Showing 25 of 1072 matching Heat Exchangers.
tube pressure rated by -1/10bar @-10/200 degrees C (volume 66 liter), shell pressure rated by -1/10bar @ -10/200 degrees C (volume 180 liter) Length: 4,800 mm. Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 121. Tube Diameter: 14 mm. Tube Length: 4,200 mm. Tube Thickness: 1.5 mm. Nozzle Schedule: shell side: (1) DN100, (2) DN200, (1) DN300; tube side: (1) DN150, (1) DN200. Capacity: 246 L. Heat Exchanger Tube Capacity: 66 L.
side A = 550 ltr, side B = 570ltr
pressure both sides -1/10 bar @ -50/150 degrees C (18 liter/17 liter) fully insulated, CE-0036,
Rated FV/300 psi @ -20 to 425 degrees tube side; FV/50 psi @ -20 to 425 degrees F shell side.
with glass lined clamped heads Tube Number: 18. Tube Diameter: 0.75 in. Tube Length: 216 in.
2-stage (2) 450 Sq Ft condensers bolted together, end to end, with same configuration and material in both stages, Upper stage and lower stage each have a 316LSS shell, CS heads. Shell is 0.135" thick, Heads are 1.12" thick CS. Spiral Material: Stainless Steel 316.
AL6XN channel heads with R-Stamp(1994) Tube Diameter: 1.25 in. Tube Length: 144 in. Tube Thickness: 0.02 in. Nozzle Schedule: - Nozzle Schedule: - Two 32" tube side nozzles (brine inlet & outlet) - One 18" steam inlet - One 4" condensate outlet - One 3" drain - Two 1" drain/vents.
(2) 300mm high cone sections,
Heads are CS faced with 316 L SS Spiral Material: Stainless Steel 316L.
Process sidde rated 45 PSI @ -30/+122 degrees F. Service side rated 30 PSI @ -30/+122 degrees F.
cubic block heat exchanger process side is 2-pass with (2160) slots, 9.5mm x 3mm,service side is multi-stage with (756) 9.5mm diameter tubescan be used vertical or horizontal.
FAILED HYDROTEST- FOR PARTS OR REBUILDING
31m² tantalum tube carbon steel shell, horizontal shell and tube heat exchanger, manufactured by Tantec, serial number 4278, tube pressure rated by -1/6bar @-10/200 degrees C (volume 100 liter), shell pressure rated by -1/8bar @ -10/200 degrees C (volume403 liter), carbon steel shell 490mm diameter x 4508mm length, (175) tubes 12.7mm diameter x 0.4mm thickness x 4.500mm length, openings shell side: (1)DN100, (1)DN250; openings tubeside: (2)DN150, mounted on 2 saddles Length: 4,500 mm. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 175. Tube Diameter: 12.7 mm. Tube Length: 4,500 mm. Tube Thickness: 0.4 mm. Nozzle Schedule: shell side: (1)DN100, (1)DN250; tubeside: (2)DN150. Capacity: 503 L. Heat Exchanger Tube Capacity: 100 L.
Tantalum lined carbon steel tube sheets TUV APPROVED Pressure tube side -1/4 bar @ 170 degrees C (volume 122 liter), pressure shell side 4 bar @ -17/40 degrees C (volume 225 liter) Expansion joint manufactured by DeDietrich, serial number 27031, internal pressure rated -1/4 bar @ 170 degrees C (volume 67 liter), openings (1) DN80 and (1) DN150, second head: manufactured by DeDietrich, serial number 27030, internal pressure rated -1/4 bar @ 170 degrees C (volume 82 liter), openings (1) DN80 and (1) DN250 Tube Type: Straight Tube. Tube Number: 179. Tube Diameter: 19.5 mm. Tube Length: 2,600 mm. Nozzle Schedule: - Openings: (1) DN40, (2) DN100, (1) DN150.
Rated 150/FV @ -20 to 400 degrees F tube side 150/FV @ -20 to 400 degrees F Shell Side Unit has (2) bolted flat heads (1) Tanalum, (1) CS with tantalum lining Length: 94.5 in. Tube Number: 84. Tube Diameter: 0.75 in. Tube Length: 72 in. Nozzle Schedule: - Nozzles: Shell side has two 4" nozzles with 1" reducing flanges - Inlet/outlet: Tube side inlet is 4", tube side outlet is 3" with a 1" drain..
(48) 1" OD welded tubes. (2) Glass lined heads. Tube Diameter: 1 in.
and two 1" vent/drains Tube Type: Straight Tube. Tube Number: 168. Tube Diameter: 0.75 in. Tube Length: 48 in. Tube Thickness: 0.01 in. Nozzle Schedule: shell side has two 4" nozzles, Bottom Bonnet has two 3" nozzles, top has one 8" nozzle.
304 SS with Hastelloy C clad tube sheet Hastelloy lined CS shell 20" diameter x 58" face to face, overall length is 89" long Length: 58 in. Tube Type: Straight Tube. Tube Number: 325. Tube Diameter: 0.75 in. Tube Length: 58 in. Tube Thickness: 0.03 in.
0.750" diameter x 16 ga wall thickness 2 pass Tube Number: 88. Tube Diameter: 0.75 in. Tube Thickness: 0.06 in. Nozzle Schedule: - Tube side nozzles: two 6" - Shell side nozzles: two 8".
Used heat exchangers are essential in virtually every industrial setting where fluids need to be heated or cooled efficiently. These systems transfer thermal energy between liquids, gases, or steam without mixing the media—making them critical in process optimization, energy recovery and environmental control. With over 47 years of experience, IPP supplies used, secondhand and surplus heat exchangers from 20 global plant sites and maintains a massive inventory of 15,000+ systems ready for fast shipment.
IPP offers a wide variety of heat exchanger types including shell and tube, plate, air-cooled, spiral, and double-pipe designs from trusted brands like Alfa Laval, API Schmidt-Bretten, Tranter, Graham and ITT Standard.
Heat exchangers are unfired heat transfer equipment used in process plants. Heat exchangers are used for the transfer of heat or cold between two fluids for the purpose of heating the process, cooling the process, or condensing vapors during the process. Heat exchangers are measured in Square Feet. There are several different types of heat exchangers. These include:
Heat exchangers must withstand temperature, pressure and chemical exposure:
Learn more about industrial heat exchanger design and selection from Chemical Processing.
Search the IPP inventory or contact IPP’s thermal systems experts to find the right used, surplus or secondhand heat exchanger for your facility. From simple replacements to full energy recovery systems, IPP helps you optimize performance while cutting lead times and costs.
