• Three pass fire tube boiler5021 MBHMBH input 6278Fireside heating surface area is 750 sq. ft Firing rate is as follows: 1000 BTU Gas (MBH) =6277, 140,000 BTU/Gal. Oil (GPH) =44.8Safety valve rated for 6000 psi Boiler has 182, two inch tubes This boiler features FGR and low Nox operation with it's IRI gas train While firing natural gas, emissions levels are are no greater than 30 PPM of NO x This boiler features 3 gas passes that extract the maximum usable heat from the fuel while maintaining optimum flow for forced draft firing It also has easy opening/closing doors that minimize labor and parts cost’s while performing routine maintenance such as cleaning and inspections Water requirements are 6551 pounds of water or 785 gallons Approximate weight wet is 16,251 lbs., approximate dry weight is 9,700 lbs.

• Trailer mounted set. Oil Type Required API CF-4
• Complete Service at 11207, Hours includes New Batteries, Oil & Filters, Air Filters, Fuel Filters.

Built in Economizer.

500 lbs./day Ozone Generator Skid mounted design includes generation chamber, controls and transformers in cabinet. Rated for 500-250 lbs./day Oxygen/Air : 70-77 scfm @ 40-104 degrees F, 43.5-116 psi Output 68.7-76.5 scfm at 17-36 psi operating pressure Cooling water: 45 psi max., @35-86 degrees F at 50 gpm Electricals: Cooling water: 45 psi max., @35-86 degrees F at 50 gpm Chamber size: 20" diameter x 109" long.

normal working pressure 83 bara, flue gas for dimensioning 16,667 Nm3/hr, flue gas temperature after economizer 139.5 deg C, content of CO2 in flue gas 8.92 volume %, H20 15.84 volume %, O2 2.07 volume %, net calorific value 42.8 MJ/kg (gas oil), 39 MJ/kg (natural gas), Saacke type TSAAYD-135-E3-6275 steam atomizing burner, designed for natural gas or gas oil, heat input 22,000kg/hr, gas oil output 190-1329 kg/hr, natural gas 163-1631 Nm3/hr, energy input 13.1 MW, fuel input natural gas 1206 kg/hr, gas oil 1097 kg/hr, air flow 14,000 Nm3/hr, flue gas flow natural gas 14,150 Nm3/hr, gas oil 14,866 Nm3/hr, heating surface area furnace 60sqm, screen 2.6sqm, evaporator 33sqm, walls of convection part 25sqm, economizer 1 683sqm, economizer 2 78sqm, total 881sqm the boiler is an all welded water tube boiler with natural water circulation, built as a vertical and self-contained construction in which the downcomers form the supporting columns, vertical expansion of the boiler is free upwards, boiler has a radiation part, a convection part and a detached economizer, the radiation part is to reduce the flue gas temperature before the convection part, the radiation part is built as an all-welded membrane wall section on the sides, top and partition wall, the economizer is in the back of the convection part and is made with horizontal tube coils, these are a nest of pipes consisting of 14-tube lines of each 28 tubes, the evaporator is made with diagonal tube coils, which are a nest of 6-tube lines of each 28 tubes, the detached economizer is built as a four sided casing tower in which are placed horizontal convection heating surfaces, boiler includes: (1) 1640ltr c/steel boiler drum, steam space load 275 m3/m3xh, 1200mm diameter x 3m long, 40mm thick, weld dished ends, (1) Detached in-line fin tube Economizer, manufactured by Emvertec, 683sqm, design pressure 13.5 bar, (1) 316 s/steel Deaerator vessel, manufactured by Cool Technology ltd, design pressure 2 bara @ 105 deg C, operating pressure 0.21 bara (3) Feed water pumps, manufactured by KSB, type HGM-2/15, Other associated equipment include fans, valves, pumps, instruments, control panels, etc

Pure Steam Generator industrial steam pressure 10 bar Feed water 5/5,5 bar @ 146 degress C flow-rate 800 l/h. Black steam 4,5 bar

LIKE NEW CONDITION! 62 hours from new. Fresh PM, incl. batteries + 2hr load test, ready to go. KD115V Skid mounted, in outdoor sound attenuating enclosure with electronic controls on day tank. Gen set manufactured by Marathon, 150 KW standby, 480 v 3ph 60Hz, Direct driven by a Volvo Penta Gen set engine. 6 cylinder 4 stroke , direct injection. Turbo Charged and air to air intercooled. Drive engine number of cylinders: 6. Batteries: Yes. Battery Charger: Yes. Controls: Yes.

