (40 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 12.4 bar (180 psi). Jacket Temperature: 204.4 °C (400 °F). Jacket Material of Construction: Stainless Steel 304L. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

• Type: Jacketed tank 105 psi with internal vacuum. Capacity Design: 200 L (52.8 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 204.4 °C (400 °F).

Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes. Support Type: Lugs.

Dimple jkt on str side and btm head. w/air actuated butterfly valve. Capacity Design: 851.7 L (225 gallons). Internal Pressure: 1.03 bar (15 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 176.7 °C (350 °F). Body Only: Yes. Orientation: Vertical. Support Type: Lugs.

235 psi w/full vac int. CS str jkt Capacity Design: 113.6 L (30 gallons). Internal Pressure: 27.6 bar (400 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 17.2 bar (250 psi). Jacket Temperature: 343.3 °C (650 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes.

jkt agit reactor. 1175/585 rpm output. Capacity Design: 757.1 L (200 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 3.4 bar (50 psi). Jacket Temperature: 204.4 °C (400 °F). Orientation: Vertical. Agitation: Yes.

100 psi w/full vac int Glass #5015/5015. Capacity Design: 757.1 L (200 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 176.7 °C (350 °F). Support Type: Lugs.

driven by 3/4 HP motor Capacity Design: 1,893 L (500 gallons). Orientation: Vertical. Agitation: Yes.

continous high viscosity reactor/dryer, rated 15000 CP @ 22.8 Kg/hr with a 37 minute retention time. with an intenal agitator shaft with discs, 150mm disk diameter. Unit has (53) discs on the shaft, 24 to 53 rpm disc speed. Shaft has double mechanical seals, and is belt driven through a vari speed gear reducer rated 900 rpm input to 279 to 1115 rpm output. Capacity Design: 36 L (9.5 gallons). Internal Pressure: 10.5 bar (152.3 psi). Internal Full Vacuum: Yes. Internal Temperature: 400 °C (752 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 400 °C (752 °F). Jacket Material of Construction: Carbon Steel. Orientation: Horizontal. Agitation: Yes.

• Purpose: polymerization reactor designed for continuous operation to react, mix, and dry high viscosity materials Twin rotor shafts are heated and rated -1/15 bar @ 400 degrees C. Hastelloy C clad Shell, Hastelloy C276 Shaft and Screws Capacity Design: 140 L (37 gallons). Internal Pressure: 10.5 bar (152.3 psi). Internal Full Vacuum: Yes. Internal Temperature: 400 °C (752 °F). Jacket Pressure: 10.5 bar (152.3 psi). Jacket Temperature: 325 °C (617 °F). Jacket Material of Construction: Carbon Steel. Orientation: Horizontal. Agitation: Yes.

Capacity Design: 24,605 L (6,500 gallons). Internal Pressure: 2.4 bar (35 psi). Internal Temperature: 121.1 °C (250 °F). Jacket Pressure: 15.5 bar (225 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes.

Philadelphia drive system with (3) sets of three blade propellers 3008 Glass. Capacity Design: 30,283 L (8,000 gallons). Internal Pressure: 2.8 bar (40 psi). Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F). Orientation: Vertical. Support Type: Lugs.

Glass type: 3009 Series 60 Total weight for complete reactor 9940 lbs. Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Agitation: Yes. Support Type: Lugs.

internal pressure -1/6 bar @ -25/200 degrees C (3120 liter), jacket -1/6 bar @ -25/200 degrees C (135 liter straight side and bottom dish TUV certified Capacity Design: 3,120 L (824.2 gallons). Internal Pressure: 6 bar (87 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

2:1 elliptical heads Heads=1.125", jacket=0.75".
Pfaudler 5035 SRW drive with a 15 HP motor and a dry seal.15:1 ratio with a 33" CBT hub and graduation marks 24" man way with pro ring and man way assist. With sight glass assembly Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

• Glass type: #3115
• Suitable for DK500 reactor. Capacity Design: 500 L (132.1 gallons). Internal Pressure: 2 bar (29 psi). Internal Full Vacuum: Yes. Jacket Pressure: 11 bar (159.5 psi). Jacket Temperature: 200 °C (392 °F). Body Only: Yes.

TUV internal pressure -1/3.2 bar @ -25/130 degrees C (6000 liter), jacket 6 bar @ -25/130 degrees C (200 liter) Motor phase : 3 400/690 volt (3) sets of intermig agitators on shaft internal baffles on sidewall Openings types: Mixture of standard flat flange fittings and Tri-clamp fittings Insulation: Fully insulated and cladded Capacity Design: 6,000 L (1,585 gallons). Internal Pressure: 3.2 bar (46.4 psi). Internal Temperature: 130 °C (266 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 130 °C (266 °F). Jacket Material of Construction: Stainless Steel 304. Agitation: Yes. Support Type: Lugs.

agitated fermenter Capacity Design: 12,500 L (3,302 gallons). Internal Pressure: 4 bar (58 psi). Internal Full Vacuum: Yes. Internal Temperature: 160 °C (320 °F). Jacket Pressure: 4 bar (58 psi). Jacket Temperature: 160 °C (320 °F). Jacket Material of Construction: Stainless Steel 316. Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

-glass lined vertical Reactor Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical.

