extraction column Has 1-8' section; (2) 36" long heads Unit has top entering agit Mech seal on shaft (no motor) Diameter (1): 457.2 mm (18 in). Length (overall): 4,267 mm (168 in). Pressure: 1 bar (14.5 psi). Temperature: 100 °C (212 °F).
Agitated Seperation for liquids seperation Fabrication # 722399 jacket rated for 29 psi at 329 degrees F volume of the jacket is 2.5 gallons Motor drive flange is 11" Drive shaft is 1" SS shaft has a flex coupling Column has eight sight glasses (four on each side) Diameter (1): 152.4 mm (6 in). Diameter (2): 152.4 mm (6 in). Length (overall): 111.8 mm (4.4 in). Pressure: 2 bar (29 psi). Temperature: 165 °C (329 °F).
with a 304 SS jacket Extraction Contactor Column Built to code four stages solid separation. Jacket rated 2 bar @ 200 C Column outside diameter is 13" with jacket. Column built in three sections, one 30", one is 26" and one is 56" long. motor with mechanical seal Diameter (1): 304.8 mm (12 in). Diameter (2): 304.8 mm (12 in). Length (overall): 3,048 mm (120 in). Pressure: 2 bar (29 psi). Temperature: 200 °C (392 °F). Packing Material: Other.
drive - 90-389 rpm 1465/305 rpm Eurodrive motor, approx (20) blades on shaft, water cooled mechanical seals (3) s/steel centrifugal pumps Diameter (1): 597 mm (23.5 in). Length (overall): 5,277 mm (207.8 in). Pressure: 2.5 bar (36.3 psi). Temperature: 150 °C (302 °F).
column chamber in (4) bolted sections, approx (20) blades on shaft water cooled mechanical seals (3) s/steel centrifugal pumps Diameter (1): 597 mm (23.5 in). Length (overall): 5,277 mm (207.8 in). Pressure: 2.5 bar (36.3 psi). Temperature: 150 °C (302 °F).
14" x 32'10" (~355mm x 10000mm) OAH Contactor Column with welded dish bottom head skirt mounted with top mounted agitator Certified by Robert Mitchell, Serial # DB-90, MFG. # 72 with an MDMT of -20 degrees F at 75/FV psi. Column diameter is 14" diameter x 26'6" high, with 4’ high top vapor section, 316SS welded dished bottom Hastelloy C flat bolted top head. With top mounted agitator driven by Reliance electric motor with an eccentric gear. Motor is 1 hp, 1750 rpm with a Master XE speed reducer with a 11:4 ratio., mechanical seal on shaft, 1" SS shaft, Stroke is up and down. Column section has the following openings: five 3", two 2", one 1" and one 1/2" Diameter (1): 355.6 mm (14 in). Length (overall): 8,077 mm (318 in). Pressure: 5.2 bar (75 psi). Vacuum: Yes. Temperature: 204.4 °C (400 °F).
12 stages agitated extraction column R25/4 (75-375 infinitely variable) Double mechanical seal, type Crane 109/109, Driven by a 0.25kW electrical motor manufactured by BBC type eQUx71MA4, 3~/50Hz/220-380V/1400rpm EX proof (ExeG3) (2) bolt dished heads Diameter (1): 320 mm (12.6 in). Pressure: 2 bar (29 psi). Vacuum: Yes.
316SSTi / 1.4571 SS Extraction column Wth Lightnin agitator drive Model 82S 7,5 V, 5 KW drive, agitator Model R 100, 7 levels with each 6 adjustable agitator blades, diameter 381 mm, max rotation 137 Rpm, mechanical seal on shaft Style C, Code / 3. Diameter (1): 900 mm (35.4 in). Length (overall): 5,580 mm (219.7 in). Pressure: 3 bar (43.5 psi). Temperature: 100 °C (212 °F).
Fractional distillation is the most common industrial separation process. Because distillation uses significant energy for both heating and cooling, it can account for half or more of a particular plant's entire operating costs. It's important to save on the capital equipment of a new distillation plant or an expansion project. Buying previously owned, aka used or second hand, distillation columns saves capital.
Another reason to consider buying used or second hand distillation columns is that the most effective ways to reduce distillation operating costs are through process optimization and control techniques, such as measuring differential pressure, not by buying newly manufactured columns.
IPP's stock of fractionation columns were used in a wide array of applications such as solvent recovery columns in Benzene, Toulene, Styrene, VCM plants, purification columns and light alcohol distillation columns in specialty chemical plants, steam stripping columns in the agrichemical/fertilizer industry at ammonia, urea, and di-methyl amine (DMA) plants, in VOC scrubbing systems for removing unreacted olefins and hydrocarbons found at PET plants and high vacuum batch distillation processes among others.
