GMP grade sanitary stainless steel construction
order number V4635
vibration bed is belt driven
electrical motor : type D160LA-6 , ExII3G, EExIIT4
system included with (1) 7m³ (1.4571) stainless steel silo
manufactured by Scholl Switzerland AG
order number 502838
serial number 201282
pressure rated -0,1/0,6 bar @ -20/120 degrees C (total volume 7100 liter)
openings on top: (3) DN40, (1) DN50, (1) DN80, (1) DN100, (1) DN200, (1) DN500 manway cover; with (1) 4500 m³/h (1.4571) stainless steel radial fan
manufactured by Reitz
type KXE100-008030
serial number 166417
shaft rating maximum 20.17kW @ 3000rpm
with frequency converter
fan is coupling driven by a 37kW electrical motor, manufactured by Felten & Guilleaume, type CD200L2-2, serial number 415274001H, 3~/50Hz/400-690V/2955rpm, ExII2G, EEXdeIICT4, mounted on carbon steel baseplate; with (1) 1.2m² (1.4404) stainless steel plate heat exchanger, manufactured by Barriquand, type IJS, serial number 26361E, pressure shell side 2bar @ 200 degrees C (volume 16 liter), pressure plate side -1/6bar @ 200 degrees C (volume 2 liter), openings plate side: (2) DN25, openings shell side: (2) ½” (2) DN80; with (1) 44.3m² (1.4404) stainless s teel plate heat exchanger, manufactured by Barriquand, type IJMASC, serial number 26362E, pressure shell side 2.9bar @ -35/100 degrees C (volume 335 liter), pressure plate side 10bar @ -35/50 degrees C (volume 165 liter), openings plate side: (2) DN80, openings shell side: (1) DN25, (2) DN250; with (1) 12.7m² (1.4404) stainless steel plate heat exchanger, manufactured by Barriquand, type IJS, serial number 26359E, pressure shell side: 2 bar @ -20/200 degrees C (volume 190 liter, pressure plate side: -1/6bar @ -20/200 degrees C (volume 25 liter)
openings plate side: (2) DN50, openings shell side: (2) ½” (2) DN250; with (1) 3.6m² (1.4435) stainless steel shell and spiral tube condenser, manufactured by Züricher Apparatebau, order number 105074, serial number 242, pressure tube side: 7.8bar @ -30/200 degrees C, pressure shell side: -1/6bar @ -30/200 degrees C, 500mm diameter x 1039mm length; with (1) 6m² (1.4404) stainless steel shell and tube condenser, manufactured by Züricher Apparatebau AG, order number 502637, serial number 1789, pressure shell side: -1/6bar @ -45/200 degrees C (volume 74 liter), pressure tube side: -1/8bar @ -45/200 degrees C (volume 45 liter), openings tube side: (2) DN50 (1) DN100, openings shell side: (2) DN40; with (1) 4.7m² (1.4404) stainless steel plate heat exchanger, manufactured by Barriquand, type IJS, serial number 26360E, pressure plate side: -1/6bar @ -20/200 degrees C (volume 8 liter), pressure shell side: 2bar @ -20/200 degrees C (volume 102 liter)
openings plate side: (2) DN25, openings shell side: (2) ½” (2) DN150; with (1) 4m³ (1.4435) stainless steel vertical agitated tank with half pipe coil jacket, manufactured by WAFAG, order number 89536, serial number 8379, pressure inside: -0.32/4bar @ -30/200 degrees C (volume 4340 liter), pressure jacket side: 7.5bar @ -30/200 degrees C (volume 176 liter), with a (1.4571) stainless steel 3-blade propeller agitator, order number 503049, with mechanical seal, manufactured by Burgmann, type M481K-D20/60, pressure -1/16bar @ -30/200 degrees C, with 3 liter lubricator, manufactured by Aerni, type A-139, pressure 26bar @ 200 degrees C, agitator is driven by a gear, type RXF97D4/P, gear is belt driven by a 7.5kW electrical motor, manufactured by ABB, type 132M-4, 3~/50Hz/400V/1450rpm, EExdeIIBT4, openings top: (1) DN500 including (2) DN100 sight glasses, (1) DN600 including (2) DN50 and (1) DN300, (2) DN100, (3) DN200, openings bottom: (1) DN65, openings half pipe coil: (2) DN40, mounted on (4) lugs; with (1) 316L stainless steel vertical cyclone separator, manufactured by Ventilex, order number 502845, openings top: (3) DN25, (1) DN200, (1) DN300, openings side wall: (1) DN300, with cone bottom, mounted on (4) lugs; with (1) 14m³/h by 20m head (1.4408) stainless steel caned motor pump, manufactured by Ruetschi, type SMN-G5-160SR5E16-2V, order number 502627, driven by a 5.6kW electrical motor, type SR5E16-2V, 3~/50Hz/400V/2930rpm, EExdeIICT4; with (1) 2000mm diameter (1.4404) stainless steel vertical dust filter, manufactured by Ventilex, order number 502846, bolt dished top and weld dished cone bottom, 2000mm diameter x 3000mm straight side (4580mm overall length), (52) 316L stainless steel inlets, 145mm diameter x 2500mm length, openings top: (2) DN25, (3) DN100 sight glass, openings side wall: (2) DN300, (2) DN 200 sight glass, (4) DN50, (8) DN15, (7) 1”, opening cone side wall: (1) 500mm diameter manway cover, opening bottom: (1) DN200, mounted on (2) lugs; with (1) 316L stainless steel discharger valve, manufactured by Matcon

