high intensity mixer Has 3-blade propellor type mixer. Vert mixing chamber 14" dia x 16" deep. Has manual plow. Manual plow valve on 4" outlet. variable speed motor 530 rpm min W/controls and timers.
Type: Mixer-Intensive
Manufacturer: Silverson
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 36 L (9.5 gallons)
Motor Power: 7.5 kW (10.1 HP)
Top: Bolt flat top Bottom: Weld cone bottom Agitator: 316SS worm type Shaft thickness: 3/4" (19mm) Worm diameter: 4 1/4" (107mm) varispeed gearbox. W/spare agit. Openings: top 1-12" (304mm) x 10 1/2" (266mm) feed chute; btm 1-2" (50mm) discharge.
Bowl Diameter: 355 mm (14 in). Bowl Depth: 355 mm (14 in). Blade Type: 107mm dia 316SS worm type agitator.
Type: Mixer-Intensive
Manufacturer: Jaygo
Model: DISHO V180/1300
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 1,300 L (343.4 gallons)
Motor Power: 14.9 kW (20 HP)
(317gallons) Vacuum Mixing, Dispersing and Homogenizing Unit with bolted dished top, cone bottom Dispersing and Homogenizing Unit Manufactured by Stainless Fabricators Inc rated FV/25 psi @ 300 degrees F internal fully insulated with SS shroud over insulation. With Top mounted dual motion agitator manufactured by Jaygo, has wide sweep with pitched blades and center shaft with pitched blades that intermesh with counter rotating wide sweep agitator. 3/60/230/460 volt motor Vessel openings include: Top -14" manway with hinged cover, (3) 4"; (3) 1". Vessel discharges into a horizontal DISHO homogenizing mill, multi chamber, driven by a 60 HP 3/60/230/460 volt motor. Complete skid mounted system with Intervac 5 HP water seal vacuum pump, controls and stainless steel enclosure for pump and mill drive.
Bowl Diameter: 1,118 mm (44 in). Bowl Depth: 1,829 mm (72 in). Blade Type: wide sweep & pitched perforated blade w/ side wall scraper. Pressure: 1.72 bar (25 psi). Temperature: 148.9 °C (300 °F). Bowl Jacket: Yes. Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 148.9 °C (300 °F). Vacuum: Yes. Controls: Yes.
Type: Mixer-Intensive
Manufacturer: Plastechnik Greiz
Model: MVA-1000R
Condition: Unused
Material: Stainless Steel 316
Capacity (Design): 1,000 L (264.2 gallons)
Motor Power: 30 kW (40.2 HP)
Trusioma high intensive mixer. Jacket rated 0.05 mPA. 2-tier 2-blade impellor. Total volume 1.0 cu M. Approx working capacity 400 to 600 liters. Top bolt cover with 1/3 hinged opening. 28-40 HP (22 to 30 KW), 3/50/220/380 volt, 740 to 1480 rpm XP motor thru gear reducer. Bowl 44.5 to 87 rpm. 200mm outlet w/manul gate valve.
Bowl Diameter: 1,440 mm (56.7 in). Bowl Speed (RPM): 87. Blade Type: 2-tier 2-blade. Bowl Jacket: Yes. Vacuum: Yes.
Type: Mixer-Intensive
Manufacturer: Henschel
Model: FM10
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 10 L (2.6 gallons)
Motor Power: 1.8 kW (2.4 HP)
sanitary jkt high intensity mixer SS 4-blade rotor, manual SS plow Variable speed drive. CS str jkt. Hinged top cover with 2 1/2" (63mm) sight glass w/light, 2-1/2" (12mm) jkt outlets, 1-2 1/4" (57mm) discharge. On/off switch, safety cutoff switch on top cover.
Bowl Diameter: 230 mm (9.1 in). Bowl Depth: 230 mm (9.1 in). Blade Type: rotor mounted (4x) SS blades w/ manual plow. Bowl Jacket: Yes. Jacket Material: Carbon Steel. Controls: Yes.
