Used twin shell and double cone dryers for sale: gentle batch drying for powders and heat-sensitive materials
Highest-ranked available inventory for this selection.
Used twin shell and double cone dryers for sale: gentle batch drying for powders and heat-sensitive materials
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Select one or more values to narrow the current listings.
Use this setting to include or exclude equipment with this feature.
Enter a keyword to match this specification.
Enter a keyword to match this specification.
Enter a keyword to match this specification.
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Showing 25 of 25 matching Twin Shell & Double Cone Dryers. Search: "glass lined".
standard 6' diameter bucket with 18" diameter manway and 8" diameter outlet with 9 to 45 rpm on bucket with Hastelloy vacuum arm with stuffing box. With bull and pinion Reconditioned gear box, driven by 3HP XP class 1, div 2 , 3 phase, 60HZ, 230, 460 Volt motor with electric 10 ft-lbs. brake.
internal pressure -1/1 bar @ -10/200 deg C (4310ltr), jacket 6 bar @ -10/200 deg C (480ltr) 1m high top and bottom cones gear driven by a vari-speed drive 3/50/300/660 volt Hastelloy vacuum arm, mechanical seal, rotary union joint top cone with 1-450mm manway, bottom cone with 1-250mm discharge with valve (1) s/steel plate heat exchanger, 70 kw, pressure 16 bar @ 150 deg C (1) 8-28 m3/hr c/steel centrifugal pump, 14.5-9.5m hd,
1000 liter, jacketed double Cone Vacuum Dryer Blender with Hastelloy vacuum arm;
geared motor;
Body rotation speed range: 1.65 – 10 rpm;
Complete with stuffing box seal, and rotary Joint.11
15 liter capacity in body and 193 liter capacity in jacket; 3/50/220/380 volt
25 PSI with FV internal. 6 Ft diameter body.
Bull and pinion gear
230/460 volt gear head motor with electric brake
5 rpm rotation for a 1.08 rpm bucket rotation.
Mechanical seal on shaft,
Hastelloy 276-C vacuum arm. 18" carge prort with cover
Unit includes a SS load platform, with the platform mounted on hydraulic cylinders that lift the platform out of the way during dryer cycle.
glass 3113 Dryer body 2100 mm diameter x 1200 mm conical sections Jacket volume: 440 liter with gear reducer With 450 mm manway Jacket's heat transfer area: 13.4 square meters
25 PSI with FV internal
Bull and pinion gear
230/460 volt gear head motor with electric brake
5 rpm rotation for a 1.08 rpm bucket rotation.
Mechanical seal on shaft,
Hastelloy 276-C vacuum arm. 18" carge prort with cover
Unit includes a SS load platform, with the platform mounted on hydraulic cylinders that lift the platform out of the way during dryer cycle.
45 PSI with FV internal. 6 Ft diameter body
Bull and pinion gear
230/460 volt gear head motor with electric brake
5 rpm rotation for a 1.08 rpm bucket rotation.
Mechanical seal on shaft,
Hastelloy 276-C vacuum arm. 18" carge prort with cover
Unit includes a SS load platform, with the platform mounted on hydraulic cylinders that lift the platform out of the way during dryer cycle.
45 PSI with FV internal. 6 Ft diameter body.
Bull and pinion gear
230/460 volt gear head motor with electric brake
5 rpm rotation for a 1.08 rpm bucket rotation.
Mechanical seal on shaft,
Hastelloy 276-C vacuum arm. 18" carge prort with cover
Unit includes a SS load platform, with the platform mounted on hydraulic cylinders that lift the platform out of the way during dryer cycle.
45 PSI with FV internal. 6 Ft diameter body. Bull and pinion gear 230/460 volt gear head motor with electric brake, 5 rpm rotation for a 1.08 rpm bucket rotation Mechanical seal on shaft 18" carge prort with cover, Unit includes a SS load platform, with the platform mounted on hydraulic cylinders that lift the pltform out of the way during dryer cycle.
dryer/ blender Lined with glass 3009 top opening. 17" charge port with cover, 8" discharge.
auftr #215140, glass 2008 1009mm high top cone and 1111mm high bottom cone gear driven by a SEW -Usocome vari-speed drive 220/380 volt, rotary union joint, top cone with a 450mm manway, bottom cone with a 200mm with valve dryer with (1) 0.6 m3/hr @ 175 deg C Pasilac s/steel plate heat exchanger, (18) 130mm wide x 450mm high s/steel plates,
220/380 volt EEx-d motor with Rossi variable speed variator 150mm diameter hastelloy C vacuum arm openings top 600mm diameter with manway cover, bottom 200mm diameter
double cone vacuum dryer internal pressure -1/+6 bar @ -10/+200 degrees C (448 liter), jacket -1/+6 bar @ -10/+200 degrees C (110 liter),
internal pressure -1 bar @ 200 degrees C jacket 6 bar @ 200 degrees C 1625 ltr total capacity
(Reglassed @ UGE facility ). Glass #5015 W/Hastelloy C vac arm inside w/packing Openings: top 1-10" w/cover; btm 1-10" w/cover varidrive reducer, max output 154 rpm, min output 15.4 rpm Control panel with start/stop switches
48" dia shell 18" charge port (no cover), 8" discharge (no valve). Bare body only.
70 cubic feet working capacity 72" diameter Openings: 1-8", 1-18". No drive Legs.
dryer (bucket only) Glass # 5015 Internal pr
6' diameter shell. Packing glands on Hastelloy vacuum arm
Designed to German TUV standards Hastelloy vac arm w/packing gland 250mm dia feed w/bolted cover 1-150mm discharge Str side has 2-175mm 220/380 volt w/SEW Euro-varidrive Type R60-VU1, 7.4-43 output speed.
78” diameter shell Vessel 9115 (Blue) glass 18” top manway. 8” center bottom discharge
1.600 liter Gear driven with Gear head motor 5,8 kw/50Hz/220-380V/13,3-7,7 kw/1715rpm. With Busch Huckepack vacuum pump model HO-437-CO007, rated 400 CbM/Hr @ 0.5 bar. openings: top. 1-450mm, jacket: 3-40mm, bottom: 1-200mm, 1-175mm
Twin shell and double cone dryers are rotating batch dryers used for low-shear, uniform drying of powders, granules and crystalline materials. Their simple, sealed design makes them ideal for vacuum drying and mixing sensitive or friable compounds. With over 47 years of experience, IPP offers a large inventory of secondhand and surplus twin shell and double cone dryers from 20 complete plant sites and more than 15,000 ready-to-ship systems.
These dryers operate by rotating the vessel to gently tumble the product while applying indirect heat through a jacket. Vacuum can be applied to reduce drying temperature, which is especially valuable for thermally sensitive materials or solvent removal.
These dryers are built for corrosion resistance, cleanability and safe operation under vacuum:
Learn more about vacuum tumble dryers and their industrial applications from Pharmaceutical Technology.
Search the IPP inventory or contact IPP’s equipment experts to find a used, secondhand or surplus twin shell or double cone dryer. With global reach and systems ready to ship, IPP helps you save time and money on premium processing equipment.
