Peeler Centrifuges from IPP. Over 49 pieces for sale. Chemical Equipment and Process Equipment buy unused, surplus, second hand or used here.
Highest-ranked available inventory for this selection.
Peeler Centrifuges from IPP. Over 49 pieces for sale. Chemical Equipment and Process Equipment buy unused, surplus, second hand or used here.
Set a numeric threshold to narrow the matching listings.
Set a numeric threshold to narrow the matching listings.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Showing 25 of 49 matching Peeler Centrifuges.
wall thickness 25 mm
belt driven by 45 kw motor, 3/50/380-660 volt,
80mm feed, 300mm discharge on front door,
260mm wide x 660mm long filtrate, central lubrication system, and controls
wall thickness 25 mm
class B IP 54
with central lubrication system
No controls
peeler centrifuge
with a 0.12kw, 3/50/230/400 volt, 1360 rpm fan motor,
discharge screw/plow driven by 2.2kw, 3/50/400 volt
Ex motor, hydraulic door locking mechanism and cake thickness device driven by a hydraulic pump with a 0.75kw, 3/50/400 volt Ex motor, hinged front door, 1-200mm discharge,
1-250mm filtrate with s/steel tank,
centrifuge with (1) Siemens OP37 controller,
(1) s/steel GAF filter, (1) diaphragm pump,
(1) 600ltr plastic tank, 900mm diameter x 1m high,
(1) s/steel centrifugal pump, manufactured by SERO, type SEMA-3111-75-2.32,
(1) 35ltr Schott glass reciever, (2) flow meter, (2) pneumatic valves, (1) main control panel
24mm basket thickness
hydraulic driven basket via a powerpack
horizontal peeler centrifuge
Motor is CE rated
80mm feed pipe
300mm discharge line on front door
260mm wide x 660mm long filtrate.
Basket 19.2mm thick
Gravity discharge. 6" sight glass, 4 x 6 sample door, 6 x 6 door in solids discharge chute,
1 1/2" feed pipe. Cake detector. Oil lubricated bearing assembly with 1/2 KW motor
Includes inertia base, springs, and visco dampeners.
24mm basket thickness
hydraulic driven basket via a powerpack
peeler centrifuge
Basket thickness: 13mm
Cake capacity: 125mm
316 stainless steel plow, hydraulically driven by powerpak. Powerpak driven by 1.5 KW, 3/50 motor.
Cake discharge with internal screw conveyor driven by approx 1.5 KW motor.
Cake depth indicator. Openings: 1-50mm feed, 2-25mm wash pipes: (1) with 1-spray nozzle and (1) with 3-spray slits, 1-200mm cake discharge, 1-160mm vapour, 300mm long x 125mm high filtrate. Unit with control panel.
maximum filling capacity 232 Kg / 180 liter
With spare parts and documents.
basket 15mm thick
perforated basket
Cake capacity 140mm
316 stainless steel hydraulically driven plow
Cake discharge with internal screw conveyor
Openings: 1-75mm feed, 1-25mm wash pipe with 1-spray nozzle,
1-150mm cake discharge, 1-100mm, 1-50mm vapour,
300mm long x 125mm high filtrate.
With available documents and parts.
peeler centrifuge
basket 15mm thick
perforated basket
cake capacity 125mm
22 KW, 3/50/380/660 volt
316L stainless steel plow, hydraulically driven by Loher powerpak, driven by 1.5 KW, 3/50/220/380 volt, 1405 rpm Ex motor. Cake discharge with internal screw conveyor driven by approx 1.5 KW motor.
Cake depth indicator.
Openings: feed 1-50mm, wash pipes 1-25mm (with 1 spray nozzle), 1-12mm (with 3 spray slits), cake discharge 1-175mm, filtrate 300mm long x 125mm high, vapour 1-150mm, 2-40mm. .
peeler centrifuge
basket 13mm thick
perforated basket
cake capacity 125mm
Basket drive serial #: 2260376
Hydraulic motor: Hydro-Gigant
3/50/220/380 volt
316 stainless steel plow driven by hydraulic powerpak, driven by 1.5 KW, 3/50/220/380 volt, 1405 rpm Ex motor.
Cake discharge with internal screw conveyor driven by approx 1.5 KW motor
Openings: feed 1-50mm, wash pipes 1-25mm (with 1 spray nozzle), 1-12mm (with 3 spray slits), cake discharge 1-175mm; filtrate 300mm long x 125mm high, vapour 1-150mm, 2-40mm.
(V4AE) peeler centrifuge.