SA Series Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes. Agitation: Yes.

internal pipe coil pressure 8 bar @ -25/180 degrees C, Capacity Design: 26,600 L (7,027 gallons). Internal Pressure: 6.5 bar (94.3 psi). Internal Full Vacuum: Yes. Internal Temperature: 180 °C (356 °F). Jacket Pressure: 8 bar (116 psi). Jacket Temperature: 180 °C (356 °F). Orientation: Vertical. Agitation: Yes.

agit jkt reactor, 1000mm dia x 1070mm from top flange to btm discharge, Driven by Lonza varispeed drive, 3.6 KW, output 22-126 rpm w/4 KW, 3/50/380 volt, 1420 rpm motor. Designed to German TUV standards. Glass #3115. Capacity Design: 757.1 L (200 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

rated -1/6 bar @ 200 degrees F internal; 6 bar @ 200 degrees C Jacket volume: 200 liter, 2,5 kw/3/50Hz/380V/5,2A/ 1420rpm motor Capacity Design: 980 L (258.9 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

autoclave reactor jacket 90 liters

• Designed to German TUV standards. Capacity Design: 570 L (150.6 gallons). Internal Pressure: 64 bar (928.2 psi). Jacket Pressure: 28 bar (406.1 psi). Jacket Temperature: 275 °C (527 °F). Agitation: Yes. Support Type: Lugs.

conventional jacket with welded 2:1 elliptical heads Body with graduation lines Shell=1 & 1/8", Heads=1.125", jacket=0.75" Two PTFE dip tubes and Alloy spray balls for CIP Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Agitation: Yes. CIP: Yes. Support Type: Legs.

Capacity Design: 3,785 L (1,000 gallons). Body Only: Yes.

reactor assembly, Reglassed by Ceramic Coating Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F).

Head rating: Head 12 psi/FV @ 450 degree psi certified by: Ceramic coating Co. Man Serial# 844219 Model# 09185KB28 Right angle driver Manufactured by Textron 2500 rpm (6:1) ratio Top material: Glass L2001 (R104) 6” handway Glass L2001 (R104) Capacity Design: 37.9 L (10 gallons). Internal Pressure: 0.83 bar (12 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 210 °C (410 °F). Orientation: Vertical. Support Type: Skid.

with the jacket chamber insulated and sheathed with 14Ga 316SS Manufacturer's number: 2516 Glass 3009 Manuf #: 2516. Head NB# 1755 Head rated for 150psi/FV @ 500 degree F Glass 3009 3 blade pitched turbine agitator Motor: driven by 2 hp,230/460 volt XP Capacity Design: 75.7 L (20 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 7.9 bar (115 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Stainless Steel 316. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Reactor assembly 90 PSI with internal vacuum Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Agitation: Yes. Support Type: Legs.

custom S66 reactor body with additional nozzles or 50 psig with internal vacuum Head thickness: 3/4" minimum with a 2:1 elliptical ratio 2:1 elliptical ratio Outlet is one 4". Vessel has 2 lifting lugs and 2 guiding lugs. Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 4.5 bar (65 psi). Jacket Temperature: 204.4 °C (400 °F). Orientation: Vertical. Support Type: Lugs.

8000 liter internal pressure -1/6 bar @ -20/250 degrees C (9900 liter), jacket -1/20 bar @ -20/250 degrees C (340 liter) 3/50/500 volt on straight side and bottom dish Capacity Design: 9,900 L (2,615 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 250 °C (482 °F). Jacket Pressure: 20 bar (290.1 psi). Jacket Temperature: 250 °C (482 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes. Support Type: Lugs.

8000 liter internal pressure -1/6 bar @ -20/250 degrees C (10130 liter), jacket -1/24 bar @ -20/250 degrees C (300 liter) 3/50/500 volt on straight side and bottom dish Capacity Design: 10,130 L (2,676 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 250 °C (482 °F). Jacket Pressure: 24 bar (348.1 psi). Jacket Temperature: 250 °C (482 °F). Jacket Material of Construction: Stainless Steel Austentic. Support Type: Lugs.

internal pressure -1/6 bar @ -20/200 degrees C (9700 liter), jacket -1/10 bar @ -20/200 degrees C (235 liter) 3-3.6kw, 3/50/60/380-415/660-720/440/480 volt 1415-1695 rpm Side jacket openings: 2-80mm CE 0408 & TUV Certified Capacity Design: 9,700 L (2,562 gallons). Internal Pressure: 6 bar (87 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes.

Reglassed at UGE facility 18" dia x 20" to btm outlet, Glass #5015/5015. Capacity Design: 75.7 L (20 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Support Type: Legs.

• Jacket coverage: 2350mm of straight side and bottom head Total weight 29200 kg Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Jacket: Carbon steel on 2350mm of straight side and bottom head Total weight 29200 kg. Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Total capacity 63.9 cubic meter rated 10.3 bar @ 100 degrees C internal; 5.3 bar at 100 degrees C

• Jacket coverage: 2350mm of straight side and bottom head Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Jacket: Carbon steel on 2350mm of straight side and bottom head Total weight 29200 kg. Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Jacket coverage: 2350mm of straight side and bottom head Total weight 29200 kg. Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Full Vacuum: Yes. Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

10.3 bar @ 100 degrees C internal; 5.3 bar at 100 degrees C in the carbon steel jacket. Jacket: Carbon steel jacket on 2350mm of straight side and bottom head Total weight 29200 kg Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Jacket: Carbon steel jacket on 2350mm of straight side and bottom head Total weight 29200 kg. Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Jacket coverage: 2350mm of straight side and bottom head Total weight 29200 kg. Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Full Vacuum: Yes. Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Jacket: Carbon steel on 2350mm of straight side and bottom head Total weight 29200 kg. Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

rated 10.3 bar @ 100 degrees C internal; 5.3 bar at 100 degrees C Jacket: Carbon steel on 2350mm of straight side and bottom head Total weight 29200 kg Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

10.3 bar @ 100 degrees C internal; 5.3 bar at 100 degrees C in the carbon steel jacket CS jacket on 2350mm of straight side and bottom head Total weight 29200 kg Capacity Design: 63,900 L (16,881 gallons). Internal Pressure: 10.3 bar (149.4 psi). Internal Temperature: 100 °C (212 °F). Jacket Pressure: 5.3 bar (76.9 psi). Jacket Temperature: 100 °C (212 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Top mounted 2.5 TW drive belt driven by a 2 HP 3/60/230/460 volt motor. Capacity Design: 113.6 L (30 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes. Support Type: Lugs.

Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 343.3 °C (650 °F). Body Only: Yes. Support Type: Lugs.

Reglassed by Pfaudler Serial number J013022 Top mounted 5 DTW drive belt driven by approx 15HP motor, Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Agitation: Yes. Support Type: Lugs.

5 TW drive, 15 to 1 ratio, belt driven by 10 HP 3/60/230/460V motor, Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes. Support Type: Legs.

5DTW, belt driven dip tube Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes. Support Type: Lugs.

5TW drive belt driven Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes. Support Type: Lugs.

Capacity Design: 1,892 L (499.8 gallons). Internal Pressure: 2.8 bar (40 psi). Jacket Pressure: 10.3 bar (150 psi). Body Only: Yes. Support Type: Legs.

4DTW drive belt driven Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6.2 bar (90 psi). Agitation: Yes. Support Type: Lugs.

• Jacket coverage: Bottom half of straight side and bottom dish only model 100-020-C crane mechanical seal with lubricator motor 3/50/360/420 volt Capacity Design: 10,000 L (2,642 gallons). Internal Pressure: 3.3 bar (47.9 psi). Internal Full Vacuum: Yes. Internal Temperature: 170 °C (338 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

mechanical seal with lubricator agitator shaft driven motor 3/50/415 volt Capacity Design: 2,500 L (660.4 gallons). Internal Pressure: 6.8 bar (99.1 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6.8 bar (99.1 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

• Limpet coil operating pressure: 4.22 barg
• Limpet coil material: 316L stainless steel motor 3/50/415 volt mechanical seal with lubricator Capacity Design: 5,000 L (1,321 gallons). Internal Pressure: 2.5 bar (36.3 psi). Internal Full Vacuum: Yes. Internal Temperature: 180 °C (356 °F). Jacket Pressure: 11.6 bar (168.2 psi). Jacket Temperature: 185 °C (365 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

• Features: internal coils, external limpet coil on bottom dish
• Coils: 2 sets of 316 stainless steel internal coils, each 3" diameter x 7 turns internal operating pressure 3.5 kg/cm2 @ -10/+185 deg C motor 3/50/415 volt mechanical seal with lubricator Capacity Design: 11,000 L (2,906 gallons). Internal Pressure: 3.8 bar (54.8 psi). Internal Full Vacuum: Yes. Internal Temperature: 235 °C (455 °F). Jacket Pressure: 14.7 bar (213.2 psi). Jacket Temperature: 235 °C (455 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

5 TW drive, 40 to 60 rpm output, belt driven motor, 2 finger up baffle. Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F). Agitation: Yes. Support Type: Lugs.

• Coils: Internal and external limpet coil on bottom dish only
• Internal coils: (2) sets of 316 stainless steel, each 3" diameter x 7 turns internal operating pressure 3.5 kg/cm2 @ -10/+185 deg C motor 3/50/415 volt mechanical seal with lubricator 2-sets of 316 s/steel internal coils each 3" diameter x 7 turns Capacity Design: 11,000 L (2,906 gallons). Internal Pressure: 3.8 bar (54.8 psi). Internal Full Vacuum: Yes. Internal Temperature: 235 °C (455 °F). Jacket Pressure: 14.7 bar (213.2 psi). Jacket Temperature: 235 °C (455 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

manufacturers job #6501/1

• Glass type: blue glass 3115 operating internal pressure 3.5 kg/cm2g @ -10/+153 degrees C, jacket 4.25 kg/cm2g @ -10/+153 degrees C, blue glass 3115 motor 3/50/415 volt mechanical seal with s/steel lubricator pot design code ASME V111 DIV.1 Capacity Design: 6,810 L (1,799 gallons). Internal Pressure: 3.8 bar (54.8 psi). Internal Full Vacuum: Yes. Internal Temperature: 180 °C (356 °F). Jacket Pressure: 5.2 bar (75.3 psi). Jacket Temperature: 180 °C (356 °F). Agitation: Yes. Support Type: Lugs.

manufacturers job #62589/69589 Glass type: Blue glass 3115 internal design pressure 3.86 kg/cm2g + full vac @ -15/+180 degrees C jacket 5.3 kg/cm2g @ -15/+180 degrees C operating internal pressure 3.5 kg/cm2g @ -10/+153 deg C jacket 4.25 kg/cm2g @ -10/+153 deg C motor 3/50/415 volt mechanical seal with s/steel lubricator pot design code ASME V111 Capacity Design: 6,810 L (1,799 gallons). Internal Pressure: 3.8 bar (54.8 psi). Internal Full Vacuum: Yes. Internal Temperature: 180 °C (356 °F). Jacket Pressure: 5.2 bar (75.3 psi). Jacket Temperature: 180 °C (356 °F). Agitation: Yes. Support Type: Lugs.

Monel reactor Top Head 1/2", Bottom Head 1 1/16"; CS jacket 1/2" thick. Top mounted Lightnin drive, Model 85-5-40, 9.33 to 1 ratio, Direct coupled to a 5 HP 3/60/230/460 volt 1765 rpm motor, 180 RPM output. (4) blade pitched paddle mid shaft, 4 blade flat turbine on bottom, (4) baffles on side wall. Capacity Design: 2,839 L (750 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 148.9 °C (300 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Lugs.