continuous vibrating fluid bed dryer
perforated fluid bed
openings: feed: 1-600mm, powder discharge: 1-300mm, top: 1-750mm manway, 1-450mm, straight side: 3-450mm manways, bottom: 2-625mm each with a 625mm diameter x 980mm straight side s/steel tank
dryer mounted on carbon steel frame with springs

Note: Drawings show Mills, we did not get some of them. Suitable for installation in Hazardous areas.
Typical working volume is 30-225 liters based on the allowable product density of 1500 kg/m
This fluid bed dryer was designed for Pharmaceutical service and features sanitary design and clean in place
With wet and dry loading ports, internal lighting, and sample ports
Air handling is custom manufactured by ZAir, Type SKG-4
Manufactured of 316 SS construction
This unit is complete with all filters, and accessories
High shear granulator (IPP Stock # 233969) is available at additional cost. 100 kg

15 Kg
bed dryer system
Heating capacity 68000 BTU/hour
Steam pressure 3 bar
air (compressed) 6 bar
with removable trolley
Drying chamber in (3) sections: (1) 21 1/2" diameter x 12" straight side; (1) 21 1/2" diameter x 27 1/2" straight side; (1) 21 1/2" diameter x 27 1/2" straight side x 15 1/2" diameter (cone shaped). Hydraulic bin closure, (2) trolley for bin removal
Unit with air filter, manufactured by HSE, Type 5.5KW-SCF, serial #2620
Motor: 3 phase
(3) control panels, (1) built-on unit
Top mounted fan driven by 4.5 KW, 3/50/440 volt, 2915 rpm non-flameproof motor.

