12 stages agitated extraction column R25/4 (75-375 infinitely variable) Double mechanical seal, type Crane 109/109, Driven by a 0.25kW electrical motor manufactured by BBC type eQUx71MA4, 3~/50Hz/220-380V/1400rpm EX proof (ExeG3) (2) bolt dished heads
Type: Column
Subtype: Contactor
Manufacturer: Kuhni
Model: 722399
Condition: Used
Material: Hastelloy - C276
Diameter (1): 152.4 mm (6 in)
Diameter (2): 152.4 mm (6 in)
Agitated Seperation for liquids seperation Fabrication # 722399 jacket rated for 29 psi at 329 degrees F volume of the jacket is 2.5 gallons Motor drive flange is 11" Drive shaft is 1" SS shaft has a flex coupling Column has eight sight glasses (four on each side)
Length (overall): 111.8 mm (4.4 in). Pressure: 2 bar (29 psi). Temperature: 165 °C (329 °F).
Type: Column
Subtype: Contactor
Manufacturer: Kuhni
Condition: Used
Material: Hastelloy - C276
Diameter (1): 304.8 mm (12 in)
Diameter (2): 304.8 mm (12 in)
with a 304 SS jacket Extraction Contactor Column Built to code four stages solid separation. Jacket rated 2 bar @ 200 C Column outside diameter is 13" with jacket. Column built in three sections, one 30", one is 26" and one is 56" long. motor with mechanical seal
Length (overall): 3,048 mm (120 in). Pressure: 2 bar (29 psi). Temperature: 200 °C (392 °F). Packing Material: Other.
Type: Column
Subtype: Contactor
Manufacturer: Kuhni
Condition: Used
Material: Stainless Steel 316
Diameter (1): 457.2 mm (18 in)
Length (overall): 4,267 mm (168 in)
extraction column Has 1-8' section; (2) 36" long heads Unit has top entering agit Mech seal on shaft (no motor)
Pressure: 1 bar (14.5 psi). Temperature: 100 °C (212 °F).