Top Head 9/16", Bottom Head 1 3/16"; CS jacket 9/16" thick. Top mounted Lightnin drive, Model 85-5-40, 9.33 to 1 ratio, Direct coupled to a 5 HP 3/60/230/460 volt 1765 rpm motor, 180 RPM output. (4) blade pitched paddle mid shaft, 4 blade flat turbine on bottom, (4) baffles on side wall. Capacity Design: 2,839 L (750 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 148.9 °C (300 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Lugs.

With a 5RW drive, 15 to ratio, belt driven by a mechanical Vari-Speed with an adjustable sheeve, 10 HP motor. Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Agitation: Yes. Support Type: Legs.

Capacity Design: 189.3 L (50 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

Shell rated for 100 psi/FV @ 500 degrees F. conventional jacket rated for 100 psi /FV @500 degrees F. conventional jacket MFN # 36008 head thickness=5/8, jacket thickness = 25/64" Capacity Design: 1,893 L (500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 260 °C (500 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

Shell rated 150/FV @ 450 degrees F. Conventional jacket 150/FV @ 450 degrees F with welded 2:1 elliptical heads Alloy mixer with dual tier agitation, lower is a CBT, upper is a PBT Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

With a 5 RW drive, 15 to ratio, belt driven by a mechanical Vari-Speed with an adjustable sheeve, Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.2 bar (90 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Agitation: Yes. Support Type: Legs.

Glass Type: 3315/Nucite Jacket Pressure Rating reduced to 105PSI w/ internal vacuum. Capacity Design: 37.9 L (10 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 176.7 °C (350 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes. Support Type: Legs.

straight side and coned bottom , internal pressure -1/6 bar @ -30/150 degrees C (13500 liter), jacket -1/10 bar @ -30/150 degrees C (270 liter), TUV certified Powder transfer unit: Capacity: 19 liters Material: 316Ti (1.4571) stainless steel Manufacturer: Enco Serial number: T5350 Internal pressure: -1/6 bar @ -30/200 degrees C (19 liters) Dimensions: 206mm diameter x 600mm straight side Bolt dished top Bolts directly onto a tank/reactor flange. Capacity Design: 13,500 L (3,566 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes.

1325mm high bottom cone section internal pressure -1/6 bar @ -30/150 degrees C (13500 liter), jacket -1/10 bar @ -30/150 degrees C (270 liter), cone side: 9-80mm (1 for jacket), 1-50mm, 1-25mm openings TUV certified Valves, filters, pipework, etc. may be available. Capacity Design: 13,500 L (3,566 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 150 °C (302 °F). Jacket Material of Construction: Stainless Steel Austentic. Agitation: Yes.

29" vacuum internal 75 psi with vacuum on jacket. Capacity Design: 2,839 L (750 gallons). Internal Pressure: 3.4 bar (50 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6.2 bar (90 psi). Body Only: Yes.

• Glass type: #9115
• Jacket type: Straight Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Body Only: Yes. Support Type: Legs.

motor 3/50/380 W/flush valve. Capacity Design: 984.2 L (260 gallons). Internal Pressure: 4 bar (58 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 165 °C (329 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Lugs.

Glass type: 3115 internal pressure -1/6 bar @ 200 degrees C (1375 liter), jacket 6 bar @ 200 degrees C (231 liter) belt driven with lubricator Capacity Design: 1,375 L (363.2 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

Type D Glass #59 W/varispeed pulleys 14.5-115 rpm, belt driven to 2.6 KW, 3/50/220/380 volt Designed to German TUV standards. Capacity Design: 757.1 L (200 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 6 °C (42.8 °F).

• with condensing system
• norm #22101/02 internal design pressure 6 bar@200 deg C (7160ltr), jacket 6 bar@200 deg C (1135ltr)
• Motor: 3 phase
• via a gearbox
• Norm number: 22101/02
• 1-15mm (jacket)
• Bottom - 4-50mm (jacket) condensing system consists of: (1) 100ltr Schott QVF glass vertical receiver, (1) 1 sqm Schott QVF glass shell & spiral tube heat exchanger, pressure -1/0.3 bar @ 150 deg C, pressure -1/0.3 bar @ 150 deg C, (1)100m3/hr @ 33mbar Travaini c/steel 2-stage vacuum pump with 40ltr c/steel separator tank Capacity Design: 7,160 L (1,891 gallons). Internal Pressure: 6 bar (87 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Support Type: Lugs.

W/dip tube and thermo thymble. motor : 3/50/220/380 volt

• Jacket type: Agitated
• Glass type: #59
• Designed to German TUV standards. Capacity Design: 757.1 L (200 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Support Type: Lugs.

• reactor with condensing system
• CE-6300 series
• Certification: TUV
• internal design pressure -1/6 bar @ -25/+ 200 deg C (7590ltr),
• jacket -1/6 bar @ -25/+200 deg C (700ltr)
• Motor: 3 phase
• 3-finger retreat curved agitator
• Crane 909/909 mechanical seal with lubricator
• Straight side openings: 2-25mm (jacket)
• Condensing system: (1) 100ltr Schott QVF glass vertical receiver, (2) 100ltr Schott QVF glass round receivers, (1) 1.5 sqm vertical Schott QVF glass shell and spiral tube heat exchanger, (1) 1 sqm Schott QVF glass shell & spiral tube heat exchanger, (1) 26 sqm Schott QVF glass shell and tube horizontal heat exchanger, (1) PTFE centrifugal pump, (1) s/steel centrifugal pump
• Control panel: (1) Capacity Design: 7,590 L (2,005 gallons). Internal Pressure: 6 bar (87 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

