(317gallons) Vacuum Mixing, Dispersing and Homogenizing Unit with bolted dished top, cone bottom Dispersing and Homogenizing Unit Manufactured by Stainless Fabricators Inc rated FV/25 psi @ 300 degrees F internal fully insulated with SS shroud over insulation. With Top mounted dual motion agitator manufactured by Jaygo, has wide sweep with pitched blades and center shaft with pitched blades that intermesh with counter rotating wide sweep agitator. 3/60/230/460 volt motor Vessel openings include: Top -14" manway with hinged cover, (3) 4"; (3) 1". Vessel discharges into a horizontal DISHO homogenizing mill, multi chamber, driven by a 60 HP 3/60/230/460 volt motor. Complete skid mounted system with Intervac 5 HP water seal vacuum pump, controls and stainless steel enclosure for pump and mill drive.
Type: Mixer-Intensive
Manufacturer: Koruma Mashinenbau GmbH
Model: DISHO V180/1300
Condition: Used
Material: Stainless Steel 316L
Capacity (Design): 1,300 L (343.4 gallons)
Motor Power: 51 kW (68.4 HP)
DISHO Vacuum Mixing Dispersing and Homogenizing Unit vessel manufactured by Hebold, rated FV/36 psi at 356 degrees F internal; 24" cone bottom. Flanged and bolted dish top head. Vessel openings include: Top -14" manway with hinged cover, (3) 4"; (3) 1". Fully insulated with SS shroud over insulation. Mounted on legs With Top mounted double motion agitator with wide sweep with perforated pitched blades and side wall scrapers, and center shaft with perforated pitched blades that intermesh with counter rotating wide sweep agitator blades. 3/60/230/460 volt motor Vessel discharges into a horizontal DISHO homogenizing mill, multi chamber, driven by a 51 KW 3/60/230/460 volt motor. Complete skid mounted system with approx. 5 HP water seal vacuum pump, controls and stainless steel enclosure for pump and mill drive.
Bowl Diameter: 1,118 mm (44 in). Bowl Depth: 1,829 mm (72 in). Blade Type: wide sweep & pitched perforated blade w/ side wall scraper. Pressure: 2.5 bar (36.3 psi). Temperature: 180 °C (356 °F). Bowl Jacket: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 180 °C (356 °F). Vacuum: Yes. Controls: Yes.
Type: Mixer-Intensive
Manufacturer: Jaygo
Model: DISHO-V-120-85
Condition: Unused
Material: Stainless Steel 304
Capacity (Design): 120 L (31.7 gallons)
Motor Power: 0.75 kW (1 HP)
Jaygo vacuum dispersion and homogenizing mixer system Mixing chamber rated 20 psi and full vacuum @ 350 degree F to -20 degree F minimum. All fittings sanitary. Unit measures 20" diameter x 20" straight side x 8" cone bottom clamped dished top. Gate design agitator with teflon scraper blades 5 rpm minimum, 34 rpm maximum. Drive has automatic hydraulic lift mechanism with 24" lift capacity System includes: (1) 3 HP Nash brass vacuum pump, Model #AT34. (1) 1 HP Moyno pump, Model #IFF4SSV, driven by 1 HP Reeves varidrive. (1) approx 5 HP inline disperser. Includes all controls and power box, temperature probes and capacitance probes.
Blade Type: teflon scrapers in gate blade design. Pressure: 1.38 bar (20 psi). Temperature: 176.7 °C (350 °F). Bowl Jacket: Yes. Jacket Pressure: 3.4 bar (50 psi). Jacket Temperature: 176.7 °C (350 °F). Vacuum: Yes. Controls: Yes.
Type: Mixer-Intensive
Manufacturer: Silverson
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 36 L (9.5 gallons)
Motor Power: 7.5 kW (10.1 HP)
Top: Bolt flat top Bottom: Weld cone bottom Agitator: 316SS worm type Shaft thickness: 3/4" (19mm) Worm diameter: 4 1/4" (107mm) varispeed gearbox. W/spare agit. Openings: top 1-12" (304mm) x 10 1/2" (266mm) feed chute; btm 1-2" (50mm) discharge.
Bowl Diameter: 355 mm (14 in). Bowl Depth: 355 mm (14 in). Blade Type: 107mm dia 316SS worm type agitator.
Type: Mixer-Intensive
Manufacturer: Gunther Papenmeier
Model: TGAHK
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 37.9 L (10 gallons)
Motor Power: 22.4 kW (30 HP)
high intensity mixer Has 3-blade propellor type mixer. Vert mixing chamber 14" dia x 16" deep. Has manual plow. Manual plow valve on 4" outlet. variable speed motor 530 rpm min W/controls and timers.
Bowl Diameter: 355.6 mm (14 in). Bowl Depth: 406.4 mm (16 in). Blade Type: 3 blade propellor. Bowl Jacket: Yes. Jacket Material: Carbon Steel. Controls: Yes.