3-pass wet back furnace tube deisgn and oil fired, Manufacturer: Hamworthy Combustion, Type: SG5/1900 automatic gas fuel, boiler has an economiser, design pressure 110psig, deisgn code BS2790:1989, class 1, (2) feed water pumps, total weight= 7625kg

50 rpm to 1.400 rpm variable speed drive Torque: Nm~1.550 driven by SEW-EURODRIVE motor, data: 290-500V, 2.0 kW, 50 Hz, 1.400 rpm, ex proof (T3).

Steam turbine originally designed to be used to drive a compressor, but can be used to drive other machines.

Dresser Rand Series ET-186, Five Rateau stages. Normal speed is 6540 rpm, max. speed is 6760 rpm. First critical speed is 2900 rpm, second critical speed is 7800 rpm. Speed regulation is by a Woodward governor, model 505E.

The turbine has the following alarms/shutdowns; Over speed, Emergency valve, solenoid valve, Low oil pressure, and high input steam pressure.

Requires 63 gpm cooling water for oil cooler. Complete pressurized oil system operating at 116 psig. Size of turbine alone is 9’ x 6’ x 7’ at 14,000 lbs.

SAA #2000-168, natural gas fired, continuous, comp ratio 9/1, min.WKI 91, ignition timing (BTDC) 11-02, service 4650 HP (3469 Kw), altitude limit 500 feet (152 meter), governed speed 1000 rpm, 0.80mm valve intake & exhaust clearance, firing order 1R-1L-4R-4L-7R-7L-6R-6L-8R-8L-5R-5L-2R-2L-3R-3L, AC generator (alternator) manufactured by Leroy Somer, type LSA-56-BM65-6P, serial #167056-2, IP 23, 3360.8 Kw, 4201 kVA power rating, 11000 volt, 220.5 Amp, 3 phase, 50 Hz, 1000 rpm, excitation AREP, all mounted on a carbon steel skid

electronic intermittent pilot ignition Surface heating area, 83.4 Sq. Ft. Gas connection is 1.25", water inlet and outlet are 2", and pressure relief line is 1" Flue size is 12".

gear reducer input 1,500rpm, output 71rpm mounted on a carbon steel baseplate.

Electric hot oil heater Heat output: 1,229,194 BTU/hr Complete system with (2) vertical 180 KW electric heaters, 3/60/480 volt, Serial Number J600-1 & 2 circulating pumps

• Turbine with 5 Rateau stages.

Agitator Gear Motor Assembly, 300 - 1300 rpm input, Output is 13 - 300 rpm Service Factor 2.7, Torque 13873 lb-in. SO number 890226484.09.09.001. Direct coupled to a 10 HP SEW-Eurodrive motor, 3/60/230/460 volt motor, with dry running mechanical seal.

Agitator Gear Motor Assembly 300 - 1300 rpm input Output is 13 - 300 rpm Service Factor 4.9 Torque 4204 lb-in SO number 390237369.04.04.001 Direct coupled to a SEW-Eurodrive motor 3/60/230/460 volt moto with dry running mechanical seal

This boiler can fire on Natural Gas or Light Oil , however, in the previous application they were only burning gas, so there are no accessories to burn the light oil. 04/25/24 Per Miller & Chitty Manufacturer weight is 36,000 LBS. (RP)

Diesel Fired backup Generator, Gen Set #3412 Generator #588 Water cooled, turbocharged and aftercooled. Four stroke V-12. With sound and weather enclosure. 3Phase / 10 Wire / 650KVa(520KW) / 1800rpm / 60Hz. Cat Gen set, brushless, revolving field solid state exciter, single bearing, close coupled. Connection WYE Driven by a 755HP Cat Engine,

• Gear Only
• Parallel shafts
• Service rating 1.68 with 39.6 US gallons of Oil -Splash lubrication.

• pressure 19 bar @ 212 degrees C,
• 43800 liter,
• 12600kW max nett capacity,
• 450 square meter,
• product group CAT IV, CE0038,
• natural gas fired,
• gas burner manufactured by Puripher,
• hinged door on back of boiler,
• (1) blower/Fan,
• control panels

• working pressure 10 bar
• inlet water temperature 95 degrees C,

Spraymaster Dearator 14 GPM Total Boiler HP 203

Unit number: W-3525 Boiler heating surface sq. ft. 1517, Water wall sq. ft. 302 Max 20.574, Main Power 460 volts. Shipping dimensions 11’ wide x 25’ long x 12’ 6” min. to 13’ 4 “ max. overall height.