• EHW Thale glass lined reactor -internal pressure: -1/6 bar @ 200°C (7160ltr),
• jacket: -1/6 bar @ 200°C (1135ltr) -built to TUV
• Motor: 3 phase
• 380/660 Volt
• 8-finger retreat curved agitator
• mechanical seal with lubricator
• Built to TUV standards
• Straight side: (1) 50mm (jacket)
• Control panels: 2 Capacity Design: 7,160 L (1,891 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Legs.

reactor with condensing system, internal design pressure -1/6 bar @ -25/+ 200 deg C (7590ltr), jacket -1/6 bar @ -25/+200 deg C (700ltr)

• TUV design: Yes
• Straight side: 2-25mm (jacket)
• Motor: 3 phase
• 380/660 volt
• mechanical seal type RF100-VOS-H with lubricator
• Condensing system components:
  • 1 x 100ltr Schott QVF glass vertical receiver, type VZG-100/g, pressure -1/0.3 bar @ 150 deg C
  • 2 x 100ltr Schott QVF glass round receivers, type VSV-100, pressure -1/0.3 bar @ 150 deg C
  • 1 x 1 sqm vertical Schott QVF glass shell and spiral tube heat exchanger, type HE6/10, pressure -1/0.3 bar @ 150 deg C
  • 1 x 1.5 sqm Schott QVF glass shell & spiral tube heat exchanger, type HE6/15, pressure -1/0.3 bar @ 150 deg C
  • 1 x 21 sqm Schott QVF glass horizontal shell and tube heat exchanger, type RGM12/21, pressure -1/0.3 bar @ 150 deg C
• Control panel: Yes Capacity Design: 7,590 L (2,005 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

• Reactor with condensing system
• CE-6300 series
• internal design pressure -1/6 bar @ -25/+ 200 deg C (7590ltr),
• jacket -1/6 bar @ -25/+200 deg C (700ltr)
• Motor: 3 phase -mechanical seal type RF100-VOS-H with lubricator
• Straight side openings: 2-25mm (jacket), bottom: 1-150mm with Pneumatic valve, 4-50mm (jacket)
• Condensing system:
  • 1 x 100 liter Schott QVF glass vertical receiver, type VZG-100/g, pressure -1/0.3 bar @ 150 deg C
  • 2 x 100 liter Schott QVF glass round receivers, type VSV-100, pressure -1/0.3 bar @ 150 deg C
  • 1 x 1 sqm vertical Schott QVF glass shell and spiral tube heat exchanger, type HE6/10, pressure -1/0.3 bar @ 150 deg C
  • 1 x 1.5 sqm Schott QVF glass shell & spiral tube heat exchanger, type HE6/15, pressure -1/0.3 bar @ 150 deg C
  • 1 x 26 sqm Schott QVF glass horizontal shell and tube heat exchanger, type RGM12/21, pressure -1/0.3 bar @ 150 deg C
  • 1 x 100 m3/hr @ 33 mbar Traveini 2-stage c/steel water seal vacuum pump with a 40 liter c/steel separator tank, type TRHC-40-190/C/RX, serial #BX432, driven by 6.6 kW, 3/50/380/420/655/725 volt, 1430 rpm Ex motor, mounted on a baseplate. Capacity Design: 7,590 L (2,005 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

• Reactor with condensing system
• Auftr number: 65577
• Standard: Din #28136 internal pressure -1/6 bar @ -25/200 deg C (8190ltr), jacket -1/6 bar @ -25/200 deg C (795ltr)
• Glass type: WWG 9115
• Straight side: 1-25mm (jacket)
• Crane mechanical seal with Pfaudler gas barrier system
• Condensing system: (1) 160 m3/hr @ 1 mbar abs. SIHI M160 CS dry running vacuum pump, DRY-Y-166016 7.5kw, 12000 rpm, CE certified, all mounted on a c/steel frame, (1) 100ltr Schott QVF glass vertical receiver, pressure -1/0.3 bar @ 150 deg C, (2) 100ltr Schott QVF glass round receivers, pressure -1/0.3 *bar @ 150 deg C, (1) 1 sqm vertical Schott QVF glass shell and spiral tube heat exchanger, pressure -1/0.3 bar @ 150 deg C, (1) 1.5 sqm Schott QVF glass shell & spiral tube heat exchanger, pressure -1/0.3 bar @ 150 deg C, (1) 10 sqm horizontal c/steel shell, s/steel tube and head heat exchanger, pressure -1/4 bar @ 150 deg C
• Control panel: (1) control panel Capacity Design: 8,190 L (2,164 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

• internal pressure 6 bar @ 200 deg C (7160ltr),
• jacket 6 bar @ 200 deg C (1135ltr)
• Certification: TUV
• Motor: 3 phase
• 380/660 volt
• 3-finger retreat curved agitator
• mechanical seal with lubricator
• Straight side:
• 1-15mm (jacket) -with (1) 1.5 sqm Schott QVF glass shell & spiral tube heat exchanger pressure: -1/0.3 bar @ 150 deg C
• Control panel: (1) Capacity Design: 7,160 L (1,891 gallons). Internal Pressure: 6 bar (87 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

1m diameter x 1m from main cover to bottom dish

• Glass type: WWG 9115
• DIN standard: 28136
• Certification: TUV & CE stamped and certified
• Ancillaries: Valves, filters, pipework, etc. may be available. Capacity Design: 861 L (227.5 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

design pressure internal -1/1.1 bar @ 50/150 deg C, jacket 6.3 bar @ 50/150 deg C (975ltr) 18.5kw, 3/50/380 volt motor Capacity Design: 12,500 L (3,302 gallons). Internal Pressure: 1.1 bar (16 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Jacket Pressure: 6.3 bar (91.4 psi). Jacket Temperature: 150 °C (302 °F). Agitation: Yes. Support Type: Legs.

