Used rotary vacuum dryers for sale: low-temperature drying for heat-sensitive materials
Highest-ranked available inventory for this selection.
Used rotary vacuum dryers for sale: low-temperature drying for heat-sensitive materials
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Use this setting to include or exclude equipment with this feature.
Select one or more values to narrow the current listings.
Set a numeric threshold to narrow the matching listings.
Use this setting to include or exclude equipment with this feature.
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Showing 25 of 59 matching Rotary Vacuum Dryers.
Vacuum dryer system internal pressure rated -1/+1bar @ -10/+165 degrees C (volume 250 liter), jacket pressure rated -1/+8bar @ -10/+165 degrees C (volume 35 liter) type CD180M-4 3~/50Hz/230-400V/1,460rpm CE confirm, EExdeIICT4, system including: (1) 3.1m² 1.4571 stainless steel tube and shell heat exchanger/condenser, (1) 8m³/h @ 3m head iron cast centrifugal pump, (1) 50 liter 1.4571 stainless steel condensate receiver, (1) 20 liter 1.4571 stainless steel gas separator, (1) 17.5 liter 1.4571 stainless steel jacketed pressure tank, (1) Frequency converter on pallet, (2) stainless steel guards on pallet, (2) Valves and (1) chain on pallet, Accessories on pallet Jacket Temperature: 165 °C.
Jacketed rotary vacuum batch paddle dryer with static chopper blades Patent and designed by List DTB manufacturing #3000.01.01.01.3000, working pressure internal -1/6 bar @ 260 degrees C (11000 liter), jacket 6 bar @ 260 degrees C (511 liter), shaft 6 bar @ 260 degrees C (560 liter), bolt flat ends, 316Ti stainless steel (1.4571) half pipe coil jacket on straight side and both ends, paddle driven by a 110/112w, 3 phase, 50/60 Hz, 400-690/460 volt, 1488/1791 rpm, IP 55 siemens CE motor via a Flender 906/9.4 rpm reduction gearbox paddle speed 9.4 rpm openings top: 1-800mm (filter), 4-250mm, 4-150mm (product inlet), 2-150mm, 2-50mm, 4-50mm (jacket), side: 8-50mm (jacket), bottom: 1-150mm (center discharge), 1-80mm, 4-50mm, both flat ends: 2-50mm (jacket) dryer with dust filter, cyclone Dust Collection: Yes. Jacket Material: Stainless Steel Austenitic. Jacket Pressure: 6 bar. Jacket Temperature: 260 °C. Jacket Type: Half Pipe/Limpet.
jacketed rotary vacuum paddle dryer Internal design pressure: -1/6 bar @ -10/150 degrees C (10180 liter) Coil jacket: 6 bar @ -10/150 degrees C (500 liter) Rotor/paddle: 6 bar @ -10/150 degrees C (300 liter) (1) bolt flat end (drive), (1) clamped flat end, rotor/paddle with union joint and cored for steam heating, rotor/paddle driven by approx 100kw motor via a gearbox center bottom discharge Jacket Pressure: 6 bar. Jacket Temperature: 150 °C. Jacket Type: Half Pipe/Limpet.
dryer with
(1) (1) 150 liter 316L stainless steel pressure tank (jacket expansion tank), pressure -1/6 barg @ 185 degrees C,
(1) 316 stainless steel centrifugal pump, manufactured by Girdlestone, type 12CS3G, serial #53534, size 80-50-175, driven by 11kW, 3/50/415 volt, 2940 rpm EEx de IIB T4 motor, mounted on a baseplate, Dust Collection: Yes. Jacket Material: Stainless Steel 316L. Jacket Pressure: 10 bar. Jacket Temperature: 185 °C. Jacket Type: Half Pipe/Limpet.
