recessed filter press. 62.4 sq meter filter area, can be expanded to (60) plates (96 sq meter). 4 eye center feed, Motorized hydraulic closure. Rated 170-200 bar. W/ safety mirrors, Cake thickness approx 30 mm. Filter volume approx 0.88 cu meter. Filter plates are suspended from an overhead beam.
Type: Filter
Subtype: Plate And Frame
Manufacturer: Rittershaus & Blecher
Condition: Used
Material: Plastic
Filtration Area: 209 m² (2,250 ft²)
Cake Volume: 3.8 m3 (134.2 ft3)
non gasketed recessed plate filter press 1 & 3 button 2 eye open delivery With single hydraulic piston closer Includes rubber belt conveyor that runs the length of the press for cake removal.
Number of Plates: 95. Plate Diameter or Width: 1,200 mm (47.2 in). Plate Height: 1,200 mm (47.2 in). Plate Thickness: 79.8 mm (3.1 in). Plates Recessed: Yes.
Type: Filter
Subtype: Plate And Frame
Manufacturer: Rittershaus & Blecher
Model: 13109
Condition: Used
Material: Plastic
Filtration Area: 96.7 m² (1,041 ft²)
Pressure: 6 bar (87 psi)
(42) recessed plates with red and blue buttons for washing, (2) end plates 2.25 cubic meter cake capacity 4-eye top center feed, closed delivery, motorized hydraulic closure pressure 270 bar.
Cake Volume: 2,250 m3 (79,457 ft3). Number of Plates: 44. Plate Diameter or Width: 1,200 mm (47.2 in). Plate Height: 1,200 mm (47.2 in). Plates Recessed: Yes.
Type: Filter
Subtype: Plate And Frame
Manufacturer: Rittershaus & Blecher
Condition: Used
Material: Plastic
Filtration Area: 37.9 m² (408 ft²)
Pressure: 15 bar (217.6 psi)
recessed membrane filter press. recest membran plates, pmeumatic cake discare, With overhead plate shifter driven by a 0,55 kW (Ex) motor, 3 ph/50Hz/1400-18 UPM. Hydraulic press closer, powered by a 2.5 kW (Ex) 3ph /50 Hz/ 1500 UPM motor. Total space for chambers 2500 mm.
Cake Volume: 0.6 m3 (21.2 ft3). Number of Plates: 36. Plate Diameter or Width: 800 mm (31.5 in). Plate Height: 800 mm (31.5 in). Plate Thickness: 66 mm (2.6 in). Plate Shifter: Yes. Plates Recessed: Yes.
Type: Filter
Subtype: Plate And Frame
Manufacturer: Rittershaus & Blecher
Model: 13109
Condition: Used
Material: Plastic
Filtration Area: 96.7 m² (1,041 ft²)
Pressure: 6 bar (87 psi)
(42) recessed plates with red and blue buttons for washing, (2) end plates. 2.25 cubic meter cake capacity. 4-eye top center feed, closed delivery. motorizzed hydraulic closure pressure 270 bar.
Cake Volume: 2.2 m3 (79.5 ft3). Number of Plates: 44. Plate Diameter or Width: 1,200 mm (47.2 in). Plate Height: 1,200 mm (47.2 in). Plates Recessed: Yes.