• Jacket: Openings: 2-75mm, 6-32mm Capacity Design: 4,400 L (1,162 gallons). Internal Pressure: 4.4 bar (63.8 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 4.4 bar (63.8 psi). Jacket Temperature: 200 °C (392 °F). Support Type: Lugs.

• Enamel number: 3008
• Jacket: 3-50mm, 3-25mm, 2-38mm
• Total capacity: 4400 liters. Capacity Design: 4,400 L (1,162 gallons). Internal Pressure: 4.4 bar (63.8 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 4.4 bar (63.8 psi). Jacket Temperature: 200 °C (392 °F). Support Type: Lugs.

Internal pressure 6.38 bar and full vacuum @ -29/+200 degree C; jacket rated 6.83 bar @ -29/+200 degree C, 5.79 bar with full vacuum internal motor : 3/50/380/420 volt Capacity Design: 4,000 L (1,057 gallons). Internal Pressure: 6.4 bar (92.5 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6.8 bar (99.1 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

Internal pressure 3.58 bar and vacuum @ -50/+200 degree C, jacket rated 6 bar @ -50/+200 degree C Capacity Design: 500 L (132.1 gallons). Internal Pressure: 3.6 bar (51.9 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Legs.

100 liter Internal rated 3.58 bar and vacuum @ 200 degree C (124 liter), jacket rated 6 bar @ 200 degree C (25 liter). motor : 3/50/220/380 Belt driven with varispeed pulleys

• Glass type: #3115
• Gland type: Low duty packing gland
• Jacket: 1-40mm, 3-25mm
• Insulation: On straight side and bottom dish Capacity Design: 124 L (32.8 gallons). Internal Pressure: 3.6 bar (51.9 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 93.3 °C (200 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Legs.

• Glass lining: #3115
• Motor type: Ex motor
• Jacket 2-40mm motor : 3/50/220/380 volt
• Insulation: on straight side and bottom dish Capacity Design: 500 L (132.1 gallons). Internal Pressure: 3.5 bar (50.8 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Lugs.

Capacity Design: 15 L (4 gallons). Internal Pressure: 1 bar (14.5 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Support Type: Lugs.

• Glass: 3115 Capacity Design: 2,270 L (599.7 gallons). Internal Pressure: 6.2 bar (89.9 psi). Jacket Pressure: 6.9 bar (99.9 psi). Agitation: Yes. Support Type: Legs.

internal pressure 6 bar + vacuum @ 200 degrees C (1490 liter), jacket 6 bar @ 200 degrees C (265 liter), Glass type: 3008 Capacity Design: 1,490 L (393.6 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Legs.

BE4000 liter internal pressure -1/6 bar @ -30/150 degrees C (5381 liter) jacket -1/9 bar @ -30/160 degrees C (108/101 liter) jacket on straight side and bottom dish

• TUV certified
• Glass type: white 3009U
• Ex II 2G certified
• Fully insulated and clad Capacity Design: 5,381 L (1,422 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 150 °C (302 °F). Jacket Pressure: 9 bar (130.5 psi). Jacket Temperature: 160 °C (320 °F). Agitation: Yes.

TUV CE0045 internal pressure -1/6 bar @ -30/200 degrees C (2330 liter) jacket -1/9 bar @ -30/200 degrees C (330 liter) glass type RAS glass Capacity Design: 2,330 L (615.5 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 9 bar (130.5 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

Capacity Design: 15,142 L (4,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes.

Capacity Design: 11,356 L (3,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Orientation: Vertical. Agitation: Yes.

contract number 400902 Standard: DIN-28136 pressure internal -1/6 bar@ -25/+ 200 degrees C (1180 liter), jacket 7 bar @ -25/+ 200 degrees C (228 liter), Glass type 3008 Lubrication tank type: AAA Motor type: Ex proof (T4) Hansen electrical motor Capacity Design: 1,180 L (311.7 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 7 bar (101.5 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

reactor assembly Capacity Design: 5,678 L (1,500 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Agitation: Yes.

Series: RA 15 HP flange mount motor Capacity Design: 7,571 L (2,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Orientation: Vertical. Agitation: Yes. Support Type: Legs.

reactor body Capacity Design: 2,839 L (750 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 10.3 bar (150 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Support Type: Lugs.

Reglassed at UGE facility 105 psi w/full vac int. Glass #59. Capacity Design: 37.9 L (10 gallons). Internal Pressure: 1.72 bar (25 psi). Internal Full Vacuum: Yes. Internal Temperature: 176.7 °C (350 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 176.7 °C (350 °F). Support Type: Legs.

Hemi-coil two circuit, two zone split pipe coil jacket rated 450 psig @ 500 degress F, -20 deg F @ 450 psig. Capacity Design: 2,839 L (750 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 31 bar (450 psi). Jacket Temperature: 260 °C (500 °F). Body Only: Yes. Support Type: Lugs.