Glatt Fluid Bed Dryer
perforated bed
400/690 volt
Capacity 200 liter bin

100kg
system includes a filter housing, control panel, body
(3) sections chamber top dish with cover 240mm high (total high with railing 560mm) x 1.180mm inside diameter first section 2.030mm long x 1.180mm inside diameter, second section 2.270mm long x 1.180mm inside diameter, third section 2.030mm long x 1.180mm inside diameter, with one product bowl
High performance fan, type RHS1U280MBGXGR360, serial number 34117

vibrating Fluid bed dryer system
All contact parts are 1.4301, with CS frame
Fluid bed size 480 mm wide x 6400mm long, overall 640 mm wide x 7356 length
Covered drying bed with a vibrator system type SVi450/6n, driven by (2) Vibra-Maschinenfabrik electrical motors
second motor: serial number 133138, 1,1kW / 50Hz/220-380V @ 940rpm
System includes a GEA heat exchanger, a 5,25kW max. 3.000rpm Polrich blower type AS 56/RU315R/GR90MR driven by an electrical 7,5kW motor type KMER132Sx2ACP, serial number VDE0530, 3~/50Hz/380-660V @ 2.860rpm

Air circulation fan is 12,5 KW, 50/220/380 Volt @ 3000rpm.

120 kg
Aeromatic Fluid bed dryer/ coater
Com.No. 88 91 42
Bowl volume is 240 liters
System utility requirements are:
Steam maximum 150 kg/h @ 6 bar g
chilled water maximum 5.4 m3/hr 27 degrees C inlet temp
compressed air 45 Nm3/hr @ 6 bar
Motor: 3 phase
Electric
System accessories include a heating coil with 10 bar housing pressure for air heating, air inlet filters and cooler, 22 Kw system Fan rated for 10 bar/s, Airflow 0.25-0.83 m3/s at static pressure 10.00 pa; product filter with shaker discharge, and a bin lift system
system Fan rated for 10 bar/s
Airflow 0.25-0.83 m3/s at static pressure 10.00 pa
product filter with shaker discharge, and a bin lift system
Electrical controls available with unit

300 kg
Glatt Fluid bed dryer
special Vitamin-A-Pulver
with cyclones
heater and cooler and de-dusting system
Filter housing is 1600 mm diamter, 2.5mm thick, with (59) bags, at the bottom of the filter housing is a tapered section that has a buterfly valve controling flow into the hopper bottom
with a 660 mm deep cone
Hopper bottom is 304 stainless steel (1.4301), 1190 mm diameter x 640 mm straight side with a 660 mm deep cone
With seperate heating cooling box,rated - heater rated 320,000 Kcal/hr @ 5 atu, air cooler rated 400,000 kcal/hr @ 0/4 degrees c. Main fan is rated 14,000 CuM/Hr, 2900 upm, driven by a 35.8 KW, 3 phase 50 cycle, ExeG3 rated motor
dedusting system rated 15000 CuM/Hr.

300 kg
special Vitamin-A-Pulver
with cyclones
heater and cooler and de-dusting system
Filter housing is 1600 mm diamter, 2.5mm thick
with (59) bags
at the bottom of the filter housing is a tapered section that has a buterfly valve controling flow into the container bottom
Hopper bottom is 304 stainless steel (1.4301), 1190 mm diameter x 640 mm straight side with a 660 mm deep cone with a 660 mm deep cone.
With separate heating cooling box, rated - heater rated 320,000 Kcal/hr @ 5 atu, air cooler rated 400,000 kcal/hr @ 0/4 degrees c. Main fan is rated 14,000 CuM/Hr, 2900 upm, driven by a 35.8 KW, 3 phase 50 cycle, ExeG3 rated motor.

• .600 liter 316/304 stainless steel Glatt fluid bed granulator dryer system, Project #8931/100.614/100.614, 1.4m diameter drying chamber, lower section has inflatable gasket, charging port with quick acting gate valve, filter housing with an installed product retaining filter, pressure relief openings with installed plates in the filter housing and following pressure relief ducts, (2) 316/304 stainless steel bowls, bowl dimensions 1.4m top diameter x 550mm straight side x 1m bottom diameter, bowls with bottom sieve mesh and trolley, bowl mesh max differential pressure 5000 Pa, system includes stainless steel bowl tipper, inlet air handling unit, Blower, Stahl Exicom control, control panel, dust filter and other ancillaries.