jacketed rotary vacuum paddle dryer safe operating pressure of vessel atmospheric/vacuum 3000 liter with rotary union joint top mounted dust filter, bottom discharge with valve,
vacuum paddle dryer with dust filter and heated shaft Order number: 14.-235/24158/00000/2-2871/53 Internal pressure rating -1/+0,5 bar @ 151 degrees C operating temperature (total volume 11.000 liter) straight side jacket pressure rated 6 bar @ 151 degrees C (volume 340 liter) Serpentine (2) 1/2 pipe coil jackets each coil rated 6 bar @ 151 degrees C (volume 50 liter); heated shaft rated 6 bar @ 151 degrees C ( volume 1120 liter) (1) bolted for shaft removal; with 3 zone jacket on straight side and 1/2 pipe coil jacket on each head Agitator shaft is 600 mm diameter and has has paddle agitators with flat blades, mechanical seals, and a rotary joint on one end for heating the shaft. Driven through a shaft mounted gear reducer Bag filter mounted on top of dryer housing. Openings include: Top - (1) 1000 mm diameter opening for bag filter, (1) 600 mm feed opening, (1) 500 mm manway with cover; center bottom outlet, 340 mm ID / 420 mm OD With Titanium Grade 2 vertical jacketed dust filter, 10 m3 (353 cubic foot) and 18 cages for filters/ socks. 1000 mm diameter x 2400 mm high, with assist top cover for sock replacement Agitation Seal Type: Mechanical. Dust Collection: Yes. Jacket Pressure: 6 bar. Jacket Temperature: 151 °C. Jacket Type: Half Pipe/Limpet.
Drais Mannheim plow type Rotary Vacuum Dryer system with a dust collector Plow blades on mixing shaft and choppers mounted in side wallUnit has Carbon steel internalsWith an (6) choppers/homogenizers, each 7,5 Kw, 1500 rpm3/50/230/400 voltDryer includes: 42 square meter S316SS tube & Head, carbon steel shell horizontal vacuum condenser manufactured by Shin Meiwa Industry, Kobe Japan rated ).5 Bar @ 90 degrees C in the shell, 6 bar @ 42 degrees C in the tubes. A top mounted dust collector, a vacuum pump and control panel. Vertical dust collector has eight filters, each is 150mm diameter x 1500 mm long, estimate filter area at 46 m2 (504 sq.ft.). Jacket Temperature: 140 °C.
4' diameter x 10' long chamber. as 24" cored shaft with paddles and removable scrapers. No drive available. Unit has chain guards for drive. Top openings one 12", one 10 ". Jacket openings are 2" NPT. 12" bottom discharge.
Rotary vacuum dryer Vessel rated for Full vacuum 12.5" diameter cored shaft with 24 fixed plows. Outboard bearings with packing glands.
HSB # 3332A Shell rated full vacuum 4' diameter x 10' long chamber Has 24" diameter cored removable shaft with paddles and bolt-on scraper blades. 3" Johnson rotary joint. Has 12" diameter bottom outlet with hinged swing bolt cover. 2-12" feed ports.
Rotary Vacuum Dryer Contract # UD-24819 vacuum test pressure is 850 mbar jacket 3 bar, test pressure is 13 barg Approximately 3800 liter, weld dished heads 316 stainless steel internal ribbon Staffa model B270/P-TACHO hydraulic motor via a hydraulic power pack. power pack driven by a Rexroth pump, type IPV2V4-18/50RA01-MN160A1, Exd 11B T4 Openings include a center bottom discharge design code BS-5500 CAT 2
25 Liter Double Shaft Kneader Mixer with 1.4306 s/steel Double wall jacket internal -1/+0,5 bar hydraulic drive
design pressure internal 4 bar + full vacuum @ -29/180 degrees C (6615 liter),
jacket 10 bar + full vacuum @ -29/180 degrees C (220 liter),
shaft 10 bar + full vacuum @ -29/180 degrees C (220 liter),
shaft driven by 55kw 3/50/415 volt, EEx de IIB T4 ATEX motor via a reduction gearbox,
shaft speed 1.6/12 rpm,
shaft rotates counter clockwise for drying and clockwise for discharging,
shaft carbons steel with Hastelloy C22 lining,
center bottom discharge with screw conveyor,
clamped dished end for quick cleaning,
dryer with
(1) 3.5 square meter 316L stainless steel tube and shell heat exchanger (vent condenser),
(1) 150 liter 316L stainless steel pressure tank (jacket expansion tank), manufactured by Bendall's of Carlisle, pressure -1/6 barg @ 185 degrees, weld dished top and bottom, 457mm diameter x 900mm straight side, mounted on lugs
(1) stainless steel centrifugal pump Dust Collection: Yes. Jacket Material: Stainless Steel 316L. Jacket Pressure: 10 bar. Jacket Temperature: 180 °C. Jacket Type: Half Pipe/Limpet.