• Series: RA
• Assembly: Reactor Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 343.3 °C (650 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 232.2 °C (450 °F). Agitation: Yes.

laboratory type reactor body Fab # 16202 Auter 416387 195 Capacity Design: 75.7 L (20 gallons). Internal Pressure: 0.55 bar (8 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Body Only: Yes.

belt drived by a 1 HP 3/60/230/460 volt motor. Capacity Design: 75.7 L (20 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 232.2 °C (450 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Legs.

clamp top reactor body Capacity Design: 37.9 L (10 gallons). Internal Pressure: 10.3 bar (150 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 8.3 bar (120 psi). Jacket Temperature: 232.2 °C (450 °F). Body Only: Yes. Support Type: Legs.

internal pressure rated by -1/6bar @ 200 degrees C (total volume 2115 liter) jacket pressure rated by 7bar @ 200 degrees C (total volume 319liter) Capacity Design: 2,115 L (558.7 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 7 bar (101.5 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

Order number: 68525 internal pressure -1/6 bar @ 200 degrees C (total volume 2115 liter) jacket pressure 7 bar @ 200 degrees C (volume 319 liter) with 10hp/600rpm/VS-10 Pfaudler gear, ratio 1:5,05, belt driven by a 3,6kW/3~/50Hz/380-660V/1430rpm/Ex proof motor. Capacity Design: 2,115 L (558.7 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 7 bar (101.5 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Lugs.

Auftr number72176, internal pressure -1/6 bar @ 200 deg C (13332ltr) jacket -1/6.9 bar @ 200 deg C (1034ltr) Glass 3115, TUV stamped. Capacity Design: 13,332 L (3,522 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6.9 bar (100.1 psi). Jacket Temperature: 200 °C (392 °F). Body Only: Yes. Support Type: Lugs.

Jacket volume: 1034 liters VS80 Pfaudler drive, 120 rpm output, belt driven by a 44KW, 50 hz motor. mechanical seal on shaft with lubricator pump. Capacity Design: 13,332 L (3,522 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6.9 bar (100.1 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

Total jacket volume: 1034 liters With VS80 Pfaudler drive, 100 u/min, belt driven by a 44 KW, 50 cycle motor. Unit includes a pump for the mechanical seal. Weight 12,600 kg Capacity Design: 13,332 L (3,522 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6.9 bar (100.1 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

internal pressure -1/6 bar @ -10/+200 degrees C jacket 7 bar @ -10+200 degrees C jacket 1100 ltr. 400mm diameter x 3180mm tangent to tangent, VonRoll drive, 40/80 rpm, belt driven by a BBC 13/20kW, 3/50 /380V, 700/1400rpm motor, with mechanical seal on shaft with lubricator pump. Total weight 12,000 kg Capacity Design: 11,700 L (3,091 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 7 bar (101.5 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

8.000 liter Glass type: 3008, total jacket volume 790 liter, 2.2m ID, 2.3m OD, height 3m, total height 5175mm, (1) 3- finger baffle, (1) beavertail baffle white glass, with a CE 3~ gear drive, manufactured by SEW-Usocome, type RF102P, serial number 2670004708.0001.97, Belt driven by a 18,5 kW motor, manufactured by BBC, type D20L/NEDL180M4, serial number 541778, 3~/50Hz/220-380V/1.455rpm, EExdIIBT4; Capacity Design: 9,320 L (2,462 gallons). Internal Pressure: 4 bar (58 psi). Internal Full Vacuum: Yes. Internal Temperature: 180 °C (356 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 180 °C (356 °F). Agitation: Yes. Support Type: Lugs.

RL-2 Series glass lined reactor 4 KW, 3/50/380 volt, W/flush valve. Capacity Design: 1,476 L (390 gallons). Internal Pressure: 4 bar (58 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 165 °C (329 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Lugs.

Rated internal -1/6 bar @-10 to 250 degrees C; jacket -1/6 bar @-10/+250Degrees C 500 mm manway. with special agitator loop type. Capacity Design: 7,565 L (1,998 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 250 °C (482 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 250 °C (482 °F).

Ekato drive HWL 2060, Lining: Glass 3008 Capacity Design: 3,800 L (1,004 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

internal pressure -1/6 bar @ -10 to 200 Degrees C, jacket -10/6 bar @ -10 to 200 Degrees C total hieght 2055mm driven by 4/4,5 kW/50Hz/380V/6,9-7,7 kw/ 965-1465rpm motor, Capacity Design: 2,000 L (528.3 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

Capacity Design: 4,000 L (1,057 gallons). Internal Pressure: 6 bar (87 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F).

• Series: CCE
• Job number: 63771 internal design pressure 6.6 bar + full vac @ -29/+200 degrees C jacket 6.6 bar + full vacuum @ -29/+200 deg C
• Bodyglass: 3115
• agitator shaft nucerite 8000, weld high domed top Capacity Design: 10,000 L (2,642 gallons). Internal Pressure: 6.6 bar (95.7 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6.6 bar (95.7 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Legs.

Internal pressure -1/6bar@ 200 Degrees C, 980 liter, jacket 6 bar@ 200 Degrees C, 200 liter, Capacity Design: 980 L (258.9 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F).

BE-5000 liter job #700071 internal and jacket -1/+6.6 bar @ -29/+200 degrees C jacket 617 liter Blue glass 9115 VSO-100 quick-change mechanical seal with lubricator Capacity Design: 5,861 L (1,548 gallons). Internal Pressure: 6.6 bar (95.7 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6.6 bar (95.7 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

internal pressure -1/6 bar @ 200 Degrees C; jacket 6 bar@ 200 Degrees C with drive Capacity Design: 1,200 L (317 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F).