• Max Capacity 1600 kg
• Stainless steel highly polished Glatt fluid bed dryer system, manufactured by Glatt AG (Switzerland), nominal capacity 500 kg, max capacity 500kg, approx. 3m diameter drying chamber, stainless steel bowl, dimensions 3m top diameter x 1.1m high x 1.1m bottom diameter, bowl fixed to a lifting mechanism, internal filters with hoist, (2) inspection doors for filter, suppression system, system include: blower, dust filter, air handling unit, control panels, duct work and other ancillaries

Documentation shows Mills but we did not get some of them. With spare product containers. (read below) 60 kg
Explosion shock resistant fluid bed dryer.
Designed for cGMP production, it is a contained system, and can be used for other process’ such as food agglomeration and drying
Model - MP2/3-K2-F1/2
Rated for Maximum absolute pre pressure of 11 bar
and Maximum explosion over pressure of 12 bar
Total volume 610 liters
typical working volume is 18-160 liters
based on the allowable product density of 1500 kg/m
This fluid bed dryer was designed for Pharmaceutical service and features sanitary design and clean in place
With wet and dry loading ports, internal lighting, and sample ports
Designed for liquid/binder addition, it includes the Peristaltic transfer pump. This dryer is part of a contained system, product never reaches outside the unit. It is also integrated to work with products upstream and downstream. Designed for easy and quick cleaning and changeovers, the clean in place and all the operations are completely automated, and can be controlled at a local operator station
Air handling is achieved with a custom manufactured unit by ZAir, Type SKG-4,2 507-68273-1
Manufactured of 304 SS construction, it’s rated for 130-670 m3/Hr. at 20-80 degrees C
This unit handles all the air heating, cooling, and humification duties
The Main fan is driven by a 12.7 kW AC motor, and it also has a HEPA filter
This unit is complete with all filters, and accessories
High shear granulator available (IPP Stock # 233967. This unit also has spare product containers. Product containers are FBP 07304A.FBP101, # 001, built 2019, with Product container trolly. FBP 07304A.FBP101, # 002, built 2019, with Product container trolly. FBP 07304A.FBP101, # 003, built 2019, with Product container trolly
Unit comes with one product container, all other additional equipment is available at an additional cost Explosion-Shock Resistant: Yes.

static fluid bed dryer system
reference number K5/8-88-001A
Bed temperature 100 - 120 degrees C
Bed with (2) pneumatic operated hinged weir plates
weir height range 140mm - 250mm
Dryer chamber approx. 920mm wide x 5.8m long, chamber with 690mm wide x 1.3m high hinged inspection door
Openings: drying air inlet 900mm, cooling air inlet 300mm, recycle 750mm, exhaust 500mm
System consists of (1) air heater, aluminium fins with carbon steel tubes, rated 250 psi, (1) centrifugal cooling air fan, manufactured by Fans & Blowers, Ltd, serial # 6331
Motor: 3 phase
(1) carbon steel cyclone, 1000mm top diameter x 1700mm straight side x 2000mm cone. Bottom outlet 350mm, straight side 760mm x 200mm, (1) exhaust/wet air fan, belt driven by 15 kw, 3/50/415V, 2940 rpm motor. (1) main dryer fan
belt driven by 75 kw, 3/50/415V, 1470 rpm motor (no motor).

load weight 300 kg
special Vitamin-A-Pulver, with cyclones
heater and cooler and de-dusting system
Filter housing is 1.6m diamter, 2.5mm thick, with (59) bags, at the bottom of the filter housing is a tapered section that has a buterfly valve controling flow into the hopper bottom.
Hopper bottom is 304 stainless steel (1.4301), 1190 mm diameter x 640 mm straight side with a 660 mm deep cone. Bottom hopper mounted on 4 legs with wheels. With seperate heating cooling box, rated - heater rated 320,000 Kcal/hr @ 5 atu, air cooler rated 400,000 kcal/hr @ 0/4 degrees c.
Main fan is rated 14,000 CuM/Hr, 2900 upm, driven by a 35.8 KW, 3 phase 50 cycle, ExeG3 rated motor

• 20,00lb/hr capacity @ 30 PCF & 30% inlet moisture. Discharges at 10% moisture & 130 deg F. Dims: 1'D x 20'6"L.