Rotary vacuum dryer CRN # H 9634.5 shell thickness .500,material SA 240/304 head thickness 1.00, head material SA 516-70 Sigle ribbon carbon steel mixer Driven by a Baldor AC motor through a gearbox 230/460 v, UL listed class 1 group D Drum measures 120" long x 51" w x 51" h. Agitation Seal Type: Packing. Jacket Pressure: 60 psi. Jacket Temperature: 250 °F.
vac dryer (cooler). 316SS shell Total capacity 0.72 cbm Shell 600mm (24") dia x 3.8m (12'6") long Has 18" dia removable cored rotor. Has 9" long scraper blades on shaft. Has (17) fixed delumpers on str side of vessel. Openings: top 2-24" w/bolt cover; btm 3-2", 2-8". Jacket Material: Stainless Steel 304. Jacket Pressure: 7 bar. Jacket Temperature: 50 °C.
304 stainless steel jacketed turbo dryer, water content of dry product @ 0.5% and a dry particle size of >420 microns capacity, gas fired, steam drum type, 304 stainless steel drum, carbon steel rotor with 304 stainless steel lining, 460 volt, 60Hz, 500 rpm turbine speed, operating pressure of drum is slightly below atmospheric @ 180/100 degrees C, jacket 10 bar g @ 175 degrees C, design pressure of jacket 12 bar g @ 220 degrees C, internal blades to keep product on the sidewall and to push product down the dryer, internal self cleaning is done via reverse rotation of the drum
(1) approx 90m3/hr 304 stainless steel blower/fan, manufactured by Chicago Blower, type MPC-2/18, 1.165 kg/m3 Density, 30 degrees C, 3480 rpm, driven by 15kW, 3/60/460 volt, motor
(1) Superheated air generator with gas burner, manufactured by Babcock Wanson, type Mixbloc 500, 500,000 kcal/h, 150-200 degrees C outlet temperature, 0-30 degrees Inlet temperature, 1150 Ncm/hr combustion air delivery, 3000/5000/6000 Ncm/hr min/nor/max primary air delivery, natural gas fired, 60Hz, 460 volt,
Rotary Vacuum Paddle Dryer with heated shaft. Vessel rated for Full vacuum internal 316SS internals, SS 1/2 pipe coil jacket. one head bolted dished, one head welded dished. Unit has approx. 12" diameter heated shaft with paddle agitator blades. Shaft is direct coupled to a gear reducer motor3/60/230/460 volt Openings inlcude: (1) 18" Top, (1) 12" x 16" end port with hinged cover, Bottom center discharge.
jacketed rotary vacuum dryer shaft 50 psi @ 300 degrees F (3) carbon steel jackets (1-straight side and 1-each end) Rotary union joint, outbaord bearings Openings: top (2) 3' x 18 1/2" hinged covers with counter balanced mechanism, 2-12"; end 1-8"; botttom 1-10" with manual open/close mechanism; jkt 4-6", 4-2", 4-1", 4-3/4"; shaft 1-2", 1-1 1/2" Jacket Pressure: 50 psi. Jacket Temperature: 300 °F.
