15mm thick basket. 350 liter volume/.3 (160mm) cake capacity With fluid coupling. CS plow discharge mechanism powerpak driven by 0.8 KW, 3/50/380 volt, 1415 rpm motor. Cake depth indicator. Openings: 280mm x 250mm product discharge, 125mm CS deed pipe, 50mm CS wash pipe with (3) spray nozzles, 100mm vapour, hinged front door with 1-225mm, 1-75mm, 1-50mm.
Type: Centrifuge-Peeler
Manufacturer: Krauss Maffei
Model: HZ1302
Condition: Used
Material: Stainless Steel 316
Basket Diameter: 1,350 mm (52.4 in)
Basket Depth: 570 mm (22.4 in)
(V4AE) peeler centrifuge. 15mm thick basket 250 liter volume/.3 (160mm) cake capacity With fluid coupling, carbon steel plow discharge mechanism hydraulically driven powerpak powerpak driven by 0.8 KW, 3/50/380 volt, 1415 rpm motor Cake depth indicator Oepnings: 280mm x 250mm product discharge, 125mm carbon feed pipe, 50mm carbon steel wash pipe with (3) spray nozzles, 400mm x 200mm filtrate, 100mm vapour, hinged front door with 1-225mm , 1-75mm, 1-50mm.
Filtration Area: 0.08 m² (0.86 ft²). Motor Power: 74.6 kW (100 HP). Speed-RPM Maximum: 1,430. Load Weight: 350 kg (772 lb).
Type: Centrifuge-Peeler
Manufacturer: Krauss Maffei
Model: HZ1302
Condition: Used
Material: Stainless Steel 316
Basket Diameter: 1,300 mm (51.2 in)
Basket Depth: 570 mm (22.4 in)
15mm thick basket 3 (160mm) cake capacity Loher motor With fluid coupling. carbon steel plow discharge mechanism. Hydraulically driven by powerpak, powerpak driven by 0.8 KW, 3/50/380 volt, 1415 rpm motor. Cake depth indicator. Openings: 280mm x 250mm product discharge, 125mm carbon steel feed pipe, 50mm carbon steel wash pipe with (3) spray nozzles, 400mm x 200mm filtrate, 100mm vapour, hinged front door with 1-225mm, 1-75mm, 1-50mm.
Filtration Area: 0.08 m² (0.86 ft²). Motor Power: 134.2 kW (180 HP). Speed-RPM Maximum: 1,110. Load Weight: 281.8 kg (621 lb).
Type: Centrifuge-Peeler
Manufacturer: Krauss Maffei
Model: HZ-100/2VK
Condition: Used
Material: Stainless Steel 316
Basket Diameter: 1,000 mm (39.4 in)
Basket Depth: 630 mm (24.8 in)
auftr # 300341/2 20mm basket thickness 125mm cake thickness 150mm filtrate outlet 75mm feed pipe (feed cone 1n basket) 2-50mm diameter adjustable pipes (suck or blow cake off) hinged front door with 2-150mm sightglasses
Motor Power: 37 kW (49.6 HP). Speed-RPM Maximum: 1,640. Load Weight: 216 kg (476.2 lb).
Type: Centrifuge-Peeler
Manufacturer: Krauss Maffei
Model: HZ-80/VK
Condition: Used
Material: Stainless Steel 316
Basket Diameter: 800 mm (31.5 in)
Basket Depth: 380 mm (15 in)
auftr # 300272/2 100mm cake thickness 300mm x 100mm filtrate opening 30mm feed pipe (feed cone in basket) 2-50mm diameter adjustable pipes (suck or blow cake off) hinged front door with 2-75mm sightglasses
Filtration Area: 0.03 m² (0.32 ft²). Motor Power: 30 kW (40.2 HP). Speed-RPM Maximum: 1,980. Load Weight: 88 kg (194 lb).