5 Kg
Aeromatic spray granulator system
Rated 6800 kcal/hr
Fan driven by 3.4 PS
Drying product bin 700mm dia top, 270mm dia btm x 650mm deep
Control panel w/switches
Including steam heater, valve, duct

250 Kg
Fluid Bed Dryer
batch type
Steam heater rated 140000 Kcal/hr steam
Motor: 3 phase
220/380 volt
With (2) product bins 1200mm upper diameter, 800mm lower diameter, sanitary polished
Drying chamber 3.5m high (11'6") x 1.2m diameter (48")
With a control panel indicating air temperature, timers, intervals, vibration indicator of dust collector

250 Kg
Aeromatic Fluid Bed Dryer / Aeromatic fluid bed spray granulator
Aeromatic type STRE 0,
86.20 H
food grade high performance fluidized bed drying system
rated 109,200 Kcal/hr
Pressure shock resistance 2,0 bar, vessel volume 610 liter, 0,86m²
The system includes dryer, powder filling station, pneumatic system, air and product filters
steam air heater (CS)
rated 5,5 bar @ 200 degrees C
Cooler, and dry product containers
Originally used for flour and starch drying in a food processing plant
Rated for Flour: inlet moisture 14-16%,outlet moisture 7%,drying temp 70 C. Starch: inlet moisture 15-17%,outlet moisture 5%,drying temp 70 C.

15-30 Kg, 45 liter bowl capacity, 52000 K/hr steam heaters, compressed air @ 6 bar, Air warming range -10 degrees C to +70 degrees C, Electrics motor

Fluid Bed Dryer Spheronizer
perforated bed
electrical motor
Motor: 3 phase
type KPER200L4-TWS

60-180 Kg
Rated 467200 Kg/hr air flow
with a Control panel, steam heater, and (2) sanitary product bins 1100/750mm dia x 500mm deep

150 Kg
110,000 Kcal/hr steam heating
with dust collector bags
and bag hanger ring

200-400 Kg
Designed drying 200 to 400 Kg batches
Housing type 105.4, made of 304SS
Product bin type 202.3, 780 liter volume, 304SS 1630mm top dia, 1230mm btm dia x 880mm conical section. W/(2) 200mm inlet for adding products, 1-500mm manway w/cover, 1-200mm sight glass, 200mm x 60mm oval sight glass.
Btm section below bin 1230mm dia x 500mm deep. Includes air inlet 500mm dia. Dryer body and product bin are mtd on steel stand w/legs, 1550mm x 1050mm x 3900mm high. Drying chamber has (2) explosion doors. Product filling nozzles for granulation are Type 2001.1, 304SS. System includes second product spray system Type 701, nozzle rated 4 liter/min.
Feed pump rated 0.01 to 11 liter/min @ 2.5 bar
Variable speed drive motor. XP rupture disc. W/centrifugal fan Type 5012, made of CS w/epoxy lining, rated 180 cbm/hr @ 500mm WA @ 2900 rpm. Steam coil rated 270,000 kCal/hr @ 6 ATU. Fine dust filter, Type 403.1, 23 sq meter filter area. Product empties from the btm of dryer into Frewitt (Switzerland) granulator, Type MGWI-624, 304SS, SN 0677449, feed 350mm x 500mm. . Driven by 1.1 KW, 3/50/220/380 volt, 1390 rpm motor, couples to variable speed gear reducer, Type R4S-1062-11-4, SN 304531, rated inlet speed 56/280 rpm, outlet speed 89/30 rpm.
connecting ducts