jacketed rotary vacuum dryer 3/50/380 volt Cleveland 63-55:1 ratio 3.8 HP, 1750 rpm gearbox shaft cored for steam heating, no national board, rated 50 psi @ 300 degrees F (1-straight side and 1-each end) Rotary union joint, outboard bearings. Unit with dust collector. Openings: top (2) 3' x 18 1/2" hinged access covers with counter balanced mechanism, 2-12"; end 1-8"; bottom 1-10" with manual open/close mechanism; jacket 4-6", 4-2", 4-1", 4-3/4"; shaft 1-2", 1-1 1/2". Jacket Pressure: 50 psi. Jacket Temperature: 300 °F.
1.4541 (321SS) vacuum paddle jacket dryer system TUV standards Dryer rated full vacuum internal shell 5 bar @ 250 degree C shaft and paddles 5 bar @ 250 degree C heads 5 bar @ 250 degree C, dome 5 bar @ 250 degree C. Shaft 440mm diameter 5.0 KW, 3/50/220/380 volt Cored for heating/cooling with (16) cored paddles @ 1195mm diameter. Dryer has end discharge 400mm x 400mm with discharge valve assembly gear driven Jacket Material: Carbon Steel. Jacket Pressure: 72.5 psi. Jacket Temperature: 482 °F.
wetted parts ST37 (CS jacket) jacketed vacuum paddle dryer DN 21792 internal pressure -1/3 bar @ 250 degrees C, 6000 liter; Jacket pressure 10 bar @ 250°C, c/steel jacket. 419 mm diameter Openings include: top 3-400mm; bottom 1-310mm. Jacket Material: Carbon Steel. Jacket Pressure: 10 bar. Jacket Temperature: 250 °C.
design pressure internal -1/2 bar @ 165 degrees C (3150 liter), jacket 6 bar @ 165 degrees C (105 liter), shaft 6 bar @ 165 degrees C (800 liter), motor is Ex CE II 2G Ex de IIC T4 Gb ATEX, 1-bolt dished end and 1-weld dished end, 1.2m diameter x 8195mm overall length, shaft cored for heating with rotary union joint, Jacket Material: Stainless Steel 304. Jacket Pressure: 87 psi. Jacket Temperature: 329 °F. Jacket Type: Half Pipe/Limpet.
w/single ribbon type agit no int rating 32" dia x 8' long shell Bolt flat heads w/1-2" opening 16" dia charge port 12" dia center btm discharge No drive or motor
Designed to German TUV standards, With 1.4571 limpet coil jacket on straight side only, full vacuum internal, 20 bar on cored shaft Shaft volume 1000 liter. Shell 1600mm diameter x 4000mm long Shaft cored for heating/cooling Paddles are cored and equipped with scrapers. Openings: top 1-600mm, 1-400mm, 1-125mm, 2-40mm; 1-200mm center bottom outlet. With gear reducer Jacket Temperature: 200 °C. Jacket Type: Half Pipe/Limpet.
Rotary vacuum dryers are indirect batch dryers designed for efficient moisture removal under vacuum conditions. They’re ideal for temperature-sensitive products, solvent recovery, and materials that require precise control during drying. With over 47 years of experience, IPP offers a wide inventory of used, secondhand and surplus rotary vacuum dryers from 20 global plant sites and more than 15,000 ready-to-ship systems. These units combine heat transfer efficiency with controlled environments, helping manufacturers reduce drying times while protecting product quality.
The rotary motion improves contact between the material and the heated wall of the jacketed vessel. Combined with vacuum pressure, this design reduces the boiling point of moisture or solvents, making it ideal for thermally unstable or hazardous materials.
These dryers are designed for cleanability, corrosion resistance and precise thermal control:
Learn more about vacuum drying principles and equipment from Pharma Manufacturing.
Search the IPP inventory or contact IPP’s equipment experts to locate the ideal used, surplus or secondhand rotary vacuum dryer for your operation. IPP helps you save time and money with equipment that’s ready to ship and backed by decades of proven experience.
