Solid Bowl-Decanter Centrifuges from IPP. Over 46 pieces for sale. Chemical Equipment and Process Equipment buy unused, surplus, second hand or used here.
Highest-ranked available inventory for this selection.
Solid Bowl-Decanter Centrifuges from IPP. Over 46 pieces for sale. Chemical Equipment and Process Equipment buy unused, surplus, second hand or used here.
Choose a subtype for a more focused set of listings.
Set a numeric threshold to narrow the matching listings.
Use this setting to include or exclude equipment with this feature.
Enter a keyword to match this specification.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Showing 25 of 46 matching Solid Bowl-Decanter Centrifuges.
single lead conveyor
w/hardfacing
Used on Dorr Oliver 16L and Flottweg Z3L
Designed for food grade and acceptable for use in Class 1 Div 2 group D areas and is fume tightSP. Rated for 10,600 lbs./hr. of feed, 9100 lbs./hr. of centrate and 1500 lbs./hr.cake. Rated for 80 degrees F.Bowl has special abrasion protection on the feed and conical section of the machine.Includes vibration sensor. Control panel includes PLC for automated dewatering. Only 30 hours of operation!
(14 x 48) 1.4408 angle conical solid bowl decanter centrifuge
Max thru put capacity 25000 l/hr
Bowl dia 354mm, bowl length 1221mm
w/V-belt drive to Cyclo gear
solid bowl centrifuge
CS bowl and scroll with ceramic flights
decanter
Contour bowl design 3 phase seperation
With ajustable weirs
Average flow rate for feed is 35 gpm
Originally built with a 110 mm pitch
Main motor : CE rated 50 CYC, 400 volt, 60 cycle 460 volt
Back drive: 4 KW 3/50/380 volt motor, 1440 rpm.
duplex stainless steel
80 mm slope
sludge density
max filling volume 33,4 kg
Motor:
IP 55
two-stage planetary drive
Single thread screw
construction material:
bowl and hubs
1.4462 stainless steel,
screw hub and flanks
construction material: bowl and hubs 1.4462 stainless steel, screw hub and flanks 1.4462/1.4571 stainless steel, casing 1.4571/ 1.4401 stainless steel, carbon steel frame,
Sharples Penwalt (Alfa Laval) P-2000 centrifuge
360 degree solids discharge,
No backdrive, torque arm control.
Positive lock weir damns.
Complete with main drive,
gearbox,
feed tubes, and base
With V belt drive to gear reducer.
4 1/4" pitch
single lead with 1 3/8" welded hardsurfacing
Solid flights
Feed ports have welded hardsurfacing.
decanter centrifuge with 10/3 deg contour on bowl tapper.
4 1/2" pitch double lead non-hardsurfaced conveyor w/rinse. 40:1 gearbox
vertical, super centrifuge with classifier design bowl
solids holding capacity 5.3 liter
inner bowl 124mm
solid bowl decanter
Nominal speed 2750 rpm
motor w/clutch
Rated 5000 liters/hr
@ 20% solids for rendering applications
conical solid bowl centrifuge
4 1/4" pitch double lead non-hard surfaced conveyor
1-piece, 3 setting, plate dam.
Screw impellor discharge (no collector)
Vaporseal design
solid bowl decanter centrifuge With one cylindrical section. with a max. centrifugal acceleration of 4700 (XG)Scroll differential is 12 (normal) with a maximum of 27.Rated for 1,200 liters/hr. With Back drive. 4.3: 1 ratio sludge scraper motor is 0.18 kW.
duplex stainless,
solid bowl decanter with back drive,
2-phase separation
360 degree solids outlet
Manufacturer specified flow rate in GPM is 200 to 400
Designed for 81 lbs/Cubic foot specific gravity of material.
Main rotating assembly components are centrifugally cast Duplex Stainless Steel type 4462
Main drive is a 125 HP 3/60/230/460 volt
and hydraulic power pack
Scroll is driven by a 40 HP 3/60/230/460 volt TEFC motor. (2) Liquid discharge flanges, 1060 mm wide x 309.45 mm each. Solids discharge flange is 1060mm wide x 460 mm. Overall Dimensions: 5700.68 mm Long X 1406.6 mm wide x 1561.20 mm high. Rotating Assembly 8,054 lbs; complete centrifuge with filling (1.0 S.G.) 18,100 lbs
Manufactures states the flight pitch is 9-10 degrees.
Continuous feed type
10 degree cone on bowl
Left hand rotation
Back drive is 25 hp. at 3600 rpm, 460 volts
Decanter Centrifuge
Gas Tight housing
Worm lengh is 600 mm x 220/125mm diameter
With spare rotating assembly, worm, and gear box
decanter centrifuge
12mm thick basket
specific gravity 2 kg/dm3
volume 10 m3/hr
decanting centrifuge
Job Number 139431
Requires motor
Rotating assembly
Ens stamped CMW3-7-08/8626,
End stamped CMW3-7-08,
Bowl stamped P-2000V-ME-88-114854,
Screw conveyor and one gearbox.
decanter centrifuge,
354/220mm diameter bowl
1/6 m3/hour throughput,
4/80 degrees C,
3kg/dm3 solids,
(1) 6 m3/hr @ 44m head 316 stainless steel centrifugal pump, manufactured by Dickow Pumpen, type SC h 4072, fabrik #18210442, 2.8kw, 1450 rpm, 10 bar @ 120 degrees C, EX 11 2 G Ex h IIC T6...T3 Gb ATEX CE, driven by 4kw, 2/50/690/400/415 volt, 1458/1461 rpm CE Ex de II C T4 Gb ATEX motor, on baseplate,
When your process requires continuous, high-volume separation of solids from liquids, solid bowl decanter centrifuges deliver unmatched reliability across demanding industrial applications. With over 47 years of process equipment expertise, IPP provides immediate access to high-quality used decanter centrifuges sourced from 20 complete plant sites and included in our inventory of over 15,000 ready-to-ship pieces of equipment. Buying used solid bowl decanter centrifuges from IPP enables companies to reduce capital costs, shorten lead times, and maintain critical process performance.
Solid bowl decanter centrifuges continuously separate solids from liquids by spinning a cylindrical bowl at high speeds, with an internal screw conveyor transporting solids toward the discharge end. These machines are ideal for handling slurries with moderate to high solids content and are essential for industries requiring high-throughput, continuous operation.
Solid bowl decanter centrifuges are built for durability, chemical compatibility, and heavy-duty operation:
Learn more about decanter centrifuge operation and optimization at Chemical Processing.
Search the IPP inventory or contact IPP’s equipment specialists to find the right decanter centrifuge for your continuous separation needs. With ready-to-ship inventory, IPP helps companies meet production demands, manage costs, and achieve consistent separation performance.