BE-5000 job #700037 design pressure internal and jacket -1/+6.6 bar @ -29/+200 degrees C

• Jacket capacity: 617 liter
• Blue glass 9115 30/135 rpm shaft speed VSO-100 quick-change mechanical seal with lubricator, Capacity Design: 5,861 L (1,548 gallons). Internal Pressure: 6.6 bar (95.7 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6.6 bar (95.7 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

internal pressure -1/6bar @ 200 Degrees C jacket 6 bar@ 200 Degrees C total volume 2115ltr, with VS 10 G drive. motor belt driven. mechanical seal with lubricator. Capacity Design: 2,115 L (558.7 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

Capacity Design: 1,375 L (363.2 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

internal pressure -1/6 bar @ -25/200 degrees C (28,309 liter), jacket -1/6 bar @ -25/200 degrees C (1510 liter) glass type 3009U (all white glass) weld high domed top, dished bottom Capacity Design: 28,309 L (7,478 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes.

Glass #3115 Driven by Lonza varispeed drive, w/4 KW, 3/50/380 volt Designed to German TUV standards. Capacity Design: 757.1 L (200 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

PLUG FREE 2000 liter Capacity Design: 2,157 L (569.8 gallons). Internal Pressure: 3.9 bar (56.9 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 15.6 bar (226.3 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

flange mtd 6 HP, 3/50/380 volt High duty packing gland. no shaft or baffle Int capacity 2000 liter; jkt capacity 300 liter. Capacity Design: 2,000 L (528.3 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Body Only: Yes. Agitation: Yes. Support Type: Lugs.

Capacity Design: 3,997 L (1,056 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Body Only: Yes. Support Type: Legs.

jacketed agitated reactor bottom. glass lined dished bottom. Atmosphere @ 400 deg. Capacity Design: 26.5 L (7 gallons). Internal Pressure: 1.01 bar (14.7 psi). Internal Temperature: 204.4 °C (400 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 204.4 °C (400 °F). Orientation: Vertical. Agitation: Yes. Support Type: Lugs.

total volume: 17.314 liter, Total jacket volume: 1.229 liters, with 36 kW Schorch 3/50Hz/500V/49,5A/1480rpm motor drive. Capacity Design: 17,314 L (4,574 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F).

Jacket volume: 318 liter with VSO 8/80 Pfaudler drive belt driven by a 6.8KW, 500V, 50 Hz, 1455 rpm, SCHORCH e-motor, ex proof (G3) Glass type WWG 9115/blue. Capacity Design: 2,050 L (541.6 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

total volume internal 2.050 liter, total volume jacket 318 liter, with VSO 8/80 Pfaudler drive, belt driven by a 5,0-7,5 KW, 500 V, 50 Hz, 1445 rpm, LOHER e-motor, ex proof (T3). Glass type WWG/blue, Capacity Design: 2,050 L (541.6 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

Tycon reactor, jacket volume 695 liter, mechanical seal on shaft type Pfaudler PC719, belt driven by 15 kW/50Hz/500V/1465 rpm e-motor, mfd by BBC type eQU180M4AF,with Pfaudler VSO gear type 021 618, Capacity Design: 7,595 L (2,006 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

total jacket volume 744 liter, with VSO 16/100 Pfaudler drive, belt driven by a 15.0 KW, 500 V, 50 Hz, 1465 rpm, SIEMENS e-motor, ex proof (T3). Glass type WWG/blue. Capacity Design: 7,605 L (2,009 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

total jacket volume 744 liter. with VSO 16/100 Pfaudler drive, belt driven by a 15.0 KW, 500 V, 50 Hz, 1450 rpm, LOHER e-motor, ex proof (G3). Glass type WWG/blue. Capacity Design: 7,605 L (2,009 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

10 bar w/full vacuum internal straight thru design agitator drive with packing gland, Capacity Design: 794.9 L (210 gallons). Internal Pressure: 10 bar (145 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Agitation: Yes. Support Type: Legs.

Glass type: WWG/blue, VSO 16/100 Pfaudler drive, belt driven by a 17.5 KW, 3/50/500 volt, 1475 rpm, SCHORCH ex proof (T3) motor, Capacity Design: 7,605 L (2,009 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

Glass type #3315. Has Lenze str thru drive 650/138 rpm output, belt driven by 2-speed motor, 2.2/4.5 HP, 3/60/220 volt 1800/900 rpm Capacity Design: 500 L (132.1 gallons). Internal Pressure: 6 bar (87 psi). Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

jacketed reactor. Glass SD40 Type FZS63F, rated 4.9 PS motor: 5.0 KW, 3/50/500 volt Designed to Swiss code. Capacity Design: 1,500 L (396.3 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Jacket Pressure: 7 bar (101.5 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Support Type: Lugs.

rated 9 PS V-belt driven w/Copp Mdl K16 gear reducer 300-1800 rpm. Agit output speed 8-49 rpm Manway cover is lifted w/hydraulic cylinder Insulation on str side and btm dish. Lifting eyes. Capacity Design: 2,500 L (660.4 gallons). Internal Pressure: 3.2 bar (46.4 psi). Internal Full Vacuum: Yes. Jacket Pressure: 5 bar (72.5 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes.

P series reactor body (1) 14" receiver cover. Capacity Design: 37.9 L (10 gallons). Jacket Pressure: 95 bar (1,378 psi). Jacket Temperature: 350 °C (662 °F). Body Only: Yes. Support Type: Legs.

Reactor Base Body, Capacity Design: 3,785 L (1,000 gallons). Internal Pressure: 6.9 bar (100 psi). Internal Full Vacuum: Yes. Internal Temperature: 232.2 °C (450 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 176.7 °C (350 °F). Body Only: Yes. Support Type: Legs.

reactor with (3) chambers rated -1/6 bar @ -25 to + 200 degrees C internal rated -1/30 bar @ -25 to +235 degrees C in the jacket Capacity Design: 14,340 L (3,788 gallons). Internal Pressure: 6 bar (87 psi). Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 30 bar (435.1 psi). Jacket Temperature: 235 °C (455 °F). Agitation: Yes.