15mm thick basket
250 liter volume/.3 (160mm) cake capacity
With fluid coupling, carbon steel plow discharge mechanism
hydraulically driven powerpak
powerpak driven by 0.8 KW, 3/50/380 volt, 1415 rpm motor
Cake depth indicator
Oepnings: 280mm x 250mm product discharge, 125mm carbon feed pipe, 50mm carbon steel wash pipe
with (3) spray nozzles, 400mm x 200mm filtrate, 100mm vapour, hinged front door with 1-225mm , 1-75mm, 1-50mm.
Single motion knife discharge
Cake thickness 126mm
Solids outlet 177mm x 126mm
filtrate 126mm; feed 50mm;
wash 2-19mm with (14) spray holes each;
vapour 75mm; sight glass 1-100mm.
carbon steel outer shell with 316 stainless steel internal lining. (*)
horizontal peeler centrifuge
basket thickness 16mm
Titanium hinged front door with hydraulic clamp mechanism
class 1 Div II motor, hydraulic operated peeler mechanism with front discharge chute, peeler driven by a powerpack, power pack unavailable but was driven by 0.75/0.86kw, 3/50/60/230-400/220-380/240-415/265-460 volt, 1390/1371/1402/1669 rpm ATEX Exd 11B T4Gb IP55 motor, level device,
Titanium Gr.2 (contact parts) Horizontal peeler centrifuge,
Titanium seive type basket,
16mm thickness,
Titanium hinged front door with hydraulic clamp mechanism
hydraulic operated peeler mechanism with front discharge chute, peeler driven by a powerpack, power pack driven by 0.75/0.86kw, 3/50/60/230-400/220-380/240-415/265-460 volt, 1390/1371/1402/1669 rpm ATEX Exd 11B T4Gb IP55 motor, level device,
Hastelloy C-4 discharge blade
955/750 u/min,
No drive or hydraulics.
1.300mm diameter
904 SS / rubber lined
basket wall thickness 20mm,
housing / door lined with rubber VULCOFERAN 2190
Hastelloy C-22 knife discharge
Hastelloy C-2000 feed pipe and Hastelloy B wash pipe
Driven by a 75kW electrical motor,
manufactured by Felten & Guilleaume,
type F315S-6, serial number 215080
EExdeII C T 4, motor fan impeller driven by a 0,37 kW electrical motor,
manufactured by Felten & Guilleaume,
type 71L-4,
serial number 215098,
3~/50Hz/500V/ 1.400rpm,
EExdeII C T 4,
with a hydraulic power pack driven by a 0,75kW electrical motor,
manufactured by Siemens,
type MA5083-4BA34,
serial number F287295001004,
3~/50/Hz/500V/
1.385rpm,
EExdeII T1...T3,
sedimentation centrifuge
Basket 8.2mm thick
Rotary knife
Max cake thickness 70mm
Single motion,
hydraulic plow w/screw discharge
Feed pipe 50mm
wash pipe 25mm
filtrate outlet 120mm x 300mm
solids outlet 285mm
Hastelloy C-4 discharge blade
No drive or hydraulics.
955/750 rpm
horizontal peeler centrifuge
basket thickness 16mm
Titanium hinged front door with hydraulic clamp mechanism
class 1 Div II motor, hydraulic operated peeler mechanism with front discharge chute, peeler driven by a powerpack, power pack driven by 0.75/0.86kw, 3/50/60/230-400/220-380/240-415/265-460 volt, 1390/1371/1402/1669 rpm ATEX Exd 11B T4Gb IP55 motor, level device,
When your process requires efficient solid-liquid separation with gentle handling of solids, peeler centrifuges deliver exceptional batch performance across multiple industries. With over 47 years of process equipment expertise, IPP offers immediate access to high-quality used peeler centrifuges sourced from 20 complete plant sites and included in our inventory of over 15,000 ready-to-ship pieces of equipment. Choosing used peeler centrifuges from IPP allows companies to save on capital costs, shorten project timelines, and maintain consistent production output.
Peeler centrifuges are batch-operated filtering centrifuges designed to separate solids from liquids and automatically remove the cake by scraping or “peeling” it off the filter media. They are ideal for applications where solids must be removed without excessive breakage, and where thorough washing of the cake is often required.
Peeler centrifuges are engineered for chemical resistance, sanitation, and heavy-duty operation:
Learn more about peeler centrifuge technology at Chemical Processing.
Search the IPP inventory or contact IPP’s equipment specialists to find a high-quality peeler centrifuge ready to meet your separation needs. With ready-to-ship inventory, IPP helps companies optimize separation efficiency, meet strict quality requirements, and manage production costs effectively.
